REF File: 240725/BX_all.T04
DUT File: 240725/EB79_all.T04

Ref Statistics

DUT Statistics

Difference Statistics
SVType Freq Track N_Samples CNo_Mean CNo_Median CNo_Std CNo_Min CNo_Max CNo_Range El_Mean El_Max
GPS L1 CA 805678 44.4 44.6 3.8 0.0 55.5 55.5 37.1 89.0
GPS L2 CM+CL 610852 43.9 44.5 4.0 18.4 52.6 34.2 38.4 89.0
GPS L2 E 192992 29.9 30.5 6.4 13.9 44.1 30.2 33.0 77.0
GPS L5/E5A I+Q 440796 47.1 47.2 3.4 20.6 54.1 33.5 37.5 88.0
GLONASS L1 CA 645104 44.3 45.3 5.2 18.8 54.6 35.8 36.0 86.0
GLONASS L1 P 644963 42.7 43.8 5.1 20.4 52.6 32.2 36.0 86.0
GLONASS L2 CA 575258 43.4 44.0 4.1 16.9 51.0 34.1 35.7 86.0
GLONASS L2 P 575192 41.9 42.4 3.9 9.3 49.1 39.8 35.7 86.0
GLONASS G3 PD 47479 44.3 45.1 3.9 27.9 50.1 22.2 37.5 79.0
Galileo L1 MBOC-PD 639059 45.9 46.1 3.5 26.9 54.8 27.9 38.4 90.0
Galileo L5/E5A BPSK(10)-PD 639059 45.1 45.7 3.3 24.6 51.0 26.4 38.4 90.0
Galileo E5B/B2 BPSK(10)-PD 639056 45.8 46.3 3.3 20.1 51.9 31.8 38.4 90.0
Galileo E5A+B AltBOC-Comp-PD 639059 48.1 48.6 2.8 30.2 53.4 23.2 38.4 90.0
Galileo E6 BPSK(5)-PD 639057 46.6 47.1 4.2 19.3 54.1 34.8 38.4 90.0
BeiDou L1 BOC-PD 604363 45.7 45.8 3.6 16.6 53.7 37.1 37.0 89.0
BeiDou L5/E5A I+Q 604365 45.5 45.9 3.3 19.9 51.7 31.8 37.0 89.0
BeiDou E5B/B2 BPSK(2)-B2 58027 45.8 46.7 3.0 30.7 50.9 20.2 41.2 82.0
BeiDou B1 BPSK(2)-B1 662413 45.6 45.7 3.5 0.0 53.9 53.9 37.4 89.0
BeiDou B3 BPSK(10)-B3 662273 43.9 44.4 3.5 24.9 51.9 27.0 37.4 89.0
start/stop time: 327,600 413,999
Total time: 86,399.0 seconds
Total time: 1,439.983 minutes
Total time: 24.000 hours
Total Samples: 10,325,045
Avg Samples/sec: 119.5

Serial Number : 6221C43829
Firmware Date : Mar 6, 2024
Release Ver : 5.70
Nav Proc Ver : 0.47
Radio Lib Ver : None
Primary Antenna Type : MI
Primary Antenna Height : 0.0000 m
Secondary Antenna Type : MI
Secondary Antenna Height : 0.0000 m
week_list : ['2324']
Start Time : 327600.185
Stop Time : 413412.109
Total Hours : 23.836645555555556
SVType Freq Track N_Samples CNo_Mean CNo_Median CNo_Std CNo_Min CNo_Max CNo_Range El_Mean El_Max
GPS L1 CA 776899 44.3 44.6 3.8 0.0 53.9 53.9 37.1 89.0
GPS L2 CM+CL 519649 43.8 44.4 4.1 19.9 52.1 32.2 38.6 89.0
GPS L2 E 158608 30.0 30.9 6.5 12.6 45.1 32.5 34.0 77.0
GPS L5/E5A I+Q 375375 47.1 47.2 3.6 23.0 54.7 31.7 37.7 88.0
GLONASS L1 CA 588283 43.6 44.8 5.1 19.6 53.9 34.3 36.0 86.0
GLONASS L2 CA 521676 43.3 43.9 4.3 13.8 51.1 37.3 35.7 86.0
Galileo L1 BOC-PD 634338 45.7 45.9 3.6 30.2 54.1 23.9 38.4 90.0
Galileo E5A+B AltBOC-Comp-PD 634338 47.9 48.6 3.0 30.2 53.1 22.9 38.4 90.0
Galileo E6 BPSK(5)-PD 634334 46.4 47.0 4.4 21.7 53.6 31.9 38.4 90.0
BeiDou E5B/B2 BPSK(2)-B2 29324 43.4 44.5 3.1 30.6 48.5 17.9 45.4 82.0
BeiDou B1 BPSK(2)-B1 601119 45.8 46.1 3.6 9.7 53.6 43.9 37.3 89.0
BeiDou B3 BPSK(10)-B3 599812 43.9 44.3 3.7 26.2 51.6 25.4 37.4 89.0
start/stop time: 327,600 413,999
Total time: 86,399.0 seconds
Total time: 1,439.983 minutes
Total time: 24.000 hours
Total Samples: 6,073,755
Avg Samples/sec: 70.3

