T04: /home/russ/Documents/_GNSS_data/2026/SUMO-416_Static_Hex/20260427_South BX992

T0x Metadata

antenna_char_code : E
antenna_height : 0.0
firmware_date : 2025-09-02
fw_ver_boot : 573
fw_ver_comm : 583
fw_ver_processor : 643
nav_proc_version : 643
product : BX992-SPS
serial_number : 5824C03159
sig_proc_version : 583

Processing Metadata

app_version : gnss_hdf5 v0.1.1
processing_date : 2026-04-28T21:09:45Z
source_directory : /home/russ/Documents/_GNSS_data/2026/SUMO-416_Static_Hex/20260427_South/gnssdata/BX992
Start Time : 3
End Time : 136
SV Types : ['BeiDou' 'Galileo' 'GLONASS' 'GPS' 'SBAS']
datum : ['ITRF2020']
datum_epoch : [200500]

Position Data

Fix Type Statistics

fix_type	fix_mode	fix_info	flags	count	Fix_Description
15	5	2	0x17:02x	133200	RTx; 3D solution; HP

Stats

antenna	w_mean_lat	w_mean_lon	w_mean_hgt	std_err	std_err_hprec	std_err_vprec	count	datum	datum_epoch
0	39.896277	-105.112933	1646.101551	0.035875	0.008212	0.02056	133200	ITRF2020	200500

Uptime

Total Time	Valid Time
133199.0	133200.0

Fix Summary

fix_type	count
15	133200

Flags Bit Table

Bit	Description
0	1 if this is the master position (i.e. record 29 position)
1	1 if the solution is a propagated solution (e.g. PM_FIX_20_HZ)
3	1 if reference station is sending moving base CMRs. Only b0 and b1 of "rtkMode" are defined in Record 29, in the rtk block "mode" field.
4	rtkMode bit 0: 0=synchronized rtk solution; 1=low-latency rtk solution;
5	rtkMode bit 1: 0=no canopy detected; 1= canopy detected;
6	1 if a baseline length constraint was used to form RTK vector.
7	1 if a clock constraint was used to form RTK vector.
8	1 if the RTK position is bridged
9	1 if the OmniSTAR position is authenticated

Individual Antennas

SNR Data

Intermediate Data File(s)

BX992_gnss.h5

SNR Statistics by Constellation

SVType	Freq	count	mean	std	min	max	slips	slips_above_20	dut
GPS	L1	1695618	44.467667	5.014163	0.000000	54.700001	18103	1	BX992
GPS	L2	1304704	42.202248	6.562112	10.900000	53.000000	7310	1	BX992
GPS	L5-E5A	868087	47.939636	4.227581	18.000000	55.500000	3523	1	BX992
SBAS	L1	399600	44.954861	0.699237	39.900002	47.500000	0	0	BX992
SBAS	L5-E5A	399600	46.826782	0.651600	44.099998	49.299999	0	0	BX992
GLONASS	L1	2138586	44.857193	4.927795	0.000000	54.500000	19199	0	BX992
GLONASS	L2	1742976	43.981358	4.029984	1.000000	52.099998	12968	461	BX992
GLONASS	G3	104182	44.531029	4.084067	18.000000	51.500000	452	0	BX992
Galileo	L1	1146883	45.212399	4.673749	0.000000	53.299999	5640	1	BX992
Galileo	E5A+B	1146850	49.504436	4.174758	15.100000	55.799999	2953	0	BX992
Galileo	E6	1130949	44.811859	4.483539	24.600000	51.599998	163	0	BX992
Galileo	E5B-B2	1144873	46.417221	4.288507	16.700001	53.099998	4376	0	BX992
Galileo	L5-E5A	1145627	45.653656	4.302156	1.000000	52.099998	4243	0	BX992
BeiDou	L1	1024052	45.988712	4.862312	14.800000	53.799999	7250	0	BX992
BeiDou	B1	1243161	44.644299	5.184978	0.000000	53.400002	15784	0	BX992
BeiDou	B3	1228114	44.467964	4.044483	18.600000	51.500000	282	0	BX992
BeiDou	E5B-B2	1001587	43.647141	4.627324	25.299999	50.400002	1279	147	BX992
BeiDou	L5-E5A	1022567	46.287781	4.402019	16.000000	53.000000	5245	0	BX992
