REF File: 240805/BX_all.T04
DUT File: 240805/EB79_all.T04

Ref Statistics

DUT Statistics

Difference Statistics
SVType Freq Track N_Samples CNo_Mean CNo_Median CNo_Std CNo_Min CNo_Max CNo_Range El_Mean El_Max
GPS L1 CA 836032 44.0 44.3 4.2 16.9 54.7 37.8 37.3 90.0
GPS L2 CM+CL 634745 44.3 44.8 3.4 23.0 51.9 28.9 38.6 90.0
GPS L2 E 200685 30.2 30.6 6.5 12.6 43.9 31.3 33.2 77.0
GPS L5/E5A I+Q 453516 47.5 47.7 2.9 30.8 54.4 23.6 37.5 88.0
SBAS L1 CA 350329 42.7 44.0 4.1 21.6 48.5 26.9 20.4 42.0
SBAS L5/E5A I 270000 46.1 46.1 0.6 42.2 48.4 6.2 39.8 42.0
GLONASS L1 CA 651262 44.5 45.3 4.8 5.9 54.1 48.2 35.7 89.0
GLONASS L1 P 648434 43.1 43.8 4.7 20.1 52.3 32.2 35.8 89.0
GLONASS L2 CA 573755 44.6 45.3 3.4 10.6 51.3 40.7 36.0 89.0
GLONASS L2 P 573722 43.0 43.7 3.3 11.9 49.4 37.5 36.0 89.0
GLONASS G3 PD 58670 43.6 43.6 3.0 22.5 49.4 26.9 30.4 66.0
Galileo L1 MBOC-PD 637466 45.2 45.6 3.8 19.7 54.0 34.3 37.1 90.0
Galileo L5/E5A BPSK(10)-PD 637466 44.9 45.2 2.7 31.9 50.8 18.9 37.1 90.0
Galileo E5B/B2 BPSK(10)-PD 637466 45.4 45.7 2.9 29.8 51.2 21.4 37.1 90.0
Galileo E5A+B AltBOC-Comp-PD 637466 47.7 47.8 2.4 35.9 52.8 16.9 37.1 90.0
Galileo E6 BPSK(5)-PD 637461 46.9 47.2 3.6 26.9 53.1 26.2 37.1 90.0
BeiDou L1 BOC-PD 638682 45.8 46.1 4.0 23.3 53.4 30.1 37.4 89.0
BeiDou L5/E5A I+Q 638683 45.9 46.3 2.8 32.8 51.4 18.6 37.4 89.0
BeiDou E5B/B2 BPSK(2)-B2 93823 45.1 45.6 2.7 30.8 50.2 19.4 33.0 85.0
BeiDou B1 BPSK(2)-B1 732517 45.3 45.7 4.1 17.6 53.9 36.3 36.9 89.0
BeiDou B3 BPSK(10)-B3 732464 44.6 45.1 3.1 29.1 50.3 21.2 36.9 89.0
start/stop time: 46,800 136,799
Total time: 89,999.0 seconds
Total time: 1,499.983 minutes
Total time: 25.000 hours
Total Samples: 11,274,644
Avg Samples/sec: 125.3

Serial Number : 6221C43829
Firmware Date : Mar 6, 2024
Release Ver : 5.70
Nav Proc Ver : 0.47
Radio Lib Ver : None
Primary Antenna Type : MI
Primary Antenna Height : 0.0000 m
Secondary Antenna Type : MI
Secondary Antenna Height : 0.0000 m
week_list : ['2326']
Start Time : 46800.213
Stop Time : 133200.189
Total Hours : 23.999993333333336
SVType Freq Track N_Samples CNo_Mean CNo_Median CNo_Std CNo_Min CNo_Max CNo_Range El_Mean El_Max
GPS L1 CA 835863 43.9 44.3 4.0 3.4 54.5 51.1 37.3 90.0
GPS L2 CM+CL 634718 44.1 44.5 3.3 23.9 51.6 27.7 38.6 90.0
GPS L2 E 835703 36.6 36.9 7.7 13.9 52.8 38.9 37.3 90.0
GPS L5/E5A I+Q 453540 47.4 47.6 2.8 22.8 53.3 30.5 37.5 88.0
SBAS L1 CA 270000 43.9 44.1 0.9 40.5 46.6 6.1 39.8 42.0
GLONASS L1 CA 650238 43.8 44.6 4.8 10.3 54.4 44.1 35.7 89.0
GLONASS L2 CA 573300 44.5 45.2 3.2 12.4 50.7 38.3 36.1 89.0
Galileo L1 MBOC-PD 638355 45.1 45.5 3.7 24.8 53.3 28.5 37.1 90.0
Galileo E5A+B AltBOC-Comp-PD 638355 47.5 47.7 2.2 35.6 52.3 16.7 37.1 90.0
BeiDou L5/E5A I+Q 638732 45.9 46.1 2.7 21.2 51.7 30.5 37.4 89.0
BeiDou E5B/B2 BPSK(2)-B2 93715 44.9 45.4 2.2 33.9 49.4 15.5 33.1 85.0
BeiDou B1 BPSK(2)-B1 732452 45.3 45.6 3.9 20.6 54.2 33.6 36.9 89.0
BeiDou B3 BPSK(10)-B3 732440 44.4 44.9 2.8 25.8 49.8 24.0 36.9 89.0
start/stop time: 46,800 136,799
Total time: 89,999.0 seconds
Total time: 1,499.983 minutes
Total time: 25.000 hours
Total Samples: 7,727,411
Avg Samples/sec: 85.9

Serial Number : 6348C01835
Firmware Date : Jun 21, 2024
Release Ver : 5.70
Nav Proc Ver : 0.51
Radio Lib Ver : None
Primary Antenna Type : E
Primary Antenna Height : 0.1080 m
Secondary Antenna Type : E
Secondary Antenna Height : 0.1080 m
week_list : ['2326']
Start Time : 46800.355
Stop Time : 136608.289
Total Hours : 24.94664833333333
SVType Freq Track N_Samples CNo_Mean CNo_Median CNo_Std CNo_Min CNo_Max CNo_Range El_Mean El_Max
GPS L1 CA 835391 +0.0 +0.1 +1.7 -21.9 +30.5 +52.4 +37.3 +90.0
GPS L2 CM+CL 634337 +0.2 +0.3 +1.4 -12.8 +13.3 +26.1 +38.6 +90.0
GPS L2 E 200461 +0.4 +0.5 +1.8 -9.4 +8.3 +17.7 +33.2 +77.0
GPS L5/E5A I+Q 453238 +0.1 +0.0 +1.1 -8.9 +19.6 +28.5 +37.6 +88.0
SBAS L1 CA 270000 +0.8 +0.8 +1.2 -2.9 +4.0 +6.9 +39.8 +42.0
GLONASS L1 CA 648473 +0.7 +0.8 +1.7 -17.2 +21.6 +38.8 +35.8 +89.0
GLONASS L2 CA 571930 +0.1 +0.1 +1.5 -21.7 +15.6 +37.3 +36.1 +89.0
Galileo L1 MBOC-PD 637234 +0.1 +0.1 +1.4 -10.0 +8.5 +18.5 +37.1 +90.0
Galileo E5A+B AltBOC-Comp-PD 637234 +0.2 +0.2 +0.9 -5.8 +6.7 +12.5 +37.1 +90.0
BeiDou L5/E5A I+Q 638340 +0.1 +0.1 +1.1 -10.1 +18.1 +28.2 +37.4 +89.0
BeiDou E5B/B2 BPSK(2)-B2 93668 +0.2 +0.4 +1.5 -11.9 +7.9 +19.8 +33.1 +85.0
BeiDou B1 BPSK(2)-B1 732024 -0.0 +0.1 +1.6 -22.0 +15.3 +37.3 +36.9 +89.0
BeiDou B3 BPSK(10)-B3 731959 +0.1 +0.2 +1.2 -8.4 +9.6 +18.0 +36.9 +89.0
start/stop time: 46,800 136,799
Total time: 89,999.0 seconds
Total time: 1,499.983 minutes
Total time: 25.000 hours
Total Samples: 7,084,289
Avg Samples/sec: 78.7

Statistics for full C/No Observations dataset
(df_ref - df_dut => positive numbers mean DUT is worse)
Mean = 0.191
Median = 0.200
Std Dev= 1.415

Plots


REF GPS L1(CA)

SV AvgEl AvgOffset AvgCNo MaxCNo MinCNo Slip_Count SVChan Ant N_Samples
2 26.0 0.0 43.1 49.6 27.1 196 [16.0, 37.0] [0.0] 30510
3 32.7 0.0 42.7 52.0 27.1 98 [21.0, 36.0] [0.0] 27079
4 45.4 0.0 44.8 51.4 33.4 0 [33.0] [0.0] 23840
5 40.2 0.0 44.2 51.9 16.9 88 [17.0, 14.0] [0.0] 26886
6 36.4 0.0 42.9 51.7 24.4 246 [28.0, 30.0, 31.0] [0.0] 28333
7 45.1 0.0 45.7 51.7 30.5 1 [29.0] [0.0] 25519
8 27.3 0.0 42.3 50.0 25.5 126 [31.0, 24.0] [0.0] 29174
9 44.1 0.0 45.0 52.8 28.7 0 [36.0] [0.0] 21419
10 43.5 0.0 46.9 53.8 31.3 0 [37.0] [0.0] 25764
11 48.6 0.0 45.5 52.8 27.3 124 [30.0, 29.0] [0.0] 27184
12 41.5 0.0 44.6 51.5 24.1 329 [32.0, 33.0, 37.0] [0.0] 28049
13 26.4 0.0 42.8 50.5 24.7 124 [29.0, 13.0] [0.0] 29957
14 44.2 0.0 45.0 50.9 30.2 0 [17.0] [0.0] 25702
15 29.1 0.0 43.3 50.4 32.3 38 [28.0, 14.0] [0.0] 27787
16 31.2 0.0 42.1 50.3 26.2 176 [30.0, 22.0] [0.0] 27101
17 45.7 0.0 45.3 52.1 30.6 4 [34.0] [0.0] 24115
18 44.2 0.0 44.9 50.9 33.3 0 [35.0] [0.0] 24957
19 41.4 0.0 44.1 51.9 30.2 216 [25.0, 21.0] [0.0] 27542
20 37.9 0.0 43.2 51.5 28.9 434 [24.0, 19.0, 25.0] [0.0] 29905
21 26.6 0.0 42.2 49.0 19.9 173 [26.0, 19.0] [0.0] 30265
22 44.4 0.0 45.1 50.7 29.2 0 [22.0] [0.0] 26007
23 43.5 0.0 44.9 50.9 27.4 6 [14.0] [0.0] 25545
24 25.5 0.0 41.0 48.8 23.9 396 [26.0, 25.0, 28.0] [0.0] 30051
25 31.3 0.0 42.3 50.5 25.6 221 [23.0, 34.0, 20.0] [0.0] 32410
26 28.0 0.0 42.6 50.5 29.7 61 [19.0, 14.0] [0.0] 28485
27 26.1 0.0 42.3 49.1 25.8 261 [34.0, 30.0] [0.0] 29919
28 36.9 0.0 42.9 50.3 22.3 280 [35.0, 20.0, 28.0] [0.0] 25365
29 43.2 0.0 45.7 52.6 30.1 247 [16.0, 13.0] [0.0] 26541
30 45.9 0.0 45.8 52.5 32.6 2 [23.0] [0.0] 23647
31 45.3 0.0 45.4 54.0 19.9 57 [35.0] [0.0] 22332
32 45.3 0.0 47.2 54.7 30.9 3 [36.0] [0.0] 24642
DUT GPS L1(CA)

