REF File: 240730/BX_all.T04
DUT File: 240730/EB81_all.T04

Ref Statistics

DUT Statistics

Difference Statistics
SVType Freq Track N_Samples CNo_Mean CNo_Median CNo_Std CNo_Min CNo_Max CNo_Range El_Mean El_Max
GPS L1 CA 835287 43.7 43.9 4.3 20.5 54.6 34.1 37.1 89.0
GPS L2 CM+CL 640216 43.6 44.3 4.1 22.1 51.4 29.3 38.4 89.0
GPS L2 E 189080 29.6 30.1 6.7 12.6 44.5 31.9 33.5 77.0
GPS L5/E5A I+Q 466117 47.2 47.5 3.4 22.1 53.7 31.6 37.7 88.0
SBAS L1 CA 270000 44.3 44.1 1.4 40.8 48.0 7.2 39.8 42.0
SBAS L5/E5A I 270000 45.8 45.9 0.9 42.9 48.7 5.8 39.8 42.0
GLONASS L1 CA 658619 43.9 44.7 5.1 16.8 54.3 37.5 36.7 89.0
GLONASS L1 P 656545 42.5 43.3 4.9 19.8 52.6 32.8 36.8 89.0
GLONASS L2 CA 560874 43.8 44.4 3.9 12.4 51.2 38.8 37.1 88.0
GLONASS L2 P 560583 42.3 42.8 3.8 9.4 49.3 39.9 37.1 89.0
GLONASS G3 PD 56925 43.9 44.1 3.1 24.1 49.0 24.9 36.0 83.0
Galileo L1 MBOC-PD 632149 45.0 45.3 3.9 19.2 54.0 34.8 37.4 89.0
Galileo L5/E5A BPSK(10)-PD 632149 44.6 45.2 3.4 26.8 50.8 24.0 37.4 89.0
Galileo E5B/B2 BPSK(10)-PD 632148 44.9 45.6 3.6 21.9 50.9 29.0 37.4 89.0
Galileo E5A+B AltBOC-Comp-PD 632149 47.4 47.9 3.1 30.2 52.9 22.7 37.4 89.0
Galileo E6 BPSK(5)-PD 632140 45.9 46.7 4.4 19.9 52.6 32.7 37.4 89.0
BeiDou L1 BOC-PD 633787 45.4 45.5 4.0 26.8 53.4 26.6 37.6 88.0
BeiDou L5/E5A I+Q 633786 45.6 46.0 3.4 21.1 51.9 30.8 37.6 88.0
BeiDou E5B/B2 BPSK(2)-B2 92052 45.1 46.0 3.1 31.9 50.8 18.9 37.8 88.0
BeiDou B1 BPSK(2)-B1 725845 45.0 45.0 4.1 28.6 54.4 25.8 37.7 88.0
BeiDou B3 BPSK(10)-B3 725835 43.9 44.6 3.8 24.2 50.4 26.2 37.7 88.0
start/stop time: 154,800 244,799
Total time: 89,999.0 seconds
Total time: 1,499.983 minutes
Total time: 25.000 hours
Total Samples: 11,136,286
Avg Samples/sec: 123.7

Serial Number : 6221C43829
Firmware Date : Mar 6, 2024
Release Ver : 5.70
Nav Proc Ver : 0.47
Radio Lib Ver : None
Primary Antenna Type : MI
Primary Antenna Height : 0.0000 m
Secondary Antenna Type : MI
Secondary Antenna Height : 0.0000 m
week_list : ['2325']
Start Time : 154800.343
Stop Time : 241200.192
Total Hours : 23.99995805555556
SVType Freq Track N_Samples CNo_Mean CNo_Median CNo_Std CNo_Min CNo_Max CNo_Range El_Mean El_Max
GPS L1 CA 834802 43.4 43.7 4.3 8.5 53.8 45.3 37.1 89.0
GPS L2 CM+CL 639770 42.9 43.5 4.1 15.0 51.0 36.0 38.4 89.0
GPS L2 E 189090 28.5 28.9 6.5 12.6 43.8 31.2 33.5 77.0
GPS L5/E5A I+Q 465738 46.3 46.5 3.3 22.6 53.1 30.5 37.7 88.0
GLONASS L1 CA 658162 43.0 43.9 5.1 0.0 53.9 53.9 36.7 89.0
GLONASS L2 CA 560798 42.8 43.4 4.0 1.0 50.8 49.8 37.1 89.0
Galileo L1 MBOC-PD 632072 44.6 44.9 3.9 0.0 54.6 54.6 37.4 89.0
Galileo E5A+B AltBOC-Comp-PD 632071 46.7 47.3 3.0 25.6 52.1 26.5 37.4 89.0
BeiDou L5/E5A I+Q 633660 44.7 45.2 3.3 20.4 51.4 31.0 37.6 88.0
BeiDou E5B/B2 BPSK(2)-B2 91978 44.8 45.6 2.9 23.5 50.0 26.5 37.8 88.0
BeiDou B1 BPSK(2)-B1 725706 44.8 45.0 4.2 15.0 53.7 38.7 37.7 88.0
BeiDou B3 BPSK(10)-B3 725423 43.5 44.2 3.8 16.9 50.1 33.2 37.7 88.0
start/stop time: 154,800 244,799
Total time: 89,999.0 seconds
Total time: 1,499.983 minutes
Total time: 25.000 hours
Total Samples: 6,789,270
Avg Samples/sec: 75.4

Serial Number : 6348C01910
Firmware Date : Jun 21, 2024
Release Ver : 5.70
Nav Proc Ver : 0.51
Radio Lib Ver : None
Primary Antenna Type : -1
Primary Antenna Height : 0.1080 m
Secondary Antenna Type : -1
Secondary Antenna Height : 0.1080 m
week_list : ['2325']
Start Time : 154800.191
Stop Time : 243396.098
Total Hours : 24.609974166666667
SVType Freq Track N_Samples CNo_Mean CNo_Median CNo_Std CNo_Min CNo_Max CNo_Range El_Mean El_Max
GPS L1 CA 834363 +0.3 +0.3 +1.8 -14.2 +18.8 +33.0 +37.1 +89.0
GPS L2 CM+CL 639420 +0.7 +0.7 +1.5 -15.2 +20.2 +35.4 +38.5 +89.0
GPS L2 E 185418 +1.1 +1.1 +1.8 -9.3 +12.6 +21.9 +34.0 +77.0
GPS L5/E5A I+Q 465479 +0.9 +0.9 +1.1 -14.6 +12.1 +26.7 +37.7 +88.0
GLONASS L1 CA 657824 +0.9 +1.0 +1.7 -24.4 +27.9 +52.3 +36.7 +89.0
GLONASS L2 CA 559903 +1.0 +1.0 +1.6 -23.0 +18.4 +41.4 +37.2 +88.0
Galileo L1 MBOC-PD 631683 +0.4 +0.4 +1.5 -17.4 +30.2 +47.6 +37.4 +89.0
Galileo E5A+B AltBOC-Comp-PD 631682 +0.6 +0.7 +0.9 -7.7 +10.2 +17.9 +37.4 +89.0
BeiDou L5/E5A I+Q 633335 +0.8 +0.9 +1.2 -14.0 +16.5 +30.5 +37.7 +88.0
BeiDou E5B/B2 BPSK(2)-B2 91901 +0.4 +0.5 +1.2 -5.5 +11.1 +16.6 +37.9 +88.0
BeiDou B1 BPSK(2)-B1 725306 +0.2 +0.2 +1.7 -8.9 +19.5 +28.4 +37.7 +88.0
BeiDou B3 BPSK(10)-B3 725023 +0.4 +0.4 +1.4 -11.6 +22.4 +34.0 +37.7 +88.0
start/stop time: 154,800 244,799
Total time: 89,999.0 seconds
Total time: 1,499.983 minutes
Total time: 25.000 hours
Total Samples: 6,781,337
Avg Samples/sec: 75.3

Statistics for full C/No Observations dataset
(df_ref - df_dut => positive numbers mean DUT is worse)
Mean = 0.623
Median = 0.600
Std Dev= 1.526

Plots


REF GPS L1(CA)

SV AvgEl AvgOffset AvgCNo MaxCNo MinCNo Slip_Count SVChan Ant N_Samples
2 26.0 0.0 42.9 48.8 30.2 49 [18.0, 19.0] [0.0] 30534
3 32.7 0.0 42.6 52.2 28.1 197 [25.0, 37.0] [0.0] 27068
4 45.4 0.0 44.2 51.1 32.4 0 [36.0] [0.0] 23847
5 40.1 0.0 44.1 51.9 21.0 127 [13.0, 18.0] [0.0] 23051
6 38.4 0.0 43.4 52.4 26.1 28 [33.0, 30.0] [0.0] 24519
7 45.1 0.0 45.6 51.6 31.4 0 [37.0] [0.0] 25493
8 26.1 0.0 41.4 50.0 27.2 219 [36.0, 31.0, 35.0] [0.0] 32626
9 44.0 0.0 44.7 52.7 30.3 10 [35.0] [0.0] 21433
10 44.3 0.0 47.0 53.9 28.3 80 [27.0, 34.0] [0.0] 29610
11 45.8 0.0 45.0 53.4 26.7 0 [36.0] [0.0] 23327
12 37.4 0.0 43.6 51.4 24.4 273 [36.0, 24.0] [0.0] 24222
13 26.0 0.0 42.3 48.9 27.7 104 [31.0, 32.0] [0.0] 30676
14 44.2 0.0 45.2 51.1 33.3 0 [29.0] [0.0] 25712
15 28.7 0.0 42.7 49.9 25.0 225 [35.0, 18.0, 30.0] [0.0] 31664
16 31.3 0.0 41.7 50.9 28.7 202 [24.0, 35.0] [0.0] 27085
17 45.7 0.0 45.5 52.9 33.6 0 [13.0] [0.0] 24078
18 45.7 0.0 45.1 51.5 33.2 227 [34.0, 37.0] [0.0] 28785
19 44.6 0.0 44.6 51.9 24.3 7 [28.0] [0.0] 24580
20 34.2 0.0 42.5 51.6 28.4 192 [19.0, 22.0] [0.0] 25992
21 26.6 0.0 42.0 49.0 27.0 107 [35.0, 24.0] [0.0] 30220
22 44.5 0.0 45.3 51.3 31.0 0 [17.0] [0.0] 25976
23 46.7 0.0 45.3 51.9 32.0 35 [13.0, 29.0] [0.0] 29430
24 26.0 0.0 40.9 47.4 29.6 156 [25.0, 23.0, 27.0] [0.0] 33613
25 28.5 0.0 41.2 49.5 25.3 297 [33.0, 21.0] [0.0] 28547
26 27.9 0.0 41.9 49.6 26.7 17 [21.0, 23.0] [0.0] 28535
27 27.2 0.0 42.2 48.4 20.5 198 [33.0, 31.0] [0.0] 33763
28 39.7 0.0 43.2 51.1 21.0 261 [28.0, 37.0] [0.0] 23194
29 44.7 0.0 45.0 53.0 30.5 218 [14.0, 15.0] [0.0] 23305
30 45.8 0.0 45.4 53.4 31.0 1 [22.0] [0.0] 23659
31 45.3 0.0 45.4 54.1 28.7 2 [34.0] [0.0] 22293
32 43.4 0.0 46.7 54.6 24.2 174 [30.0, 24.0] [0.0] 28450
DUT GPS L1(CA)

