T04: /home/russ/Documents/_GNSS_data/2025/CSNMR-4325_Terrasat_Gaps/20250701 MP1086Line

Meta Data


Start : 2373 241176.0
Stop : 2373 259200.0
Number Samples : 18025
Input Source : T04
Total Time: 18024.0 seconds = 5.007 hours

pos_ant.csv

Heading, Antenna distance

Weighted Mean heading_mean: 264.7813
Weighted Mean dist_mean: 0.0770
Weighted Mean ant_list: [0, 1]
Weighted Mean hprec: 0.0249
Weighted Mean vprec: 0.0350
Weighted Mean vdiff_mean: -0.0019
Weighted Mean heading_uptime: 0.0000

Stats


antenna w_mean_lat w_mean_lon w_mean_hgt std_err std_err_hprec std_err_vprec count datum datum_epoch
0 39.896468 -105.115028 1668.465924 0.035893 0.019686 0.038633 18025 WGS-84 0
1 39.896468 -105.115027 1668.467777 0.017509 0.002516 0.003400 18024 WGS-84 0
ref 39.882762 -105.078564 1648.692215 7.448389 NaN NaN 18025 WGS-84 0

Uptime


antenna limit h_uptime v_uptime hv_uptime
0 0.03 0.999667 0.999667 0.999667
0 0.05 0.999667 0.999667 0.999667
0 0.10 0.999667 0.999667 0.999667
1 0.03 0.999889 0.999889 0.999889
1 0.05 0.999889 0.999889 0.999889
1 0.10 0.999889 0.999889 0.999889

Fix Summary

VSysFlgs MFixType MFixMode MFixInfo MSysFlgs count Fix_Description Ant VFixType VFixMode VFixInfo
NaN 4.0 5.0 0.0 0x17:02x 18019 RTK fixed; 3D solution; Min error 0 NaN NaN NaN
NaN 9.0 5.0 0.0 0x1:02x 6 Autonomous (Kalman Filter); 3D solution; Unknown fix_type 9 to get fix_info. 0 NaN NaN NaN
0x0.0:02x NaN NaN NaN NaN 18024 RTK fixed; 3D solution; Unknown fix_info RTK value 10.0. 1 4.0 5.0 10.0
Flags Bit Table
Bit Description
0 1 if this is the master position (i.e. record 29 position)
1 1 if the solution is a propagated solution (e.g. PM_FIX_20_HZ)
3 1 if reference station is sending moving base CMRs. Only b0 and b1 of "rtkMode" are defined in Record 29, in the rtk block "mode" field.
4 rtkMode bit 0: 0=synchronized rtk solution; 1=low-latency rtk solution;
5 rtkMode bit 1: 0=no canopy detected; 1= canopy detected;
6 1 if a baseline length constraint was used to form RTK vector.
7 1 if a clock constraint was used to form RTK vector.
8 1 if the RTK position is bridged
9 1 if the OmniSTAR position is authenticated

Individual Antennas
