REF File: ./BX_all.T04
DUT File: ./EB93_all.T04

Ref Statistics

DUT Statistics

Difference Statistics
SVType Freq Track N_Samples CNo_Mean CNo_Median CNo_Std CNo_Min CNo_Max CNo_Range El_Mean El_Max
GPS L1 BOC-PD 5234 48.8 49.0 1.0 45.1 51.1 6.0 69.2 75.0
GPS L1 CA 25552 41.1 42.6 6.1 10.9 50.9 40.0 32.6 75.0
GPS L2 CM+CL 20398 41.6 42.3 5.1 18.5 49.8 31.3 37.1 75.0
GPS L2 E 2985 19.9 19.6 2.9 13.9 29.5 15.6 15.4 26.0
GPS L5/E5A I+Q 14446 47.9 48.4 4.4 23.3 54.8 31.5 39.5 75.0
SBAS L1 CA 7826 44.7 44.7 1.4 24.6 47.9 23.3 39.7 42.0
GLONASS L1 CA 14097 44.4 48.5 6.7 0.0 53.2 53.2 48.4 74.0
GLONASS L2 CA 10131 43.1 44.6 3.9 13.1 47.3 34.2 49.8 74.0
GLONASS L2 P 10106 41.7 43.3 3.9 15.6 45.9 30.3 49.9 73.0
GLONASS G3 PD 2617 47.4 47.3 0.6 44.7 49.7 5.0 62.2 70.0
Galileo L1 MBOC-PD 19455 44.5 45.2 5.0 12.0 52.2 40.2 37.9 75.0
Galileo L5/E5A BPSK(10)-PD 19455 45.5 46.5 3.5 27.2 51.2 24.0 37.9 75.0
Galileo E5B/B2 BPSK(10)-PD 19454 45.2 46.0 3.5 22.7 51.1 28.4 37.9 75.0
Galileo E5A+B AltBOC-Comp-PD 19455 48.4 49.3 3.1 26.2 54.6 28.4 37.9 75.0
Galileo E6 BPSK(5)-PD 19350 47.2 47.8 4.6 23.5 54.4 30.9 38.0 75.0
BeiDou L1 BOC-PD 15700 45.7 45.5 3.8 22.4 51.7 29.3 48.6 89.0
BeiDou L5/E5A I+Q 15702 47.0 46.9 3.0 22.5 52.8 30.3 48.6 89.0
BeiDou E5B/B2 I 15686 43.2 43.5 3.7 23.9 49.4 25.5 48.7 89.0
BeiDou B1 BPSK(2)-B1 15702 45.6 46.0 3.6 27.3 51.5 24.2 48.6 89.0
BeiDou B3 BPSK(10)-B3 15690 44.7 44.8 2.2 27.9 50.0 22.1 48.7 89.0
MSS MSS None 1845 50.1 50.4 1.3 36.1 52.2 16.1 NaN NaN
start/stop time: 152,183 154,799
Total time: 2,616.0 seconds
Total time: 43.600 minutes
Total Samples: 290,886
Avg Samples/sec: 111.2

Serial Number : 6402C12585
Firmware Date : May 23, 2024
Release Ver : 5.70
Nav Proc Ver : 0.50
Radio Lib Ver : None
Primary Antenna Type : E
Primary Antenna Height : 0.0000 m
Secondary Antenna Type : E
Secondary Antenna Height : 0.0000 m
week_list : ['2325']
Start Time : 152183.095
Stop Time : 153900.14
Total Hours : 0.476956944444448
SVType Freq Track N_Samples CNo_Mean CNo_Median CNo_Std CNo_Min CNo_Max CNo_Range El_Mean El_Max
GPS L1 CA 28704 40.5 40.8 5.9 0.0 51.0 51.0 29.4 75.0
GPS L2 CM+CL 23154 39.3 39.9 5.0 16.3 47.5 31.2 33.1 75.0
GPS L2 E 2144 20.1 19.9 3.1 12.6 30.4 17.8 17.4 26.0
GPS L5/E5A I+Q 16493 44.4 44.9 4.8 18.2 52.3 34.1 35.0 75.0
SBAS L1 CA 7809 43.8 43.9 2.7 28.6 49.5 20.9 39.7 42.0
SBAS L5/E5A I 7809 43.5 43.4 1.4 26.7 46.5 19.8 39.7 42.0
GLONASS L1 CA 15867 41.4 43.9 7.3 0.0 51.7 51.7 43.6 74.0
GLONASS L1 P 14989 41.1 43.7 5.9 15.2 50.5 35.3 45.7 74.0
GLONASS L2 CA 12134 39.6 41.8 5.2 12.5 46.0 33.5 42.7 73.0
GLONASS L2 P 11777 38.1 40.4 5.3 13.0 44.5 31.5 43.8 73.0
GLONASS G3 PD 2605 45.1 45.1 0.8 41.8 48.3 6.5 62.1 70.0
Galileo L1 MBOC-PD 20670 43.7 44.2 4.9 0.0 51.3 51.3 35.8 75.0
Galileo L5/E5A BPSK(10)-PD 20614 42.1 43.4 4.0 21.8 48.0 26.2 35.9 75.0
Galileo E5B/B2 BPSK(10)-PD 20611 41.8 42.7 4.2 20.9 48.5 27.6 35.9 75.0
Galileo E5A+B AltBOC-Comp-PD 20615 44.8 45.7 3.5 24.0 50.5 26.5 35.9 75.0
Galileo E6 BPSK(5)-PD 20400 43.3 43.9 5.6 21.8 52.2 30.4 36.2 75.0
BeiDou L5/E5A I+Q 16639 43.3 44.0 4.0 14.6 48.9 34.3 45.9 89.0
BeiDou E5B/B2 I 15792 40.4 41.3 3.8 23.9 45.7 21.8 48.0 89.0
BeiDou B1 BPSK(2)-B1 16687 45.4 47.2 5.0 12.8 51.9 39.1 45.8 89.0
BeiDou B3 BPSK(10)-B3 16365 42.1 42.6 3.7 19.6 47.9 28.3 46.5 89.0
start/stop time: 152,191 154,799
Total time: 2,608.0 seconds
Total time: 43.467 minutes
Total Samples: 311,878
Avg Samples/sec: 119.6

