Files


./BX_all.T04 ./EB93_all.T04 ./EB95_all.T04
Modified: 2024-07-29 17:18:59

Serial Number : 6402C12585
Firmware Date : May 23, 2024
Release Ver : 5.70
Nav Proc Ver : 0.50
Radio Lib Ver : None
Primary Antenna Type : E
Primary Antenna Height : 0.0000 m
Secondary Antenna Type : E
Secondary Antenna Height : 0.0000 m
week_list : ['2325']
Start Time : 152183.095
Stop Time : 153900.14
Total Hours : 0.476956944444448

Mean Primary Pos: [39.89587006314299, -105.11339999873266]
Mean Secondary Pos: [39.89586595814673, -105.11339906288661]
Mean Heading: 350.08 (deg)
Mean Slope Distance: 0.46338 (m)
 Modified: 2024-07-29 17:18:59

Serial Number : 6348C01838
Firmware Date : May 23, 2024
Release Ver : 5.70
Nav Proc Ver : 0.50
Radio Lib Ver : None
Primary Antenna Type : -1
Primary Antenna Height : 0.0000 m
Secondary Antenna Type : -1
Secondary Antenna Height : 0.0000 m
week_list : ['2325']
Start Time : 152191.108
Stop Time : 153900.286
Total Hours : 0.4747716666666626

Mean Primary Pos: [39.8958694976392, -105.11339984684267]
Mean Secondary Pos: [39.895869472075084, -105.11340011832864]
Mean Heading: 83.003 (deg)
Mean Slope Distance: 0.023334 (m)
 Modified: 2024-07-29 17:18:59

Serial Number : 6348C01926
Firmware Date : Apr 12, 2024
Release Ver : 5.70
Nav Proc Ver : 0.49
Radio Lib Ver : None
Primary Antenna Type : E
Primary Antenna Height : 0.0000 m
Secondary Antenna Type : E
Secondary Antenna Height : 0.0000 m
week_list : ['2325']
Start Time : 152235.102
Stop Time : 153900.316
Total Hours : 0.46255944444443836

Mean Primary Pos: [39.89586516981481, -105.11339753956982]
Mean Secondary Pos: [39.89586514164538, -105.11339781241315]
Mean Heading: 82.336 (deg)
Mean Slope Distance: 0.023486 (m)

Difference Report Links

./results/BX_all_0-EB93_all_0.html
./results/BX_all_0-EB95_all_0.html
./results/BX_all_1-EB93_all_1.html
./results/BX_all_1-EB95_all_1.html

Summary Table

SVType Freq Track N_Samples_EB93_0 CNo_Mean_EB93_0 N_Samples_EB95_0 CNo_Mean_EB95_0 N_Samples_EB93_1 CNo_Mean_EB93_1 N_Samples_EB95_1 CNo_Mean_EB95_1
GPS L1 BOC-PD 0 0 0 0
GPS L1 CA 25,396 -0.2 23,030 -1.4 25,217 -0.0 23,020 -0.4
GPS L2 CM+CL 20,232 1.4 18,922 -1.7 20,286 3.6 18,954 0.7
GPS L2 E 1,777 -0.9 1,994 0.7 2,237 2.2 2,977 -1.2
GPS L5/E5A I+Q 14,386 2.5 13,683 -0.4 14,386 1.2 13,683 -1.4
SBAS L1 CA 7,790 0.9 7,670 0.8 0 0
SBAS L5/E5A I 0 0 0 0
GLONASS L1 CA 13,552 1.7 12,694 1.5 13,509 0.3 12,694 -0.5
GLONASS L1 P 0 0 0 0
GLONASS L2 CA 10,021 1.8 9,437 -1.6 10,305 3.2 9,436 0.5
GLONASS L2 P 9,999 2.1 9,437 -1.7 10,211 3.5 9,436 0.6
GLONASS G3 PD 2,605 2.2 2,565 -1.4 2,605 2.5 2,565 -1.0
Galileo L1 MBOC-PD 19,359 0.2 17,217 0.0 19,326 -0.0 17,217 -0.0
Galileo L5/E5A BPSK(10)-PD 19,358 3.0 17,217 -0.7 19,359 0.7 17,217 -1.8
Galileo E5B/B2 BPSK(10)-PD 19,354 3.0 17,217 -1.6 19,357 2.0 17,217 -1.7
Galileo E5A+B AltBOC-Comp-PD 19,359 3.3 17,217 -1.2 19,359 1.6 17,217 -1.8
Galileo E6 BPSK(5)-PD 19,194 3.3 17,138 1.2 18,977 -0.1 17,170 -1.9
BeiDou L1 BOC-PD 0 0 0 0
BeiDou L5/E5A I+Q 15,630 2.9 15,390 -0.7 15,630 1.6 15,390 -0.8
BeiDou E5B/B2 BPSK(2)-B2 0 0 0 0
BeiDou E5B/B2 I 15,501 2.7 15,371 -1.8 15,610 2.5 15,384 -0.7
BeiDou B1 BPSK(2)-B1 15,630 -0.4 15,390 -1.3 15,630 -1.5 15,390 -1.9
BeiDou B3 BPSK(10)-B3 15,548 2.3 15,376 -0.3 15,618 2.0 15,384 -0.1
QZSS L1 CA 0 0 0 0
QZSS L1 SLAS 0 0 0 0
QZSS L2 CM+CL 0 0 0 0
QZSS L5/E5A I+Q 0 0 0 0
MSS 0 0 0 0
Total 264,691 1.9 246,965 -0.7 257,622 1.3 240,351 -0.8