SV AvgEl AvgOffset AvgCNo MaxCNo MinCNo Slip_Count SVChan Ant N_Samples
2 26.1 0.0 43.0 49.8 32.7 43 [16.0, 36.0] [0.0] 30487
3 32.7 0.0 42.7 52.1 28.7 127 [21.0, 35.0] [0.0] 27104
4 45.4 0.0 44.6 51.1 33.3 0 [34.0] [0.0] 23802
5 40.2 0.0 44.6 51.9 31.9 205 [17.0, 14.0, 15.0] [0.0] 26869
6 36.3 0.0 43.2 51.5 32.1 318 [26.0, 28.0, 29.0] [0.0] 28378
7 45.1 0.0 45.5 51.6 25.8 8 [33.0] [0.0] 25520
8 27.4 0.0 42.1 49.5 28.7 248 [31.0, 25.0] [0.0] 29157
9 44.0 0.0 45.2 52.5 31.7 0 [30.0] [0.0] 21428
10 43.5 0.0 47.0 53.8 33.8 0 [36.0] [0.0] 25782
11 48.6 0.0 45.7 52.3 30.8 48 [31.0, 33.0] [0.0] 27167
12 41.5 0.0 44.7 51.3 26.0 284 [32.0, 33.0, 36.0] [0.0] 28054
13 26.4 0.0 42.9 48.8 28.8 17 [29.0, 15.0] [0.0] 29932
14 44.1 0.0 44.7 49.8 29.6 0 [18.0] [0.0] 25734
15 29.1 0.0 43.0 49.9 31.0 108 [26.0, 12.0] [0.0] 27766
16 31.2 0.0 41.8 50.1 29.7 206 [31.0, 22.0] [0.0] 27078
17 45.7 0.0 45.8 52.5 33.7 0 [34.0] [0.0] 24093
18 44.1 0.0 44.8 50.9 31.9 0 [37.0] [0.0] 24960
19 41.4 0.0 44.3 50.8 26.4 98 [27.0, 21.0] [0.0] 27538
20 38.0 0.0 43.1 50.2 29.0 399 [25.0, 19.0] [0.0] 29858
21 26.6 0.0 42.5 49.6 29.5 249 [23.0, 22.0] [0.0] 30259
22 44.4 0.0 44.9 50.9 33.2 0 [24.0] [0.0] 25993
23 43.5 0.0 44.7 50.0 30.7 0 [14.0] [0.0] 25565
24 25.5 0.0 41.3 47.8 29.2 165 [24.0, 27.0] [0.0] 30080
25 31.3 0.0 42.3 50.0 27.1 257 [23.0, 35.0, 22.0] [0.0] 32368
26 28.0 0.0 42.0 50.2 27.2 213 [19.0, 14.0] [0.0] 28495
27 26.1 0.0 42.6 48.3 26.3 33 [35.0, 32.0] [0.0] 29887
28 36.9 0.0 42.8 51.2 3.4 327 [37.0, 20.0, 27.0] [0.0] 25357
29 43.1 0.0 45.0 53.0 31.4 20 [16.0, 14.0] [0.0] 26564
30 45.9 0.0 45.7 52.7 29.3 2 [23.0] [0.0] 23628
31 45.3 0.0 45.6 53.0 28.9 1 [37.0] [0.0] 22312
32 45.3 0.0 47.0 54.5 13.3 44 [30.0] [0.0] 24648
DIFF GPS L1(CA)

SV AvgEl AvgCNoDiff MaxCNoDiff MinCNoDiff SVChan N_Samples
2 26.1 0.1 5.8 -9.4 [16.0, 37.0, 36.0] 30472
3 32.7 0.0 7.7 -10.8 [21.0, 36.0, 35.0] 27058
4 45.4 0.2 5.1 -4.6 [33.0, 34.0] 23802
5 40.2 -0.4 5.8 -21.9 [17.0, 14.0, 15.0] 26868
6 36.4 -0.3 5.4 -14.8 [28.0, 26.0, 30.0, 31.0, 29.0] 28326
7 45.1 0.2 9.9 -4.1 [29.0, 33.0] 25518
8 27.4 0.2 8.5 -10.8 [31.0, 24.0, 25.0] 29149
9 44.1 -0.2 6.0 -8.0 [36.0, 30.0] 21419
10 43.5 -0.1 5.4 -8.1 [37.0, 36.0] 25758
11 48.6 -0.2 4.6 -9.0 [30.0, 31.0, 29.0, 33.0] 27166
12 41.5 -0.2 9.4 -13.8 [32.0, 33.0, 37.0, 36.0] 28012
13 26.4 -0.1 7.1 -14.3 [29.0, 13.0, 15.0] 29932
14 44.2 0.3 8.3 -7.5 [17.0, 18.0] 25702
15 29.1 0.3 8.9 -6.4 [28.0, 26.0, 14.0, 12.0] 27756
16 31.2 0.2 6.2 -7.3 [30.0, 31.0, 22.0] 27072
17 45.7 -0.5 4.7 -8.1 [34.0] 24093
18 44.2 0.1 5.3 -5.3 [35.0, 37.0] 24951
19 41.5 -0.2 6.5 -6.1 [25.0, 27.0, 21.0] 27524
20 38.0 0.1 9.4 -6.5 [24.0, 25.0, 19.0] 29832
21 26.6 -0.2 6.2 -13.1 [26.0, 23.0, 19.0, 22.0] 30240
22 44.5 0.2 4.9 -10.2 [22.0, 24.0] 25982
23 43.5 0.3 7.2 -10.5 [14.0] 25545
24 25.5 -0.3 6.8 -12.4 [26.0, 24.0, 25.0, 27.0, 28.0] 30042
25 31.3 0.0 6.9 -11.5 [23.0, 34.0, 35.0, 20.0, 22.0] 32368
26 28.0 0.6 9.9 -5.6 [19.0, 14.0] 28468
27 26.2 -0.3 5.3 -9.2 [34.0, 35.0, 30.0, 32.0] 29881
28 36.9 0.1 30.5 -12.8 [35.0, 37.0, 20.0, 28.0, 27.0] 25335
29 43.2 0.7 7.6 -9.5 [16.0, 13.0, 14.0] 26540
30 45.9 0.2 6.0 -5.7 [23.0] 23627
31 45.3 -0.2 6.3 -19.5 [35.0, 37.0] 22312
32 45.3 0.2 19.1 -7.5 [36.0, 30.0] 24641
REF GPS L2(E)

SV AvgEl AvgOffset AvgCNo MaxCNo MinCNo Slip_Count SVChan Ant N_Samples
2 26.0 0.0 30.4 38.3 13.9 129 [16.0, 37.0] [0.0] 30510
13 26.4 0.0 27.5 36.1 14.8 160 [29.0, 13.0] [0.0] 29900
16 31.2 0.0 28.5 40.8 13.9 19 [30.0, 22.0] [0.0] 27101
19 41.4 0.0 33.6 43.9 13.9 202 [25.0, 21.0] [0.0] 27538
20 38.1 0.0 30.5 40.5 13.9 208 [24.0, 19.0, 25.0] [0.0] 29780
21 26.9 0.0 28.1 38.1 12.6 177 [26.0, 19.0] [0.0] 29849
22 44.4 0.0 33.2 40.9 14.8 1 [22.0] [0.0] 26007
DUT GPS L2(E)

SV AvgEl AvgOffset AvgCNo MaxCNo MinCNo Slip_Count SVChan Ant N_Samples
2 26.1 0.0 30.1 36.5 15.6 223 [16.0, 36.0] [0.0] 30487
3 32.7 0.0 39.2 50.0 23.6 3 [21.0, 35.0] [0.0] 27104
4 45.4 0.0 33.3 42.6 16.9 0 [34.0] [0.0] 23802
5 40.2 0.0 41.1 50.0 21.8 266 [17.0, 14.0, 15.0] [0.0] 26869
6 36.3 0.0 40.8 51.1 23.6 392 [26.0, 28.0, 29.0] [0.0] 28378
7 45.1 0.0 41.8 49.5 23.6 3 [33.0] [0.0] 25509
8 27.4 0.0 38.2 47.3 23.8 172 [31.0, 25.0] [0.0] 29157
9 44.0 0.0 44.0 52.4 25.1 0 [30.0] [0.0] 21428
10 43.5 0.0 44.2 51.6 27.3 0 [36.0] [0.0] 25782
11 48.6 0.0 34.5 43.3 15.6 182 [31.0, 33.0] [0.0] 27167
12 41.5 0.0 40.9 49.1 23.2 352 [32.0, 33.0, 36.0] [0.0] 28045
13 26.4 0.0 27.0 35.9 14.8 114 [29.0, 15.0] [0.0] 29932
14 44.1 0.0 34.0 41.3 15.6 0 [18.0] [0.0] 25734
15 29.1 0.0 38.0 47.0 22.6 160 [26.0, 12.0] [0.0] 27766
16 31.2 0.0 27.6 39.7 13.9 236 [31.0, 22.0] [0.0] 27078
17 45.7 0.0 42.4 50.3 20.1 0 [34.0] [0.0] 24093
18 44.1 0.0 33.5 42.2 19.0 0 [37.0] [0.0] 24960
19 41.4 0.0 33.3 43.6 13.9 79 [27.0, 21.0] [0.0] 27538
20 38.0 0.0 30.1 40.0 14.8 269 [25.0, 19.0] [0.0] 29858
21 26.6 0.0 27.8 37.7 14.8 223 [23.0, 22.0] [0.0] 30259
22 44.4 0.0 32.5 40.2 15.6 0 [24.0] [0.0] 25993
23 43.5 0.0 33.5 40.6 18.3 0 [14.0] [0.0] 25565
24 25.5 0.0 37.9 46.2 24.1 57 [24.0, 27.0] [0.0] 30080
25 31.3 0.0 38.0 47.0 19.0 231 [23.0, 35.0, 22.0] [0.0] 32368
26 28.0 0.0 37.4 46.7 22.5 222 [19.0, 14.0] [0.0] 28495
27 26.2 0.0 39.3 46.0 26.2 114 [35.0, 32.0] [0.0] 29880
28 37.0 0.0 30.8 41.6 13.9 264 [37.0, 20.0, 27.0] [0.0] 25266
29 43.1 0.0 41.5 51.3 24.8 66 [16.0, 14.0] [0.0] 26564
30 45.9 0.0 43.3 50.5 26.2 2 [23.0] [0.0] 23628
31 45.3 0.0 41.9 50.9 26.2 1 [37.0] [0.0] 22312
32 45.4 0.0 44.1 52.8 16.9 8 [30.0] [0.0] 24606
DIFF GPS L2(E)

SV AvgEl AvgCNoDiff MaxCNoDiff MinCNoDiff SVChan N_Samples
2 26.1 0.4 8.3 -9.0 [16.0, 37.0, 36.0] 30472
13 26.5 0.4 7.9 -9.4 [29.0, 13.0, 15.0] 29884
16 31.2 0.8 7.4 -6.1 [30.0, 31.0, 22.0] 27072
19 41.5 0.3 6.3 -8.2 [25.0, 27.0, 21.0] 27520
20 38.1 0.4 8.0 -7.0 [24.0, 25.0, 19.0] 29707
21 26.9 0.2 8.2 -7.3 [26.0, 23.0, 19.0, 22.0] 29824
22 44.5 0.7 6.1 -6.3 [22.0, 24.0] 25982
REF GPS L2(CM+CL)

SV AvgEl AvgOffset AvgCNo MaxCNo MinCNo Slip_Count SVChan Ant N_Samples
3 32.7 0.0 42.9 48.4 34.5 141 [21.0, 36.0] [0.0] 27079
4 45.4 0.0 46.5 51.5 35.8 0 [33.0] [0.0] 23840
5 40.2 0.0 44.3 49.4 31.8 194 [17.0, 14.0] [0.0] 26886
6 36.4 0.0 44.6 50.0 32.3 210 [28.0, 30.0, 31.0] [0.0] 28333
7 45.1 0.0 44.6 49.1 30.7 0 [29.0] [0.0] 25519
8 27.3 0.0 42.9 47.6 31.8 94 [31.0, 24.0] [0.0] 29174
9 44.1 0.0 45.0 50.0 34.5 0 [36.0] [0.0] 21419
10 43.5 0.0 44.8 49.4 35.1 0 [37.0] [0.0] 25764
11 48.6 0.0 46.8 51.9 28.7 174 [30.0, 29.0] [0.0] 27184
12 41.5 0.0 44.1 48.9 34.6 4 [32.0, 33.0, 37.0] [0.0] 28049
14 44.2 0.0 46.6 51.8 23.0 16 [17.0] [0.0] 25702
15 29.1 0.0 42.3 47.6 31.7 97 [28.0, 14.0] [0.0] 27787
17 45.7 0.0 44.2 49.6 28.4 0 [34.0] [0.0] 24115
18 44.2 0.0 46.6 51.4 36.3 0 [35.0] [0.0] 24957
23 43.5 0.0 46.2 51.1 35.3 0 [14.0] [0.0] 25545
24 25.5 0.0 42.1 46.8 28.9 243 [26.0, 25.0, 28.0] [0.0] 30051
25 31.3 0.0 42.4 48.5 31.0 323 [23.0, 34.0, 20.0] [0.0] 32410
26 28.0 0.0 42.4 48.0 31.3 167 [19.0, 14.0] [0.0] 28485
27 26.1 0.0 42.4 46.8 32.9 68 [34.0, 30.0] [0.0] 29919
28 36.9 0.0 46.0 51.7 36.2 252 [35.0, 20.0, 28.0] [0.0] 25365
29 43.2 0.0 44.3 49.3 35.1 51 [16.0, 13.0] [0.0] 26541
30 45.9 0.0 44.2 48.8 35.4 0 [23.0] [0.0] 23647
31 45.3 0.0 44.8 49.8 34.4 0 [35.0] [0.0] 22332
32 45.3 0.0 44.8 49.7 27.6 0 [36.0] [0.0] 24642
DUT GPS L2(CM+CL)

