Comments


Run with Ch 152 = 925.5 MHz, 1 MHz BW (local whip)

Files


240730/BX_all.T04 240730/EB79_all.T04 240730/EB81_all.T04
Modified: 2024-08-19 17:20:07

Serial Number : 6221C43829
Firmware Date : Mar 6, 2024
Release Ver : 5.70
Nav Proc Ver : 0.47
Radio Lib Ver : None
Primary Antenna Type : MI
Primary Antenna Height : 0.0000 m
Secondary Antenna Type : MI
Secondary Antenna Height : 0.0000 m
week_list : ['2325']
Start Time : 154800.343
Stop Time : 241200.192
Total Hours : 23.99995805555556

Mean Primary Pos: [39.896475383951184, -105.11507168129152]
Mean Secondary Pos: [39.89648139767383, -105.11507019977765]
Mean Heading: 190.7 (deg)
Mean Slope Distance: 0.68054 (m)
 Modified: 2024-08-19 17:20:07

Serial Number : 6348C01835
Firmware Date : Jun 21, 2024
Release Ver : 5.70
Nav Proc Ver : 0.51
Radio Lib Ver : None
Primary Antenna Type : E
Primary Antenna Height : 0.1080 m
Secondary Antenna Type : E
Secondary Antenna Height : 0.1080 m
week_list : ['2325']
Start Time : 154800.179
Stop Time : 244252.434
Total Hours : 24.84784861111111

Mean Primary Pos: [39.89647479940246, -105.11505730784417]
Mean Secondary Pos: [39.89646864988954, -105.1150634927849]
Mean Heading: 37.655 (deg)
Mean Slope Distance: 0.8637 (m)
 Modified: 2024-08-19 17:20:08

Serial Number : 6348C01910
Firmware Date : Jun 21, 2024
Release Ver : 5.70
Nav Proc Ver : 0.51
Radio Lib Ver : None
Primary Antenna Type : -1
Primary Antenna Height : 0.1080 m
Secondary Antenna Type : -1
Secondary Antenna Height : 0.1080 m
week_list : ['2325']
Start Time : 154800.191
Stop Time : 243396.098
Total Hours : 24.609974166666667

Mean Primary Pos: [39.896477857323525, -105.11503901544846]
Mean Secondary Pos: [39.89648238991309, -105.11503892440258]
Mean Heading: 180.88 (deg)
Mean Slope Distance: 0.50406 (m)

Difference Report Links

240730/results/BX_all_0-EB79_all_0.html
240730/results/BX_all_0-EB81_all_0.html
240730/results/BX_all_1-EB79_all_1.html
240730/results/BX_all_1-EB81_all_1.html

Summary Table

SVType Freq Track N_Samples_EB79_0 CNo_Mean_EB79_0 N_Samples_EB81_0 CNo_Mean_EB81_0 N_Samples_EB79_1 CNo_Mean_EB79_1 N_Samples_EB81_1 CNo_Mean_EB81_1
GPS L1 BOC-PD 0 0 0 0
GPS L1 CA 834077 0.2632316920380253 834,363 0.3 834074 0.06372324278181549 834,356 0.1
GPS L2 CM+CL 639096 0.40053763440860213 639,420 0.7 639002 0.12965499325510718 639,388 0.5
GPS L2 E 188903 0.8377288873125363 185,418 1.1 192774 0.19746646331974232 189,679 0.5
GPS L5/E5A I+Q 465189 0.37335384112693965 465,479 0.9 465112 0.21024075921498478 465,461 0.4
SBAS L1 CA 270000 -0.05428962962962963 0 0 0
SBAS L5/E5A I 0 0 0 0
GLONASS L1 CA 657731 0.8185172965847741 657,824 0.9 657977 0.6063678517638156 657,845 0.6
GLONASS L1 P 0 0 0 0
GLONASS L2 CA 559904 0.4639200648682629 559,903 1.0 560327 -0.04452721357350263 560,440 0.3
GLONASS L2 P 0 0 0 0
GLONASS G3 PD 0 0 0 0
Galileo L1 MBOC-PD 0 631,683 0.4 0 631,667 0.0
Galileo L5/E5A BPSK(10)-PD 0 0 0 0
Galileo E5B/B2 BPSK(10)-PD 0 0 0 0
Galileo E5A+B AltBOC-Comp-PD 631841 0.47151055407927006 631,682 0.6 631846 0.31099207718336425 631,693 0.6
Galileo E6 BPSK(5)-PD 631747 0.5480632278427918 0 631845 0.11302661253946776 0
BeiDou L1 BOC-PD 0 0 0 0
BeiDou E5B/B2 BPSK(2)-B2 36122 3.7847239909196615 633,335 0.8 38065 2.9948167608038885 633,340 0.4
BeiDou B1 BPSK(2)-B1 725396 0.07888091470038433 91,901 0.4 725405 -0.16674409467814533 91,963 0.5
BeiDou B3 BPSK(10)-B3 725245 0.40072017042516667 725,306 0.2 725234 0.0061729041936809375 725,321 -0.1
QZSS L1 CA 0 725,023 0.4 0 725,063 0.3
QZSS L1 SLAS 0 0 0 0
QZSS L2 CM+CL 0 0 0 0
QZSS L5/E5A I+Q 0 0 0 0
MSS 0 0 0 0
Total 6365251 0.4272624598778592 0 6101661 0.14935438071698856 0
89,999 Total time (seconds) 6,781,337 0.6 89,999 Total time (seconds) 6,786,216 0.3

