T04: /home/russ/Documents/_GNSS_data/2026/SUMO-416_Static_Hex/20260425_East SUMO1

T0x Metadata


antenna_char_code : E
antenna_height : 0.0
firmware_date : 2026-03-06
fw_ver_boot : 25755
fw_ver_comm : 660
fw_ver_processor : 27
internal_name : STELLA
nav_proc_version : 27
product : BD1092i
serial_number : STELLA2C19
sig_proc_version : 660

Processing Metadata


app_version : gnss_hdf5 v0.1.1
processing_date : 2026-04-29T16:43:36Z
source_directory : /home/russ/Documents/_GNSS_data/2026/SUMO-416_Static_Hex/20260425_East/gnssdata/SUMO1
Start Time : 0
End Time : 604
SV Types : ['BeiDou' 'Galileo' 'GLONASS' 'GPS']
datum : ['WGS-84']
datum_epoch : [0]

Position Data

Fix Type Statistics

fix_type fix_mode fix_info flags count Fix_Description
0 5 0 0x1:02x 15 Autonomous (Least Squares); 3D solution; Unknown fix_type 0 to get fix_info.
9 5 0 0x1:02x 96846 Autonomous (Kalman Filter); 3D solution; Unknown fix_type 9 to get fix_info.

Stats


antenna w_mean_lat w_mean_lon w_mean_hgt std_err std_err_hprec std_err_vprec count datum datum_epoch
0 39.895521 -105.113410 1645.804320 2.567196 0.579113 1.134179 96861 WGS-84 0
1 39.895533 -105.113429 1642.536802 0.005879 0.002532 0.004126 96844 WGS-84 0

Uptime


Total Time Valid Time
604799.0 -507397.170803

Fix Summary

fix_type count
0 15
9 96846
Flags Bit Table
Bit Description
0 1 if this is the master position (i.e. record 29 position)
1 1 if the solution is a propagated solution (e.g. PM_FIX_20_HZ)
3 1 if reference station is sending moving base CMRs. Only b0 and b1 of "rtkMode" are defined in Record 29, in the rtk block "mode" field.
4 rtkMode bit 0: 0=synchronized rtk solution; 1=low-latency rtk solution;
5 rtkMode bit 1: 0=no canopy detected; 1= canopy detected;
6 1 if a baseline length constraint was used to form RTK vector.
7 1 if a clock constraint was used to form RTK vector.
8 1 if the RTK position is bridged
9 1 if the OmniSTAR position is authenticated

Individual Antennas

SNR Data

Intermediate Data File(s)

SUMO1_gnss.h5

SNR Statistics by Constellation

SVType Freq count mean std min max slips slips_above_20 dut
GPS L1 2580621 42.835545 5.395863 0.000000 54.500000 49464 36 SUMO1
GPS L2 1928258 35.573963 8.443580 12.600000 54.099998 770 24 SUMO1
GPS L5-E5A 1321401 48.400974 4.768968 17.100000 58.299999 4080 12 SUMO1
GLONASS L1 3052670 44.506142 5.016757 0.000000 54.099998 22599 47 SUMO1
GLONASS L2 2574249 43.731251 4.383593 10.600000 52.900002 19154 387 SUMO1
Galileo L1 1784438 43.798790 5.036425 0.000000 53.900002 16478 30 SUMO1
Galileo E5A+B 1783151 49.824562 4.744457 14.100000 58.000000 4739 30 SUMO1
Galileo E6 1733152 44.395348 5.367037 21.299999 53.799999 770 34 SUMO1
BeiDou L1 1477612 43.950077 5.150419 15.500000 53.200001 17108 15 SUMO1
BeiDou B1 1791911 44.220612 5.595753 0.000000 54.099998 27333 18 SUMO1
BeiDou B3 1773163 44.831543 4.905824 18.600000 53.700001 1264 18 SUMO1
BeiDou L5-E5A 1477404 47.121593 4.708619 16.200001 55.700001 5868 14 SUMO1

SNR Plots

Delta Phase Data

Delta Phase Plots

AGC Data

AGC Plots

FFT Data

Stinger Average

Pre-Mitigation (SP1) - Contour Plots

Antenna L1 L2 L5 E6 B1 S1 G1
Ant 0 - - -
Ant 1 - - -

Pre-Mitigation (SP1) - Mean Spectrum Plots

Antenna L1 L2 L5 E6 B1 S1 G1
Ant 0 - - -
Ant 1 - - -

Post-Mitigation (SP2) - Contour Plots

Antenna L1 L2 L5 E6 B1 S1 G1
Ant 0 - - -
Ant 1 - - -

Post-Mitigation (SP2) - Mean Spectrum Plots

Antenna L1 L2 L5 E6 B1 S1 G1
Ant 0 - - -
Ant 1 - - -

MSS FFT (60s mean, rec35:38)