SV AvgEl AvgOffset AvgCNo MaxCNo MinCNo Slip_Count SVChan Ant N_Samples
3 32.7 0.0 42.8 48.2 34.2 19 [21.0, 35.0] [0.0] 27104
4 45.4 0.0 46.3 51.6 36.3 0 [34.0] [0.0] 23802
5 40.2 0.0 43.9 48.9 29.8 91 [17.0, 14.0, 15.0] [0.0] 26869
6 36.3 0.0 44.1 49.8 26.6 448 [26.0, 28.0, 29.0] [0.0] 28378
7 45.1 0.0 44.3 49.1 34.0 0 [33.0] [0.0] 25520
8 27.4 0.0 42.8 48.0 33.6 152 [31.0, 25.0] [0.0] 29157
9 44.0 0.0 44.5 49.1 32.9 0 [30.0] [0.0] 21428
10 43.5 0.0 44.5 48.9 34.9 0 [36.0] [0.0] 25782
11 48.6 0.0 46.6 51.6 30.7 139 [31.0, 33.0] [0.0] 27167
12 41.5 0.0 43.6 48.8 32.9 199 [32.0, 33.0, 36.0] [0.0] 28054
14 44.1 0.0 46.5 50.8 34.6 0 [18.0] [0.0] 25734
15 29.1 0.0 42.1 47.6 28.0 81 [26.0, 12.0] [0.0] 27766
17 45.7 0.0 44.3 49.9 27.5 0 [34.0] [0.0] 24093
18 44.1 0.0 46.2 51.5 37.9 0 [37.0] [0.0] 24960
23 43.5 0.0 46.2 50.5 35.0 0 [14.0] [0.0] 25565
24 25.5 0.0 41.9 47.7 32.4 22 [24.0, 27.0] [0.0] 30080
25 31.3 0.0 42.0 47.0 23.9 171 [23.0, 35.0, 22.0] [0.0] 32368
26 28.0 0.0 42.3 47.8 32.9 17 [19.0, 14.0] [0.0] 28495
27 26.1 0.0 42.5 46.9 32.4 31 [35.0, 32.0] [0.0] 29887
28 36.9 0.0 45.3 51.1 25.9 260 [37.0, 20.0, 27.0] [0.0] 25357
29 43.1 0.0 43.6 49.2 30.1 107 [16.0, 14.0] [0.0] 26564
30 45.9 0.0 44.2 48.0 34.0 0 [23.0] [0.0] 23628
31 45.3 0.0 44.6 49.1 35.3 0 [37.0] [0.0] 22312
32 45.3 0.0 45.0 49.5 24.3 5 [30.0] [0.0] 24648
DIFF GPS L2(CM+CL)

SV AvgEl AvgCNoDiff MaxCNoDiff MinCNoDiff SVChan N_Samples
3 32.7 0.1 5.3 -6.4 [21.0, 36.0, 35.0] 27058
4 45.4 0.3 4.4 -7.3 [33.0, 34.0] 23802
5 40.2 0.4 10.1 -5.3 [17.0, 14.0, 15.0] 26868
6 36.4 0.4 10.8 -6.4 [28.0, 26.0, 30.0, 31.0, 29.0] 28326
7 45.1 0.3 4.3 -4.9 [29.0, 33.0] 25518
8 27.4 0.1 6.0 -5.9 [31.0, 24.0, 25.0] 29149
9 44.1 0.5 5.8 -5.1 [36.0, 30.0] 21419
10 43.5 0.3 5.2 -4.5 [37.0, 36.0] 25758
11 48.6 0.2 5.8 -7.4 [30.0, 31.0, 29.0, 33.0] 27166
12 41.5 0.5 6.9 -3.7 [32.0, 33.0, 37.0, 36.0] 28012
14 44.2 0.0 4.7 -12.8 [17.0, 18.0] 25702
15 29.1 0.3 7.8 -9.1 [28.0, 26.0, 14.0, 12.0] 27756
17 45.7 -0.0 5.2 -6.2 [34.0] 24093
18 44.2 0.4 4.9 -5.7 [35.0, 37.0] 24951
23 43.5 0.0 5.7 -5.1 [14.0] 25545
24 25.5 0.1 5.0 -5.9 [26.0, 24.0, 25.0, 27.0, 28.0] 30042
25 31.3 0.4 12.5 -7.0 [23.0, 34.0, 35.0, 20.0, 22.0] 32368
26 28.0 0.1 6.1 -5.6 [19.0, 14.0] 28468
27 26.2 -0.0 5.1 -5.9 [34.0, 35.0, 30.0, 32.0] 29881
28 36.9 0.7 13.3 -5.8 [35.0, 37.0, 20.0, 28.0, 27.0] 25335
29 43.2 0.7 9.2 -3.1 [16.0, 13.0, 14.0] 26540
30 45.9 0.1 4.3 -4.6 [23.0] 23627
31 45.3 0.2 3.6 -4.6 [35.0, 37.0] 22312
32 45.3 -0.2 7.4 -6.2 [36.0, 30.0] 24641
REF GPS L5/E5A(I+Q)

SV AvgEl AvgOffset AvgCNo MaxCNo MinCNo Slip_Count SVChan Ant N_Samples
3 32.7 0.0 47.0 51.7 39.0 150 [21.0, 36.0] [0.0] 27079
4 45.4 0.0 48.3 52.7 40.2 0 [33.0] [0.0] 23840
6 36.4 0.0 47.3 52.1 38.5 367 [28.0, 30.0, 31.0] [0.0] 28333
8 27.3 0.0 46.6 50.5 38.1 136 [31.0, 24.0] [0.0] 29174
9 44.1 0.0 48.6 52.1 40.5 0 [36.0] [0.0] 21419
10 43.5 0.0 48.0 51.6 40.2 0 [37.0] [0.0] 25764
11 48.6 0.0 48.7 54.4 34.9 203 [30.0, 29.0] [0.0] 27184
14 44.2 0.0 48.5 52.8 40.8 0 [17.0] [0.0] 25702
18 44.2 0.0 48.8 53.0 40.5 0 [35.0] [0.0] 24957
23 43.5 0.0 48.3 52.9 38.1 0 [14.0] [0.0] 25545
24 25.5 0.0 46.1 50.8 34.2 421 [26.0, 25.0, 28.0] [0.0] 30051
25 31.3 0.0 46.9 52.0 36.3 339 [23.0, 34.0, 20.0] [0.0] 32410
26 28.0 0.0 46.4 50.8 39.8 251 [19.0, 14.0] [0.0] 28485
27 26.1 0.0 46.3 49.8 40.1 124 [34.0, 30.0] [0.0] 29919
28 36.9 0.0 47.8 52.8 40.9 113 [35.0, 20.0, 28.0] [0.0] 25365
30 45.9 0.0 48.9 52.5 41.1 0 [23.0] [0.0] 23647
32 45.3 0.0 46.6 50.7 30.8 0 [36.0] [0.0] 24642
DUT GPS L5/E5A(I+Q)

SV AvgEl AvgOffset AvgCNo MaxCNo MinCNo Slip_Count SVChan Ant N_Samples
3 32.7 0.0 47.0 51.8 39.1 134 [21.0, 35.0] [0.0] 27104
4 45.4 0.0 48.1 52.8 37.5 0 [34.0] [0.0] 23802
6 36.3 0.0 46.9 51.5 38.3 131 [26.0, 28.0, 29.0] [0.0] 28378
8 27.4 0.0 46.4 50.5 37.2 2 [31.0, 25.0] [0.0] 29157
9 44.0 0.0 48.4 51.9 38.0 0 [30.0] [0.0] 21428
10 43.5 0.0 48.1 51.4 40.9 0 [36.0] [0.0] 25782
11 48.6 0.0 48.8 53.2 22.8 250 [31.0, 33.0] [0.0] 27167
14 44.1 0.0 48.4 52.8 38.9 0 [18.0] [0.0] 25734
18 44.1 0.0 48.7 53.0 38.4 0 [37.0] [0.0] 24960
23 43.5 0.0 48.6 53.0 39.0 0 [14.0] [0.0] 25565
24 25.5 0.0 45.9 50.8 38.0 179 [24.0, 27.0] [0.0] 30080
25 31.3 0.0 46.6 51.2 31.5 425 [23.0, 35.0, 22.0] [0.0] 32368
26 28.0 0.0 46.5 50.7 39.5 57 [19.0, 14.0] [0.0] 28495
27 26.1 0.0 46.3 49.9 39.9 95 [35.0, 32.0] [0.0] 29887
28 36.9 0.0 47.5 53.3 36.8 432 [37.0, 20.0, 27.0] [0.0] 25357
30 45.9 0.0 48.7 51.9 40.8 0 [23.0] [0.0] 23628
32 45.3 0.0 47.0 50.9 32.3 0 [30.0] [0.0] 24648
DIFF GPS L5/E5A(I+Q)

SV AvgEl AvgCNoDiff MaxCNoDiff MinCNoDiff SVChan N_Samples
3 32.7 0.0 5.1 -3.8 [21.0, 36.0, 35.0] 27058
4 45.4 0.3 4.3 -2.3 [33.0, 34.0] 23802
6 36.4 0.4 6.0 -5.0 [28.0, 26.0, 30.0, 31.0, 29.0] 28326
8 27.4 0.2 4.3 -3.3 [31.0, 24.0, 25.0] 29149
9 44.1 0.2 4.4 -2.2 [36.0, 30.0] 21419
10 43.5 -0.1 2.7 -3.0 [37.0, 36.0] 25758
11 48.6 -0.1 19.6 -5.9 [30.0, 31.0, 29.0, 33.0] 27166
14 44.2 0.0 2.8 -3.8 [17.0, 18.0] 25702
18 44.2 0.1 3.5 -2.9 [35.0, 37.0] 24951
23 43.5 -0.3 2.8 -3.7 [14.0] 25545
24 25.5 0.2 4.2 -8.9 [26.0, 24.0, 25.0, 27.0, 28.0] 30042
25 31.3 0.3 6.6 -6.1 [23.0, 34.0, 35.0, 20.0, 22.0] 32368
26 28.0 -0.1 3.2 -4.5 [19.0, 14.0] 28468
27 26.2 -0.0 4.7 -4.3 [34.0, 35.0, 30.0, 32.0] 29881
28 36.9 0.3 7.3 -4.2 [35.0, 37.0, 20.0, 28.0, 27.0] 25335
30 45.9 0.2 2.6 -3.1 [23.0] 23627
32 45.3 -0.5 2.0 -4.8 [36.0, 30.0] 24641
REF SBAS L1(CA)

SV AvgEl AvgOffset AvgCNo MaxCNo MinCNo Slip_Count SVChan Ant N_Samples
131 42.0 0.0 46.3 48.5 44.0 0 [57.0] [0.0] 90000
133 38.0 0.0 43.1 45.3 41.0 0 [56.0] [0.0] 90000
135 39.4 0.0 44.9 47.0 42.7 0 [55.0] [0.0] 90000
158 -45.0 0.0 35.7 39.9 21.6 516 [54.0] [0.0] 80329
DUT SBAS L1(CA)

SV AvgEl AvgOffset AvgCNo MaxCNo MinCNo Slip_Count SVChan Ant N_Samples
131 42.0 0.0 44.4 46.5 42.0 0 [55.0] [0.0] 90000
133 38.0 0.0 43.5 45.8 40.5 0 [56.0] [0.0] 90000
135 39.4 0.0 43.9 46.6 40.6 0 [57.0] [0.0] 90000
DIFF SBAS L1(CA)

SV AvgEl AvgCNoDiff MaxCNoDiff MinCNoDiff SVChan N_Samples
131 42.0 1.9 3.7 -0.4 [57.0, 55.0] 90000
133 38.0 -0.5 2.0 -2.9 [56.0] 90000
135 39.4 1.0 4.0 -1.5 [55.0, 57.0] 90000
REF SBAS L5/E5A(I)

SV AvgEl AvgOffset AvgCNo MaxCNo MinCNo Slip_Count SVChan Ant N_Samples
131 42.0 0.0 46.7 48.4 43.5 0 [57.0] [0.0] 90000
133 38.0 0.0 45.9 47.6 42.4 0 [56.0] [0.0] 90000
135 39.4 0.0 45.8 47.7 42.2 0 [55.0] [0.0] 90000
DUT SBAS L5/E5A(I)
DIFF SBAS L5/E5A(I)
REF GLONASS L1(CA)

SV AvgEl AvgOffset AvgCNo MaxCNo MinCNo Slip_Count FDMA Ant N_Samples
1 33.3 0.0 42.2 49.4 20.6 202 [1.0] [0.0] 30081
2 31.2 0.0 46.7 53.2 35.7 254 [-4.0] [0.0] 35664
3 31.8 0.0 44.7 49.8 31.2 108 [5.0] [0.0] 34055
4 34.2 0.0 44.4 49.6 33.4 176 [6.0] [0.0] 29788
5 36.2 0.0 46.2 52.6 33.0 130 [1.0] [0.0] 26895
6 39.5 0.0 37.2 42.5 23.9 847 [-4.0] [0.0] 22791
7 38.8 0.0 46.2 51.3 33.4 0 [5.0] [0.0] 23279
8 42.2 0.0 44.4 50.2 34.5 0 [6.0] [0.0] 21410
9 29.5 0.0 45.9 51.7 35.8 73 [-2.0] [0.0] 33016
10 33.2 0.0 41.7 48.0 30.1 93 [-7.0] [0.0] 26148
11 44.4 0.0 46.9 53.0 32.1 0 [0.0] [0.0] 20244
12 39.6 0.0 47.6 53.1 29.6 0 [-1.0] [0.0] 22953
14 35.8 0.0 47.6 54.1 31.4 149 [-7.0] [0.0] 27301
15 35.6 0.0 45.9 53.2 32.8 176 [0.0] [0.0] 34705
16 34.6 0.0 47.0 52.6 32.6 276 [-1.0] [0.0] 36929
17 41.3 0.0 46.4 52.1 30.4 171 [4.0] [0.0] 32663
18 43.9 0.0 47.9 52.4 25.3 12 [-3.0] [0.0] 34037
19 39.6 0.0 37.0 41.8 19.1 316 [3.0] [0.0] 30220
20 40.0 0.0 33.5 40.2 5.9 4301 [2.0] [0.0] 22315
21 31.6 0.0 44.8 50.9 33.6 33 [4.0] [0.0] 25655
22 28.2 0.0 46.1 52.0 29.9 185 [-3.0] [0.0] 26745
23 29.7 0.0 43.7 49.1 32.9 89 [3.0] [0.0] 26401
24 33.1 0.0 45.8 52.5 35.7 409 [2.0] [0.0] 27967
DUT GLONASS L1(CA)