Serial Number : 6348C01838
Firmware Date : May 23, 2024
Release Ver : 5.70
Nav Proc Ver : 0.50
Radio Lib Ver : None
Primary Antenna Type : -1
Primary Antenna Height : 0.0000 m
Secondary Antenna Type : -1
Secondary Antenna Height : 0.0000 m
week_list : ['2325']
Start Time : 152191.108
Stop Time : 153900.286
Total Hours : 0.4747716666666626
SVType Freq Track N_Samples CNo_Mean CNo_Median CNo_Std CNo_Min CNo_Max CNo_Range El_Mean El_Max
GPS L1 CA 25396 -0.2 +0.3 +3.6 -25.7 +29.5 +55.2 +32.6 +75.0
GPS L2 CM+CL 20232 +1.4 +1.5 +2.4 -13.3 +17.6 +30.9 +37.1 +75.0
GPS L2 E 1777 -0.9 -1.2 +3.2 -8.3 +8.4 +16.7 +17.8 +26.0
GPS L5/E5A I+Q 14386 +2.5 +2.5 +2.5 -11.7 +19.8 +31.5 +39.5 +75.0
SBAS L1 CA 7790 +0.9 +0.2 +3.4 -14.2 +12.3 +26.5 +39.7 +42.0
GLONASS L1 CA 13552 +1.7 +1.8 +2.4 -28.9 +32.1 +61.0 +49.8 +74.0
GLONASS L2 CA 10021 +1.8 +1.7 +1.9 -10.3 +12.4 +22.7 +50.1 +73.0
GLONASS L2 P 9999 +2.1 +1.9 +1.8 -8.5 +23.6 +32.1 +50.2 +73.0
GLONASS G3 PD 2605 +2.2 +2.4 +0.9 -1.9 +4.7 +6.6 +62.1 +70.0
Galileo L1 MBOC-PD 19359 +0.2 +0.6 +3.0 -23.8 +23.3 +47.1 +37.9 +75.0
Galileo L5/E5A BPSK(10)-PD 19358 +3.0 +2.9 +2.8 -10.2 +19.9 +30.1 +37.9 +75.0
Galileo E5B/B2 BPSK(10)-PD 19354 +3.0 +2.6 +2.6 -15.7 +20.3 +36.0 +37.9 +75.0
Galileo E5A+B AltBOC-Comp-PD 19359 +3.3 +3.1 +2.1 -13.3 +18.6 +31.9 +37.9 +75.0
Galileo E6 BPSK(5)-PD 19194 +3.3 +3.2 +3.4 -12.8 +20.0 +32.8 +38.1 +75.0
BeiDou L5/E5A I+Q 15630 +2.9 +3.2 +1.9 -15.5 +13.4 +28.9 +48.6 +89.0
BeiDou E5B/B2 I 15501 +2.7 +2.7 +2.4 -8.2 +12.6 +20.8 +48.8 +89.0
BeiDou B1 BPSK(2)-B1 15630 -0.4 -0.4 +3.0 -10.6 +16.6 +27.2 +48.6 +89.0
BeiDou B3 BPSK(10)-B3 15548 +2.3 +1.9 +2.3 -7.6 +20.9 +28.5 +48.7 +89.0
start/stop time: 152,191 154,799
Total time: 2,608.0 seconds
Total time: 43.467 minutes
Total Samples: 264,691
Avg Samples/sec: 101.5

Statistics for full C/No Observations dataset
(df_ref - df_dut => positive numbers mean DUT is worse)
Mean = 1.861
Median = 2.000
Std Dev= 2.992

Plots


REF GPS L1(CA)

SV AvgEl AvgOffset AvgCNo MaxCNo MinCNo Slip_Count SVChan Ant N_Samples
5 9.2 0.0 34.7 43.5 22.5 54 [20.0] [0.0] 824
10 33.3 0.0 44.1 48.0 39.4 0 [21.0] [0.0] 2617
13 19.1 0.0 35.6 45.1 13.7 259 [7.0] [0.0] 2617
15 47.5 0.0 47.0 50.6 41.3 0 [17.0] [0.0] 2617
16 10.6 0.0 34.5 41.8 17.8 39 [37.0] [0.0] 2431
18 73.2 0.0 48.2 50.9 44.2 0 [10.0] [0.0] 2617
23 65.2 0.0 47.4 49.4 42.2 0 [11.0] [0.0] 2617
24 16.1 0.0 34.1 40.5 10.9 208 [27.0] [0.0] 2617
27 24.3 0.0 41.7 46.6 31.0 1 [28.0] [0.0] 2617
29 20.9 0.0 39.2 46.8 19.0 173 [29.0] [0.0] 2617
32 11.9 0.0 40.6 45.5 19.9 36 [35.0] [0.0] 1361
DUT GPS L1(CA)

SV AvgEl AvgOffset AvgCNo MaxCNo MinCNo Slip_Count SVChan Ant N_Samples
5 6.7 0.0 35.0 44.8 0.0 374 [19.0] [0.0] 1731
8 4.0 0.0 34.1 41.3 14.8 92 [37.0] [0.0] 431
10 33.3 0.0 43.6 50.2 34.3 152 [20.0] [0.0] 2605
13 19.1 0.0 40.0 47.8 16.9 241 [7.0] [0.0] 2605
15 47.5 0.0 47.4 51.0 39.4 130 [16.0] [0.0] 2605
16 10.3 0.0 35.1 44.4 21.2 252 [30.0] [0.0] 2605
18 73.2 0.0 47.1 50.9 44.3 245 [10.0] [0.0] 2605
23 65.2 0.0 46.5 49.5 43.0 36 [11.0] [0.0] 2605
24 16.1 0.0 36.4 42.7 0.0 153 [27.0] [0.0] 2565
26 4.3 0.0 32.5 44.1 0.0 260 [31.0] [0.0] 910
27 24.3 0.0 39.5 47.5 29.5 203 [28.0] [0.0] 2605
29 20.8 0.0 38.0 48.4 14.6 495 [29.0] [0.0] 2605
32 9.0 0.0 39.0 48.2 20.9 333 [18.0] [0.0] 2227
DIFF GPS L1(CA)

SV AvgEl AvgCNoDiff MaxCNoDiff MinCNoDiff SVChan N_Samples
5 9.1 -2.7 23.5 -11.0 [20.0, 19.0] 816
10 33.3 0.5 10.5 -5.1 [21.0, 20.0] 2605
13 19.1 -4.4 16.3 -25.7 [7.0] 2605
15 47.5 -0.4 8.4 -4.7 [17.0, 16.0] 2605
16 10.6 -0.7 10.9 -15.0 [37.0, 30.0] 2419
18 73.2 1.1 4.8 -3.0 [10.0] 2605
23 65.2 0.9 4.2 -3.7 [11.0] 2605
24 16.1 -2.2 29.5 -17.0 [27.0] 2565
27 24.3 2.2 13.0 -7.9 [28.0] 2605
29 20.8 1.1 19.4 -14.6 [29.0] 2605
32 11.9 0.9 11.7 -19.2 [35.0, 18.0] 1361
REF GPS L1(BOC-PD)