SV AvgEl AvgOffset AvgCNo MaxCNo MinCNo Slip_Count SVChan Ant N_Samples
2 26.0 0.0 42.7 48.4 32.6 92 [18.0, 19.0] [0.0] 30540
3 32.7 0.0 42.2 51.1 25.0 110 [24.0, 37.0] [0.0] 27078
4 45.8 0.0 44.2 51.3 29.7 2 [37.0] [0.0] 23573
5 40.1 0.0 43.4 51.1 8.5 204 [13.0, 18.0] [0.0] 23018
6 38.3 0.0 42.6 52.5 26.7 224 [25.0, 29.0] [0.0] 24545
7 45.1 0.0 45.2 51.7 26.7 9 [36.0] [0.0] 25501
8 26.1 0.0 40.4 49.8 21.8 392 [37.0, 33.0] [0.0] 32600
9 44.0 0.0 44.4 52.3 31.1 4 [29.0] [0.0] 21441
10 44.3 0.0 46.8 53.6 32.9 69 [27.0, 35.0] [0.0] 29613
11 45.7 0.0 44.7 51.6 29.3 2 [36.0] [0.0] 23341
12 37.3 0.0 43.2 50.9 28.9 42 [37.0, 23.0] [0.0] 24235
13 26.1 0.0 42.3 49.1 33.0 27 [31.0, 32.0] [0.0] 30577
14 44.2 0.0 45.2 51.4 34.3 0 [30.0] [0.0] 25704
15 28.7 0.0 42.2 50.7 16.1 214 [35.0, 18.0, 29.0] [0.0] 31637
16 31.3 0.0 41.0 49.5 25.1 340 [23.0, 33.0] [0.0] 27045
17 45.7 0.0 45.2 52.1 29.6 0 [13.0] [0.0] 24088
18 45.7 0.0 44.6 50.5 28.4 90 [34.0, 37.0] [0.0] 28791
19 44.6 0.0 44.7 51.6 30.2 4 [25.0] [0.0] 24576
20 34.2 0.0 41.8 49.9 29.4 22 [19.0, 22.0] [0.0] 25985
21 26.6 0.0 41.6 48.3 27.3 270 [21.0, 23.0] [0.0] 30239
22 44.4 0.0 45.1 50.9 34.1 0 [17.0] [0.0] 26001
23 46.7 0.0 45.4 51.4 34.1 200 [13.0, 30.0] [0.0] 29415
24 26.0 0.0 40.8 47.1 29.8 74 [24.0, 27.0] [0.0] 33651
25 28.6 0.0 41.1 49.7 27.0 230 [25.0, 21.0] [0.0] 28407
26 28.0 0.0 41.3 49.9 27.1 254 [35.0, 24.0] [0.0] 28502
27 27.3 0.0 42.4 48.7 30.1 242 [25.0, 28.0] [0.0] 33739
28 39.7 0.0 42.4 50.2 23.9 240 [28.0, 37.0] [0.0] 23186
29 44.7 0.0 44.9 51.5 32.6 73 [14.0, 15.0] [0.0] 23315
30 45.9 0.0 45.1 51.9 31.2 6 [21.0] [0.0] 23651
31 45.3 0.0 45.1 52.3 30.1 0 [34.0] [0.0] 22307
32 43.3 0.0 46.6 53.8 21.1 125 [29.0, 24.0] [0.0] 28501
DIFF GPS L1(CA)

SV AvgEl AvgCNoDiff MaxCNoDiff MinCNoDiff SVChan N_Samples
2 26.0 0.2 6.4 -12.1 [18.0, 19.0] 30522
3 32.7 0.5 9.1 -7.9 [25.0, 24.0, 37.0] 27047
4 45.8 0.1 7.3 -6.1 [36.0, 37.0] 23573
5 40.1 0.7 15.9 -13.7 [13.0, 18.0] 23018
6 38.4 0.8 9.8 -11.0 [33.0, 25.0, 30.0, 29.0] 24507
7 45.1 0.4 10.8 -4.9 [37.0, 36.0] 25493
8 26.1 1.0 15.5 -8.0 [36.0, 37.0, 31.0, 33.0, 35.0] 32591
9 44.0 0.3 7.9 -6.6 [35.0, 29.0] 21433
10 44.3 0.2 5.4 -8.6 [27.0, 34.0, 35.0] 29610
11 45.8 0.3 7.5 -10.6 [36.0] 23327
12 37.4 0.4 8.0 -9.2 [36.0, 37.0, 24.0, 23.0] 24222
13 26.1 0.1 6.6 -10.2 [31.0, 32.0] 30570
14 44.2 0.0 6.1 -8.5 [29.0, 30.0] 25704
15 28.7 0.6 17.0 -8.9 [35.0, 18.0, 30.0, 29.0] 31636
16 31.3 0.7 11.1 -8.7 [24.0, 23.0, 35.0, 33.0] 27026
17 45.7 0.3 9.8 -7.6 [13.0] 24077
18 45.7 0.5 7.9 -5.7 [34.0, 37.0] 28785
19 44.6 -0.1 9.0 -13.4 [28.0, 25.0] 24575
20 34.2 0.7 7.6 -8.9 [19.0, 22.0] 25984
21 26.6 0.3 8.6 -9.4 [35.0, 21.0, 24.0, 23.0] 30213
22 44.5 0.1 6.4 -10.6 [17.0] 25976
23 46.7 -0.0 6.5 -5.7 [13.0, 29.0, 30.0] 29415
24 26.0 0.1 7.4 -7.9 [25.0, 24.0, 23.0, 27.0] 33612
25 28.6 0.2 9.5 -11.9 [33.0, 25.0, 21.0] 28402
26 28.0 0.6 10.5 -9.8 [21.0, 35.0, 23.0, 24.0] 28494
27 27.3 -0.2 6.2 -12.9 [33.0, 25.0, 28.0, 31.0] 33731
28 39.7 0.8 13.8 -14.2 [28.0, 37.0] 23165
29 44.7 0.1 5.7 -7.6 [14.0, 15.0] 23288
30 45.9 0.2 8.3 -8.0 [22.0, 21.0] 23634
31 45.3 0.4 6.3 -7.8 [34.0] 22283
32 43.4 0.1 18.8 -11.9 [30.0, 29.0, 24.0] 28450
REF GPS L2(E)

SV AvgEl AvgOffset AvgCNo MaxCNo MinCNo Slip_Count SVChan Ant N_Samples
2 26.2 0.0 29.3 36.2 12.6 77 [18.0, 19.0] [0.0] 30242
13 27.2 0.0 27.0 35.3 13.9 241 [31.0, 32.0] [0.0] 28624
16 32.5 0.0 28.1 40.5 12.6 259 [24.0, 35.0] [0.0] 25627
19 45.0 0.0 34.2 44.5 13.9 4 [28.0] [0.0] 24299
20 35.3 0.0 29.3 40.8 13.9 223 [19.0, 22.0] [0.0] 25011
21 27.2 0.0 27.0 36.5 12.6 209 [35.0, 24.0] [0.0] 29298
22 44.5 0.0 33.1 40.9 14.8 0 [17.0] [0.0] 25976
27 8.0 0.0 19.5 19.6 19.3 0 [33.0] [0.0] 3
DUT GPS L2(E)

SV AvgEl AvgOffset AvgCNo MaxCNo MinCNo Slip_Count SVChan Ant N_Samples
2 26.0 0.0 28.4 35.2 14.8 93 [18.0, 19.0] [0.0] 30540
13 26.2 0.0 25.7 34.0 13.9 111 [31.0, 32.0] [0.0] 30324
16 33.5 0.0 27.0 38.8 13.9 108 [23.0, 33.0] [0.0] 24582
19 45.1 0.0 33.4 43.8 13.9 11 [25.0] [0.0] 24236
20 36.0 0.0 28.1 39.1 12.6 116 [19.0, 22.0] [0.0] 24287
21 27.3 0.0 26.1 36.8 13.9 247 [21.0, 23.0] [0.0] 29106
22 44.4 0.0 32.0 40.6 12.6 3 [17.0] [0.0] 25987
31 9.9 0.0 21.6 23.0 19.9 63 [34.0] [0.0] 28
DIFF GPS L2(E)

SV AvgEl AvgCNoDiff MaxCNoDiff MinCNoDiff SVChan N_Samples
2 26.2 0.7 6.6 -7.2 [18.0, 19.0] 30242
13 27.4 0.8 6.6 -5.9 [31.0, 32.0] 28324
16 34.2 1.7 7.4 -4.0 [24.0, 23.0, 35.0, 33.0] 23841
19 45.4 0.9 12.6 -9.3 [28.0, 25.0] 24054
20 36.3 1.6 9.3 -4.5 [19.0, 22.0] 24010
21 27.3 0.9 10.7 -9.3 [35.0, 21.0, 24.0, 23.0] 28985
22 44.5 1.0 6.5 -5.1 [17.0] 25962
REF GPS L2(CM+CL)

SV AvgEl AvgOffset AvgCNo MaxCNo MinCNo Slip_Count SVChan Ant N_Samples
3 32.7 0.0 41.7 48.3 28.3 17 [25.0, 37.0] [0.0] 27068
4 45.4 0.0 46.1 51.3 36.6 0 [36.0] [0.0] 23847
5 40.1 0.0 43.7 49.1 29.8 129 [13.0, 18.0] [0.0] 23051
6 38.4 0.0 44.1 50.1 26.8 231 [33.0, 30.0] [0.0] 24519
7 45.1 0.0 44.1 49.0 32.2 0 [37.0] [0.0] 25493
8 26.1 0.0 42.0 48.4 32.9 289 [36.0, 31.0, 35.0] [0.0] 32626
9 44.0 0.0 44.1 49.2 29.5 0 [35.0] [0.0] 21433
10 44.3 0.0 44.5 49.2 32.1 88 [27.0, 34.0] [0.0] 29610
11 45.8 0.0 45.6 51.3 26.9 3 [36.0] [0.0] 23327
12 37.4 0.0 42.6 48.6 28.3 50 [36.0, 24.0] [0.0] 24222
14 44.2 0.0 46.2 51.4 22.3 28 [29.0] [0.0] 25712
15 28.7 0.0 41.9 48.1 30.8 152 [35.0, 18.0, 30.0] [0.0] 31664
17 45.7 0.0 43.5 49.7 29.4 0 [13.0] [0.0] 24078
18 45.7 0.0 46.5 51.2 35.4 44 [34.0, 37.0] [0.0] 28785
23 46.7 0.0 46.1 51.0 28.3 156 [13.0, 29.0] [0.0] 29430
24 26.0 0.0 41.3 47.3 23.0 398 [25.0, 23.0, 27.0] [0.0] 33613
25 28.5 0.0 40.6 47.1 28.4 242 [33.0, 21.0] [0.0] 28547
26 27.9 0.0 41.7 47.5 30.4 101 [21.0, 23.0] [0.0] 28535
27 27.2 0.0 41.9 46.9 22.1 492 [33.0, 31.0] [0.0] 33755
28 39.7 0.0 45.9 51.2 33.2 85 [28.0, 37.0] [0.0] 23194
29 44.7 0.0 43.8 49.3 31.0 51 [14.0, 15.0] [0.0] 23305
30 45.8 0.0 43.9 49.0 34.0 0 [22.0] [0.0] 23659
31 45.3 0.0 43.9 49.6 27.3 27 [34.0] [0.0] 22293
32 43.4 0.0 44.0 49.6 26.7 71 [30.0, 24.0] [0.0] 28450
DUT GPS L2(CM+CL)

SV AvgEl AvgOffset AvgCNo MaxCNo MinCNo Slip_Count SVChan Ant N_Samples
3 32.7 0.0 41.4 47.9 26.0 117 [24.0, 37.0] [0.0] 27078
4 45.8 0.0 45.1 50.7 32.9 0 [37.0] [0.0] 23573
5 40.1 0.0 42.8 49.1 30.8 98 [13.0, 18.0] [0.0] 23018
6 38.3 0.0 43.3 49.6 29.8 6 [25.0, 29.0] [0.0] 24545
7 45.1 0.0 43.3 48.3 28.2 4 [36.0] [0.0] 25501
8 26.1 0.0 41.5 47.2 29.0 158 [37.0, 33.0] [0.0] 32600
9 44.0 0.0 43.2 49.3 22.1 63 [29.0] [0.0] 21441
10 44.3 0.0 43.8 48.3 31.6 150 [27.0, 35.0] [0.0] 29613
11 45.7 0.0 44.8 50.7 21.9 33 [36.0] [0.0] 23341
12 37.3 0.0 41.9 48.0 27.2 69 [37.0, 23.0] [0.0] 24235
14 44.2 0.0 45.8 50.8 32.6 0 [30.0] [0.0] 25704
15 28.7 0.0 40.8 46.8 27.2 289 [35.0, 18.0, 29.0] [0.0] 31637
17 45.7 0.0 43.2 49.2 25.2 29 [13.0] [0.0] 24088
18 45.7 0.0 45.7 50.7 31.8 133 [34.0, 37.0] [0.0] 28791
23 46.7 0.0 45.5 50.6 31.7 252 [13.0, 30.0] [0.0] 29415
24 26.0 0.0 40.9 45.9 27.4 286 [24.0, 27.0] [0.0] 33651
25 28.6 0.0 40.0 46.5 24.5 242 [25.0, 21.0] [0.0] 28407
26 28.0 0.0 40.8 46.7 29.1 115 [35.0, 24.0] [0.0] 28502
27 27.3 0.0 41.6 46.2 22.7 326 [25.0, 28.0] [0.0] 33739
28 39.7 0.0 44.8 51.0 33.3 233 [28.0, 37.0] [0.0] 23186
29 44.7 0.0 42.6 49.0 28.9 60 [14.0, 15.0] [0.0] 23315
30 45.9 0.0 43.0 48.5 29.6 2 [21.0] [0.0] 23651
31 45.4 0.0 43.0 48.8 15.0 451 [34.0] [0.0] 22244
32 43.3 0.0 43.2 48.7 16.9 404 [29.0, 24.0] [0.0] 28495
DIFF GPS L2(CM+CL)