Az-El Plots

BX_all_0-EB93_all_0 BX_all_0-EB95_all_0 BX_all_1-EB93_all_1 BX_all_1-EB95_all_1

Mean Elevation Plots

Antenna 0

GPS
SBAS
GLONASS
Galileo
BeiDou

Antenna 1

GPS
GLONASS
Galileo
BeiDou

Oscillation Check

BX_all_0: 650.1
Antenna SVType Freq Track SV osc_factor
0 GPS L1 0 29 650
0 GPS L1 0 16 600
0 GPS L5/E5A 8 24 530
0 BeiDou E5B/B2 6 27 462
0 Galileo L1 23 21 457
0 GPS L2 5 24 447
0 GPS L2 5 29 438
0 GPS L1 0 13 432
0 GPS L1 0 24 418
0 GLONASS L1 0 8 397
EB93_all_0: 921.2
Antenna SVType Freq Track SV osc_factor
0 Galileo L1 23 27 921
0 GPS L1 0 16 587
0 Galileo E6 36 27 574
0 GPS L1 0 32 557
0 GPS L1 0 26 545
0 GPS L2 5 32 544
0 Galileo E6 36 21 541
0 GLONASS L2 1 8 530
0 GPS L1 0 24 516
0 GPS L1 0 29 513
EB95_all_0: 481.9
Antenna SVType Freq Track SV osc_factor
0 GPS L1 0 29 482
0 GPS L2 5 24 454
0 SBAS L1 0 133 411
0 GPS L1 0 24 410
0 Galileo E6 36 5 400
0 BeiDou B3 29 27 363
0 GPS L1 0 13 354
0 Galileo E6 36 13 349
0 SBAS L1 0 135 343
0 GPS L2 2 13 333
BX_all_1: 578.8
Antenna SVType Freq Track SV osc_factor
1 GPS L1 0 24 579
1 GPS L5/E5A 8 24 532
1 BeiDou E5B/B2 6 20 500
1 BeiDou E5B/B2 6 29 433
1 GPS L2 5 27 431
1 GPS L2 5 24 424
1 GPS L2 5 29 415
1 Galileo E5B/B2 11 21 415
1 Galileo L1 23 21 408
1 GPS L5/E5A 8 27 403
EB93_all_1: 726.2
Antenna SVType Freq Track SV osc_factor
1 Galileo L1 23 27 726
1 GPS L1 0 16 696
1 Galileo E5B/B2 11 27 613
1 GLONASS L1 0 8 612
1 GLONASS L2 1 8 598
1 GPS L1 0 29 592
1 GPS L1 0 32 580
1 GPS L1 0 5 578
1 Galileo L1 23 21 567
1 GPS L2 5 24 554
EB95_all_1: 513.7
Antenna SVType Freq Track SV osc_factor
1 GPS L5/E5A 8 24 514
1 GPS L2 5 24 504
1 GPS L1 0 24 467
1 GPS L1 0 27 426
1 Galileo L1 23 5 406
1 GPS L1 0 29 352
1 BeiDou B3 29 20 323
1 GPS L2 2 13 304
1 GPS L2 5 29 294
1 Galileo E6 36 5 291

FFT Plots

L1 L2 L5 E6 G1 B1
BX
EB93
EB95