SV AvgEl AvgOffset AvgCNo MaxCNo MinCNo Slip_Count SVChan Ant N_Samples
18 73.2 0.0 49.1 51.1 47.0 0 [10.0] [0.0] 2617
23 65.2 0.0 48.5 50.0 45.1 0 [11.0] [0.0] 2617
DUT GPS L1(BOC-PD)
DIFF GPS L1(BOC-PD)
REF GPS L2(E)

SV AvgEl AvgOffset AvgCNo MaxCNo MinCNo Slip_Count SVChan Ant N_Samples
13 19.4 0.0 20.3 29.5 13.9 16 [7.0] [0.0] 1646
16 10.6 0.0 19.4 26.0 13.9 22 [37.0] [0.0] 1339
DUT GPS L2(E)

SV AvgEl AvgOffset AvgCNo MaxCNo MinCNo Slip_Count SVChan Ant N_Samples
13 19.8 0.0 21.2 30.4 13.9 187 [7.0] [0.0] 1571
16 10.6 0.0 17.0 24.4 12.6 82 [30.0] [0.0] 573
DIFF GPS L2(E)

SV AvgEl AvgCNoDiff MaxCNoDiff MinCNoDiff SVChan N_Samples
13 19.7 -1.5 8.4 -8.3 [7.0] 1400
16 10.8 1.5 8.2 -6.7 [37.0, 30.0] 377
REF GPS L2(CM+CL)

SV AvgEl AvgOffset AvgCNo MaxCNo MinCNo Slip_Count SVChan Ant N_Samples
5 9.2 0.0 34.7 44.3 24.6 25 [20.0] [0.0] 824
10 33.3 0.0 42.3 44.7 36.6 0 [21.0] [0.0] 2617
15 47.5 0.0 43.9 46.6 37.6 0 [17.0] [0.0] 2617
18 73.2 0.0 48.3 49.8 45.8 0 [10.0] [0.0] 2617
23 65.2 0.0 47.0 48.3 43.6 0 [11.0] [0.0] 2617
24 16.1 0.0 37.3 43.2 20.9 61 [27.0] [0.0] 2617
27 24.3 0.0 40.8 45.4 30.3 2 [28.0] [0.0] 2617
29 21.1 0.0 36.0 43.5 18.5 463 [29.0] [0.0] 2511
32 11.9 0.0 36.8 43.1 23.0 7 [35.0] [0.0] 1361
DUT GPS L2(CM+CL)

SV AvgEl AvgOffset AvgCNo MaxCNo MinCNo Slip_Count SVChan Ant N_Samples
5 7.0 0.0 32.6 41.6 17.7 235 [19.0] [0.0] 1611
8 4.0 0.0 34.8 39.7 27.4 3 [37.0] [0.0] 431
10 33.3 0.0 40.6 43.5 34.4 170 [20.0] [0.0] 2605
15 47.5 0.0 42.6 45.3 35.8 44 [16.0] [0.0] 2605
18 73.2 0.0 45.5 47.5 43.2 212 [10.0] [0.0] 2605
23 65.2 0.0 44.9 46.9 42.1 152 [11.0] [0.0] 2605
24 16.1 0.0 35.8 42.1 16.7 301 [27.0] [0.0] 2583
26 4.5 0.0 32.5 38.8 19.4 110 [31.0] [0.0] 784
27 24.3 0.0 39.2 44.3 25.3 182 [28.0] [0.0] 2605
29 21.0 0.0 36.3 42.7 19.0 613 [29.0] [0.0] 2554
32 9.1 0.0 35.9 42.9 16.3 326 [18.0] [0.0] 2166
DIFF GPS L2(CM+CL)

SV AvgEl AvgCNoDiff MaxCNoDiff MinCNoDiff SVChan N_Samples
5 9.1 1.0 14.0 -7.1 [20.0, 19.0] 815
10 33.3 1.6 8.5 -5.9 [21.0, 20.0] 2605
15 47.5 1.3 8.5 -2.5 [17.0, 16.0] 2605
18 73.2 2.8 5.4 0.1 [10.0] 2605
23 65.2 2.0 4.7 -2.2 [11.0] 2605
24 16.1 1.5 14.8 -9.3 [27.0] 2583
27 24.3 1.6 17.6 -6.1 [28.0] 2605
29 21.3 -0.5 11.6 -13.3 [29.0] 2448
32 11.9 -0.4 7.1 -10.6 [35.0, 18.0] 1361
REF GPS L5/E5A(I+Q)

SV AvgEl AvgOffset AvgCNo MaxCNo MinCNo Slip_Count SVChan Ant N_Samples
10 33.3 0.0 47.5 51.3 41.1 0 [21.0] [0.0] 2617
18 73.2 0.0 53.0 54.8 51.1 0 [10.0] [0.0] 2617
23 65.2 0.0 51.8 53.4 48.2 0 [11.0] [0.0] 2617
24 16.1 0.0 43.8 48.3 23.3 26 [27.0] [0.0] 2617
27 24.3 0.0 47.4 51.8 37.7 0 [28.0] [0.0] 2617
32 11.9 0.0 40.6 46.3 30.9 1 [35.0] [0.0] 1361
DUT GPS L5/E5A(I+Q)

SV AvgEl AvgOffset AvgCNo MaxCNo MinCNo Slip_Count SVChan Ant N_Samples
8 4.0 0.0 38.6 43.7 27.9 1 [37.0] [0.0] 431
10 33.3 0.0 45.3 49.3 39.5 211 [20.0] [0.0] 2605
18 73.2 0.0 49.8 52.3 47.3 178 [10.0] [0.0] 2605
23 65.2 0.0 49.0 51.5 45.7 239 [11.0] [0.0] 2605
24 16.1 0.0 41.7 46.4 22.6 281 [27.0] [0.0] 2605
26 4.5 0.0 38.6 44.7 22.1 32 [31.0] [0.0] 811
27 24.3 0.0 44.0 49.2 34.7 115 [28.0] [0.0] 2605
32 9.0 0.0 38.4 45.2 18.2 99 [18.0] [0.0] 2226
DIFF GPS L5/E5A(I+Q)

SV AvgEl AvgCNoDiff MaxCNoDiff MinCNoDiff SVChan N_Samples
10 33.3 2.2 8.4 -5.1 [21.0, 20.0] 2605
18 73.2 3.2 6.4 -0.4 [10.0] 2605
23 65.2 2.8 5.6 -1.8 [11.0] 2605
24 16.1 2.2 19.8 -11.7 [27.0] 2605
27 24.3 3.4 16.0 -5.4 [28.0] 2605
32 11.9 0.6 8.8 -8.3 [35.0, 18.0] 1361
REF SBAS L1(CA)