SV AvgEl AvgCNoDiff MaxCNoDiff MinCNoDiff SVChan N_Samples
3 32.7 0.3 10.8 -7.5 [25.0, 24.0, 37.0] 27047
4 45.8 1.1 6.8 -2.9 [36.0, 37.0] 23573
5 40.1 1.0 6.3 -6.2 [13.0, 18.0] 23018
6 38.4 0.8 6.8 -6.6 [33.0, 25.0, 30.0, 29.0] 24507
7 45.1 0.8 7.0 -3.3 [37.0, 36.0] 25493
8 26.1 0.5 8.7 -5.7 [36.0, 37.0, 31.0, 33.0, 35.0] 32591
9 44.0 1.0 13.2 -7.0 [35.0, 29.0] 21433
10 44.3 0.7 8.1 -6.9 [27.0, 34.0, 35.0] 29610
11 45.8 0.8 9.1 -5.1 [36.0] 23327
12 37.4 0.7 8.9 -6.7 [36.0, 37.0, 24.0, 23.0] 24222
14 44.2 0.4 4.7 -15.2 [29.0, 30.0] 25704
15 28.7 1.1 10.3 -4.0 [35.0, 18.0, 30.0, 29.0] 31636
17 45.7 0.4 7.8 -7.5 [13.0] 24077
18 45.7 0.9 7.7 -4.8 [34.0, 37.0] 28785
23 46.7 0.6 7.5 -7.8 [13.0, 29.0, 30.0] 29415
24 26.0 0.4 5.7 -9.0 [25.0, 24.0, 23.0, 27.0] 33612
25 28.6 0.7 12.7 -7.0 [33.0, 25.0, 21.0] 28402
26 28.0 0.9 7.8 -4.9 [21.0, 35.0, 23.0, 24.0] 28494
27 27.3 0.3 6.7 -9.3 [33.0, 25.0, 28.0, 31.0] 33723
28 39.7 1.1 7.4 -4.3 [28.0, 37.0] 23165
29 44.7 1.2 9.0 -4.5 [14.0, 15.0] 23288
30 45.9 0.9 6.0 -2.5 [22.0, 21.0] 23634
31 45.4 0.9 20.2 -7.9 [34.0] 22220
32 43.4 0.8 14.9 -8.6 [30.0, 29.0, 24.0] 28444
REF GPS L5/E5A(I+Q)

SV AvgEl AvgOffset AvgCNo MaxCNo MinCNo Slip_Count SVChan Ant N_Samples
3 32.7 0.0 46.4 52.5 36.9 77 [25.0, 37.0] [0.0] 27068
4 45.4 0.0 48.1 53.1 40.0 0 [36.0] [0.0] 23847
6 38.4 0.0 47.3 52.5 38.1 0 [33.0, 30.0] [0.0] 24519
8 26.1 0.0 46.1 50.7 35.5 209 [36.0, 31.0, 35.0] [0.0] 32626
9 44.0 0.0 48.0 52.5 37.5 0 [35.0] [0.0] 21433
10 44.3 0.0 48.0 51.4 38.1 56 [27.0, 34.0] [0.0] 29610
11 45.8 0.0 48.0 53.7 37.1 0 [36.0] [0.0] 23327
14 44.2 0.0 48.0 53.4 31.3 0 [29.0] [0.0] 25712
18 45.7 0.0 48.9 53.7 38.7 18 [34.0, 37.0] [0.0] 28785
23 46.7 0.0 48.5 53.2 34.3 213 [13.0, 29.0] [0.0] 29430
24 26.0 0.0 45.6 50.4 22.1 206 [25.0, 23.0, 27.0] [0.0] 33612
25 28.5 0.0 45.3 50.7 30.9 148 [33.0, 21.0] [0.0] 28547
26 27.9 0.0 46.2 50.7 38.6 175 [21.0, 23.0] [0.0] 28535
27 27.2 0.0 46.3 50.1 34.6 47 [33.0, 31.0] [0.0] 33763
28 39.7 0.0 47.8 53.4 38.4 130 [28.0, 37.0] [0.0] 23194
30 45.8 0.0 48.7 52.8 41.0 0 [22.0] [0.0] 23659
32 43.4 0.0 46.1 51.0 31.9 243 [30.0, 24.0] [0.0] 28450
DUT GPS L5/E5A(I+Q)

SV AvgEl AvgOffset AvgCNo MaxCNo MinCNo Slip_Count SVChan Ant N_Samples
3 32.7 0.0 45.8 51.6 35.4 119 [24.0, 37.0] [0.0] 27078
4 45.8 0.0 47.2 52.8 35.4 0 [37.0] [0.0] 23573
6 38.3 0.0 46.2 51.2 36.5 213 [25.0, 29.0] [0.0] 24545
8 26.1 0.0 45.4 49.8 34.2 143 [37.0, 33.0] [0.0] 32600
9 44.0 0.0 47.1 51.5 36.6 0 [29.0] [0.0] 21441
10 44.3 0.0 47.1 51.0 38.0 248 [27.0, 35.0] [0.0] 29613
11 45.7 0.0 46.9 52.6 30.6 0 [36.0] [0.0] 23341
14 44.2 0.0 47.6 53.0 38.3 0 [30.0] [0.0] 25704
18 45.7 0.0 47.8 53.1 37.3 152 [34.0, 37.0] [0.0] 28791
23 46.7 0.0 47.8 52.1 36.0 118 [13.0, 30.0] [0.0] 29415
24 26.0 0.0 44.9 49.1 33.9 88 [24.0, 27.0] [0.0] 33651
25 28.6 0.0 44.6 49.8 22.6 227 [25.0, 21.0] [0.0] 28407
26 28.0 0.0 44.9 50.0 36.3 188 [35.0, 24.0] [0.0] 28502
27 27.3 0.0 45.6 48.8 35.4 227 [25.0, 28.0] [0.0] 33739
28 39.7 0.0 46.7 51.9 36.2 171 [28.0, 37.0] [0.0] 23186
30 45.9 0.0 47.7 52.5 36.2 0 [21.0] [0.0] 23651
32 43.3 0.0 45.2 50.1 31.2 37 [29.0, 24.0] [0.0] 28501
DIFF GPS L5/E5A(I+Q)

SV AvgEl AvgCNoDiff MaxCNoDiff MinCNoDiff SVChan N_Samples
3 32.7 0.6 5.7 -3.5 [25.0, 24.0, 37.0] 27047
4 45.8 1.0 6.6 -1.7 [36.0, 37.0] 23573
6 38.4 1.0 5.6 -2.7 [33.0, 25.0, 30.0, 29.0] 24507
8 26.1 0.7 3.9 -3.1 [36.0, 37.0, 31.0, 33.0, 35.0] 32591
9 44.0 0.9 4.6 -2.5 [35.0, 29.0] 21433
10 44.3 1.0 4.0 -3.3 [27.0, 34.0, 35.0] 29610
11 45.8 1.1 7.7 -2.5 [36.0] 23327
14 44.2 0.3 4.1 -8.6 [29.0, 30.0] 25704
18 45.7 1.1 4.3 -2.1 [34.0, 37.0] 28785
23 46.7 0.8 3.6 -5.5 [13.0, 29.0, 30.0] 29415
24 26.0 0.6 4.2 -14.6 [25.0, 24.0, 23.0, 27.0] 33611
25 28.6 0.8 12.1 -6.1 [33.0, 25.0, 21.0] 28402
26 28.0 1.3 6.9 -2.1 [21.0, 35.0, 23.0, 24.0] 28494
27 27.3 0.7 3.3 -4.4 [33.0, 25.0, 28.0, 31.0] 33731
28 39.7 1.1 6.3 -3.1 [28.0, 37.0] 23165
30 45.9 1.0 7.0 -1.4 [22.0, 21.0] 23634
32 43.4 0.8 5.8 -8.0 [30.0, 29.0, 24.0] 28450
REF SBAS L1(CA)

SV AvgEl AvgOffset AvgCNo MaxCNo MinCNo Slip_Count SVChan Ant N_Samples
131 42.0 0.0 45.9 48.0 43.6 0 [57.0] [0.0] 90000
133 38.0 0.0 42.8 45.1 40.8 0 [56.0] [0.0] 90000
135 39.4 0.0 44.0 46.2 41.8 0 [55.0] [0.0] 90000
DUT SBAS L1(CA)
DIFF SBAS L1(CA)
REF SBAS L5/E5A(I)

SV AvgEl AvgOffset AvgCNo MaxCNo MinCNo Slip_Count SVChan Ant N_Samples
131 42.0 0.0 46.8 48.7 44.5 0 [57.0] [0.0] 90000
133 38.0 0.0 45.9 47.8 43.8 0 [56.0] [0.0] 90000
135 39.4 0.0 44.7 46.4 42.9 0 [55.0] [0.0] 90000
DUT SBAS L5/E5A(I)
DIFF SBAS L5/E5A(I)
REF GLONASS L1(CA)

SV AvgEl AvgOffset AvgCNo MaxCNo MinCNo Slip_Count FDMA Ant N_Samples
1 36.6 0.0 43.0 48.8 30.8 9 [1.0] [0.0] 28511
2 42.3 0.0 48.1 53.7 38.4 0 [-4.0] [0.0] 21295
3 38.2 0.0 44.4 52.2 27.3 72 [5.0] [0.0] 23116
4 31.5 0.0 44.2 51.5 24.2 144 [6.0] [0.0] 25660
5 28.5 0.0 45.5 50.4 20.4 5 [1.0] [0.0] 26755
6 29.9 0.0 35.2 41.7 18.9 1902 [-4.0] [0.0] 31723
7 40.7 0.0 44.6 51.2 31.3 362 [5.0] [0.0] 35461
8 45.7 0.0 43.9 49.4 29.8 47 [6.0] [0.0] 32730
9 35.5 0.0 45.7 53.5 30.1 161 [-2.0] [0.0] 28070
10 33.7 0.0 41.7 48.4 25.5 53 [-7.0] [0.0] 29237
11 33.1 0.0 46.8 51.9 16.8 61 [0.0] [0.0] 29588
12 35.0 0.0 46.0 53.4 32.1 117 [-1.0] [0.0] 28524
13 44.6 0.0 37.0 43.2 17.3 337 [-2.0] [0.0] 20128
14 39.7 0.0 48.8 54.3 32.8 0 [-7.0] [0.0] 22971
15 38.9 0.0 48.0 53.8 34.9 0 [0.0] [0.0] 23365
16 36.9 0.0 46.9 54.1 33.1 157 [-1.0] [0.0] 25497
17 30.0 0.0 45.2 51.2 29.5 197 [4.0] [0.0] 26227
18 34.9 0.0 45.7 52.8 32.4 180 [-3.0] [0.0] 24523
19 41.2 0.0 34.5 41.1 19.1 2223 [3.0] [0.0] 21712
20 39.3 0.0 35.6 41.6 20.7 765 [2.0] [0.0] 22601
21 36.5 0.0 45.7 51.1 31.0 187 [4.0] [0.0] 28855
22 43.7 0.0 46.9 53.8 29.2 317 [-3.0] [0.0] 34211
23 38.7 0.0 43.4 49.5 30.6 148 [3.0] [0.0] 36367
24 27.7 0.0 45.1 50.2 34.2 218 [2.0] [0.0] 31492
DUT GLONASS L1(CA)

SV AvgEl AvgOffset AvgCNo MaxCNo MinCNo Slip_Count FDMA Ant N_Samples
1 36.6 0.0 42.4 47.9 27.5 154 [1.0] [0.0] 28451
2 42.2 0.0 46.6 52.6 35.1 0 [-4.0] [0.0] 21333
3 38.2 0.0 42.9 50.9 28.5 82 [5.0] [0.0] 23117
4 31.5 0.0 43.0 50.2 31.7 124 [6.0] [0.0] 25654
5 28.5 0.0 44.9 50.9 36.1 29 [1.0] [0.0] 26715
6 30.1 0.0 33.5 41.1 0.0 4191 [-4.0] [0.0] 31537
7 40.7 0.0 43.4 49.9 28.2 280 [5.0] [0.0] 35465
8 45.7 0.0 43.2 48.7 25.1 37 [6.0] [0.0] 32697
9 35.5 0.0 45.1 53.1 33.3 52 [-2.0] [0.0] 28065
10 33.7 0.0 40.9 47.6 29.4 114 [-7.0] [0.0] 29236
11 33.1 0.0 46.0 51.7 34.1 151 [0.0] [0.0] 29585
12 35.0 0.0 45.4 52.6 31.0 65 [-1.0] [0.0] 28540
13 44.5 0.0 36.4 43.2 25.9 60 [-2.0] [0.0] 20167
14 39.7 0.0 48.0 53.9 31.9 0 [-7.0] [0.0] 22968
15 38.9 0.0 47.6 52.7 37.3 0 [0.0] [0.0] 23358
16 36.9 0.0 46.0 52.7 31.1 187 [-1.0] [0.0] 25442
17 30.0 0.0 43.9 50.6 30.6 65 [4.0] [0.0] 26229
18 35.0 0.0 44.4 51.8 29.2 174 [-3.0] [0.0] 24493
19 41.3 0.0 33.4 39.8 17.7 3634 [3.0] [0.0] 21648
20 39.5 0.0 34.8 40.7 14.4 801 [2.0] [0.0] 22512
21 36.5 0.0 44.7 50.1 32.3 72 [4.0] [0.0] 28850
22 43.7 0.0 45.8 52.8 25.5 90 [-3.0] [0.0] 34249
23 38.7 0.0 42.5 48.7 28.4 230 [3.0] [0.0] 36368
24 27.8 0.0 44.6 49.8 35.0 169 [2.0] [0.0] 31483
DIFF GLONASS L1(CA)