SV AvgEl AvgOffset AvgCNo MaxCNo MinCNo Slip_Count FDMA Ant N_Samples
1 33.4 0.0 41.5 48.5 18.6 388 [1.0] [0.0] 30067
2 31.2 0.0 46.3 53.4 36.1 175 [-4.0] [0.0] 35664
3 31.8 0.0 43.6 48.7 33.7 175 [5.0] [0.0] 34062
4 34.2 0.0 43.3 49.2 19.9 382 [6.0] [0.0] 29757
5 36.2 0.0 45.4 52.2 31.2 163 [1.0] [0.0] 26899
6 38.9 0.0 36.3 42.2 17.7 1406 [-4.0] [0.0] 23220
7 38.7 0.0 45.4 50.8 35.7 0 [5.0] [0.0] 23322
8 42.2 0.0 43.4 49.2 30.5 0 [6.0] [0.0] 21379
9 29.5 0.0 45.1 51.6 34.5 462 [-2.0] [0.0] 32969
10 33.2 0.0 41.0 48.5 30.9 66 [-7.0] [0.0] 26125
11 44.4 0.0 46.5 52.9 15.3 25 [0.0] [0.0] 20204
12 39.7 0.0 47.3 52.6 32.6 0 [-1.0] [0.0] 22942
14 35.8 0.0 47.0 54.4 33.4 137 [-7.0] [0.0] 27259
15 35.6 0.0 45.9 52.4 24.3 127 [0.0] [0.0] 34708
16 34.6 0.0 46.8 52.9 34.1 366 [-1.0] [0.0] 36934
17 41.3 0.0 45.5 51.0 32.3 210 [4.0] [0.0] 32666
18 43.9 0.0 47.4 51.7 31.7 140 [-3.0] [0.0] 34021
19 38.7 0.0 35.7 40.4 21.5 106 [3.0] [0.0] 31222
20 42.9 0.0 33.4 39.4 10.3 2960 [2.0] [0.0] 20085
21 31.6 0.0 43.8 50.5 33.6 193 [4.0] [0.0] 25671
22 28.2 0.0 45.4 51.6 31.0 242 [-3.0] [0.0] 26731
23 29.8 0.0 42.2 48.1 29.8 201 [3.0] [0.0] 26345
24 33.1 0.0 44.6 51.9 30.7 194 [2.0] [0.0] 27986
DIFF GLONASS L1(CA)

SV AvgEl AvgCNoDiff MaxCNoDiff MinCNoDiff FDMA N_Samples
1 33.4 0.7 17.8 -10.9 [1.0] 30045
2 31.2 0.4 6.6 -7.4 [-4.0] 35664
3 31.8 1.1 7.4 -7.9 [5.0] 34033
4 34.2 1.1 15.4 -5.2 [6.0] 29755
5 36.2 0.8 7.9 -6.8 [1.0] 26894
6 39.5 0.7 9.4 -5.5 [-4.0] 22791
7 38.8 0.7 5.5 -6.1 [5.0] 23279
8 42.2 1.0 10.6 -6.6 [6.0] 21379
9 29.6 0.8 7.8 -6.7 [-2.0] 32956
10 33.2 0.7 9.0 -6.7 [-7.0] 26111
11 44.4 0.4 21.6 -5.5 [0.0] 20204
12 39.7 0.3 8.6 -8.4 [-1.0] 22942
14 35.8 0.6 10.0 -11.6 [-7.0] 27259
15 35.6 0.0 11.2 -8.4 [0.0] 34678
16 34.6 0.2 5.4 -8.5 [-1.0] 36929
17 41.3 0.9 7.4 -10.5 [4.0] 32663
18 43.9 0.5 5.9 -13.0 [-3.0] 34021
19 39.7 1.1 7.2 -9.0 [3.0] 30130
20 43.0 0.5 12.0 -17.2 [2.0] 20068
21 31.6 1.0 7.8 -7.7 [4.0] 25641
22 28.2 0.7 7.1 -7.5 [-3.0] 26731
23 29.8 1.5 9.9 -4.4 [3.0] 26345
24 33.1 1.2 9.2 -5.2 [2.0] 27955
REF GLONASS L1(P)

SV AvgEl AvgOffset AvgCNo MaxCNo MinCNo Slip_Count FDMA Ant N_Samples
1 33.3 0.0 40.7 47.6 26.3 388 [1.0] [0.0] 30081
2 31.2 0.0 45.5 51.5 35.1 348 [-4.0] [0.0] 35664
3 31.8 0.0 43.1 48.2 29.6 309 [5.0] [0.0] 34055
4 34.2 0.0 42.4 47.6 31.7 121 [6.0] [0.0] 29788
5 36.2 0.0 44.8 50.8 34.5 7 [1.0] [0.0] 26895
6 39.5 0.0 35.8 40.9 23.2 786 [-4.0] [0.0] 22791
7 38.8 0.0 44.7 49.6 33.5 0 [5.0] [0.0] 23279
8 42.2 0.0 42.6 47.9 34.6 0 [6.0] [0.0] 21410
9 29.5 0.0 44.4 50.0 35.1 222 [-2.0] [0.0] 33016
10 33.2 0.0 40.4 46.4 29.9 238 [-7.0] [0.0] 26148
11 44.4 0.0 45.3 50.9 34.5 0 [0.0] [0.0] 20244
12 39.6 0.0 46.7 51.7 31.1 1 [-1.0] [0.0] 22953
14 35.8 0.0 46.2 52.3 33.2 262 [-7.0] [0.0] 27301
15 35.6 0.0 44.2 51.0 32.2 121 [0.0] [0.0] 34705
16 34.6 0.0 45.6 50.8 33.9 268 [-1.0] [0.0] 36929
17 41.3 0.0 44.4 49.9 31.0 42 [4.0] [0.0] 32663
18 43.9 0.0 46.3 50.5 28.7 218 [-3.0] [0.0] 34037
19 39.6 0.0 35.0 39.7 23.1 1028 [3.0] [0.0] 30220
20 44.4 0.0 33.2 38.6 20.1 3038 [2.0] [0.0] 19487
21 31.6 0.0 43.1 49.0 33.3 163 [4.0] [0.0] 25655
22 28.2 0.0 45.0 50.5 33.3 177 [-3.0] [0.0] 26745
23 29.7 0.0 41.9 47.2 33.9 41 [3.0] [0.0] 26401
24 33.1 0.0 44.2 50.8 35.5 356 [2.0] [0.0] 27967
DUT GLONASS L1(P)
DIFF GLONASS L1(P)
REF GLONASS L2(CA)

SV AvgEl AvgOffset AvgCNo MaxCNo MinCNo Slip_Count FDMA Ant N_Samples
1 33.3 0.0 39.2 45.3 28.6 408 [1.0] [0.0] 30081
2 31.2 0.0 44.3 49.9 31.7 127 [-4.0] [0.0] 35664
3 31.8 0.0 44.5 49.8 33.7 129 [5.0] [0.0] 34055
4 34.2 0.0 45.0 50.0 33.9 224 [6.0] [0.0] 29788
5 36.2 0.0 44.9 49.9 34.1 55 [1.0] [0.0] 26895
6 51.8 0.0 11.7 13.0 10.6 3 [-4.0] [0.0] 4
7 38.8 0.0 45.9 50.0 35.4 0 [5.0] [0.0] 23279
8 42.2 0.0 46.1 49.6 37.7 0 [6.0] [0.0] 21410
9 29.5 0.0 45.3 50.2 35.1 19 [-2.0] [0.0] 33016
10 66.2 0.0 30.0 40.5 15.6 24 [-7.0] [0.0] 25
11 44.4 0.0 47.0 51.0 37.2 0 [0.0] [0.0] 20244
12 39.6 0.0 46.4 51.3 29.2 0 [-1.0] [0.0] 22953
14 35.8 0.0 45.3 49.9 35.2 206 [-7.0] [0.0] 27301
15 35.6 0.0 44.7 50.0 33.9 224 [0.0] [0.0] 34705
16 34.6 0.0 45.4 50.0 33.7 241 [-1.0] [0.0] 36929
17 41.3 0.0 45.4 50.0 30.5 187 [4.0] [0.0] 32663
18 43.9 0.0 46.4 50.4 32.3 236 [-3.0] [0.0] 34037
19 39.6 0.0 44.3 48.3 33.4 79 [3.0] [0.0] 30220
20 43.4 0.0 38.7 43.5 29.9 215 [2.0] [0.0] 20072
21 31.6 0.0 43.7 49.6 31.0 110 [4.0] [0.0] 25655
22 28.2 0.0 44.7 50.2 32.9 107 [-3.0] [0.0] 26745
23 40.9 0.0 35.2 42.4 18.0 125 [3.0] [0.0] 47
24 33.1 0.0 44.1 49.6 34.6 162 [2.0] [0.0] 27967
DUT GLONASS L2(CA)

SV AvgEl AvgOffset AvgCNo MaxCNo MinCNo Slip_Count FDMA Ant N_Samples
1 33.4 0.0 39.3 44.7 25.6 437 [1.0] [0.0] 30066
2 31.2 0.0 44.5 49.4 31.0 356 [-4.0] [0.0] 35664
3 31.8 0.0 44.9 49.5 35.4 226 [5.0] [0.0] 34061
4 34.2 0.0 44.7 50.0 34.1 361 [6.0] [0.0] 29756
5 36.2 0.0 44.6 49.7 34.9 9 [1.0] [0.0] 26899
6 47.0 0.0 14.3 16.2 12.4 1 [-4.0] [0.0] 2
7 38.7 0.0 45.8 50.0 33.3 0 [5.0] [0.0] 23322
8 42.2 0.0 45.7 49.6 34.7 0 [6.0] [0.0] 21379
9 29.5 0.0 45.2 50.7 34.7 405 [-2.0] [0.0] 32969
10 65.2 0.0 30.0 40.4 13.5 34 [-7.0] [0.0] 36
11 44.4 0.0 46.9 50.7 36.7 0 [0.0] [0.0] 20204
12 39.7 0.0 46.3 50.7 34.6 0 [-1.0] [0.0] 22942
14 35.8 0.0 45.0 50.1 36.7 64 [-7.0] [0.0] 27259
15 35.6 0.0 44.4 49.5 28.7 106 [0.0] [0.0] 34708
16 34.6 0.0 45.3 49.6 34.4 178 [-1.0] [0.0] 36934
17 41.3 0.0 45.6 49.7 32.5 114 [4.0] [0.0] 32666
18 43.9 0.0 46.1 49.9 32.6 54 [-3.0] [0.0] 34021
19 38.7 0.0 43.8 47.7 33.1 48 [3.0] [0.0] 31222
20 45.3 0.0 39.1 43.4 26.0 130 [2.0] [0.0] 18781
21 31.6 0.0 44.3 49.3 33.3 107 [4.0] [0.0] 25671
22 28.2 0.0 44.8 49.6 26.5 238 [-3.0] [0.0] 26731
23 50.1 0.0 33.5 40.3 12.4 144 [3.0] [0.0] 21
24 33.1 0.0 43.9 49.4 27.9 385 [2.0] [0.0] 27986
DIFF GLONASS L2(CA)

SV AvgEl AvgCNoDiff MaxCNoDiff MinCNoDiff FDMA N_Samples
1 33.4 -0.1 8.3 -7.0 [1.0] 30044
2 31.2 -0.1 5.1 -6.7 [-4.0] 35664
3 31.8 -0.4 5.8 -9.1 [5.0] 34033
4 34.2 0.3 6.2 -8.0 [6.0] 29754
5 36.2 0.3 7.7 -5.4 [1.0] 26894
7 38.8 0.0 7.8 -5.2 [5.0] 23279
8 42.2 0.4 6.1 -4.1 [6.0] 21379
9 29.6 0.2 6.5 -7.1 [-2.0] 32956
10 69.0 -0.4 15.6 -21.7 [-7.0] 10
11 44.4 0.1 6.5 -3.9 [0.0] 20204
12 39.7 0.1 4.5 -9.2 [-1.0] 22942
14 35.8 0.3 6.0 -4.8 [-7.0] 27259
15 35.6 0.2 10.2 -8.5 [0.0] 34678
16 34.6 0.1 7.4 -6.1 [-1.0] 36929
17 41.3 -0.2 5.7 -5.8 [4.0] 32663
18 43.9 0.3 6.8 -5.6 [-3.0] 34021
19 39.7 0.5 6.6 -5.5 [3.0] 30130
20 45.3 -0.2 8.4 -6.6 [2.0] 18764
21 31.6 -0.6 5.2 -7.4 [4.0] 25641
22 28.2 -0.1 7.6 -9.0 [-3.0] 26731
24 33.1 0.2 10.0 -6.0 [2.0] 27955
REF GLONASS L2(P)