SV AvgEl AvgOffset AvgCNo MaxCNo MinCNo Slip_Count SVChan Ant N_Samples
131 42.0 0.0 44.6 47.9 27.3 0 [57.0] [0.0] 2617
133 38.0 0.0 44.7 47.6 29.6 2 [56.0] [0.0] 2598
135 39.0 0.0 44.8 47.3 24.6 2 [55.0] [0.0] 2611
DUT SBAS L1(CA)

SV AvgEl AvgOffset AvgCNo MaxCNo MinCNo Slip_Count SVChan Ant N_Samples
131 42.0 0.0 45.3 49.5 28.6 206 [57.0] [0.0] 2605
133 38.0 0.0 42.7 48.4 31.5 210 [55.0] [0.0] 2599
135 39.0 0.0 43.4 48.9 29.1 83 [56.0] [0.0] 2605
DIFF SBAS L1(CA)

SV AvgEl AvgCNoDiff MaxCNoDiff MinCNoDiff SVChan N_Samples
131 42.0 -0.8 8.0 -6.8 [57.0] 2605
133 38.0 1.9 8.7 -12.0 [56.0, 55.0] 2586
135 39.0 1.5 12.3 -14.2 [55.0, 56.0] 2599
REF SBAS L5/E5A(I)
DUT SBAS L5/E5A(I)

SV AvgEl AvgOffset AvgCNo MaxCNo MinCNo Slip_Count SVChan Ant N_Samples
131 42.0 0.0 44.3 46.5 30.8 254 [57.0] [0.0] 2605
133 38.0 0.0 42.8 46.2 26.7 128 [55.0] [0.0] 2599
135 39.0 0.0 43.3 46.0 30.5 154 [56.0] [0.0] 2605
DIFF SBAS L5/E5A(I)
REF GLONASS L1(CA)

SV AvgEl AvgOffset AvgCNo MaxCNo MinCNo Slip_Count FDMA Ant N_Samples
5 8.2 0.0 27.7 38.5 0.0 235 [1.0] [0.0] 385
6 61.9 0.0 37.4 40.1 34.1 0 [-4.0] [0.0] 2617
7 62.4 0.0 49.7 51.7 42.9 0 [5.0] [0.0] 2617
8 15.4 0.0 40.8 46.4 18.1 72 [6.0] [0.0] 2132
21 62.2 0.0 49.2 51.7 46.9 0 [4.0] [0.0] 2617
22 55.3 0.0 50.1 53.2 45.7 0 [-3.0] [0.0] 2617
23 12.5 0.0 36.5 43.5 20.2 127 [3.0] [0.0] 1112
DUT GLONASS L1(CA)

SV AvgEl AvgOffset AvgCNo MaxCNo MinCNo Slip_Count FDMA Ant N_Samples
5 6.2 0.0 32.2 45.4 0.0 266 [1.0] [0.0] 775
6 61.9 0.0 36.1 38.9 30.7 27 [-4.0] [0.0] 2605
7 62.5 0.0 46.2 50.2 40.6 175 [5.0] [0.0] 2605
8 13.6 0.0 40.7 45.8 16.8 326 [6.0] [0.0] 2605
20 8.6 0.0 26.6 34.4 0.0 1266 [2.0] [0.0] 1375
21 62.1 0.0 47.2 50.0 43.9 197 [4.0] [0.0] 2605
22 55.3 0.0 47.9 51.7 44.3 161 [-3.0] [0.0] 2605
23 14.1 0.0 38.9 42.6 23.3 4 [3.0] [0.0] 692
DIFF GLONASS L1(CA)

SV AvgEl AvgCNoDiff MaxCNoDiff MinCNoDiff FDMA N_Samples
5 8.2 -3.7 32.1 -28.9 [1.0] 312
6 61.9 1.3 7.4 -2.1 [-4.0] 2605
7 62.5 3.5 6.9 -2.6 [5.0] 2605
8 15.4 0.0 14.5 -17.5 [6.0] 2128
21 62.1 2.0 5.6 -2.0 [4.0] 2605
22 55.3 2.2 7.0 -3.0 [-3.0] 2605
23 14.1 0.7 14.3 -4.5 [3.0] 692
REF GLONASS L1(P)
DUT GLONASS L1(P)

SV AvgEl AvgOffset AvgCNo MaxCNo MinCNo Slip_Count FDMA Ant N_Samples
5 7.0 0.0 33.7 43.6 15.2 199 [1.0] [0.0] 660
6 61.9 0.0 35.1 37.7 30.5 26 [-4.0] [0.0] 2605
7 62.5 0.0 45.1 48.5 39.0 56 [5.0] [0.0] 2605
8 13.6 0.0 39.0 43.4 21.0 115 [6.0] [0.0] 2596
20 9.6 0.0 27.1 32.6 18.3 604 [2.0] [0.0] 621
21 62.1 0.0 45.6 48.2 42.7 187 [4.0] [0.0] 2605
22 55.3 0.0 46.9 50.5 43.4 173 [-3.0] [0.0] 2605
23 14.1 0.0 37.2 40.1 24.8 3 [3.0] [0.0] 692
DIFF GLONASS L1(P)
REF GLONASS L2(CA)

SV AvgEl AvgOffset AvgCNo MaxCNo MinCNo Slip_Count FDMA Ant N_Samples
5 8.0 0.0 30.0 36.4 20.7 91 [1.0] [0.0] 163
6 65.5 0.0 15.0 16.9 13.1 1 [-4.0] [0.0] 2
7 62.4 0.0 44.8 46.4 36.2 0 [5.0] [0.0] 2617
8 15.4 0.0 37.4 43.3 19.2 67 [6.0] [0.0] 2115
21 62.2 0.0 44.3 46.0 41.8 0 [4.0] [0.0] 2617
22 55.3 0.0 45.6 47.3 41.7 0 [-3.0] [0.0] 2617
DUT GLONASS L2(CA)

SV AvgEl AvgOffset AvgCNo MaxCNo MinCNo Slip_Count FDMA Ant N_Samples
5 6.8 0.0 30.5 40.5 17.5 238 [1.0] [0.0] 627
6 59.0 0.0 12.5 12.5 12.5 0 [-4.0] [0.0] 1
7 62.5 0.0 43.7 45.6 39.9 119 [5.0] [0.0] 2605
8 13.6 0.0 36.6 44.2 19.0 103 [6.0] [0.0] 2596
20 9.3 0.0 29.0 36.3 19.7 575 [2.0] [0.0] 1095
21 62.1 0.0 42.5 45.0 39.0 188 [4.0] [0.0] 2605
22 55.3 0.0 42.4 46.0 37.5 65 [-3.0] [0.0] 2605
DIFF GLONASS L2(CA)

