T04: /home/russ/Documents/_GNSS_data/2026/SUMO-416_Static_Hex/20260427_South SUMO1

T0x Metadata

antenna_char_code : E
antenna_height : 0.0
firmware_date : 2026-03-06
fw_ver_boot : 25755
fw_ver_comm : 660
fw_ver_processor : 27
internal_name : STELLA
nav_proc_version : 27
product : BD1092i
serial_number : STELLA2C19
sig_proc_version : 660

Processing Metadata

app_version : gnss_hdf5 v0.1.1
processing_date : 2026-04-28T21:07:02Z
source_directory : /home/russ/Documents/_GNSS_data/2026/SUMO-416_Static_Hex/20260427_South/gnssdata/SUMO1
Start Time : 3
End Time : 136
SV Types : ['BeiDou' 'Galileo' 'GLONASS' 'GPS']
datum : ['WGS-84']
datum_epoch : [0]

Position Data

Fix Type Statistics

fix_type	fix_mode	fix_info	flags	count	Fix_Description
0	5	0	0x1:02x	1	Autonomous (Least Squares); 3D solution; Unknown fix_type 0 to get fix_info.
9	5	0	0x1:02x	132960	Autonomous (Kalman Filter); 3D solution; Unknown fix_type 9 to get fix_info.

Stats

antenna	w_mean_lat	w_mean_lon	w_mean_hgt	std_err	std_err_hprec	std_err_vprec	count	datum	datum_epoch
0	39.895509	-105.113387	1645.217113	2.191047	0.570888	1.137518	132961	WGS-84	0
1	39.895533	-105.113386	1641.819049	0.005041	0.003173	0.003965	132955	WGS-84	0

Uptime

Total Time	Valid Time
133199.0	133193.991012

Fix Summary

fix_type	count
0	1
9	132960

Flags Bit Table

Bit	Description
0	1 if this is the master position (i.e. record 29 position)
1	1 if the solution is a propagated solution (e.g. PM_FIX_20_HZ)
3	1 if reference station is sending moving base CMRs. Only b0 and b1 of "rtkMode" are defined in Record 29, in the rtk block "mode" field.
4	rtkMode bit 0: 0=synchronized rtk solution; 1=low-latency rtk solution;
5	rtkMode bit 1: 0=no canopy detected; 1= canopy detected;
6	1 if a baseline length constraint was used to form RTK vector.
7	1 if a clock constraint was used to form RTK vector.
8	1 if the RTK position is bridged
9	1 if the OmniSTAR position is authenticated

Individual Antennas

SNR Data

Intermediate Data File(s)

SUMO1_gnss.h5

SNR Statistics by Constellation

SVType	Freq	count	mean	std	min	max	slips	slips_above_20	dut
GPS	L1	3567466	42.775272	5.296487	0.000000	55.000000	60925	39	SUMO1
GPS	L2	2689737	35.353844	8.692672	12.600000	54.099998	736	30	SUMO1
GPS	L5-E5A	1842589	48.430901	4.717905	16.799999	58.400002	6283	18	SUMO1
GLONASS	L1	4360801	44.161324	5.014507	0.000000	54.599998	34133	69	SUMO1
GLONASS	L2	3570638	43.476093	4.512216	12.200000	53.200001	32980	756	SUMO1
Galileo	L1	2368008	44.040188	4.995883	0.000000	53.799999	17548	20	SUMO1
Galileo	E5A+B	2366329	50.133671	4.630919	16.299999	58.099998	5279	18	SUMO1
Galileo	E6	2316734	44.491714	5.492330	24.000000	53.400002	944	22	SUMO1
BeiDou	L1	2080075	43.613602	5.112609	15.100000	53.000000	25493	27	SUMO1
BeiDou	B1	2549621	43.885567	5.502049	0.000000	54.500000	39903	24	SUMO1
BeiDou	B3	2520377	44.521999	4.914508	18.600000	53.299999	1729	24	SUMO1
BeiDou	L5-E5A	2079338	46.917934	4.814897	15.500000	55.500000	10353	24	SUMO1