SV AvgEl AvgCNoDiff MaxCNoDiff MinCNoDiff FDMA N_Samples
1 36.6 0.7 10.8 -5.9 [1.0] 28451
2 42.3 1.5 8.9 -4.2 [-4.0] 21295
3 38.2 1.4 9.8 -9.5 [5.0] 23109
4 31.5 1.1 9.1 -17.9 [6.0] 25641
5 28.5 0.6 8.9 -18.6 [1.0] 26695
6 30.1 1.7 27.9 -8.3 [-4.0] 31537
7 40.8 1.2 10.0 -7.9 [5.0] 35431
8 45.7 0.8 16.5 -6.9 [6.0] 32697
9 35.5 0.6 7.9 -15.0 [-2.0] 28052
10 33.7 0.8 8.3 -9.9 [-7.0] 29221
11 33.1 0.8 7.9 -24.4 [0.0] 29574
12 35.0 0.6 8.9 -8.7 [-1.0] 28524
13 44.6 0.6 5.8 -13.8 [-2.0] 20128
14 39.7 0.8 14.1 -9.0 [-7.0] 22968
15 38.9 0.4 7.6 -6.2 [0.0] 23358
16 36.9 1.0 10.1 -6.0 [-1.0] 25442
17 30.0 1.2 9.0 -8.9 [4.0] 26212
18 35.0 1.3 12.0 -5.7 [-3.0] 24489
19 41.3 1.1 12.1 -11.5 [3.0] 21630
20 39.5 0.9 13.7 -13.3 [2.0] 22511
21 36.5 1.0 8.1 -7.5 [4.0] 28847
22 43.7 1.1 10.5 -9.9 [-3.0] 34203
23 38.7 0.9 8.5 -8.8 [3.0] 36355
24 27.8 0.5 6.6 -7.8 [2.0] 31454
REF GLONASS L1(P)

SV AvgEl AvgOffset AvgCNo MaxCNo MinCNo Slip_Count FDMA Ant N_Samples
1 36.6 0.0 41.6 47.0 30.5 224 [1.0] [0.0] 28511
2 42.3 0.0 46.9 52.3 37.9 0 [-4.0] [0.0] 21295
3 38.2 0.0 42.7 49.6 29.7 41 [5.0] [0.0] 23116
4 31.5 0.0 42.4 49.5 30.3 69 [6.0] [0.0] 25660
5 28.5 0.0 44.2 49.0 33.8 50 [1.0] [0.0] 26755
6 30.4 0.0 34.1 40.2 19.8 1484 [-4.0] [0.0] 31003
7 40.7 0.0 43.3 49.0 32.4 335 [5.0] [0.0] 35461
8 45.7 0.0 42.3 47.4 29.4 69 [6.0] [0.0] 32730
9 35.5 0.0 44.1 51.2 31.1 248 [-2.0] [0.0] 28070
10 33.7 0.0 40.5 47.2 29.0 254 [-7.0] [0.0] 29237
11 33.1 0.0 45.2 50.0 30.7 238 [0.0] [0.0] 29588
12 35.0 0.0 45.1 51.8 33.7 102 [-1.0] [0.0] 28524
13 44.7 0.0 35.6 41.7 20.4 454 [-2.0] [0.0] 20094
14 39.7 0.0 47.5 52.4 33.9 0 [-7.0] [0.0] 22971
15 38.9 0.0 46.3 51.2 35.3 0 [0.0] [0.0] 23365
16 36.9 0.0 45.5 52.6 33.2 125 [-1.0] [0.0] 25497
17 30.0 0.0 43.4 49.3 31.2 151 [4.0] [0.0] 26227
18 34.9 0.0 44.3 51.1 33.8 60 [-3.0] [0.0] 24523
19 43.3 0.0 33.1 39.0 20.1 2835 [3.0] [0.0] 20392
20 39.3 0.0 34.5 40.3 21.7 1174 [2.0] [0.0] 22601
21 36.5 0.0 44.2 49.9 32.3 69 [4.0] [0.0] 28855
22 43.7 0.0 45.7 51.9 31.7 278 [-3.0] [0.0] 34211
23 38.7 0.0 41.6 47.6 29.6 244 [3.0] [0.0] 36367
24 27.7 0.0 43.7 48.2 34.4 198 [2.0] [0.0] 31492
DUT GLONASS L1(P)
DIFF GLONASS L1(P)
REF GLONASS L2(CA)

SV AvgEl AvgOffset AvgCNo MaxCNo MinCNo Slip_Count FDMA Ant N_Samples
1 36.6 0.0 39.8 45.1 17.4 597 [1.0] [0.0] 28465
2 42.3 0.0 45.1 49.1 29.2 0 [-4.0] [0.0] 21295
3 38.2 0.0 44.4 50.2 30.1 7 [5.0] [0.0] 23116
4 31.5 0.0 43.3 49.6 27.9 197 [6.0] [0.0] 25660
5 28.5 0.0 43.6 48.8 26.5 172 [1.0] [0.0] 26755
7 40.7 0.0 44.7 50.2 29.2 250 [5.0] [0.0] 35461
8 45.7 0.0 45.6 49.5 31.8 143 [6.0] [0.0] 32730
9 35.5 0.0 44.8 51.2 30.4 177 [-2.0] [0.0] 28070
10 60.2 0.0 33.8 40.9 20.0 10 [-7.0] [0.0] 11
11 33.1 0.0 45.1 50.3 26.4 29 [0.0] [0.0] 29588
12 35.0 0.0 44.5 50.2 34.8 222 [-1.0] [0.0] 28524
13 44.7 0.0 37.7 42.7 22.9 389 [-2.0] [0.0] 20101
14 39.7 0.0 45.0 49.9 12.4 76 [-7.0] [0.0] 22964
15 38.9 0.0 45.7 50.2 33.3 0 [0.0] [0.0] 23365
16 36.9 0.0 45.1 50.0 33.2 210 [-1.0] [0.0] 25497
17 30.0 0.0 44.0 49.5 33.2 80 [4.0] [0.0] 26227
18 34.9 0.0 44.4 50.1 33.1 4 [-3.0] [0.0] 24523
19 41.7 0.0 42.5 48.4 30.2 159 [3.0] [0.0] 21355
20 39.5 0.0 38.1 43.7 19.6 781 [2.0] [0.0] 22493
21 36.5 0.0 44.8 48.9 33.1 218 [4.0] [0.0] 28855
22 43.7 0.0 45.7 50.5 33.4 373 [-3.0] [0.0] 34211
23 63.9 0.0 34.8 42.1 15.2 174 [3.0] [0.0] 116
24 27.7 0.0 43.0 47.9 22.7 472 [2.0] [0.0] 31492
DUT GLONASS L2(CA)

SV AvgEl AvgOffset AvgCNo MaxCNo MinCNo Slip_Count FDMA Ant N_Samples
1 36.6 0.0 38.6 44.0 22.2 496 [1.0] [0.0] 28451
2 42.2 0.0 43.6 48.5 25.4 115 [-4.0] [0.0] 21333
3 38.2 0.0 43.5 49.1 23.8 211 [5.0] [0.0] 23117
4 31.5 0.0 42.5 48.8 17.3 264 [6.0] [0.0] 25633
5 28.5 0.0 42.7 47.7 28.3 105 [1.0] [0.0] 26715
7 40.7 0.0 43.9 49.1 30.1 310 [5.0] [0.0] 35465
8 45.7 0.0 44.3 48.7 19.9 275 [6.0] [0.0] 32692
9 35.5 0.0 43.7 50.8 19.5 293 [-2.0] [0.0] 28055
10 49.8 0.0 25.4 36.2 1.0 12 [-7.0] [0.0] 4
11 33.1 0.0 44.1 49.1 26.4 119 [0.0] [0.0] 29585
12 35.0 0.0 43.6 49.1 32.0 9 [-1.0] [0.0] 28540
13 44.6 0.0 36.6 41.6 19.2 1598 [-2.0] [0.0] 20131
14 39.7 0.0 43.8 48.8 25.4 6 [-7.0] [0.0] 22968
15 38.9 0.0 44.6 49.2 33.7 0 [0.0] [0.0] 23358
16 36.9 0.0 43.9 49.3 30.3 130 [-1.0] [0.0] 25442
17 30.0 0.0 43.3 48.7 31.2 91 [4.0] [0.0] 26229
18 35.0 0.0 43.4 49.1 26.4 99 [-3.0] [0.0] 24493
19 41.4 0.0 41.7 47.5 22.2 164 [3.0] [0.0] 21533
20 39.6 0.0 37.2 42.8 20.4 898 [2.0] [0.0] 22391
21 36.5 0.0 43.9 48.1 30.6 247 [4.0] [0.0] 28850
22 43.7 0.0 44.4 50.0 27.1 360 [-3.0] [0.0] 34249
23 61.7 0.0 34.2 41.6 13.7 222 [3.0] [0.0] 81
24 27.8 0.0 41.8 46.7 28.0 230 [2.0] [0.0] 31483
DIFF GLONASS L2(CA)

SV AvgEl AvgCNoDiff MaxCNoDiff MinCNoDiff FDMA N_Samples
1 36.7 1.1 7.2 -11.4 [1.0] 28405
2 42.3 1.4 9.7 -4.3 [-4.0] 21295
3 38.2 0.9 11.7 -5.1 [5.0] 23109
4 31.5 0.9 16.2 -7.9 [6.0] 25630
5 28.5 1.0 7.5 -9.5 [1.0] 26695
7 40.8 0.9 10.3 -7.1 [5.0] 35431
8 45.7 1.3 18.4 -6.6 [6.0] 32692
9 35.5 1.1 17.3 -5.5 [-2.0] 28042
11 33.1 1.0 13.0 -8.4 [0.0] 29574
12 35.0 0.9 8.3 -5.2 [-1.0] 28524
13 44.7 1.1 7.3 -3.2 [-2.0] 20098
14 39.7 1.2 9.9 -23.0 [-7.0] 22961
15 38.9 1.1 7.0 -6.0 [0.0] 23358
16 36.9 1.2 10.2 -5.4 [-1.0] 25442
17 30.0 0.7 7.9 -6.6 [4.0] 26212
18 35.0 1.0 9.9 -5.7 [-3.0] 24489
19 42.0 0.8 14.2 -5.8 [3.0] 21158
20 39.8 1.0 13.1 -9.7 [2.0] 22284
21 36.5 0.9 7.8 -7.1 [4.0] 28847
22 43.7 1.3 9.7 -5.4 [-3.0] 34203
24 27.8 1.2 7.1 -12.1 [2.0] 31454
REF GLONASS L2(P)

SV AvgEl AvgOffset AvgCNo MaxCNo MinCNo Slip_Count FDMA Ant N_Samples
1 36.8 0.0 37.9 42.9 15.5 1026 [1.0] [0.0] 28325
2 42.3 0.0 43.3 47.3 31.4 0 [-4.0] [0.0] 21295
3 38.2 0.0 42.9 48.7 28.5 38 [5.0] [0.0] 23116
4 31.5 0.0 41.5 47.8 27.2 77 [6.0] [0.0] 25660
5 28.5 0.0 42.1 47.2 27.5 75 [1.0] [0.0] 26755
6 53.7 0.0 12.8 14.4 11.7 2 [-4.0] [0.0] 3
7 40.7 0.0 43.4 48.3 28.1 326 [5.0] [0.0] 35461
8 45.7 0.0 44.2 48.0 28.8 64 [6.0] [0.0] 32730
9 35.5 0.0 42.8 49.3 27.3 172 [-2.0] [0.0] 28070
10 29.0 0.0 21.2 33.6 12.6 21 [-7.0] [0.0] 6
11 33.1 0.0 43.4 48.9 25.1 148 [0.0] [0.0] 29588
12 35.0 0.0 42.6 47.9 34.1 49 [-1.0] [0.0] 28524
13 44.7 0.0 39.1 43.9 23.7 434 [-2.0] [0.0] 20101
14 39.7 0.0 43.5 48.7 22.2 120 [-7.0] [0.0] 22971
15 38.9 0.0 44.4 48.5 33.7 0 [0.0] [0.0] 23365
16 36.9 0.0 43.3 48.0 33.2 56 [-1.0] [0.0] 25497
17 30.0 0.0 42.5 47.8 31.7 127 [4.0] [0.0] 26227
18 34.9 0.0 42.8 48.4 33.0 113 [-3.0] [0.0] 24523
19 41.7 0.0 40.9 46.2 31.0 249 [3.0] [0.0] 21355
20 39.6 0.0 36.8 42.6 10.8 1729 [2.0] [0.0] 22401
21 36.5 0.0 43.7 47.5 31.7 226 [4.0] [0.0] 28855
22 43.7 0.0 44.0 49.0 33.6 446 [-3.0] [0.0] 34211
23 56.3 0.0 25.9 42.9 9.4 157 [3.0] [0.0] 53
24 27.8 0.0 41.3 46.2 17.7 467 [2.0] [0.0] 31491
DUT GLONASS L2(P)
DIFF GLONASS L2(P)
REF GLONASS G3(PD)