SV AvgEl AvgCNoDiff MaxCNoDiff MinCNoDiff FDMA N_Samples
5 7.2 1.0 5.6 -10.3 [1.0] 96
7 62.5 1.1 4.7 -6.0 [5.0] 2605
8 15.5 0.9 12.4 -8.2 [6.0] 2110
21 62.1 1.9 5.9 -2.0 [4.0] 2605
22 55.3 3.2 8.1 -1.8 [-3.0] 2605
REF GLONASS L2(P)

SV AvgEl AvgOffset AvgCNo MaxCNo MinCNo Slip_Count FDMA Ant N_Samples
5 7.9 0.0 27.7 32.9 15.6 69 [1.0] [0.0] 144
7 62.4 0.0 43.4 45.1 35.1 0 [5.0] [0.0] 2617
8 15.5 0.0 35.8 41.4 17.9 126 [6.0] [0.0] 2111
21 62.2 0.0 43.2 44.7 40.9 0 [4.0] [0.0] 2617
22 55.3 0.0 43.9 45.9 40.4 0 [-3.0] [0.0] 2617
DUT GLONASS L2(P)

SV AvgEl AvgOffset AvgCNo MaxCNo MinCNo Slip_Count FDMA Ant N_Samples
5 6.6 0.0 28.4 38.9 14.1 295 [1.0] [0.0] 513
7 62.5 0.0 42.0 43.9 38.8 38 [5.0] [0.0] 2605
8 13.7 0.0 34.3 42.1 13.0 462 [6.0] [0.0] 2581
20 9.9 0.0 26.5 33.8 18.7 825 [2.0] [0.0] 868
21 62.1 0.0 41.1 43.7 37.5 177 [4.0] [0.0] 2605
22 55.3 0.0 40.8 44.5 36.0 202 [-3.0] [0.0] 2605
DIFF GLONASS L2(P)

SV AvgEl AvgCNoDiff MaxCNoDiff MinCNoDiff FDMA N_Samples
5 7.0 0.9 5.7 -8.5 [1.0] 86
7 62.5 1.4 5.3 -6.0 [5.0] 2605
8 15.5 1.8 23.6 -7.3 [6.0] 2098
21 62.1 2.1 6.2 -1.3 [4.0] 2605
22 55.3 3.1 8.3 -3.7 [-3.0] 2605
REF GLONASS G3(PD)

SV AvgEl AvgOffset AvgCNo MaxCNo MinCNo Slip_Count FDMA Ant N_Samples
21 62.2 0.0 47.4 49.7 44.7 0 [4.0] [0.0] 2617
DUT GLONASS G3(PD)

SV AvgEl AvgOffset AvgCNo MaxCNo MinCNo Slip_Count FDMA Ant N_Samples
21 62.1 0.0 45.1 48.3 41.8 32 [4.0] [0.0] 2605
DIFF GLONASS G3(PD)

SV AvgEl AvgCNoDiff MaxCNoDiff MinCNoDiff FDMA N_Samples
21 62.1 2.2 4.7 -1.9 [4.0] 2605
REF Galileo L1(MBOC-PD)

SV AvgEl AvgOffset AvgCNo MaxCNo MinCNo Slip_Count SVChan Ant N_Samples
3 63.3 0.0 50.4 52.2 47.5 0 [53.0] [0.0] 2617
5 26.2 0.0 40.4 47.3 22.9 6 [51.0] [0.0] 2617
8 36.9 0.0 47.0 50.6 18.8 11 [49.0] [0.0] 2617
13 34.4 0.0 44.6 48.1 39.7 0 [45.0] [0.0] 2617
15 74.4 0.0 49.1 51.0 46.9 0 [44.0] [0.0] 2617
21 10.0 0.0 37.3 44.7 12.0 75 [52.0] [0.0] 2431
27 9.9 0.0 38.7 46.4 21.0 55 [50.0] [0.0] 1322
34 32.2 0.0 45.0 49.1 22.4 7 [43.0] [0.0] 2617
DUT Galileo L1(MBOC-PD)

SV AvgEl AvgOffset AvgCNo MaxCNo MinCNo Slip_Count SVChan Ant N_Samples
3 63.3 0.0 49.1 51.2 46.5 91 [51.0] [0.0] 2605
5 26.1 0.0 43.6 49.6 23.9 125 [53.0] [0.0] 2605
8 36.9 0.0 45.6 51.3 17.6 155 [49.0] [0.0] 2605
13 34.4 0.0 43.7 47.8 34.4 243 [45.0] [0.0] 2605
15 74.5 0.0 48.7 50.8 46.7 48 [44.0] [0.0] 2605
21 9.7 0.0 38.6 45.7 24.3 131 [50.0] [0.0] 2605
27 7.4 0.0 36.5 46.2 0.0 331 [52.0] [0.0] 2435
34 32.2 0.0 43.4 50.4 22.3 37 [43.0] [0.0] 2605
DIFF Galileo L1(MBOC-PD)

SV AvgEl AvgCNoDiff MaxCNoDiff MinCNoDiff SVChan N_Samples
3 63.3 1.3 4.6 -2.2 [53.0, 51.0] 2605
5 26.1 -3.2 9.3 -12.7 [51.0, 53.0] 2605
8 36.9 1.4 8.9 -21.9 [49.0] 2605
13 34.4 0.9 10.6 -4.3 [45.0] 2605
15 74.5 0.3 3.1 -2.4 [44.0] 2605
21 10.0 -1.4 11.0 -23.8 [52.0, 50.0] 2419
27 9.9 0.6 23.3 -18.6 [50.0, 52.0] 1310
34 32.2 1.6 12.3 -18.5 [43.0] 2605
REF Galileo L5/E5A(BPSK(10)-PD)

SV AvgEl AvgOffset AvgCNo MaxCNo MinCNo Slip_Count SVChan Ant N_Samples
3 63.3 0.0 48.3 50.6 45.1 0 [53.0] [0.0] 2617
5 26.2 0.0 43.3 49.8 27.2 3 [51.0] [0.0] 2617
8 36.9 0.0 46.0 49.0 27.7 9 [49.0] [0.0] 2617
13 34.4 0.0 46.7 50.0 38.2 0 [45.0] [0.0] 2617
15 74.4 0.0 49.3 50.9 46.2 0 [44.0] [0.0] 2617
21 10.0 0.0 41.2 47.6 30.6 6 [52.0] [0.0] 2431
27 9.9 0.0 41.3 47.4 30.5 11 [50.0] [0.0] 1322
34 32.2 0.0 45.5 51.2 31.9 2 [43.0] [0.0] 2617
DUT Galileo L5/E5A(BPSK(10)-PD)