SV AvgEl AvgOffset AvgCNo MaxCNo MinCNo Slip_Count FDMA Ant N_Samples
1 33.3 0.0 37.2 43.5 25.8 713 [1.0] [0.0] 30081
2 31.2 0.0 42.8 48.2 30.7 20 [-4.0] [0.0] 35664
3 31.8 0.0 43.3 47.9 34.5 304 [5.0] [0.0] 34055
4 34.2 0.0 43.3 48.5 32.1 376 [6.0] [0.0] 29788
5 36.2 0.0 43.3 48.1 32.8 224 [1.0] [0.0] 26895
6 50.5 0.0 14.7 19.5 11.9 3 [-4.0] [0.0] 4
7 38.8 0.0 44.6 48.4 35.4 0 [5.0] [0.0] 23279
8 42.2 0.0 44.4 47.8 36.8 0 [6.0] [0.0] 21410
9 29.5 0.0 43.3 48.2 32.3 90 [-2.0] [0.0] 33016
10 53.8 0.0 26.1 39.4 14.1 10 [-7.0] [0.0] 10
11 44.4 0.0 45.2 49.1 35.6 0 [0.0] [0.0] 20244
12 39.6 0.0 44.7 49.4 29.7 2 [-1.0] [0.0] 22953
14 35.8 0.0 43.8 48.2 35.3 298 [-7.0] [0.0] 27301
15 35.6 0.0 43.1 48.2 32.7 376 [0.0] [0.0] 34705
16 34.6 0.0 43.5 47.7 33.5 329 [-1.0] [0.0] 36929
17 41.3 0.0 44.1 48.1 31.7 232 [4.0] [0.0] 32663
18 43.9 0.0 44.7 48.3 33.8 198 [-3.0] [0.0] 34037
19 39.6 0.0 42.9 46.8 32.9 50 [3.0] [0.0] 30220
20 43.4 0.0 37.4 42.3 27.5 287 [2.0] [0.0] 20072
21 31.6 0.0 42.6 48.4 33.2 127 [4.0] [0.0] 25655
22 28.2 0.0 43.1 48.4 31.8 192 [-3.0] [0.0] 26745
23 31.0 0.0 23.5 41.3 15.5 136 [3.0] [0.0] 29
24 33.1 0.0 42.3 47.4 34.1 331 [2.0] [0.0] 27967
DUT GLONASS L2(P)
DIFF GLONASS L2(P)
REF GLONASS G3(PD)

SV AvgEl AvgOffset AvgCNo MaxCNo MinCNo Slip_Count FDMA Ant N_Samples
9 29.5 0.0 44.1 49.0 36.9 74 [-2.0] [0.0] 33016
21 31.6 0.0 43.0 49.4 22.5 119 [4.0] [0.0] 25654
DUT GLONASS G3(PD)
DIFF GLONASS G3(PD)
REF Galileo L1(MBOC-PD)

SV AvgEl AvgOffset AvgCNo MaxCNo MinCNo Slip_Count SVChan Ant N_Samples
2 38.9 0.0 46.5 50.2 38.7 0 [43.0] [0.0] 12984
3 17.9 0.0 43.0 47.4 32.6 251 [52.0, 40.0] [0.0] 25778
4 43.9 0.0 46.4 51.7 19.7 91 [53.0, 50.0] [0.0] 31131
5 23.7 0.0 43.9 50.6 32.3 136 [49.0, 42.0] [0.0] 23167
7 42.0 0.0 45.6 50.3 34.0 0 [51.0] [0.0] 26322
8 32.0 0.0 45.5 50.1 36.5 0 [38.0] [0.0] 20594
9 39.2 0.0 46.1 51.0 35.7 67 [44.0, 42.0] [0.0] 24401
10 35.0 0.0 46.0 52.3 35.8 25 [43.0, 38.0] [0.0] 39633
11 39.2 0.0 42.7 48.2 30.2 34 [39.0, 52.0] [0.0] 32876
12 33.2 0.0 42.5 48.3 28.8 214 [44.0, 49.0] [0.0] 41243
13 48.8 0.0 46.6 50.1 36.7 0 [45.0] [0.0] 27980
15 43.5 0.0 46.4 51.7 34.3 0 [46.0] [0.0] 18049
19 46.2 0.0 43.3 48.6 29.7 4 [46.0] [0.0] 31952
21 33.7 0.0 45.9 51.6 33.1 139 [50.0, 40.0] [0.0] 38709
24 45.4 0.0 47.7 53.7 32.7 1 [48.0] [0.0] 32593
25 50.0 0.0 48.2 52.6 39.0 0 [53.0] [0.0] 24302
26 37.9 0.0 45.8 51.7 33.1 34 [39.0, 52.0] [0.0] 39173
27 31.6 0.0 45.0 53.4 29.9 225 [47.0, 42.0] [0.0] 27778
30 17.0 0.0 41.7 49.3 35.1 276 [43.0, 48.0, 49.0] [0.0] 15700
31 42.6 0.0 46.8 54.0 33.4 245 [48.0, 47.0] [0.0] 34549
33 34.3 0.0 44.7 49.9 27.4 145 [47.0, 41.0] [0.0] 41057
34 20.1 0.0 43.1 49.0 35.3 231 [41.0, 46.0] [0.0] 11377
36 39.9 0.0 45.7 52.7 34.9 170 [48.0, 45.0] [0.0] 16118
DUT Galileo L1(MBOC-PD)

SV AvgEl AvgOffset AvgCNo MaxCNo MinCNo Slip_Count SVChan Ant N_Samples
2 38.8 0.0 46.1 50.5 38.4 0 [43.0] [0.0] 12992
3 17.8 0.0 42.7 47.0 33.2 247 [52.0, 40.0] [0.0] 25803
4 43.9 0.0 46.1 51.3 24.8 202 [53.0, 50.0] [0.0] 31138
5 23.7 0.0 44.2 50.1 33.2 88 [48.0, 42.0] [0.0] 23184
7 42.1 0.0 45.6 50.0 34.3 0 [50.0] [0.0] 26300
8 32.0 0.0 45.5 50.2 38.0 0 [38.0] [0.0] 20636
9 39.1 0.0 46.4 50.8 36.5 126 [44.0, 42.0] [0.0] 24424
10 35.0 0.0 46.2 52.2 32.6 210 [43.0, 38.0] [0.0] 39646
11 39.2 0.0 42.3 48.2 28.2 175 [39.0, 51.0] [0.0] 32861
12 33.2 0.0 42.2 48.0 30.2 125 [45.0, 49.0] [0.0] 41309
13 48.8 0.0 46.5 50.0 37.0 0 [44.0] [0.0] 27990
15 43.5 0.0 46.0 51.5 33.4 0 [45.0] [0.0] 18049
19 45.3 0.0 42.9 48.1 28.9 6 [46.0] [0.0] 32733
21 33.7 0.0 46.1 51.5 34.6 145 [51.0, 40.0] [0.0] 38709
24 45.4 0.0 47.7 53.3 36.3 0 [48.0] [0.0] 32630
25 50.0 0.0 47.5 51.8 35.5 0 [53.0] [0.0] 24302
26 37.9 0.0 45.3 51.7 31.1 75 [39.0, 46.0] [0.0] 39149
27 31.6 0.0 45.2 52.9 32.3 222 [49.0, 42.0] [0.0] 27754
30 17.0 0.0 42.4 50.8 32.4 363 [43.0, 48.0, 49.0] [0.0] 15648
31 42.6 0.0 46.8 53.3 34.9 236 [48.0, 47.0] [0.0] 34560
33 34.3 0.0 44.7 49.9 33.7 203 [47.0, 41.0] [0.0] 41025
34 20.1 0.0 43.3 48.3 36.4 62 [41.0, 47.0] [0.0] 11387
36 39.8 0.0 46.3 52.3 34.2 6 [48.0, 45.0] [0.0] 16126
DIFF Galileo L1(MBOC-PD)

SV AvgEl AvgCNoDiff MaxCNoDiff MinCNoDiff SVChan N_Samples
2 38.9 0.4 5.0 -3.3 [43.0] 12984
3 17.9 0.3 5.4 -7.8 [52.0, 40.0] 25774
4 43.9 0.3 8.5 -6.7 [53.0, 50.0] 31118
5 23.7 -0.3 5.6 -6.6 [49.0, 48.0, 42.0] 23162
7 42.1 0.0 3.9 -4.3 [51.0, 50.0] 26292
8 32.0 -0.0 3.0 -4.8 [38.0] 20594
9 39.2 -0.4 4.0 -9.0 [44.0, 42.0] 24401
10 35.0 -0.3 6.5 -6.2 [43.0, 38.0] 39624
11 39.2 0.4 5.9 -5.3 [39.0, 52.0, 51.0] 32854
12 33.2 0.3 5.8 -6.4 [44.0, 45.0, 49.0] 41243
13 48.8 0.0 3.0 -4.1 [45.0, 44.0] 27980
15 43.5 0.5 6.1 -3.4 [46.0, 45.0] 18049
19 46.2 0.2 5.8 -5.4 [46.0] 31952
21 33.7 -0.2 5.0 -7.1 [50.0, 51.0, 40.0] 38707
24 45.4 0.0 4.6 -6.6 [48.0] 32593
25 50.0 0.7 5.9 -2.8 [53.0] 24302
26 37.9 0.5 5.8 -5.0 [39.0, 52.0, 46.0] 39145
27 31.6 -0.2 4.0 -10.0 [47.0, 49.0, 42.0] 27754
30 17.0 -0.7 6.7 -7.2 [43.0, 48.0, 49.0] 15648
31 42.6 0.0 4.3 -6.7 [48.0, 47.0] 34542
33 34.3 0.0 6.0 -8.9 [47.0, 41.0] 41021
34 20.1 -0.2 3.1 -5.4 [41.0, 46.0, 47.0] 11377
36 39.9 -0.6 4.9 -6.7 [48.0, 45.0] 16118
REF Galileo L5/E5A(BPSK(10)-PD)

SV AvgEl AvgOffset AvgCNo MaxCNo MinCNo Slip_Count SVChan Ant N_Samples
2 38.9 0.0 46.5 49.6 41.1 0 [43.0] [0.0] 12984
3 17.9 0.0 43.2 47.1 34.4 240 [52.0, 40.0] [0.0] 25778
4 43.9 0.0 46.2 50.3 34.8 83 [53.0, 50.0] [0.0] 31131
5 23.7 0.0 44.5 49.5 35.6 27 [49.0, 42.0] [0.0] 23167
7 42.0 0.0 45.8 49.7 37.8 0 [51.0] [0.0] 26322
8 32.0 0.0 45.1 48.6 39.4 0 [38.0] [0.0] 20594
9 39.2 0.0 46.0 50.8 36.1 32 [44.0, 42.0] [0.0] 24401
10 35.0 0.0 45.8 49.9 36.4 6 [43.0, 38.0] [0.0] 39633
11 39.2 0.0 42.3 46.6 33.8 85 [39.0, 52.0] [0.0] 32876
12 33.2 0.0 43.2 47.7 32.4 15 [44.0, 49.0] [0.0] 41243
13 48.8 0.0 46.5 49.8 38.6 0 [45.0] [0.0] 27980
15 43.5 0.0 45.5 49.9 34.7 0 [46.0] [0.0] 18049
19 46.2 0.0 42.6 46.5 31.9 0 [46.0] [0.0] 31952
21 33.7 0.0 45.5 50.1 36.3 169 [50.0, 40.0] [0.0] 38709
24 45.4 0.0 46.4 50.3 36.1 0 [48.0] [0.0] 32593
25 50.0 0.0 46.9 50.4 39.8 0 [53.0] [0.0] 24302
26 37.9 0.0 45.0 49.5 35.9 85 [39.0, 52.0] [0.0] 39173
27 31.6 0.0 44.5 50.4 35.2 160 [47.0, 42.0] [0.0] 27778
30 17.0 0.0 43.0 48.5 36.9 390 [43.0, 48.0, 49.0] [0.0] 15700
31 42.6 0.0 45.5 49.8 34.9 252 [48.0, 47.0] [0.0] 34549
33 34.3 0.0 45.0 50.1 34.9 93 [47.0, 41.0] [0.0] 41057
34 20.1 0.0 43.3 48.2 37.5 79 [41.0, 46.0] [0.0] 11377
36 39.9 0.0 45.1 49.8 34.4 115 [48.0, 45.0] [0.0] 16118
DUT Galileo L5/E5A(BPSK(10)-PD)
DIFF Galileo L5/E5A(BPSK(10)-PD)
REF Galileo E5B/B2(BPSK(10)-PD)