SV AvgEl AvgOffset AvgCNo MaxCNo MinCNo Slip_Count FDMA Ant N_Samples
9 35.5 0.0 43.6 49.0 24.1 238 [-2.0] [0.0] 28070
21 36.5 0.0 44.2 48.6 33.3 17 [4.0] [0.0] 28855
DUT GLONASS G3(PD)
DIFF GLONASS G3(PD)
REF Galileo L1(MBOC-PD)

SV AvgEl AvgOffset AvgCNo MaxCNo MinCNo Slip_Count SVChan Ant N_Samples
2 17.8 0.0 41.9 46.5 29.4 193 [52.0, 40.0] [0.0] 25895
3 37.0 0.0 45.5 51.0 35.2 0 [51.0] [0.0] 12249
4 33.5 0.0 45.4 49.7 31.5 69 [48.0, 43.0] [0.0] 39032
5 18.9 0.0 41.6 49.0 27.7 139 [53.0, 45.0] [0.0] 14426
7 45.4 0.0 46.5 51.4 31.6 0 [49.0] [0.0] 32695
8 50.4 0.0 47.8 52.8 32.2 0 [50.0] [0.0] 23539
9 33.4 0.0 44.7 50.8 36.4 13 [44.0, 38.0] [0.0] 28364
10 44.7 0.0 47.2 53.5 30.7 0 [53.0] [0.0] 32298
11 48.9 0.0 44.5 49.0 30.7 1 [48.0] [0.0] 28262
12 38.4 0.0 42.2 48.7 28.1 132 [44.0, 39.0] [0.0] 38564
13 38.5 0.0 44.7 50.3 32.6 248 [45.0, 49.0] [0.0] 32916
15 35.4 0.0 44.1 51.1 32.9 123 [46.0, 50.0] [0.0] 16434
19 35.1 0.0 40.9 48.6 28.1 178 [41.0, 44.0] [0.0] 40650
21 45.6 0.0 47.1 54.0 19.2 14 [52.0] [0.0] 30409
24 41.5 0.0 46.7 52.9 31.1 0 [41.0] [0.0] 25963
25 31.2 0.0 44.6 49.6 32.6 0 [45.0] [0.0] 20226
26 33.0 0.0 45.5 50.5 34.6 49 [53.0, 43.0] [0.0] 41374
27 39.9 0.0 46.8 52.9 34.5 0 [40.0] [0.0] 24798
30 26.0 0.0 44.5 49.6 33.8 203 [48.0, 47.0] [0.0] 21881
31 45.7 0.0 47.2 53.7 35.4 0 [47.0] [0.0] 31073
33 34.3 0.0 44.5 50.7 34.2 84 [43.0, 42.0] [0.0] 41017
34 21.1 0.0 43.9 50.1 36.2 212 [52.0, 44.0] [0.0] 11250
36 45.8 0.0 46.8 52.6 36.4 0 [50.0] [0.0] 18834
DUT Galileo L1(MBOC-PD)

SV AvgEl AvgOffset AvgCNo MaxCNo MinCNo Slip_Count SVChan Ant N_Samples
2 17.8 0.0 41.4 47.0 25.8 152 [51.0, 40.0] [0.0] 25922
3 36.9 0.0 44.4 51.1 32.9 0 [52.0] [0.0] 12261
4 33.5 0.0 44.9 50.1 32.6 227 [48.0, 42.0] [0.0] 39031
5 18.9 0.0 40.9 48.1 31.7 265 [45.0, 42.0] [0.0] 14463
7 45.4 0.0 46.4 50.5 36.0 0 [49.0] [0.0] 32699
8 50.4 0.0 47.3 52.1 28.9 2 [53.0] [0.0] 23526
9 33.4 0.0 44.3 50.4 31.7 153 [45.0, 38.0] [0.0] 28315
10 44.7 0.0 47.3 52.8 35.3 0 [51.0] [0.0] 32279
11 48.7 0.0 44.3 48.4 31.4 1 [48.0] [0.0] 28347
12 38.3 0.0 42.0 48.6 28.0 120 [44.0, 39.0] [0.0] 38571
13 38.5 0.0 44.4 49.8 20.3 248 [42.0, 49.0] [0.0] 32928
15 35.3 0.0 43.8 50.4 32.2 207 [46.0, 50.0] [0.0] 16447
19 35.1 0.0 40.6 48.3 0.0 127 [41.0, 44.0] [0.0] 40654
21 45.7 0.0 47.1 53.2 31.6 0 [53.0] [0.0] 30375
24 41.6 0.0 46.2 52.8 34.8 0 [41.0] [0.0] 25910
25 31.2 0.0 44.3 49.4 31.9 0 [45.0] [0.0] 20189
26 33.0 0.0 45.1 50.7 30.8 98 [45.0, 44.0] [0.0] 41338
27 39.9 0.0 45.9 52.3 35.5 0 [40.0] [0.0] 24797
30 26.0 0.0 43.8 50.2 29.5 69 [48.0, 47.0] [0.0] 21864
31 45.6 0.0 46.8 54.6 30.4 1 [47.0] [0.0] 31108
33 34.4 0.0 44.0 49.9 33.9 2 [43.0] [0.0] 40994
34 21.1 0.0 42.9 48.6 35.9 101 [51.0, 44.0] [0.0] 11280
36 46.0 0.0 46.4 52.8 34.7 0 [50.0] [0.0] 18774
DIFF Galileo L1(MBOC-PD)

SV AvgEl AvgCNoDiff MaxCNoDiff MinCNoDiff SVChan N_Samples
2 17.8 0.5 12.4 -14.7 [52.0, 51.0, 40.0] 25893
3 37.0 1.0 6.7 -4.0 [51.0, 52.0] 12249
4 33.6 0.5 7.9 -7.6 [48.0, 43.0, 42.0] 39030
5 18.9 0.7 8.4 -7.5 [53.0, 45.0, 42.0] 14424
7 45.4 0.1 4.0 -7.0 [49.0] 32691
8 50.4 0.5 9.8 -6.7 [50.0, 53.0] 23526
9 33.4 0.4 9.2 -5.1 [44.0, 45.0, 38.0] 28315
10 44.7 -0.1 5.1 -6.7 [53.0, 51.0] 32275
11 48.9 0.1 5.8 -6.8 [48.0] 28262
12 38.4 0.2 9.6 -7.3 [44.0, 39.0] 38542
13 38.5 0.3 14.4 -7.9 [45.0, 42.0, 49.0] 32911
15 35.4 0.3 5.6 -5.4 [46.0, 50.0] 16426
19 35.1 0.3 30.2 -7.2 [41.0, 44.0] 40630
21 45.7 0.0 6.8 -17.4 [52.0, 53.0] 30375
24 41.6 0.5 6.2 -6.5 [41.0] 25910
25 31.2 0.3 8.5 -5.6 [45.0] 20189
26 33.0 0.4 10.5 -5.0 [53.0, 45.0, 43.0, 44.0] 41338
27 39.9 0.9 6.3 -5.4 [40.0] 24778
30 26.1 0.7 8.9 -4.5 [48.0, 47.0] 21841
31 45.7 0.4 12.0 -4.9 [47.0] 31073
33 34.4 0.5 7.1 -4.9 [43.0, 42.0] 40981
34 21.1 1.0 6.2 -2.8 [52.0, 51.0, 44.0] 11250
36 46.0 0.4 7.2 -4.1 [50.0] 18774
REF Galileo L5/E5A(BPSK(10)-PD)

SV AvgEl AvgOffset AvgCNo MaxCNo MinCNo Slip_Count SVChan Ant N_Samples
2 17.8 0.0 42.5 46.5 32.0 144 [52.0, 40.0] [0.0] 25895
3 37.0 0.0 45.8 49.7 37.0 0 [51.0] [0.0] 12249
4 33.5 0.0 45.3 50.0 33.6 165 [48.0, 43.0] [0.0] 39032
5 18.9 0.0 41.8 49.7 33.8 96 [53.0, 45.0] [0.0] 14426
7 45.4 0.0 46.1 50.7 32.5 0 [49.0] [0.0] 32695
8 50.4 0.0 45.9 50.1 31.6 0 [50.0] [0.0] 23539
9 33.4 0.0 44.9 50.1 35.7 199 [44.0, 38.0] [0.0] 28364
10 44.7 0.0 46.0 50.8 35.6 0 [53.0] [0.0] 32298
11 48.9 0.0 42.7 46.4 26.9 11 [48.0] [0.0] 28262
12 38.4 0.0 42.2 48.3 26.8 42 [44.0, 39.0] [0.0] 38564
13 38.5 0.0 45.2 50.3 33.3 220 [45.0, 49.0] [0.0] 32916
15 35.4 0.0 45.4 49.9 39.3 49 [46.0, 50.0] [0.0] 16434
19 35.1 0.0 40.7 47.0 28.3 144 [41.0, 44.0] [0.0] 40650
21 45.6 0.0 45.9 50.4 32.1 0 [52.0] [0.0] 30409
24 41.5 0.0 45.2 49.6 33.4 0 [41.0] [0.0] 25963
25 31.2 0.0 44.4 49.2 32.6 0 [45.0] [0.0] 20226
26 33.0 0.0 44.8 49.1 29.9 124 [53.0, 43.0] [0.0] 41374
27 39.9 0.0 46.1 50.3 37.3 0 [40.0] [0.0] 24798
30 26.0 0.0 44.3 48.5 38.4 109 [48.0, 47.0] [0.0] 21881
31 45.7 0.0 46.0 50.0 34.8 0 [47.0] [0.0] 31073
33 34.3 0.0 45.2 49.8 34.4 223 [43.0, 42.0] [0.0] 41017
34 21.1 0.0 43.1 48.3 35.6 103 [52.0, 44.0] [0.0] 11250
36 45.8 0.0 45.9 50.3 36.0 0 [50.0] [0.0] 18834
DUT Galileo L5/E5A(BPSK(10)-PD)
DIFF Galileo L5/E5A(BPSK(10)-PD)
REF Galileo E5B/B2(BPSK(10)-PD)

SV AvgEl AvgOffset AvgCNo MaxCNo MinCNo Slip_Count SVChan Ant N_Samples
2 17.8 0.0 42.2 46.2 30.7 123 [52.0, 40.0] [0.0] 25895
3 37.0 0.0 46.3 50.3 38.2 0 [51.0] [0.0] 12249
4 33.5 0.0 45.5 50.3 28.7 212 [48.0, 43.0] [0.0] 39032
5 18.9 0.0 41.8 49.8 33.7 243 [53.0, 45.0] [0.0] 14426
7 45.4 0.0 46.5 50.8 29.3 1 [49.0] [0.0] 32695
8 50.4 0.0 46.6 50.9 33.2 0 [50.0] [0.0] 23539
9 33.4 0.0 45.6 50.5 34.1 109 [44.0, 38.0] [0.0] 28364
10 44.7 0.0 46.1 50.1 30.9 0 [53.0] [0.0] 32298
11 48.9 0.0 42.8 46.5 23.6 348 [48.0] [0.0] 28262
12 38.4 0.0 42.5 48.7 29.9 234 [44.0, 39.0] [0.0] 38564
13 38.5 0.0 45.5 50.6 34.6 94 [45.0, 49.0] [0.0] 32916
15 35.4 0.0 45.5 50.5 39.3 198 [46.0, 50.0] [0.0] 16434
19 35.1 0.0 40.8 47.4 27.2 76 [41.0, 44.0] [0.0] 40650
21 45.6 0.0 46.4 50.7 32.7 0 [52.0] [0.0] 30409
24 41.5 0.0 45.5 50.0 33.7 1 [41.0] [0.0] 25963
25 31.2 0.0 44.3 49.0 21.9 44 [45.0] [0.0] 20225
26 33.0 0.0 45.3 50.5 30.5 192 [53.0, 43.0] [0.0] 41374
27 39.9 0.0 46.5 50.7 37.1 0 [40.0] [0.0] 24798
30 26.0 0.0 44.3 48.9 38.4 13 [48.0, 47.0] [0.0] 21881
31 45.7 0.0 46.5 50.5 36.1 0 [47.0] [0.0] 31073
33 34.3 0.0 45.6 50.2 36.1 211 [43.0, 42.0] [0.0] 41017
34 21.1 0.0 43.3 48.2 33.2 114 [52.0, 44.0] [0.0] 11250
36 45.8 0.0 46.3 50.5 37.8 0 [50.0] [0.0] 18834
DUT Galileo E5B/B2(BPSK(10)-PD)
DIFF Galileo E5B/B2(BPSK(10)-PD)
REF Galileo E5A+B(AltBOC-Comp-PD)