SV AvgEl AvgOffset AvgCNo MaxCNo MinCNo Slip_Count SVChan Ant N_Samples
3 63.3 0.0 45.2 47.8 41.9 134 [51.0] [0.0] 2605
5 26.1 0.0 41.6 45.7 28.4 27 [53.0] [0.0] 2605
8 36.9 0.0 44.6 46.8 26.3 111 [49.0] [0.0] 2605
13 34.4 0.0 41.8 46.3 32.5 207 [45.0] [0.0] 2605
15 74.5 0.0 46.1 48.0 43.4 118 [44.0] [0.0] 2605
21 9.7 0.0 35.6 46.3 21.8 343 [50.0] [0.0] 2605
27 7.5 0.0 38.3 45.2 23.7 99 [52.0] [0.0] 2379
34 32.2 0.0 43.5 45.9 31.6 145 [43.0] [0.0] 2605
DIFF Galileo L5/E5A(BPSK(10)-PD)

SV AvgEl AvgCNoDiff MaxCNoDiff MinCNoDiff SVChan N_Samples
3 63.3 3.1 6.3 -0.8 [53.0, 51.0] 2605
5 26.1 1.7 13.1 -10.2 [51.0, 53.0] 2605
8 36.9 1.4 10.1 -5.4 [49.0] 2605
13 34.4 4.9 15.1 -5.4 [45.0] 2605
15 74.5 3.2 6.2 -0.3 [44.0] 2605
21 10.0 5.6 19.9 -7.7 [52.0, 50.0] 2419
27 9.9 1.8 18.9 -9.7 [50.0, 52.0] 1309
34 32.2 2.0 7.5 -5.2 [43.0] 2605
REF Galileo E5B/B2(BPSK(10)-PD)

SV AvgEl AvgOffset AvgCNo MaxCNo MinCNo Slip_Count SVChan Ant N_Samples
3 63.3 0.0 48.2 50.6 45.3 0 [53.0] [0.0] 2617
5 26.2 0.0 43.0 48.9 28.9 4 [51.0] [0.0] 2617
8 36.9 0.0 45.4 48.9 28.3 8 [49.0] [0.0] 2617
13 34.4 0.0 46.1 49.9 39.4 0 [45.0] [0.0] 2617
15 74.4 0.0 49.1 51.1 45.6 0 [44.0] [0.0] 2617
21 10.0 0.0 41.1 47.2 28.7 5 [52.0] [0.0] 2431
27 9.9 0.0 40.9 47.2 22.7 18 [50.0] [0.0] 1321
34 32.2 0.0 45.5 51.0 24.9 3 [43.0] [0.0] 2617
DUT Galileo E5B/B2(BPSK(10)-PD)

SV AvgEl AvgOffset AvgCNo MaxCNo MinCNo Slip_Count SVChan Ant N_Samples
3 63.3 0.0 46.1 48.3 43.4 202 [51.0] [0.0] 2605
5 26.1 0.0 39.0 45.4 25.5 125 [53.0] [0.0] 2605
8 36.9 0.0 43.7 47.1 26.3 43 [49.0] [0.0] 2605
13 34.4 0.0 42.0 46.0 35.3 233 [45.0] [0.0] 2605
15 74.5 0.0 46.5 48.5 44.1 149 [44.0] [0.0] 2605
21 9.7 0.0 36.2 45.9 21.7 249 [50.0] [0.0] 2604
27 7.5 0.0 37.2 43.8 20.9 259 [52.0] [0.0] 2377
34 32.2 0.0 43.4 46.4 28.1 111 [43.0] [0.0] 2605
DIFF Galileo E5B/B2(BPSK(10)-PD)

SV AvgEl AvgCNoDiff MaxCNoDiff MinCNoDiff SVChan N_Samples
3 63.3 2.1 4.5 -1.8 [53.0, 51.0] 2605
5 26.1 4.0 17.9 -4.1 [51.0, 53.0] 2605
8 36.9 1.7 11.0 -6.8 [49.0] 2605
13 34.4 4.1 13.6 -3.5 [45.0] 2605
15 74.5 2.6 5.7 -2.0 [44.0] 2605
21 10.0 4.9 18.7 -10.9 [52.0, 50.0] 2418
27 9.9 2.5 20.3 -15.7 [50.0, 52.0] 1306
34 32.2 2.2 11.5 -9.9 [43.0] 2605
REF Galileo E5A+B(AltBOC-Comp-PD)

SV AvgEl AvgOffset AvgCNo MaxCNo MinCNo Slip_Count SVChan Ant N_Samples
3 63.3 0.0 50.9 53.6 48.0 0 [53.0] [0.0] 2617
5 26.2 0.0 46.5 52.4 34.4 0 [51.0] [0.0] 2617
8 36.9 0.0 48.8 51.3 26.2 6 [49.0] [0.0] 2617
13 34.4 0.0 49.4 52.3 43.6 0 [45.0] [0.0] 2617
15 74.4 0.0 51.7 53.6 49.2 0 [44.0] [0.0] 2617
21 10.0 0.0 44.8 50.7 33.3 3 [52.0] [0.0] 2431
27 9.9 0.0 44.7 49.7 30.9 7 [50.0] [0.0] 1322
34 32.2 0.0 48.7 54.6 34.7 1 [43.0] [0.0] 2617
DUT Galileo E5A+B(AltBOC-Comp-PD)

SV AvgEl AvgOffset AvgCNo MaxCNo MinCNo Slip_Count SVChan Ant N_Samples
3 63.3 0.0 48.0 50.0 45.6 186 [51.0] [0.0] 2605
5 26.1 0.0 43.6 47.9 31.5 80 [53.0] [0.0] 2605
8 36.9 0.0 46.6 48.9 26.9 188 [49.0] [0.0] 2605
13 34.4 0.0 44.8 48.2 40.3 158 [45.0] [0.0] 2605
15 74.5 0.0 48.8 50.5 46.2 139 [44.0] [0.0] 2605
21 9.7 0.0 39.3 48.2 24.0 268 [50.0] [0.0] 2605
27 7.5 0.0 41.0 47.8 29.4 261 [52.0] [0.0] 2380
34 32.2 0.0 46.1 48.3 33.9 77 [43.0] [0.0] 2605
DIFF Galileo E5A+B(AltBOC-Comp-PD)