SV AvgEl AvgOffset AvgCNo MaxCNo MinCNo Slip_Count SVChan Ant N_Samples
2 38.9 0.0 46.5 50.3 38.9 0 [43.0] [0.0] 12984
3 17.9 0.0 43.4 47.2 33.1 234 [52.0, 40.0] [0.0] 25778
4 43.9 0.0 46.6 50.6 33.6 37 [53.0, 50.0] [0.0] 31131
5 23.7 0.0 44.8 49.5 34.3 79 [49.0, 42.0] [0.0] 23167
7 42.0 0.0 46.5 50.2 39.3 0 [51.0] [0.0] 26322
8 32.0 0.0 45.5 48.9 39.7 0 [38.0] [0.0] 20594
9 39.2 0.0 46.6 50.7 36.1 166 [44.0, 42.0] [0.0] 24401
10 35.0 0.0 46.2 50.6 38.6 134 [43.0, 38.0] [0.0] 39633
11 39.2 0.0 42.5 47.0 32.6 180 [39.0, 52.0] [0.0] 32876
12 33.2 0.0 43.7 48.2 29.8 100 [44.0, 49.0] [0.0] 41243
13 48.8 0.0 47.3 50.8 38.4 0 [45.0] [0.0] 27980
15 43.5 0.0 46.0 51.2 35.2 0 [46.0] [0.0] 18049
19 46.2 0.0 43.3 47.4 32.9 0 [46.0] [0.0] 31952
21 33.7 0.0 46.0 50.1 37.4 251 [50.0, 40.0] [0.0] 38709
24 45.4 0.0 47.1 50.9 37.4 0 [48.0] [0.0] 32593
25 50.0 0.0 47.4 50.7 40.4 0 [53.0] [0.0] 24302
26 37.9 0.0 45.7 50.6 38.1 180 [39.0, 52.0] [0.0] 39173
27 31.6 0.0 45.0 50.3 35.6 217 [47.0, 42.0] [0.0] 27778
30 17.0 0.0 43.6 48.8 38.3 283 [43.0, 48.0, 49.0] [0.0] 15700
31 42.6 0.0 45.9 50.6 36.0 250 [48.0, 47.0] [0.0] 34549
33 34.3 0.0 45.5 50.5 35.8 253 [47.0, 41.0] [0.0] 41057
34 20.1 0.0 43.9 48.3 35.7 95 [41.0, 46.0] [0.0] 11377
36 39.9 0.0 45.9 50.8 35.7 113 [48.0, 45.0] [0.0] 16118
DUT Galileo E5B/B2(BPSK(10)-PD)
DIFF Galileo E5B/B2(BPSK(10)-PD)
REF Galileo E5A+B(AltBOC-Comp-PD)

SV AvgEl AvgOffset AvgCNo MaxCNo MinCNo Slip_Count SVChan Ant N_Samples
2 38.9 0.0 48.8 51.9 44.0 0 [43.0] [0.0] 12984
3 17.9 0.0 46.1 49.3 38.1 129 [52.0, 40.0] [0.0] 25778
4 43.9 0.0 48.8 52.7 36.7 67 [53.0, 50.0] [0.0] 31131
5 23.7 0.0 47.2 51.4 39.6 37 [49.0, 42.0] [0.0] 23167
7 42.0 0.0 48.5 52.0 42.3 0 [51.0] [0.0] 26322
8 32.0 0.0 47.7 51.2 43.1 0 [38.0] [0.0] 20594
9 39.2 0.0 48.7 52.6 40.2 20 [44.0, 42.0] [0.0] 24401
10 35.0 0.0 48.4 52.5 41.2 20 [43.0, 38.0] [0.0] 39633
11 39.2 0.0 44.9 48.4 37.2 192 [39.0, 52.0] [0.0] 32876
12 33.2 0.0 46.2 50.0 35.9 247 [44.0, 49.0] [0.0] 41243
13 48.8 0.0 49.2 52.2 42.2 0 [45.0] [0.0] 27980
15 43.5 0.0 48.2 52.4 39.0 0 [46.0] [0.0] 18049
19 46.2 0.0 45.8 49.5 37.5 0 [46.0] [0.0] 31952
21 33.7 0.0 48.1 51.7 41.2 240 [50.0, 40.0] [0.0] 38709
24 45.4 0.0 49.1 52.3 42.0 0 [48.0] [0.0] 32593
25 50.0 0.0 49.5 52.8 43.8 0 [53.0] [0.0] 24302
26 37.9 0.0 47.8 52.0 41.4 192 [39.0, 52.0] [0.0] 39173
27 31.6 0.0 47.3 51.9 40.0 158 [47.0, 42.0] [0.0] 27778
30 17.0 0.0 46.1 50.8 41.2 221 [43.0, 48.0, 49.0] [0.0] 15700
31 42.6 0.0 48.2 52.6 40.2 51 [48.0, 47.0] [0.0] 34549
33 34.3 0.0 47.8 52.4 40.0 238 [47.0, 41.0] [0.0] 41057
34 20.1 0.0 46.4 50.6 41.7 165 [41.0, 46.0] [0.0] 11377
36 39.9 0.0 48.0 52.3 40.2 253 [48.0, 45.0] [0.0] 16118
DUT Galileo E5A+B(AltBOC-Comp-PD)

SV AvgEl AvgOffset AvgCNo MaxCNo MinCNo Slip_Count SVChan Ant N_Samples
2 38.8 0.0 47.7 51.1 40.5 0 [43.0] [0.0] 12992
3 17.8 0.0 46.0 48.9 39.6 239 [52.0, 40.0] [0.0] 25803
4 43.9 0.0 48.5 52.2 35.6 92 [53.0, 50.0] [0.0] 31138
5 23.7 0.0 46.8 50.0 42.9 24 [48.0, 42.0] [0.0] 23184
7 42.1 0.0 48.6 52.1 42.0 0 [50.0] [0.0] 26300
8 32.0 0.0 47.7 51.3 42.8 0 [38.0] [0.0] 20636
9 39.1 0.0 48.5 51.9 40.2 39 [44.0, 42.0] [0.0] 24424
10 35.0 0.0 48.0 51.8 36.6 234 [43.0, 38.0] [0.0] 39646
11 39.2 0.0 44.7 47.9 37.9 127 [39.0, 51.0] [0.0] 32861
12 33.2 0.0 46.0 49.4 39.8 98 [45.0, 49.0] [0.0] 41309
13 48.8 0.0 49.1 52.0 41.9 0 [44.0] [0.0] 27990
15 43.5 0.0 48.5 52.3 40.0 0 [45.0] [0.0] 18049
19 45.3 0.0 45.7 49.2 36.6 1 [46.0] [0.0] 32733
21 33.7 0.0 48.1 51.9 42.3 153 [51.0, 40.0] [0.0] 38709
24 45.4 0.0 48.5 51.7 41.7 0 [48.0] [0.0] 32630
25 50.0 0.0 48.5 52.0 40.4 0 [53.0] [0.0] 24302
26 37.9 0.0 47.6 52.1 40.5 236 [39.0, 46.0] [0.0] 39149
27 31.6 0.0 47.5 52.1 40.7 230 [49.0, 42.0] [0.0] 27754
30 17.0 0.0 45.7 50.4 40.8 217 [43.0, 48.0, 49.0] [0.0] 15648
31 42.6 0.0 48.2 52.0 41.2 251 [48.0, 47.0] [0.0] 34560
33 34.3 0.0 47.7 52.2 40.9 213 [47.0, 41.0] [0.0] 41025
34 20.1 0.0 46.5 50.5 42.2 52 [41.0, 47.0] [0.0] 11387
36 39.8 0.0 47.7 50.7 42.0 206 [48.0, 45.0] [0.0] 16126
DIFF Galileo E5A+B(AltBOC-Comp-PD)

SV AvgEl AvgCNoDiff MaxCNoDiff MinCNoDiff SVChan N_Samples
2 38.9 1.1 4.8 -1.6 [43.0] 12984
3 17.9 0.2 4.4 -2.8 [52.0, 40.0] 25774
4 43.9 0.4 5.7 -4.1 [53.0, 50.0] 31118
5 23.7 0.5 2.7 -4.7 [49.0, 48.0, 42.0] 23162
7 42.1 -0.1 2.3 -3.5 [51.0, 50.0] 26292
8 32.0 -0.0 3.5 -1.9 [38.0] 20594
9 39.2 0.2 3.5 -3.8 [44.0, 42.0] 24401
10 35.0 0.4 6.7 -2.8 [43.0, 38.0] 39624
11 39.2 0.2 4.0 -3.6 [39.0, 52.0, 51.0] 32854
12 33.2 0.3 5.1 -5.8 [44.0, 45.0, 49.0] 41243
13 48.8 0.1 2.3 -2.0 [45.0, 44.0] 27980
15 43.5 -0.2 1.7 -2.7 [46.0, 45.0] 18049
19 46.2 -0.0 3.2 -2.8 [46.0] 31952
21 33.7 0.0 2.5 -3.2 [50.0, 51.0, 40.0] 38707
24 45.4 0.6 2.8 -3.2 [48.0] 32593
25 50.0 0.9 4.5 -1.6 [53.0] 24302
26 37.9 0.2 4.4 -3.4 [39.0, 52.0, 46.0] 39145
27 31.6 -0.2 2.6 -3.4 [47.0, 49.0, 42.0] 27754
30 17.0 0.4 3.4 -2.5 [43.0, 48.0, 49.0] 15648
31 42.6 0.0 4.3 -4.7 [48.0, 47.0] 34542
33 34.3 0.1 3.7 -4.0 [47.0, 41.0] 41021
34 20.1 -0.1 2.7 -4.2 [41.0, 46.0, 47.0] 11377
36 39.9 0.3 4.7 -3.7 [48.0, 45.0] 16118
REF Galileo E6(BPSK(5)-PD)

SV AvgEl AvgOffset AvgCNo MaxCNo MinCNo Slip_Count SVChan Ant N_Samples
2 38.9 0.0 47.6 51.6 37.7 0 [43.0] [0.0] 12984
3 17.9 0.0 43.9 47.8 26.9 6 [52.0, 40.0] [0.0] 25778
4 43.9 0.0 48.3 52.9 30.8 191 [53.0, 50.0] [0.0] 31127
5 23.7 0.0 45.9 51.7 31.9 195 [49.0, 42.0] [0.0] 23167
7 42.0 0.0 48.3 52.5 36.3 0 [51.0] [0.0] 26322
8 32.0 0.0 47.0 50.8 39.2 0 [38.0] [0.0] 20594
9 39.2 0.0 48.0 52.4 31.8 23 [44.0, 42.0] [0.0] 24401
10 35.0 0.0 47.7 52.8 36.6 220 [43.0, 38.0] [0.0] 39633
11 39.2 0.0 44.3 49.7 32.0 256 [39.0, 52.0] [0.0] 32875
12 33.2 0.0 44.8 50.0 27.9 105 [44.0, 49.0] [0.0] 41243
13 48.8 0.0 48.9 52.6 37.5 0 [45.0] [0.0] 27980
15 43.5 0.0 48.0 52.6 34.0 0 [46.0] [0.0] 18049
19 46.2 0.0 44.2 48.8 28.7 4 [46.0] [0.0] 31952
21 33.7 0.0 47.5 51.8 35.3 167 [50.0, 40.0] [0.0] 38709
24 45.4 0.0 49.1 53.0 36.9 1 [48.0] [0.0] 32593
25 50.0 0.0 49.4 53.1 40.3 0 [53.0] [0.0] 24302
26 37.9 0.0 47.2 52.7 35.4 1 [39.0, 52.0] [0.0] 39173
27 31.6 0.0 46.5 52.7 35.8 41 [47.0, 42.0] [0.0] 27778
30 17.0 0.0 44.6 49.8 34.8 195 [43.0, 48.0, 49.0] [0.0] 15700
31 42.6 0.0 47.3 52.0 29.3 169 [48.0, 47.0] [0.0] 34549
33 34.3 0.0 47.0 52.8 33.7 90 [47.0, 41.0] [0.0] 41057
34 20.1 0.0 45.1 49.6 36.7 200 [41.0, 46.0] [0.0] 11377
36 39.9 0.0 46.9 52.2 28.3 125 [48.0, 45.0] [0.0] 16118
DUT Galileo E6(BPSK(5)-PD)
DIFF Galileo E6(BPSK(5)-PD)
REF BeiDou L1(BOC-PD)

SV AvgEl AvgOffset AvgCNo MaxCNo MinCNo Slip_Count SVChan Ant N_Samples
19 44.4 0.0 46.7 52.4 31.1 0 [49.0] [0.0] 28281
20 45.5 0.0 46.8 52.4 33.8 0 [21.0] [0.0] 25462
21 41.2 0.0 46.7 53.0 34.6 177 [32.0, 19.0] [0.0] 28650
22 44.3 0.0 47.3 53.2 30.9 0 [52.0] [0.0] 28326
23 41.8 0.0 46.9 52.3 28.3 1 [39.0] [0.0] 23096
24 44.9 0.0 47.9 53.4 32.5 0 [45.0] [0.0] 28685
25 45.8 0.0 47.3 52.0 35.0 0 [16.0] [0.0] 26733
26 45.4 0.0 46.5 51.8 33.0 0 [51.0] [0.0] 27610
27 37.7 0.0 46.0 52.5 33.1 11 [53.0, 30.0] [0.0] 22546
28 38.7 0.0 46.0 52.1 26.0 34 [44.0] [0.0] 22195
29 36.8 0.0 44.5 50.9 23.3 45 [42.0, 52.0] [0.0] 30833
30 51.0 0.0 47.5 51.9 33.2 0 [20.0] [0.0] 22583
32 39.0 0.0 46.1 51.6 35.7 0 [26.0] [0.0] 21255
33 25.4 0.0 44.3 50.5 28.6 381 [21.0, 27.0, 15.0] [0.0] 29655
34 34.5 0.0 45.2 51.8 31.3 66 [45.0, 46.0] [0.0] 31978
35 29.4 0.0 44.3 50.8 31.0 169 [53.0, 35.0] [0.0] 34602
36 30.9 0.0 44.7 50.7 33.0 197 [51.0, 17.0] [0.0] 30262
37 26.4 0.0 43.7 50.4 31.6 282 [49.0, 48.0, 51.0] [0.0] 25306
38 7.0 0.0 40.3 42.9 37.0 0 [15.0] [0.0] 2199
41 23.7 0.0 44.2 49.0 36.2 372 [18.0, 43.0, 48.0] [0.0] 27847
42 33.6 0.0 45.2 51.8 25.7 101 [50.0, 47.0] [0.0] 30530
43 49.7 0.0 47.3 52.3 29.2 1 [26.0] [0.0] 23861
44 29.1 0.0 44.4 49.9 33.1 84 [50.0, 18.0] [0.0] 34709
45 35.4 0.0 45.4 51.9 30.4 254 [48.0, 41.0] [0.0] 31478
DUT BeiDou L1(BOC-PD)
DIFF BeiDou L1(BOC-PD)
REF BeiDou L5/E5A(I+Q)