SV AvgEl AvgOffset AvgCNo MaxCNo MinCNo Slip_Count SVChan Ant N_Samples
2 17.8 0.0 45.4 49.2 35.8 208 [52.0, 40.0] [0.0] 25895
3 37.0 0.0 48.6 52.3 41.5 0 [51.0] [0.0] 12249
4 33.5 0.0 47.9 52.3 35.5 96 [48.0, 43.0] [0.0] 39032
5 18.9 0.0 44.9 51.7 38.8 240 [53.0, 45.0] [0.0] 14426
7 45.4 0.0 48.8 52.9 34.8 1 [49.0] [0.0] 32695
8 50.4 0.0 48.8 52.7 37.0 1 [50.0] [0.0] 23539
9 33.4 0.0 47.9 52.6 39.1 4 [44.0, 38.0] [0.0] 28364
10 44.7 0.0 48.6 52.4 37.6 1 [53.0] [0.0] 32298
11 48.9 0.0 45.1 48.4 32.0 77 [48.0] [0.0] 28262
12 38.4 0.0 45.3 50.5 33.8 168 [44.0, 39.0] [0.0] 38564
13 38.5 0.0 48.0 52.9 36.1 25 [45.0, 49.0] [0.0] 32916
15 35.4 0.0 48.1 52.3 43.2 120 [46.0, 50.0] [0.0] 16434
19 35.1 0.0 43.9 49.8 30.2 264 [41.0, 44.0] [0.0] 40650
21 45.6 0.0 48.7 52.9 36.8 0 [52.0] [0.0] 30409
24 41.5 0.0 47.9 52.1 33.9 8 [41.0] [0.0] 25963
25 31.2 0.0 47.0 51.2 37.5 0 [45.0] [0.0] 20226
26 33.0 0.0 47.7 51.9 35.6 173 [53.0, 43.0] [0.0] 41374
27 39.9 0.0 48.8 52.5 41.0 0 [40.0] [0.0] 24798
30 26.0 0.0 47.1 50.8 42.3 209 [48.0, 47.0] [0.0] 21881
31 45.7 0.0 48.7 52.3 40.0 0 [47.0] [0.0] 31073
33 34.3 0.0 48.0 52.0 39.3 39 [43.0, 42.0] [0.0] 41017
34 21.1 0.0 46.2 51.0 38.6 86 [52.0, 44.0] [0.0] 11250
36 45.8 0.0 48.6 52.3 41.1 0 [50.0] [0.0] 18834
DUT Galileo E5A+B(AltBOC-Comp-PD)

SV AvgEl AvgOffset AvgCNo MaxCNo MinCNo Slip_Count SVChan Ant N_Samples
2 17.8 0.0 44.9 48.2 34.2 21 [51.0, 40.0] [0.0] 25922
3 36.9 0.0 47.6 51.3 39.9 0 [52.0] [0.0] 12261
4 33.5 0.0 47.4 51.5 38.1 149 [48.0, 42.0] [0.0] 39031
5 18.9 0.0 44.5 51.0 36.2 264 [45.0, 42.0] [0.0] 14463
7 45.4 0.0 48.4 52.1 36.4 0 [49.0] [0.0] 32699
8 50.4 0.0 48.2 51.9 34.0 1 [53.0] [0.0] 23526
9 33.4 0.0 47.3 51.5 38.7 51 [45.0, 38.0] [0.0] 28315
10 44.7 0.0 47.9 51.7 37.6 0 [51.0] [0.0] 32279
11 48.7 0.0 44.4 47.4 34.1 3 [48.0] [0.0] 28347
12 38.3 0.0 44.6 49.7 32.3 84 [44.0, 39.0] [0.0] 38571
13 38.5 0.0 47.3 51.8 32.2 175 [42.0, 49.0] [0.0] 32928
15 35.3 0.0 47.6 51.5 41.4 200 [46.0, 50.0] [0.0] 16447
19 35.1 0.0 43.1 49.3 25.6 487 [41.0, 44.0] [0.0] 40654
21 45.7 0.0 47.9 52.0 35.0 3 [53.0] [0.0] 30374
24 41.6 0.0 47.2 51.1 36.9 0 [41.0] [0.0] 25910
25 31.2 0.0 46.5 50.1 37.5 0 [45.0] [0.0] 20189
26 33.0 0.0 47.4 51.3 38.3 3 [45.0, 44.0] [0.0] 41338
27 39.9 0.0 48.0 51.7 40.8 0 [40.0] [0.0] 24797
30 26.0 0.0 46.8 49.8 41.9 179 [48.0, 47.0] [0.0] 21864
31 45.6 0.0 48.0 51.8 37.5 0 [47.0] [0.0] 31108
33 34.4 0.0 47.4 51.5 39.8 2 [43.0] [0.0] 40994
34 21.1 0.0 45.8 49.8 40.2 87 [51.0, 44.0] [0.0] 11280
36 46.0 0.0 47.7 51.8 39.9 0 [50.0] [0.0] 18774
DIFF Galileo E5A+B(AltBOC-Comp-PD)

SV AvgEl AvgCNoDiff MaxCNoDiff MinCNoDiff SVChan N_Samples
2 17.8 0.5 5.8 -7.7 [52.0, 51.0, 40.0] 25893
3 37.0 1.0 3.4 -1.6 [51.0, 52.0] 12249
4 33.6 0.5 3.1 -3.8 [48.0, 43.0, 42.0] 39030
5 18.9 0.3 4.7 -3.0 [53.0, 45.0, 42.0] 14424
7 45.4 0.4 2.1 -2.6 [49.0] 32691
8 50.4 0.5 6.4 -6.9 [50.0, 53.0] 23526
9 33.4 0.6 5.0 -2.6 [44.0, 45.0, 38.0] 28315
10 44.7 0.7 3.6 -3.5 [53.0, 51.0] 32275
11 48.9 0.7 2.9 -5.4 [48.0] 28262
12 38.4 0.7 5.6 -5.2 [44.0, 39.0] 38542
13 38.5 0.7 10.2 -5.5 [45.0, 42.0, 49.0] 32911
15 35.4 0.5 3.4 -3.0 [46.0, 50.0] 16426
19 35.1 0.9 10.0 -5.2 [41.0, 44.0] 40630
21 45.7 0.8 8.2 -4.5 [52.0, 53.0] 30374
24 41.6 0.7 5.1 -4.4 [41.0] 25910
25 31.2 0.5 2.8 -3.7 [45.0] 20189
26 33.0 0.3 2.7 -4.4 [53.0, 45.0, 43.0, 44.0] 41338
27 39.9 0.8 3.8 -2.8 [40.0] 24778
30 26.1 0.3 2.2 -1.9 [48.0, 47.0] 21841
31 45.7 0.7 3.5 -1.2 [47.0] 31073
33 34.4 0.6 3.5 -3.0 [43.0, 42.0] 40981
34 21.1 0.4 3.1 -3.8 [52.0, 51.0, 44.0] 11250
36 46.0 1.0 3.3 -0.7 [50.0] 18774
REF Galileo E6(BPSK(5)-PD)

SV AvgEl AvgOffset AvgCNo MaxCNo MinCNo Slip_Count SVChan Ant N_Samples
2 17.8 0.0 42.1 46.7 28.6 90 [52.0, 40.0] [0.0] 25895
3 37.0 0.0 46.7 51.2 37.4 0 [51.0] [0.0] 12249
4 33.5 0.0 46.5 51.6 27.5 244 [48.0, 43.0] [0.0] 39032
5 18.9 0.0 41.5 51.3 27.3 198 [53.0, 45.0] [0.0] 14426
7 45.4 0.0 48.1 52.6 26.8 0 [49.0] [0.0] 32695
8 50.4 0.0 48.3 52.1 31.0 0 [50.0] [0.0] 23539
9 33.4 0.0 46.2 52.1 35.7 158 [44.0, 38.0] [0.0] 28364
10 44.7 0.0 48.1 52.4 27.1 0 [53.0] [0.0] 32298
11 48.9 0.0 44.9 49.1 19.9 1 [48.0] [0.0] 28262
12 38.4 0.0 43.5 50.1 30.0 73 [44.0, 39.0] [0.0] 38564
13 38.5 0.0 46.5 52.1 33.0 80 [45.0, 49.0] [0.0] 32916
15 35.4 0.0 46.5 52.0 37.9 192 [46.0, 50.0] [0.0] 16434
19 35.1 0.0 40.8 48.7 27.2 258 [41.0, 44.0] [0.0] 40650
21 45.6 0.0 47.9 52.3 30.5 6 [52.0] [0.0] 30400
24 41.5 0.0 47.4 52.4 34.4 0 [41.0] [0.0] 25963
25 31.2 0.0 45.8 50.8 29.7 0 [45.0] [0.0] 20226
26 33.0 0.0 46.2 51.4 26.5 78 [53.0, 43.0] [0.0] 41374
27 39.9 0.0 47.8 52.3 37.5 0 [40.0] [0.0] 24798
30 26.0 0.0 45.1 50.8 35.4 64 [48.0, 47.0] [0.0] 21881
31 45.7 0.0 48.0 51.9 37.0 0 [47.0] [0.0] 31073
33 34.3 0.0 46.8 52.4 36.3 221 [43.0, 42.0] [0.0] 41017
34 21.1 0.0 43.2 48.8 30.2 240 [52.0, 44.0] [0.0] 11250
36 45.8 0.0 47.5 51.9 36.9 0 [50.0] [0.0] 18834
DUT Galileo E6(BPSK(5)-PD)
DIFF Galileo E6(BPSK(5)-PD)
REF BeiDou L1(BOC-PD)

SV AvgEl AvgOffset AvgCNo MaxCNo MinCNo Slip_Count SVChan Ant N_Samples
19 44.4 0.0 46.8 52.9 36.6 0 [47.0] [0.0] 28176
20 48.8 0.0 48.3 53.4 37.0 0 [42.0] [0.0] 23274
21 31.0 0.0 44.9 51.5 31.9 171 [39.0, 29.0] [0.0] 33997
22 38.7 0.0 45.4 53.0 33.9 149 [51.0, 49.0] [0.0] 30167
23 24.7 0.0 43.0 50.5 27.9 80 [44.0, 27.0] [0.0] 27614
24 45.8 0.0 47.0 52.7 35.5 0 [26.0] [0.0] 26421
25 39.2 0.0 45.6 51.7 31.8 180 [40.0, 52.0] [0.0] 23145
26 44.9 0.0 47.0 52.7 33.8 0 [53.0] [0.0] 28571
27 42.5 0.0 45.9 50.9 33.3 5 [18.0, 42.0] [0.0] 19958
28 48.0 0.0 46.7 52.3 32.4 0 [46.0] [0.0] 24956
29 30.7 0.0 44.0 48.5 33.8 33 [40.0, 34.0] [0.0] 30069
30 28.1 0.0 42.9 50.8 26.9 274 [41.0, 50.0] [0.0] 24990
32 36.8 0.0 45.5 52.4 34.2 34 [48.0, 51.0] [0.0] 21681
33 33.6 0.0 44.8 51.9 32.4 150 [51.0, 49.0] [0.0] 32229
34 45.3 0.0 46.7 52.4 34.5 0 [31.0] [0.0] 27551
35 29.8 0.0 44.3 50.7 31.7 60 [24.0, 16.0] [0.0] 34348
36 44.3 0.0 46.0 52.4 30.4 0 [46.0] [0.0] 24533
37 22.1 0.0 42.9 48.7 31.7 25 [23.0, 16.0] [0.0] 28789
38 7.0 0.0 39.6 41.3 37.1 0 [17.0] [0.0] 1732
41 48.5 0.0 46.1 52.5 28.8 194 [44.0, 14.0] [0.0] 18924
42 29.3 0.0 44.5 49.6 31.6 93 [23.0, 26.0] [0.0] 34854
43 44.7 0.0 46.7 52.3 32.7 0 [52.0] [0.0] 28704
44 35.7 0.0 44.8 52.6 26.8 115 [41.0, 46.0] [0.0] 31317
45 45.3 0.0 47.0 52.6 33.6 0 [45.0] [0.0] 27787
DUT BeiDou L1(BOC-PD)
DIFF BeiDou L1(BOC-PD)
REF BeiDou L5/E5A(I+Q)

