T04: /home/russ/Documents/_GNSS_data/2026/SUMO-416_Static_Hex/20260425_East SUMO2

T0x Metadata

antenna_char_code : E
antenna_height : 0.0
firmware_date : 2026-03-06
fw_ver_boot : 25755
fw_ver_comm : 660
fw_ver_processor : 27
internal_name : STELLA
nav_proc_version : 27
product : BD1092i
serial_number : STELLA2C21
sig_proc_version : 660

Processing Metadata

app_version : gnss_hdf5 v0.1.1
processing_date : 2026-04-29T16:42:23Z
source_directory : /home/russ/Documents/_GNSS_data/2026/SUMO-416_Static_Hex/20260425_East/gnssdata/SUMO2
Start Time : 0
End Time : 604
SV Types : ['BeiDou' 'Galileo' 'GLONASS' 'GPS' 'SBAS']
datum : ['ITRF2020' 'WGS-84']
datum_epoch : [202631 0 202632]

Position Data

Fix Type Statistics

fix_type	fix_mode	fix_info	flags	count	Fix_Description
9	5	0	0x1:02x	57	Autonomous (Kalman Filter); 3D solution; Unknown fix_type 9 to get fix_info.
11	5	0	0x1:02x	31	SBAS corrected DGPS (Kalman Filter); 3D solution; Unknown fix_type 11 to get fix_info.
15	5	1	0x17:02x	98406	RTx; 3D solution; AM
26	5	1	0x1:02x	1	GVBS; 3D solution; Unknown fix_type 26 to get fix_info.

Stats

antenna	w_mean_lat	w_mean_lon	w_mean_hgt	std_err	std_err_hprec	std_err_vprec	count	datum	datum_epoch
0	39.895519	-105.113452	1645.705453	0.042736	0.026338	0.051176	98495	ITRF2020,WGS-84	202631,0,202632
1	39.895519	-105.113458	1645.186770	0.005771	0.002058	0.002972	98486	ITRF2020,WGS-84	202631,0,202632

Uptime

Total Time	Valid Time
604799.0	-503968.062765

Fix Summary

fix_type	count
9	57
11	31
15	98406
26	1

Flags Bit Table

Bit	Description
0	1 if this is the master position (i.e. record 29 position)
1	1 if the solution is a propagated solution (e.g. PM_FIX_20_HZ)
3	1 if reference station is sending moving base CMRs. Only b0 and b1 of "rtkMode" are defined in Record 29, in the rtk block "mode" field.
4	rtkMode bit 0: 0=synchronized rtk solution; 1=low-latency rtk solution;
5	rtkMode bit 1: 0=no canopy detected; 1= canopy detected;
6	1 if a baseline length constraint was used to form RTK vector.
7	1 if a clock constraint was used to form RTK vector.
8	1 if the RTK position is bridged
9	1 if the OmniSTAR position is authenticated

Individual Antennas

SNR Data

Intermediate Data File(s)

SUMO2_gnss.h5

SNR Statistics by Constellation

SVType	Freq	count	mean	std	min	max	slips	slips_above_20	dut
GPS	L1	2633315	43.423786	5.595862	0.000000	54.900002	46543	164	SUMO2
GPS	L2	3750913	39.692062	8.233892	10.900000	54.799999	13764	114	SUMO2
GPS	L5-E5A	1345155	48.489262	4.652084	17.500000	57.900002	4065	28	SUMO2
SBAS	L1	295427	45.020931	0.814613	39.700001	48.400002	9	9	SUMO2
SBAS	L5-E5A	295417	46.570293	0.704717	39.200001	51.099998	11	11	SUMO2
GLONASS	L1	3105737	44.353840	5.274976	0.000000	54.099998	28452	99	SUMO2
GLONASS	L2	2622650	44.131859	4.295645	12.900000	53.400002	15231	632	SUMO2
GLONASS	G3	118024	44.125301	4.654788	19.100000	53.099998	670	0	SUMO2
Galileo	L1	1816485	43.961887	5.270898	0.000000	53.799999	17516	64	SUMO2
Galileo	E5A+B	1820767	49.865364	4.759470	17.600000	57.700001	4822	42	SUMO2
Galileo	E6	1774252	44.565357	5.376873	22.200001	53.700001	860	45	SUMO2
Galileo	E5B-B2	1816945	46.423763	4.849265	7.000000	54.799999	8123	42	SUMO2
Galileo	L5-E5A	1818552	45.872082	4.768499	1.000000	54.500000	8175	42	SUMO2
BeiDou	L1	1496695	45.271664	5.334231	14.700000	54.299999	13508	47	SUMO2
BeiDou	B1	1813170	44.156406	5.780945	0.000000	54.000000	28581	1730	SUMO2
BeiDou	B3	1792906	45.120426	4.790970	18.299999	53.700001	1676	62	SUMO2
BeiDou	E5B-B2	1465782	44.337040	4.856731	21.700001	52.500000	1192	74	SUMO2
BeiDou	L5-E5A	1496847	47.222931	4.641651	17.000000	55.400002	5750	40	SUMO2