SV AvgEl AvgCNoDiff MaxCNoDiff MinCNoDiff SVChan N_Samples
3 63.3 2.9 5.5 -1.2 [53.0, 51.0] 2605
5 26.1 2.9 10.7 -5.2 [51.0, 53.0] 2605
8 36.9 2.2 11.0 -9.1 [49.0] 2605
13 34.4 4.6 11.3 -2.3 [45.0] 2605
15 74.5 3.0 5.8 -0.8 [44.0] 2605
21 10.0 5.4 18.6 -6.8 [52.0, 50.0] 2419
27 9.9 2.5 14.3 -13.3 [50.0, 52.0] 1310
34 32.2 2.6 8.5 -5.0 [43.0] 2605
REF Galileo E6(BPSK(5)-PD)

SV AvgEl AvgOffset AvgCNo MaxCNo MinCNo Slip_Count SVChan Ant N_Samples
3 63.3 0.0 51.4 54.1 48.3 0 [53.0] [0.0] 2617
5 26.2 0.0 43.7 50.0 34.2 4 [51.0] [0.0] 2612
8 36.9 0.0 48.2 51.1 34.4 6 [49.0] [0.0] 2610
13 34.4 0.0 48.2 51.0 42.0 0 [45.0] [0.0] 2617
15 74.4 0.0 52.9 54.4 51.2 0 [44.0] [0.0] 2617
21 10.0 0.0 42.0 49.8 32.6 48 [52.0] [0.0] 2389
27 9.9 0.0 39.6 49.1 23.5 30 [50.0] [0.0] 1277
34 32.2 0.0 47.3 52.0 35.1 4 [43.0] [0.0] 2611
DUT Galileo E6(BPSK(5)-PD)

SV AvgEl AvgOffset AvgCNo MaxCNo MinCNo Slip_Count SVChan Ant N_Samples
3 63.3 0.0 49.3 51.2 46.4 116 [51.0] [0.0] 2605
5 26.1 0.0 42.1 47.1 27.6 108 [53.0] [0.0] 2597
8 36.9 0.0 44.7 49.4 30.1 102 [49.0] [0.0] 2599
13 34.4 0.0 43.0 49.2 39.9 214 [45.0] [0.0] 2605
15 74.5 0.0 49.7 52.2 46.8 47 [44.0] [0.0] 2605
21 9.7 0.0 37.1 45.2 23.0 129 [50.0] [0.0] 2588
27 7.7 0.0 33.9 46.8 21.8 139 [52.0] [0.0] 2203
34 32.2 0.0 45.2 49.5 30.9 252 [43.0] [0.0] 2598
DIFF Galileo E6(BPSK(5)-PD)

SV AvgEl AvgCNoDiff MaxCNoDiff MinCNoDiff SVChan N_Samples
3 63.3 2.1 7.0 -2.7 [53.0, 51.0] 2605
5 26.1 1.7 20.0 -3.8 [51.0, 53.0] 2597
8 36.9 3.5 12.9 -1.8 [49.0] 2595
13 34.4 5.2 10.8 -2.0 [45.0] 2605
15 74.5 3.2 5.8 -0.4 [44.0] 2605
21 10.0 4.8 17.7 -7.1 [52.0, 50.0] 2362
27 9.9 4.3 19.7 -12.8 [50.0, 52.0] 1231
34 32.2 2.2 10.3 -3.2 [43.0] 2594
REF BeiDou L1(BOC-PD)

SV AvgEl AvgOffset AvgCNo MaxCNo MinCNo Slip_Count SVChan Ant N_Samples
20 31.8 0.0 44.8 48.4 32.9 0 [48.0] [0.0] 2617
27 41.1 0.0 45.0 49.4 26.8 2 [25.0] [0.0] 2617
29 26.1 0.0 41.9 48.6 32.9 1 [23.0] [0.0] 2617
30 76.8 0.0 49.7 50.9 47.9 0 [22.0] [0.0] 2617
32 84.8 0.0 50.2 51.7 48.8 0 [19.0] [0.0] 2617
41 31.3 0.0 42.3 48.1 22.4 8 [18.0] [0.0] 2615
DUT BeiDou L1(BOC-PD)
DIFF BeiDou L1(BOC-PD)
REF BeiDou L5/E5A(I+Q)

SV AvgEl AvgOffset AvgCNo MaxCNo MinCNo Slip_Count SVChan Ant N_Samples
20 31.8 0.0 45.9 49.2 26.8 6 [48.0] [0.0] 2617
27 41.1 0.0 45.5 49.4 22.5 7 [25.0] [0.0] 2617
29 26.1 0.0 44.8 48.8 34.2 1 [23.0] [0.0] 2617
30 76.8 0.0 49.2 51.0 46.7 0 [22.0] [0.0] 2617
32 84.8 0.0 51.3 52.8 49.5 0 [19.0] [0.0] 2617
41 31.3 0.0 45.2 52.4 26.1 3 [18.0] [0.0] 2617
DUT BeiDou L5/E5A(I+Q)

SV AvgEl AvgOffset AvgCNo MaxCNo MinCNo Slip_Count SVChan Ant N_Samples
20 31.8 0.0 43.1 47.3 32.7 101 [48.0] [0.0] 2605
27 41.1 0.0 42.4 46.9 29.9 230 [26.0] [0.0] 2605
28 3.1 0.0 31.8 44.1 14.6 511 [25.0] [0.0] 1009
29 26.1 0.0 42.5 46.3 32.7 87 [24.0] [0.0] 2605
30 76.8 0.0 45.9 47.4 43.0 151 [23.0] [0.0] 2605
32 84.8 0.0 47.2 48.9 45.6 116 [22.0] [0.0] 2605
41 31.3 0.0 43.6 47.3 33.6 106 [21.0] [0.0] 2605
DIFF BeiDou L5/E5A(I+Q)

SV AvgEl AvgCNoDiff MaxCNoDiff MinCNoDiff SVChan N_Samples
20 31.8 2.8 10.1 -15.5 [48.0] 2605
27 41.1 3.1 10.2 -7.9 [25.0, 26.0] 2605
29 26.1 2.4 13.4 -6.3 [23.0, 24.0] 2605
30 76.8 3.3 5.2 0.4 [22.0, 23.0] 2605
32 84.8 4.1 6.2 1.3 [19.0, 22.0] 2605
41 31.3 1.6 10.2 -8.9 [18.0, 21.0] 2605
REF BeiDou E5B/B2(I)