SV AvgEl AvgOffset AvgCNo MaxCNo MinCNo Slip_Count SVChan Ant N_Samples
19 44.4 0.0 47.1 50.9 35.1 0 [47.0] [0.0] 28176
20 48.8 0.0 47.5 51.3 38.3 0 [42.0] [0.0] 23274
21 31.0 0.0 45.0 51.1 32.5 155 [39.0, 29.0] [0.0] 33997
22 38.7 0.0 45.8 51.3 35.4 154 [51.0, 49.0] [0.0] 30167
23 24.7 0.0 44.0 49.6 30.6 141 [44.0, 27.0] [0.0] 27614
24 45.8 0.0 47.7 51.9 40.1 0 [26.0] [0.0] 26421
25 39.2 0.0 45.0 49.8 32.2 125 [40.0, 52.0] [0.0] 23145
26 44.9 0.0 46.0 49.9 31.2 0 [53.0] [0.0] 28571
27 42.5 0.0 45.9 49.7 35.5 149 [18.0, 42.0] [0.0] 19958
28 48.0 0.0 45.7 49.4 35.9 0 [46.0] [0.0] 24956
29 30.7 0.0 44.3 49.4 21.1 165 [40.0, 34.0] [0.0] 30068
30 28.1 0.0 43.5 49.9 33.7 264 [41.0, 50.0] [0.0] 24990
32 36.8 0.0 45.4 51.2 34.2 202 [48.0, 51.0] [0.0] 21681
33 33.6 0.0 45.8 51.0 34.8 154 [51.0, 49.0] [0.0] 32229
34 45.3 0.0 45.4 50.0 32.1 0 [31.0] [0.0] 27551
35 29.8 0.0 44.5 48.9 33.5 31 [24.0, 16.0] [0.0] 34348
36 44.3 0.0 46.9 51.7 36.4 0 [46.0] [0.0] 24533
37 22.1 0.0 44.2 48.6 35.2 139 [23.0, 16.0] [0.0] 28789
38 7.0 0.0 41.3 43.6 39.2 0 [17.0] [0.0] 1732
41 48.5 0.0 47.2 51.3 36.5 190 [44.0, 14.0] [0.0] 18924
42 29.3 0.0 45.3 49.7 34.7 6 [23.0, 26.0] [0.0] 34854
43 44.7 0.0 45.5 49.7 27.5 5 [52.0] [0.0] 28704
44 35.7 0.0 44.8 50.9 34.5 1 [41.0, 46.0] [0.0] 31317
45 45.3 0.0 47.2 51.4 33.4 0 [45.0] [0.0] 27787
DUT BeiDou L5/E5A(I+Q)

SV AvgEl AvgOffset AvgCNo MaxCNo MinCNo Slip_Count SVChan Ant N_Samples
19 44.5 0.0 46.1 50.6 35.9 0 [47.0] [0.0] 28127
20 48.9 0.0 46.7 50.5 38.9 0 [50.0] [0.0] 23258
21 31.0 0.0 44.2 50.4 27.8 173 [39.0, 30.0] [0.0] 33974
22 38.7 0.0 44.6 50.2 33.3 93 [52.0, 49.0] [0.0] 30147
23 24.7 0.0 43.4 48.5 33.1 106 [44.0, 27.0] [0.0] 27588
24 45.9 0.0 46.5 51.4 34.4 0 [26.0] [0.0] 26335
25 39.1 0.0 44.2 49.5 24.8 106 [40.0, 53.0] [0.0] 23183
26 44.9 0.0 45.6 49.3 33.4 0 [51.0] [0.0] 28592
27 42.4 0.0 44.8 49.1 36.2 69 [18.0, 43.0] [0.0] 20008
28 48.0 0.0 44.4 48.8 32.3 0 [46.0] [0.0] 24948
29 30.7 0.0 43.6 48.5 20.4 260 [40.0, 34.0] [0.0] 30066
30 28.1 0.0 42.7 48.8 25.3 184 [41.0, 50.0] [0.0] 25016
32 36.8 0.0 44.7 50.3 33.9 158 [48.0, 52.0] [0.0] 21639
33 33.7 0.0 44.5 49.6 33.9 93 [52.0, 49.0] [0.0] 32206
34 45.3 0.0 44.7 49.3 27.8 11 [33.0] [0.0] 27512
35 29.8 0.0 43.6 48.1 34.3 239 [23.0, 16.0] [0.0] 34369
36 44.3 0.0 46.2 50.4 35.0 0 [46.0] [0.0] 24561
37 22.1 0.0 43.6 47.0 34.9 75 [22.0, 16.0] [0.0] 28785
38 7.0 0.0 42.0 43.8 40.4 0 [17.0] [0.0] 1731
41 48.5 0.0 45.7 50.3 34.6 8 [44.0, 14.0] [0.0] 18920
42 29.3 0.0 44.9 47.9 35.4 64 [31.0, 26.0] [0.0] 34821
43 44.7 0.0 45.0 49.0 33.0 0 [53.0] [0.0] 28712
44 35.7 0.0 43.9 50.0 34.0 123 [41.0, 46.0] [0.0] 31366
45 45.3 0.0 46.5 51.4 30.5 0 [42.0] [0.0] 27796
DIFF BeiDou L5/E5A(I+Q)

SV AvgEl AvgCNoDiff MaxCNoDiff MinCNoDiff SVChan N_Samples
19 44.5 1.0 4.8 -3.0 [47.0] 28127
20 48.9 0.8 2.9 -3.7 [42.0, 50.0] 23258
21 31.0 0.7 8.4 -5.9 [39.0, 29.0, 30.0] 33968
22 38.7 1.2 5.2 -3.7 [51.0, 52.0, 49.0] 30140
23 24.7 0.6 4.2 -4.4 [44.0, 27.0] 27582
24 45.9 1.2 7.7 -2.0 [26.0] 26335
25 39.2 0.8 12.4 -7.2 [40.0, 52.0, 53.0] 23145
26 44.9 0.4 3.7 -3.7 [53.0, 51.0] 28570
27 42.5 1.0 4.5 -2.9 [18.0, 42.0, 43.0] 19958
28 48.0 1.4 6.4 -1.3 [46.0] 24948
29 30.7 0.7 16.5 -14.0 [40.0, 34.0] 30047
30 28.1 0.8 14.3 -4.2 [41.0, 50.0] 24990
32 36.8 0.7 3.8 -5.3 [48.0, 51.0, 52.0] 21639
33 33.7 1.3 7.9 -3.7 [51.0, 52.0, 49.0] 32200
34 45.3 0.7 10.2 -5.1 [31.0, 33.0] 27512
35 29.8 0.8 4.7 -3.2 [24.0, 23.0, 16.0] 34346
36 44.3 0.8 6.1 -4.5 [46.0] 24532
37 22.1 0.6 3.7 -3.6 [23.0, 22.0, 16.0] 28779
38 7.0 -0.7 1.3 -2.6 [17.0] 1731
41 48.5 1.5 5.5 -1.9 [44.0, 14.0] 18920
42 29.3 0.5 3.5 -6.4 [23.0, 31.0, 26.0] 34821
43 44.7 0.5 3.9 -9.6 [52.0, 53.0] 28683
44 35.7 0.9 6.1 -3.4 [41.0, 46.0] 31317
45 45.3 0.7 6.8 -4.8 [45.0, 42.0] 27787
REF BeiDou E5B/B2(BPSK(2)-B2)

SV AvgEl AvgOffset AvgCNo MaxCNo MinCNo Slip_Count SVChan Ant N_Samples
11 44.4 0.0 45.4 49.6 35.0 0 [51.0] [0.0] 28365
12 40.1 0.0 44.8 50.8 31.9 229 [44.0, 50.0] [0.0] 29408
14 30.4 0.0 45.2 49.6 37.5 68 [25.0, 13.0] [0.0] 34279
DUT BeiDou E5B/B2(BPSK(2)-B2)

SV AvgEl AvgOffset AvgCNo MaxCNo MinCNo Slip_Count SVChan Ant N_Samples
11 44.4 0.0 45.1 49.1 33.9 0 [52.0] [0.0] 28369
12 40.1 0.0 44.4 50.0 23.5 179 [44.0, 50.0] [0.0] 29422
14 30.4 0.0 44.8 48.6 33.6 268 [24.0, 13.0] [0.0] 34187
DIFF BeiDou E5B/B2(BPSK(2)-B2)

SV AvgEl AvgCNoDiff MaxCNoDiff MinCNoDiff SVChan N_Samples
11 44.4 0.3 5.2 -5.5 [51.0, 52.0] 28342
12 40.2 0.4 11.1 -4.5 [44.0, 50.0] 29378
14 30.4 0.5 6.9 -3.7 [25.0, 24.0, 13.0] 34181
REF BeiDou B1(BPSK(2)-B1)

SV AvgEl AvgOffset AvgCNo MaxCNo MinCNo Slip_Count SVChan Ant N_Samples
11 44.4 0.0 44.9 51.2 30.3 0 [51.0] [0.0] 28370
12 40.1 0.0 42.7 50.1 28.9 236 [44.0, 50.0] [0.0] 29408
14 30.4 0.0 42.1 48.8 30.4 221 [25.0, 13.0] [0.0] 34279
19 44.4 0.0 46.5 53.0 34.5 0 [47.0] [0.0] 28176
20 48.8 0.0 48.7 53.9 37.9 0 [42.0] [0.0] 23274
21 31.0 0.0 44.5 52.0 33.1 115 [39.0, 29.0] [0.0] 33997
22 38.7 0.0 45.5 53.7 32.9 227 [51.0, 49.0] [0.0] 30167
23 24.7 0.0 42.7 49.9 31.2 137 [44.0, 27.0] [0.0] 27614
24 45.8 0.0 46.6 54.4 32.6 0 [26.0] [0.0] 26421
25 39.2 0.0 45.6 52.3 32.5 85 [40.0, 52.0] [0.0] 23146
26 44.9 0.0 47.2 53.0 31.6 0 [53.0] [0.0] 28571
27 42.5 0.0 46.1 51.9 33.2 63 [18.0, 42.0] [0.0] 19958
28 48.0 0.0 46.6 52.7 34.0 0 [46.0] [0.0] 24956
29 30.7 0.0 44.4 49.3 32.4 227 [40.0, 34.0] [0.0] 30069
30 28.1 0.0 42.8 51.0 32.1 273 [41.0, 50.0] [0.0] 24990
32 36.8 0.0 44.9 52.4 29.7 177 [48.0, 51.0] [0.0] 21681
33 33.6 0.0 44.2 51.5 30.2 227 [51.0, 49.0] [0.0] 32229
34 45.3 0.0 46.4 53.4 33.7 0 [31.0] [0.0] 27551
35 29.8 0.0 44.6 51.5 34.4 192 [24.0, 16.0] [0.0] 34348
36 44.3 0.0 45.8 52.9 28.6 0 [46.0] [0.0] 24533
37 22.1 0.0 42.5 47.9 33.6 128 [23.0, 16.0] [0.0] 28789
38 7.0 0.0 39.8 41.7 37.8 0 [17.0] [0.0] 1732
41 48.5 0.0 45.3 52.7 29.9 187 [44.0, 14.0] [0.0] 18924
42 29.3 0.0 43.8 49.8 34.5 174 [23.0, 26.0] [0.0] 34854
43 44.7 0.0 46.6 53.0 32.4 0 [52.0] [0.0] 28704
44 35.7 0.0 44.7 53.6 30.6 22 [41.0, 46.0] [0.0] 31317
45 45.3 0.0 46.6 53.5 29.2 0 [45.0] [0.0] 27787
DUT BeiDou B1(BPSK(2)-B1)