SV AvgEl AvgOffset AvgCNo MaxCNo MinCNo Slip_Count SVChan Ant N_Samples
19 44.4 0.0 46.5 50.6 36.0 0 [49.0] [0.0] 28281
20 45.5 0.0 46.6 50.8 37.3 0 [21.0] [0.0] 25462
21 41.2 0.0 47.0 51.4 38.9 197 [32.0, 19.0] [0.0] 28650
22 44.3 0.0 47.1 50.9 36.6 0 [52.0] [0.0] 28326
23 41.8 0.0 47.4 50.9 37.3 0 [39.0] [0.0] 23096
24 44.9 0.0 47.7 51.4 38.1 0 [45.0] [0.0] 28685
25 45.8 0.0 46.5 50.0 37.1 0 [16.0] [0.0] 26733
26 45.4 0.0 45.6 50.0 34.3 0 [51.0] [0.0] 27610
27 37.7 0.0 45.3 49.5 37.5 174 [53.0, 30.0] [0.0] 22546
28 38.7 0.0 44.6 49.1 32.8 6 [44.0] [0.0] 22195
29 36.8 0.0 45.3 49.5 37.2 237 [42.0, 52.0] [0.0] 30833
30 51.0 0.0 46.6 49.8 37.2 0 [20.0] [0.0] 22583
32 39.0 0.0 46.7 50.7 39.9 0 [26.0] [0.0] 21255
33 25.4 0.0 45.2 50.7 36.1 99 [21.0, 27.0, 15.0] [0.0] 29655
34 34.5 0.0 45.2 49.5 34.7 44 [45.0, 46.0] [0.0] 31978
35 29.4 0.0 44.0 49.0 33.3 105 [53.0, 35.0] [0.0] 34602
36 30.9 0.0 46.4 49.8 38.1 179 [51.0, 17.0] [0.0] 30262
37 26.4 0.0 45.5 51.3 38.1 173 [49.0, 48.0, 51.0] [0.0] 25306
38 7.0 0.0 39.4 41.4 36.7 0 [15.0] [0.0] 2199
41 23.7 0.0 45.1 48.4 37.9 46 [18.0, 43.0, 48.0] [0.0] 27847
42 33.6 0.0 46.0 51.1 35.2 52 [50.0, 47.0] [0.0] 30530
43 49.7 0.0 46.5 50.6 33.9 0 [26.0] [0.0] 23862
44 29.1 0.0 45.0 49.4 37.7 23 [50.0, 18.0] [0.0] 34709
45 35.4 0.0 46.3 51.0 36.9 88 [48.0, 41.0] [0.0] 31478
DUT BeiDou L5/E5A(I+Q)

SV AvgEl AvgOffset AvgCNo MaxCNo MinCNo Slip_Count SVChan Ant N_Samples
19 44.3 0.0 47.0 51.1 37.5 0 [49.0] [0.0] 28334
20 45.5 0.0 46.9 50.6 35.9 0 [21.0] [0.0] 25468
21 41.2 0.0 46.6 51.3 37.0 168 [29.0, 47.0] [0.0] 28645
22 44.3 0.0 47.1 50.8 38.5 0 [52.0] [0.0] 28333
23 41.8 0.0 47.0 50.8 30.8 0 [39.0] [0.0] 23094
24 44.8 0.0 47.8 51.7 38.0 0 [45.0] [0.0] 28736
25 45.8 0.0 46.0 49.6 36.8 0 [16.0] [0.0] 26734
26 45.4 0.0 46.0 49.6 35.5 0 [51.0] [0.0] 27621
27 37.7 0.0 45.2 49.8 35.0 186 [53.0, 32.0] [0.0] 22545
28 38.8 0.0 44.6 48.5 30.6 251 [47.0, 44.0] [0.0] 22175
29 36.8 0.0 45.1 49.1 37.4 143 [42.0, 24.0] [0.0] 30864
30 51.0 0.0 46.3 49.4 30.7 0 [20.0] [0.0] 22584
32 38.9 0.0 46.7 51.3 37.6 0 [24.0] [0.0] 21295
33 25.5 0.0 45.3 49.9 38.5 416 [21.0, 26.0, 16.0] [0.0] 29617
34 34.5 0.0 44.8 49.5 33.8 224 [44.0, 14.0] [0.0] 32013
35 29.4 0.0 43.8 48.8 21.2 122 [53.0, 37.0] [0.0] 34536
36 31.0 0.0 46.2 50.2 35.3 240 [50.0, 17.0] [0.0] 30195
37 26.4 0.0 45.2 49.4 38.3 235 [48.0, 46.0] [0.0] 25287
38 7.0 0.0 42.3 44.5 40.0 0 [15.0] [0.0] 2201
41 23.7 0.0 45.1 49.3 36.4 300 [18.0, 43.0, 48.0] [0.0] 27841
42 33.6 0.0 46.0 51.1 36.2 125 [50.0, 52.0] [0.0] 30553
43 49.6 0.0 46.1 49.3 36.7 0 [28.0] [0.0] 23877
44 29.1 0.0 44.8 48.4 37.1 31 [51.0, 17.0] [0.0] 34704
45 35.4 0.0 46.5 51.6 38.4 236 [46.0, 41.0] [0.0] 31480
DIFF BeiDou L5/E5A(I+Q)

SV AvgEl AvgCNoDiff MaxCNoDiff MinCNoDiff SVChan N_Samples
19 44.4 -0.4 2.1 -3.8 [49.0] 28273
20 45.5 -0.4 3.0 -3.2 [21.0] 25461
21 41.3 0.4 4.2 -2.5 [32.0, 29.0, 19.0, 47.0] 28644
22 44.3 -0.1 3.3 -3.8 [52.0] 28326
23 41.8 0.4 6.5 -2.1 [39.0] 23094
24 44.9 -0.1 3.9 -4.8 [45.0] 28685
25 45.8 0.4 3.7 -3.2 [16.0] 26733
26 45.4 -0.4 2.5 -10.1 [51.0] 27609
27 37.7 0.1 4.4 -2.9 [53.0, 30.0, 32.0] 22544
28 38.8 0.0 4.3 -6.0 [44.0, 47.0] 22165
29 36.8 0.1 3.8 -4.0 [42.0, 52.0, 24.0] 30830
30 51.0 0.3 7.1 -2.6 [20.0] 22583
32 39.0 0.0 4.6 -2.8 [26.0, 24.0] 21255
33 25.5 -0.0 4.4 -6.3 [21.0, 27.0, 26.0, 15.0, 16.0] 29612
34 34.5 0.3 4.4 -3.7 [45.0, 44.0, 46.0, 14.0] 31964
35 29.4 0.2 18.1 -5.1 [53.0, 35.0, 37.0] 34536
36 31.0 0.2 6.6 -4.3 [51.0, 50.0, 17.0] 30195
37 26.4 0.3 3.6 -4.1 [49.0, 48.0, 51.0, 46.0] 25256
38 7.0 -2.9 0.4 -5.8 [15.0] 2199
41 23.7 0.0 4.2 -2.9 [18.0, 43.0, 48.0] 27821
42 33.6 0.0 4.9 -5.1 [50.0, 47.0, 52.0] 30523
43 49.7 0.4 3.0 -4.6 [26.0, 28.0] 23862
44 29.1 0.2 4.1 -4.3 [50.0, 51.0, 18.0, 17.0] 34693
45 35.4 -0.2 5.0 -4.6 [48.0, 46.0, 41.0] 31477
REF BeiDou E5B/B2(BPSK(2)-B2)

SV AvgEl AvgOffset AvgCNo MaxCNo MinCNo Slip_Count SVChan Ant N_Samples
11 38.2 0.0 45.0 50.2 30.8 118 [28.0, 50.0] [0.0] 30580
12 30.8 0.0 45.3 49.5 35.7 130 [19.0, 20.0] [0.0] 34088
14 30.1 0.0 45.1 50.2 35.5 387 [48.0, 49.0, 36.0] [0.0] 29155
DUT BeiDou E5B/B2(BPSK(2)-B2)

SV AvgEl AvgOffset AvgCNo MaxCNo MinCNo Slip_Count SVChan Ant N_Samples
11 38.3 0.0 44.8 49.1 34.8 29 [28.0, 50.0] [0.0] 30529
12 30.8 0.0 44.9 48.9 33.9 172 [19.0, 20.0] [0.0] 34100
14 30.2 0.0 45.1 49.4 36.0 336 [46.0, 49.0, 35.0] [0.0] 29086
DIFF BeiDou E5B/B2(BPSK(2)-B2)

SV AvgEl AvgCNoDiff MaxCNoDiff MinCNoDiff SVChan N_Samples
11 38.3 0.2 6.1 -11.9 [28.0, 50.0] 30516
12 30.8 0.4 7.9 -5.7 [19.0, 20.0] 34077
14 30.2 -0.0 6.0 -6.8 [48.0, 46.0, 49.0, 36.0, 35.0] 29075
REF BeiDou B1(BPSK(2)-B1)

SV AvgEl AvgOffset AvgCNo MaxCNo MinCNo Slip_Count SVChan Ant N_Samples
11 38.2 0.0 43.5 51.4 20.1 194 [28.0, 50.0] [0.0] 30590
12 30.8 0.0 42.4 49.1 31.6 90 [19.0, 20.0] [0.0] 34088
14 30.1 0.0 42.7 49.6 26.7 119 [48.0, 49.0, 36.0] [0.0] 29155
19 44.4 0.0 46.5 52.8 29.7 0 [49.0] [0.0] 28281
20 45.5 0.0 47.0 52.8 33.5 0 [21.0] [0.0] 25462
21 41.2 0.0 46.5 53.2 31.6 123 [32.0, 19.0] [0.0] 28650
22 44.3 0.0 47.6 53.9 35.4 0 [52.0] [0.0] 28326
23 41.8 0.0 46.3 52.2 32.2 0 [39.0] [0.0] 23096
24 44.9 0.0 47.4 53.1 34.0 0 [45.0] [0.0] 28685
25 45.8 0.0 47.1 52.7 35.6 0 [16.0] [0.0] 26733
26 45.4 0.0 46.6 52.6 34.4 0 [51.0] [0.0] 27610
27 37.7 0.0 46.6 53.5 35.1 183 [53.0, 30.0] [0.0] 22546
28 38.7 0.0 46.2 52.7 33.0 14 [44.0] [0.0] 22195
29 36.8 0.0 45.0 51.5 17.6 38 [42.0, 52.0] [0.0] 30833
30 51.0 0.0 47.8 52.7 32.7 0 [20.0] [0.0] 22583
32 39.0 0.0 45.7 51.7 33.7 0 [26.0] [0.0] 21255
33 25.4 0.0 43.6 50.1 29.6 242 [21.0, 27.0, 15.0] [0.0] 29655
34 34.5 0.0 45.1 51.8 33.8 183 [45.0, 46.0] [0.0] 31978
35 29.4 0.0 44.7 51.0 32.1 40 [53.0, 35.0] [0.0] 34602
36 30.9 0.0 45.0 51.1 34.5 76 [51.0, 17.0] [0.0] 30262
37 26.4 0.0 43.2 50.0 30.3 250 [49.0, 48.0, 51.0] [0.0] 25306
38 7.0 0.0 40.4 42.3 37.7 0 [15.0] [0.0] 2199
41 23.7 0.0 43.5 49.0 33.1 216 [18.0, 43.0, 48.0] [0.0] 27847
42 33.6 0.0 44.3 51.6 27.1 176 [50.0, 47.0] [0.0] 30530
43 49.7 0.0 46.9 52.8 27.2 0 [26.0] [0.0] 23863
44 29.1 0.0 44.7 51.0 35.1 240 [50.0, 18.0] [0.0] 34709
45 35.4 0.0 45.0 52.1 31.7 130 [48.0, 41.0] [0.0] 31478
DUT BeiDou B1(BPSK(2)-B1)

