240918_el0 BX992_all.T04

Meta Data


Serial Number : 6221C43829
Firmware Date : Aug 8, 2024
Release Ver : 5.70
Nav Proc Ver : 0.53
Radio Lib Ver : None
Primary Antenna Type : P5
Primary Antenna Height : 0.0000 m
Secondary Antenna Type : P5
Secondary Antenna Height : 0.0000 m
week_list : ['2332']
Start Time : 322610.0
Stop Time : 330252.9
Total Hours : 2.122175833333345
Total Time: 7642.900000000023 seconds = 2.123 hours

BX992_d35-2.tsv

Heading, Antenna distance

Weighted Mean heading_mean: 215.0297
Weighted Mean dist_mean: 1.0914
Weighted Mean ant_list: [0, 1]
Weighted Mean hprec: 0.8219
Weighted Mean vprec: 1.3214
Weighted Mean vdiff_mean: 1.5031
Weighted Mean heading_uptime: 0.0000

Stats


antenna w_mean_lat w_mean_lon w_mean_hgt std_err std_err_hprec std_err_vprec count
0 39.89584851031925 -105.11318930188720 1643.53216303162230 3.18628881346941 0.58111156756389 1.32143055126828 76430
1 39.89585654726729 -105.11318195874328 1642.02909413454518 0.00881928835401 0.00582796882233 0.00551446924540 76430

Uptime


antenna limit h_uptime v_uptime hv_uptime
0 0.03 0.000000 0.0 0.000000
0 0.05 0.000000 0.0 0.000000
0 0.10 0.000000 0.0 0.000000
1 0.03 0.997645 1.0 0.997645
1 0.05 1.000000 1.0 1.000000
1 0.10 1.000000 1.0 1.000000

Fix Summary

VSysFlgs MFixType MFixMode MFixInfo MSysFlgs count Fix_Description Ant VFixType VFixMode VFixInfo
NaN 11.0 5.0 0.0 0x1:02x 76430 SBAS corrected DGPS (Kalman Filter); 3D solution; Unknown fix_type 11 to get fix_info. 0 NaN NaN NaN
0x0:02x NaN NaN NaN NaN 5930 RTK float; 3D solution; Unknown fix_info RTK value 10. 1 3.0 5.0 10.0
0x0:02x NaN NaN NaN NaN 70500 RTK fixed; 3D solution; Unknown fix_info RTK value 10. 1 4.0 5.0 10.0
Flags Bit Table
Bit Description
0 1 if this is the master position (i.e. record 29 position)
1 1 if the solution is a propagated solution (e.g. PM_FIX_20_HZ)
3 1 if reference station is sending moving base CMRs. Only b0 and b1 of "rtkMode" are defined in Record 29, in the rtk block "mode" field.
4 rtkMode bit 0: 0=synchronized rtk solution; 1=low-latency rtk solution;
5 rtkMode bit 1: 0=no canopy detected; 1= canopy detected;
6 1 if a baseline length constraint was used to form RTK vector.
7 1 if a clock constraint was used to form RTK vector.
8 1 if the RTK position is bridged
9 1 if the OmniSTAR position is authenticated

Individual Antennas