SV AvgEl AvgOffset AvgCNo MaxCNo MinCNo Slip_Count SVChan Ant N_Samples
11 44.4 0.0 45.0 51.0 30.6 0 [52.0] [0.0] 28369
12 40.1 0.0 42.3 50.5 26.7 22 [44.0, 50.0] [0.0] 29422
14 30.4 0.0 41.4 48.2 21.6 330 [24.0, 13.0] [0.0] 34249
19 44.5 0.0 46.3 52.8 35.3 0 [47.0] [0.0] 28127
20 48.9 0.0 48.9 53.7 39.1 0 [50.0] [0.0] 23258
21 31.0 0.0 44.3 52.1 31.2 133 [39.0, 30.0] [0.0] 33974
22 38.7 0.0 45.3 53.2 32.0 188 [52.0, 49.0] [0.0] 30148
23 24.7 0.0 42.4 48.9 15.0 182 [44.0, 27.0] [0.0] 27588
24 45.9 0.0 46.3 53.1 27.0 13 [26.0] [0.0] 26336
25 39.1 0.0 45.1 52.3 27.3 25 [40.0, 53.0] [0.0] 23183
26 44.9 0.0 47.1 52.6 34.7 0 [51.0] [0.0] 28592
27 42.4 0.0 45.9 51.8 33.6 58 [18.0, 43.0] [0.0] 20008
28 48.0 0.0 46.4 52.7 20.6 105 [46.0] [0.0] 24949
29 30.7 0.0 44.4 50.0 31.7 118 [40.0, 34.0] [0.0] 30068
30 28.1 0.0 42.9 50.8 32.7 305 [41.0, 50.0] [0.0] 25016
32 36.8 0.0 45.1 52.3 32.1 32 [48.0, 52.0] [0.0] 21640
33 33.7 0.0 43.6 51.5 27.9 189 [52.0, 49.0] [0.0] 32206
34 45.3 0.0 46.7 52.9 29.3 0 [33.0] [0.0] 27512
35 29.8 0.0 43.8 51.9 19.9 181 [23.0, 16.0] [0.0] 34369
36 44.3 0.0 45.7 52.3 29.9 1 [46.0] [0.0] 24561
37 22.1 0.0 41.6 47.7 26.9 180 [22.0, 16.0] [0.0] 28785
38 7.0 0.0 41.7 43.6 38.6 0 [17.0] [0.0] 1731
41 48.5 0.0 45.4 52.2 30.5 104 [44.0, 14.0] [0.0] 18920
42 29.3 0.0 43.6 49.4 34.1 5 [31.0, 26.0] [0.0] 34821
43 44.7 0.0 46.7 52.0 36.4 0 [53.0] [0.0] 28712
44 35.7 0.0 44.3 52.5 32.5 183 [41.0, 46.0] [0.0] 31366
45 45.3 0.0 46.6 52.7 33.4 0 [42.0] [0.0] 27796
DIFF BeiDou B1(BPSK(2)-B1)

SV AvgEl AvgCNoDiff MaxCNoDiff MinCNoDiff SVChan N_Samples
11 44.4 -0.1 6.7 -6.2 [51.0, 52.0] 28342
12 40.2 0.4 8.7 -6.6 [44.0, 50.0] 29378
14 30.4 0.8 10.8 -7.1 [25.0, 24.0, 13.0] 34243
19 44.5 0.2 5.4 -5.2 [47.0] 28127
20 48.9 -0.2 5.7 -5.1 [42.0, 50.0] 23258
21 31.0 0.2 9.6 -7.3 [39.0, 29.0, 30.0] 33968
22 38.7 0.1 6.9 -5.8 [51.0, 52.0, 49.0] 30141
23 24.7 0.3 19.5 -8.1 [44.0, 27.0] 27582
24 45.9 0.3 10.4 -7.3 [26.0] 26336
25 39.2 0.5 12.1 -7.1 [40.0, 52.0, 53.0] 23146
26 44.9 0.1 7.3 -6.8 [53.0, 51.0] 28570
27 42.5 0.2 7.8 -4.9 [18.0, 42.0, 43.0] 19958
28 48.0 0.1 18.5 -6.3 [46.0] 24949
29 30.7 0.0 7.0 -6.1 [40.0, 34.0] 30050
30 28.1 -0.0 6.8 -8.7 [41.0, 50.0] 24990
32 36.8 -0.2 7.6 -8.6 [48.0, 51.0, 52.0] 21640
33 33.7 0.6 9.6 -7.1 [51.0, 52.0, 49.0] 32200
34 45.3 -0.3 10.0 -5.8 [31.0, 33.0] 27512
35 29.8 0.8 18.2 -4.2 [24.0, 23.0, 16.0] 34346
36 44.3 0.1 7.4 -7.8 [46.0] 24532
37 22.1 0.9 11.2 -5.9 [23.0, 22.0, 16.0] 28779
38 7.0 -1.9 1.8 -4.6 [17.0] 1731
41 48.5 -0.0 8.5 -8.4 [44.0, 14.0] 18920
42 29.3 0.2 6.3 -4.7 [23.0, 31.0, 26.0] 34821
43 44.7 -0.1 4.4 -7.7 [52.0, 53.0] 28683
44 35.7 0.4 6.9 -8.9 [41.0, 46.0] 31317
45 45.3 -0.0 8.9 -7.9 [45.0, 42.0] 27787
REF BeiDou B3(BPSK(10)-B3)

SV AvgEl AvgOffset AvgCNo MaxCNo MinCNo Slip_Count SVChan Ant N_Samples
11 44.4 0.0 44.6 49.0 26.5 0 [51.0] [0.0] 28365
12 40.1 0.0 43.4 49.9 24.2 127 [44.0, 50.0] [0.0] 29408
14 30.4 0.0 43.4 48.8 32.7 43 [25.0, 13.0] [0.0] 34279
19 44.4 0.0 45.7 49.3 35.1 0 [47.0] [0.0] 28176
20 48.8 0.0 45.9 49.3 34.5 0 [42.0] [0.0] 23274
21 31.0 0.0 43.5 49.9 31.9 142 [39.0, 29.0] [0.0] 33997
22 38.7 0.0 44.0 50.0 33.8 147 [51.0, 49.0] [0.0] 30167
23 24.7 0.0 41.7 48.8 27.9 44 [44.0, 27.0] [0.0] 27614
24 45.8 0.0 45.7 50.0 36.9 0 [26.0] [0.0] 26421
25 39.2 0.0 44.2 49.3 29.0 141 [40.0, 52.0] [0.0] 23141
26 44.9 0.0 45.3 49.4 31.5 0 [53.0] [0.0] 28571
27 42.5 0.0 44.1 48.6 33.5 246 [18.0, 42.0] [0.0] 19958
28 48.0 0.0 44.3 48.4 34.3 0 [46.0] [0.0] 24956
29 30.7 0.0 42.6 48.2 26.2 132 [40.0, 34.0] [0.0] 30069
30 28.1 0.0 41.1 49.0 26.8 278 [41.0, 50.0] [0.0] 24990
32 36.8 0.0 43.8 49.3 29.2 167 [48.0, 51.0] [0.0] 21681
33 33.6 0.0 43.6 49.6 35.4 147 [51.0, 49.0] [0.0] 32229
34 45.3 0.0 44.4 49.2 30.5 0 [31.0] [0.0] 27551
35 29.8 0.0 43.4 49.1 33.4 188 [24.0, 16.0] [0.0] 34348
36 44.3 0.0 45.1 49.7 29.6 0 [46.0] [0.0] 24533
37 22.1 0.0 41.7 46.7 34.2 128 [23.0, 16.0] [0.0] 28789
38 7.0 0.0 36.8 38.6 34.5 0 [17.0] [0.0] 1732
41 48.5 0.0 45.1 49.6 34.4 223 [44.0, 14.0] [0.0] 18924
42 29.3 0.0 43.8 48.6 32.5 69 [23.0, 26.0] [0.0] 34854
43 44.7 0.0 44.6 48.8 33.1 0 [52.0] [0.0] 28704
44 35.7 0.0 43.2 50.4 29.3 234 [41.0, 46.0] [0.0] 31317
45 45.3 0.0 45.6 50.0 31.0 0 [45.0] [0.0] 27787
DUT BeiDou B3(BPSK(10)-B3)

SV AvgEl AvgOffset AvgCNo MaxCNo MinCNo Slip_Count SVChan Ant N_Samples
11 44.4 0.0 44.4 49.0 29.9 0 [52.0] [0.0] 28369
12 40.1 0.0 43.2 49.5 27.5 111 [44.0, 50.0] [0.0] 29422
14 30.4 0.0 43.1 48.6 32.6 132 [24.0, 13.0] [0.0] 34187
19 44.5 0.0 45.1 49.6 34.1 0 [47.0] [0.0] 28127
20 48.9 0.0 45.4 49.0 34.9 0 [50.0] [0.0] 23258
21 31.0 0.0 43.0 49.4 26.4 2 [39.0, 30.0] [0.0] 33974
22 38.7 0.0 43.3 49.8 28.6 52 [52.0, 49.0] [0.0] 30143
23 24.7 0.0 41.5 48.2 30.8 186 [44.0, 27.0] [0.0] 27552
24 45.9 0.0 45.0 50.1 31.5 13 [26.0] [0.0] 26331
25 39.1 0.0 43.7 48.8 26.7 147 [40.0, 53.0] [0.0] 23178
26 44.9 0.0 44.9 49.1 30.3 0 [51.0] [0.0] 28592
27 42.4 0.0 43.5 48.5 30.8 123 [18.0, 43.0] [0.0] 20008
28 48.2 0.0 43.9 48.5 29.2 10 [46.0] [0.0] 24843
29 30.7 0.0 42.5 48.0 27.1 158 [40.0, 34.0] [0.0] 30068
30 28.1 0.0 41.0 48.0 28.7 259 [41.0, 50.0] [0.0] 25016
32 36.8 0.0 43.6 49.2 31.0 110 [48.0, 52.0] [0.0] 21635
33 33.7 0.0 42.9 48.8 31.8 52 [52.0, 49.0] [0.0] 32206
34 45.3 0.0 44.0 49.1 28.5 0 [33.0] [0.0] 27512
35 29.8 0.0 43.1 48.6 32.3 168 [23.0, 16.0] [0.0] 34334
36 44.3 0.0 44.4 49.5 30.6 1 [46.0] [0.0] 24561
37 22.1 0.0 41.6 45.7 31.7 57 [22.0, 16.0] [0.0] 28785
38 7.0 0.0 37.5 39.9 34.5 0 [17.0] [0.0] 1731
41 48.5 0.0 44.6 49.4 33.0 208 [44.0, 14.0] [0.0] 18920
42 29.3 0.0 43.6 48.1 33.8 38 [31.0, 26.0] [0.0] 34821
43 44.7 0.0 44.3 48.3 31.8 0 [53.0] [0.0] 28712
44 35.7 0.0 42.2 49.1 25.6 52 [41.0, 46.0] [0.0] 31366
45 45.3 0.0 44.8 49.9 16.9 4 [42.0] [0.0] 27772
DIFF BeiDou B3(BPSK(10)-B3)

SV AvgEl AvgCNoDiff MaxCNoDiff MinCNoDiff SVChan N_Samples
11 44.4 0.2 5.9 -6.3 [51.0, 52.0] 28342
12 40.2 0.2 5.1 -11.6 [44.0, 50.0] 29378
14 30.4 0.3 5.5 -3.9 [25.0, 24.0, 13.0] 34181
19 44.5 0.7 6.3 -2.9 [47.0] 28127
20 48.9 0.5 4.3 -3.8 [42.0, 50.0] 23258
21 31.0 0.5 11.5 -6.3 [39.0, 29.0, 30.0] 33968
22 38.7 0.8 8.0 -4.8 [51.0, 52.0, 49.0] 30136
23 24.7 0.2 5.1 -5.8 [44.0, 27.0] 27546
24 45.9 0.7 7.5 -3.0 [26.0] 26331
25 39.2 0.5 11.3 -8.8 [40.0, 52.0, 53.0] 23141
26 44.9 0.4 4.8 -4.3 [53.0, 51.0] 28570
27 42.5 0.6 6.4 -2.6 [18.0, 42.0, 43.0] 19958
28 48.2 0.5 7.5 -3.5 [46.0] 24843
29 30.7 0.1 6.0 -5.6 [40.0, 34.0] 30050
30 28.1 0.1 8.9 -7.3 [41.0, 50.0] 24990
32 36.8 0.2 3.7 -6.5 [48.0, 51.0, 52.0] 21635
33 33.7 0.8 7.6 -2.9 [51.0, 52.0, 49.0] 32200
34 45.3 0.4 11.0 -5.6 [31.0, 33.0] 27512
35 29.8 0.3 5.9 -4.4 [24.0, 23.0, 16.0] 34311
36 44.3 0.6 8.5 -6.6 [46.0] 24532
37 22.1 0.0 6.6 -4.4 [23.0, 22.0, 16.0] 28779
38 7.0 -0.7 1.6 -2.6 [17.0] 1731
41 48.5 0.5 5.1 -3.4 [44.0, 14.0] 18920
42 29.3 0.2 5.0 -4.7 [23.0, 31.0, 26.0] 34821
43 44.7 0.3 3.6 -5.2 [52.0, 53.0] 28683
44 35.7 1.0 10.2 -6.3 [41.0, 46.0] 31317
45 45.3 0.8 22.4 -3.9 [45.0, 42.0] 27763