Az-El Plots

BX_all_0-EB79_all_0 BX_all_0-EB81_all_0 BX_all_1-EB79_all_1 BX_all_1-EB81_all_1

Mean Elevation Plots

Antenna 0

GPS
SBAS
GLONASS
Galileo
BeiDou

Antenna 1

GPS
GLONASS
Galileo
BeiDou

Oscillation Check

BX_all_0: 1843.6
Antenna SVType Freq Track SV osc_factor
0 GLONASS L1 0 21 1,844
0 GLONASS L1 1 21 1,741
0 GLONASS L1 0 3 1,714
0 GLONASS L1 0 11 1,711
0 GLONASS L1 0 20 1,705
0 GLONASS L1 1 11 1,613
0 GPS L1 0 5 1,549
0 GLONASS L1 0 6 1,477
0 Galileo E6 36 2 1,475
0 GLONASS L1 0 19 1,469
EB79_all_0: 1730.1
Antenna SVType Freq Track SV osc_factor
0 GLONASS L1 0 20 1,730
0 GPS L1 0 15 1,690
0 GPS L1 0 8 1,653
0 GLONASS L1 0 3 1,639
0 GLONASS L1 0 6 1,608
0 Galileo E6 36 5 1,584
0 GLONASS L1 0 15 1,555
0 BeiDou B1 26 23 1,535
0 GPS L1 0 12 1,429
0 GPS L1 0 25 1,387
EB81_all_0: 2069.3
Antenna SVType Freq Track SV osc_factor
0 BeiDou B1 26 23 2,069
0 GLONASS L1 0 20 1,787
0 GLONASS L2 0 16 1,420
0 GPS L1 0 6 1,390
0 GPS L1 0 12 1,366
0 GPS L1 0 25 1,365
0 GLONASS L1 0 6 1,318
0 GLONASS L2 0 2 1,300
0 BeiDou B1 26 41 1,281
0 GLONASS L1 0 19 1,267
BX_all_1: 1640.0
Antenna SVType Freq Track SV osc_factor
1 GLONASS L1 1 12 1,640
1 GLONASS L1 0 12 1,613
1 BeiDou L1 20 26 1,612
1 GLONASS L1 1 21 1,523
1 GPS L1 0 5 1,517
1 GPS L1 0 6 1,458
1 GLONASS L2 0 9 1,447
1 GLONASS L1 0 11 1,443
1 GLONASS L1 0 21 1,388
1 GLONASS L1 0 20 1,360
EB79_all_1: 1750.7
Antenna SVType Freq Track SV osc_factor
1 BeiDou B1 26 26 1,751
1 GLONASS L1 0 2 1,514
1 GLONASS L1 0 20 1,410
1 GLONASS L1 0 3 1,389
1 GPS L2 2 16 1,337
1 GLONASS L1 0 11 1,328
1 GLONASS L1 0 12 1,302
1 GPS L1 0 14 1,240
1 GLONASS L1 0 21 1,237
1 GLONASS L1 0 6 1,225
EB81_all_1: 1708.5
Antenna SVType Freq Track SV osc_factor
1 GLONASS L1 0 21 1,709
1 Galileo L1 23 30 1,589
1 GLONASS L1 0 13 1,582
1 GPS L1 0 22 1,548
1 GLONASS L1 0 12 1,509
1 GLONASS L1 0 14 1,427
1 GLONASS L1 0 19 1,427
1 BeiDou B1 26 43 1,348
1 GLONASS L2 0 15 1,346
1 GLONASS L2 0 16 1,280