SV AvgEl AvgOffset AvgCNo MaxCNo MinCNo Slip_Count SVChan Ant N_Samples
20 31.8 0.0 42.6 46.0 28.3 4 [48.0] [0.0] 2604
27 41.1 0.0 40.9 46.3 23.9 2 [25.0] [0.0] 2617
29 26.1 0.0 41.3 45.3 29.9 8 [23.0] [0.0] 2614
30 76.8 0.0 46.5 48.1 43.9 0 [22.0] [0.0] 2617
32 84.8 0.0 47.6 49.4 45.3 0 [19.0] [0.0] 2617
41 31.3 0.0 40.7 46.7 26.7 15 [18.0] [0.0] 2617
DUT BeiDou E5B/B2(I)

SV AvgEl AvgOffset AvgCNo MaxCNo MinCNo Slip_Count SVChan Ant N_Samples
20 31.8 0.0 39.0 45.1 25.3 19 [48.0] [0.0] 2593
27 41.3 0.0 38.6 43.9 25.3 172 [26.0] [0.0] 2533
28 3.8 0.0 29.5 38.0 23.9 16 [25.0] [0.0] 282
29 26.2 0.0 39.3 43.3 25.1 263 [24.0] [0.0] 2577
30 76.8 0.0 43.6 45.7 41.6 59 [23.0] [0.0] 2605
32 84.8 0.0 43.8 45.2 42.0 13 [22.0] [0.0] 2605
41 31.3 0.0 39.5 43.4 26.2 85 [21.0] [0.0] 2597
DIFF BeiDou E5B/B2(I)

SV AvgEl AvgCNoDiff MaxCNoDiff MinCNoDiff SVChan N_Samples
20 31.8 3.5 12.3 -3.7 [48.0] 2587
27 41.3 2.5 12.3 -5.5 [25.0, 26.0] 2533
29 26.2 2.0 12.6 -8.2 [23.0, 24.0] 2574
30 76.8 2.8 5.7 0.7 [22.0, 23.0] 2605
32 84.8 3.8 6.0 1.4 [19.0, 22.0] 2605
41 31.3 1.3 11.2 -6.0 [18.0, 21.0] 2597
REF BeiDou B1(BPSK(2)-B1)

SV AvgEl AvgOffset AvgCNo MaxCNo MinCNo Slip_Count SVChan Ant N_Samples
20 31.8 0.0 45.2 49.1 27.3 6 [48.0] [0.0] 2617
27 41.1 0.0 45.4 50.1 29.4 1 [25.0] [0.0] 2617
29 26.1 0.0 41.9 47.9 32.0 4 [23.0] [0.0] 2617
30 76.8 0.0 49.7 51.5 46.6 0 [22.0] [0.0] 2617
32 84.8 0.0 49.1 51.4 47.0 0 [19.0] [0.0] 2617
41 31.3 0.0 42.2 48.4 28.1 6 [18.0] [0.0] 2617
DUT BeiDou B1(BPSK(2)-B1)

SV AvgEl AvgOffset AvgCNo MaxCNo MinCNo Slip_Count SVChan Ant N_Samples
20 31.8 0.0 46.5 49.8 31.4 156 [48.0] [0.0] 2605
27 41.1 0.0 44.7 51.9 26.0 176 [26.0] [0.0] 2605
28 3.0 0.0 35.7 49.1 12.8 159 [25.0] [0.0] 1057
29 26.1 0.0 39.8 47.6 30.4 149 [24.0] [0.0] 2605
30 76.8 0.0 49.5 51.7 46.7 196 [23.0] [0.0] 2605
32 84.8 0.0 49.6 51.5 45.9 51 [22.0] [0.0] 2605
41 31.3 0.0 46.0 49.9 24.5 30 [21.0] [0.0] 2605
DIFF BeiDou B1(BPSK(2)-B1)

SV AvgEl AvgCNoDiff MaxCNoDiff MinCNoDiff SVChan N_Samples
20 31.8 -1.3 7.5 -10.6 [48.0] 2605
27 41.1 0.7 16.6 -9.8 [25.0, 26.0] 2605
29 26.1 2.1 11.0 -8.5 [23.0, 24.0] 2605
30 76.8 0.2 2.8 -2.5 [22.0, 23.0] 2605
32 84.8 -0.5 2.2 -3.0 [19.0, 22.0] 2605
41 31.3 -3.8 9.9 -8.8 [18.0, 21.0] 2605
REF BeiDou B3(BPSK(10)-B3)

SV AvgEl AvgOffset AvgCNo MaxCNo MinCNo Slip_Count SVChan Ant N_Samples
20 31.8 0.0 43.5 46.7 29.6 2 [48.0] [0.0] 2606
27 41.1 0.0 44.2 47.8 27.9 2 [25.0] [0.0] 2617
29 26.1 0.0 43.0 46.6 35.4 4 [23.0] [0.0] 2616
30 76.8 0.0 46.7 49.3 44.2 0 [22.0] [0.0] 2617
32 84.8 0.0 47.4 50.0 45.2 0 [19.0] [0.0] 2617
41 31.3 0.0 43.6 48.2 32.6 6 [18.0] [0.0] 2617
DUT BeiDou B3(BPSK(10)-B3)

SV AvgEl AvgOffset AvgCNo MaxCNo MinCNo Slip_Count SVChan Ant N_Samples
20 31.8 0.0 43.3 46.8 24.0 258 [48.0] [0.0] 2605
27 41.3 0.0 39.7 47.2 28.0 7 [26.0] [0.0] 2545
28 3.4 0.0 34.4 42.0 19.6 246 [25.0] [0.0] 805
29 26.1 0.0 40.2 44.1 27.7 127 [24.0] [0.0] 2603
30 76.8 0.0 45.4 47.8 42.9 102 [23.0] [0.0] 2605
32 84.8 0.0 45.7 47.9 43.6 18 [22.0] [0.0] 2605
41 31.3 0.0 40.5 46.8 24.8 75 [21.0] [0.0] 2597
DIFF BeiDou B3(BPSK(10)-B3)

SV AvgEl AvgCNoDiff MaxCNoDiff MinCNoDiff SVChan N_Samples
20 31.8 0.2 9.8 -7.6 [48.0] 2594
27 41.3 4.5 10.2 -5.5 [25.0, 26.0] 2545
29 26.1 2.7 16.6 -6.1 [23.0, 24.0] 2602
30 76.8 1.3 3.8 -1.3 [22.0, 23.0] 2605
32 84.8 1.7 4.5 -0.6 [19.0, 22.0] 2605
41 31.3 3.1 20.9 -3.5 [18.0, 21.0] 2597
MSS Ref

Mean CNo: 50.11