SV AvgEl AvgOffset AvgCNo MaxCNo MinCNo Slip_Count SVChan Ant N_Samples
11 38.3 0.0 43.7 51.6 31.0 36 [28.0, 50.0] [0.0] 30529
12 30.8 0.0 42.3 48.6 27.6 126 [19.0, 20.0] [0.0] 34105
14 30.2 0.0 43.0 50.3 30.1 256 [46.0, 49.0, 35.0] [0.0] 29086
19 44.3 0.0 46.6 52.8 34.8 0 [49.0] [0.0] 28334
20 45.5 0.0 47.1 53.4 32.7 0 [21.0] [0.0] 25468
21 41.2 0.0 46.3 53.3 31.6 32 [29.0, 47.0] [0.0] 28645
22 44.3 0.0 47.7 54.2 36.0 0 [52.0] [0.0] 28333
23 41.8 0.0 46.5 52.1 20.6 5 [39.0] [0.0] 23094
24 44.8 0.0 47.3 52.5 34.1 0 [45.0] [0.0] 28736
25 45.8 0.0 46.9 52.3 36.5 0 [16.0] [0.0] 26734
26 45.4 0.0 46.6 52.9 31.8 0 [51.0] [0.0] 27621
27 37.7 0.0 46.3 53.6 34.0 43 [53.0, 32.0] [0.0] 22545
28 38.8 0.0 46.0 52.0 26.2 245 [47.0, 44.0] [0.0] 22175
29 36.8 0.0 45.0 51.8 27.1 193 [42.0, 24.0] [0.0] 30864
30 51.0 0.0 47.9 52.6 34.7 0 [20.0] [0.0] 22584
32 38.9 0.0 45.3 51.9 32.2 0 [24.0] [0.0] 21295
33 25.5 0.0 43.9 49.9 32.1 316 [21.0, 26.0, 16.0] [0.0] 29617
34 34.5 0.0 45.1 52.0 34.5 117 [44.0, 14.0] [0.0] 32013
35 29.4 0.0 44.6 51.1 35.3 19 [53.0, 37.0] [0.0] 34536
36 31.0 0.0 45.1 50.7 33.6 232 [50.0, 17.0] [0.0] 30195
37 26.4 0.0 43.3 50.3 31.8 154 [48.0, 46.0] [0.0] 25287
38 7.0 0.0 41.3 43.6 38.1 0 [15.0] [0.0] 2201
41 23.7 0.0 43.2 48.5 31.9 255 [18.0, 43.0, 48.0] [0.0] 27841
42 33.6 0.0 44.9 51.8 28.5 103 [50.0, 52.0] [0.0] 30553
43 49.6 0.0 47.3 52.7 29.9 0 [28.0] [0.0] 23877
44 29.1 0.0 44.6 50.5 35.4 29 [51.0, 17.0] [0.0] 34704
45 35.4 0.0 44.8 52.5 33.7 42 [46.0, 41.0] [0.0] 31480
DIFF BeiDou B1(BPSK(2)-B1)

SV AvgEl AvgCNoDiff MaxCNoDiff MinCNoDiff SVChan N_Samples
11 38.3 -0.3 6.1 -13.2 [28.0, 50.0] 30526
12 30.8 0.1 8.4 -5.9 [19.0, 20.0] 34082
14 30.2 -0.3 5.2 -11.9 [48.0, 46.0, 49.0, 36.0, 35.0] 29075
19 44.4 -0.1 4.2 -10.2 [49.0] 28273
20 45.5 -0.1 4.2 -7.8 [21.0] 25461
21 41.3 0.2 7.0 -7.0 [32.0, 29.0, 19.0, 47.0] 28644
22 44.3 -0.2 3.7 -6.4 [52.0] 28326
23 41.8 -0.1 15.3 -9.4 [39.0] 23094
24 44.9 0.1 6.9 -8.6 [45.0] 28685
25 45.8 0.2 4.2 -4.3 [16.0] 26733
26 45.4 -0.0 4.4 -5.7 [51.0] 27609
27 37.7 0.3 7.3 -4.6 [53.0, 30.0, 32.0] 22544
28 38.8 0.2 7.8 -7.1 [44.0, 47.0] 22165
29 36.8 0.0 9.6 -22.0 [42.0, 52.0, 24.0] 30830
30 51.0 -0.0 5.3 -6.0 [20.0] 22583
32 39.0 0.4 8.0 -6.1 [26.0, 24.0] 21255
33 25.5 -0.2 10.4 -8.2 [21.0, 27.0, 26.0, 15.0, 16.0] 29612
34 34.5 -0.0 5.9 -7.5 [45.0, 44.0, 46.0, 14.0] 31964
35 29.4 0.1 5.5 -7.1 [53.0, 35.0, 37.0] 34536
36 31.0 -0.1 6.0 -7.1 [51.0, 50.0, 17.0] 30195
37 26.4 -0.0 6.3 -6.2 [49.0, 48.0, 51.0, 46.0] 25256
38 7.0 -0.9 1.9 -3.3 [15.0] 2199
41 23.7 0.3 5.8 -5.7 [18.0, 43.0, 48.0] 27821
42 33.6 -0.6 4.7 -8.8 [50.0, 47.0, 52.0] 30523
43 49.7 -0.4 8.3 -10.2 [26.0, 28.0] 23863
44 29.1 0.1 6.4 -6.9 [50.0, 51.0, 18.0, 17.0] 34693
45 35.4 0.1 5.8 -8.0 [48.0, 46.0, 41.0] 31477
REF BeiDou B3(BPSK(10)-B3)

SV AvgEl AvgOffset AvgCNo MaxCNo MinCNo Slip_Count SVChan Ant N_Samples
11 38.2 0.0 43.9 49.1 31.9 238 [28.0, 50.0] [0.0] 30580
12 30.8 0.0 44.1 48.9 33.0 247 [19.0, 20.0] [0.0] 34088
14 30.1 0.0 43.7 49.3 30.7 191 [48.0, 49.0, 36.0] [0.0] 29155
19 44.4 0.0 45.6 49.8 34.6 0 [49.0] [0.0] 28281
20 45.5 0.0 45.2 49.5 36.1 0 [21.0] [0.0] 25462
21 41.2 0.0 45.4 50.3 36.8 137 [32.0, 19.0] [0.0] 28650
22 44.3 0.0 46.0 50.2 33.9 0 [52.0] [0.0] 28326
23 41.8 0.0 45.7 50.0 32.3 0 [39.0] [0.0] 23096
24 44.9 0.0 46.2 50.0 36.8 0 [45.0] [0.0] 28685
25 45.8 0.0 45.7 49.9 33.7 0 [16.0] [0.0] 26733
26 45.4 0.0 45.0 49.1 33.6 0 [51.0] [0.0] 27610
27 37.7 0.0 44.4 48.9 36.0 215 [53.0, 30.0] [0.0] 22546
28 38.7 0.0 44.1 48.6 30.5 9 [44.0] [0.0] 22195
29 36.8 0.0 44.0 49.1 33.4 100 [42.0, 52.0] [0.0] 30796
30 51.0 0.0 45.6 49.0 31.3 0 [20.0] [0.0] 22583
32 39.0 0.0 45.4 49.6 33.8 0 [26.0] [0.0] 21255
33 25.4 0.0 43.6 49.8 34.6 33 [21.0, 27.0, 15.0] [0.0] 29655
34 34.5 0.0 43.9 49.4 32.8 221 [45.0, 46.0] [0.0] 31978
35 29.4 0.0 43.4 48.8 32.4 84 [53.0, 35.0] [0.0] 34602
36 30.9 0.0 44.7 48.9 34.1 104 [51.0, 17.0] [0.0] 30262
37 26.4 0.0 43.3 49.1 29.1 246 [49.0, 48.0, 51.0] [0.0] 25306
38 7.0 0.0 37.3 40.0 33.9 0 [15.0] [0.0] 2199
41 23.7 0.0 43.7 48.1 34.9 161 [18.0, 43.0, 48.0] [0.0] 27847
42 33.6 0.0 44.7 49.8 33.3 228 [50.0, 47.0] [0.0] 30530
43 49.7 0.0 45.5 49.1 30.9 0 [26.0] [0.0] 23857
44 29.1 0.0 43.4 48.0 34.3 85 [50.0, 18.0] [0.0] 34709
45 35.4 0.0 44.5 49.8 34.0 246 [48.0, 41.0] [0.0] 31478
DUT BeiDou B3(BPSK(10)-B3)

SV AvgEl AvgOffset AvgCNo MaxCNo MinCNo Slip_Count SVChan Ant N_Samples
11 38.3 0.0 44.3 48.8 34.0 74 [28.0, 50.0] [0.0] 30529
12 30.8 0.0 44.1 49.3 35.6 8 [19.0, 20.0] [0.0] 34100
14 30.2 0.0 43.9 48.5 34.3 335 [46.0, 49.0, 35.0] [0.0] 29086
19 44.3 0.0 45.6 49.4 34.7 0 [49.0] [0.0] 28334
20 45.5 0.0 44.9 48.6 35.8 0 [21.0] [0.0] 25468
21 41.2 0.0 45.0 49.5 34.4 189 [29.0, 47.0] [0.0] 28645
22 44.3 0.0 45.6 49.6 36.2 0 [52.0] [0.0] 28333
23 41.8 0.0 45.4 49.5 34.9 1 [39.0] [0.0] 23087
24 44.8 0.0 46.0 49.8 36.1 0 [45.0] [0.0] 28736
25 45.8 0.0 45.3 49.6 31.1 0 [16.0] [0.0] 26734
26 45.4 0.0 45.1 49.2 28.9 0 [51.0] [0.0] 27621
27 37.7 0.0 44.2 48.6 35.2 122 [53.0, 32.0] [0.0] 22545
28 38.8 0.0 44.0 48.2 31.3 70 [47.0, 44.0] [0.0] 22175
29 36.8 0.0 43.7 48.4 33.4 103 [42.0, 24.0] [0.0] 30864
30 51.0 0.0 44.8 48.8 33.1 0 [20.0] [0.0] 22584
32 38.9 0.0 44.9 49.2 36.5 0 [24.0] [0.0] 21295
33 25.5 0.0 43.6 48.7 35.8 223 [21.0, 26.0, 16.0] [0.0] 29617
34 34.5 0.0 44.0 49.1 30.4 42 [44.0, 14.0] [0.0] 32013
35 29.4 0.0 43.3 47.8 33.1 204 [53.0, 37.0] [0.0] 34536
36 31.0 0.0 44.3 49.0 33.8 212 [50.0, 17.0] [0.0] 30195
37 26.4 0.0 43.3 48.4 35.2 97 [48.0, 46.0] [0.0] 25287
38 7.0 0.0 38.9 40.7 36.5 0 [15.0] [0.0] 2201
41 23.7 0.0 43.5 48.1 36.5 205 [18.0, 43.0, 48.0] [0.0] 27841
42 33.6 0.0 44.7 49.4 26.8 110 [50.0, 52.0] [0.0] 30553
43 49.6 0.0 45.6 49.1 25.8 0 [28.0] [0.0] 23877
44 29.1 0.0 43.2 47.9 35.0 118 [51.0, 17.0] [0.0] 34704
45 35.4 0.0 44.5 49.6 34.6 172 [46.0, 41.0] [0.0] 31480
DIFF BeiDou B3(BPSK(10)-B3)

SV AvgEl AvgCNoDiff MaxCNoDiff MinCNoDiff SVChan N_Samples
11 38.3 -0.4 4.9 -5.2 [28.0, 50.0] 30516
12 30.8 -0.0 6.1 -4.7 [19.0, 20.0] 34077
14 30.2 -0.1 3.8 -7.2 [48.0, 46.0, 49.0, 36.0, 35.0] 29075
19 44.4 -0.0 3.2 -4.0 [49.0] 28273
20 45.5 0.3 3.2 -4.1 [21.0] 25461
21 41.3 0.4 5.4 -3.0 [32.0, 29.0, 19.0, 47.0] 28644
22 44.3 0.4 4.4 -4.0 [52.0] 28326
23 41.8 0.3 3.8 -4.6 [39.0] 23087
24 44.9 0.2 4.4 -4.8 [45.0] 28685
25 45.8 0.4 5.5 -2.9 [16.0] 26733
26 45.4 -0.1 6.4 -5.8 [51.0] 27609
27 37.7 0.2 4.5 -4.0 [53.0, 30.0, 32.0] 22544
28 38.8 0.1 3.7 -7.8 [44.0, 47.0] 22165
29 36.8 0.3 6.4 -6.2 [42.0, 52.0, 24.0] 30793
30 51.0 0.7 3.9 -6.4 [20.0] 22583
32 39.0 0.5 4.7 -5.2 [26.0, 24.0] 21255
33 25.5 0.1 4.4 -7.0 [21.0, 27.0, 26.0, 15.0, 16.0] 29612
34 34.5 -0.1 4.6 -5.8 [45.0, 44.0, 46.0, 14.0] 31964
35 29.4 0.1 3.7 -5.4 [53.0, 35.0, 37.0] 34536
36 31.0 0.4 5.4 -3.5 [51.0, 50.0, 17.0] 30195
37 26.4 -0.0 3.7 -8.4 [49.0, 48.0, 51.0, 46.0] 25256
38 7.0 -1.6 1.8 -4.5 [15.0] 2199
41 23.7 0.2 3.2 -3.8 [18.0, 43.0, 48.0] 27821
42 33.6 -0.1 8.2 -3.8 [50.0, 47.0, 52.0] 30523
43 49.7 -0.1 9.6 -4.4 [26.0, 28.0] 23857
44 29.1 0.2 4.7 -5.9 [50.0, 51.0, 18.0, 17.0] 34693
45 35.4 0.0 5.4 -5.5 [48.0, 46.0, 41.0] 31477