Serial Number : 6348C01835
Firmware Date : Jun 21, 2024
Release Ver : 5.70
Nav Proc Ver : 0.51
Radio Lib Ver : None
Primary Antenna Type : E
Primary Antenna Height : 0.1080 m
Secondary Antenna Type : E
Secondary Antenna Height : 0.1080 m
week_list : ['2324']
Start Time : 327600.148
Stop Time : 413452.062
Total Hours : 23.847753888888885
SVType Freq Track N_Samples CNo_Mean CNo_Median CNo_Std CNo_Min CNo_Max CNo_Range El_Mean El_Max
GPS L1 CA 776508 +0.1 +0.1 +1.5 -36.4 +24.6 +61.0 +37.1 +89.0
GPS L2 CM+CL 519274 +0.2 +0.1 +1.5 -15.6 +14.6 +30.2 +38.6 +89.0
GPS L2 E 157664 +0.3 +0.2 +1.6 -7.0 +8.5 +15.5 +34.1 +77.0
GPS L5/E5A I+Q 375113 +0.1 +0.0 +1.2 -22.0 +18.9 +40.9 +37.8 +88.0
GLONASS L1 CA 587914 +0.6 +0.6 +1.5 -13.4 +15.0 +28.4 +36.0 +86.0
GLONASS L2 CA 521336 +0.1 +0.1 +1.5 -12.5 +18.1 +30.6 +35.8 +86.0
Galileo E5A+B AltBOC-Comp-PD 633934 +0.2 +0.1 +0.8 -4.4 +6.9 +11.3 +38.5 +90.0
Galileo E6 BPSK(5)-PD 633930 +0.2 +0.1 +1.4 -12.4 +10.5 +22.9 +38.5 +90.0
BeiDou E5B/B2 BPSK(2)-B2 29322 +3.2 +2.9 +1.4 -2.9 +9.5 +12.4 +45.5 +82.0
BeiDou B1 BPSK(2)-B1 600872 -0.2 -0.2 +1.4 -29.0 +22.9 +51.9 +37.4 +89.0
BeiDou B3 BPSK(10)-B3 599486 +0.1 +0.0 +1.3 -8.1 +10.7 +18.8 +37.4 +89.0
start/stop time: 327,600 413,999
Total time: 86,399.0 seconds
Total time: 1,439.983 minutes
Total time: 24.000 hours
Total Samples: 5,435,353
Avg Samples/sec: 62.9

Statistics for full C/No Observations dataset
(df_ref - df_dut => positive numbers mean DUT is worse)
Mean = 0.175
Median = 0.100
Std Dev= 1.380

Plots


REF GPS L1(CA)

SV AvgEl AvgOffset AvgCNo MaxCNo MinCNo Slip_Count SVChan Ant N_Samples
2 26.1 0.0 43.3 49.9 27.1 121 [79.0, 87.0] [1.0] 30492
3 32.7 0.0 44.4 52.0 28.2 3 [94.0, 92.0] [1.0] 27069
4 45.4 0.0 44.9 51.3 33.8 0 [95.0] [1.0] 23844
5 40.1 0.0 45.2 50.8 26.0 263 [87.0, 74.0] [1.0] 23003
6 38.4 0.0 44.4 51.8 32.9 146 [86.0, 88.0] [1.0] 24483
7 45.1 0.0 45.7 52.8 28.1 1 [84.0] [1.0] 25484
8 27.4 0.0 42.3 49.4 30.5 111 [95.0, 85.0] [1.0] 29151
9 44.0 0.0 46.2 53.1 34.2 0 [92.0] [1.0] 21426
10 43.4 0.0 46.3 54.7 24.9 267 [93.0, 94.0] [1.0] 26016
11 45.8 0.0 46.1 52.9 32.8 0 [91.0] [1.0] 23288
12 37.2 0.0 45.3 51.6 29.2 109 [95.0, 85.0] [1.0] 24310
13 26.3 0.0 43.4 50.2 29.7 293 [90.0, 79.0, 88.0] [1.0] 30181
14 44.1 0.0 44.6 51.3 27.4 10 [77.0] [1.0] 25733
15 29.2 0.0 43.7 49.6 28.7 364 [87.0, 91.0] [1.0] 28045
16 31.1 0.0 42.6 49.5 30.7 392 [95.0, 90.0] [1.0] 27315
17 45.7 0.0 46.4 52.5 33.2 0 [95.0] [1.0] 24077
18 44.5 0.0 44.6 52.1 32.6 378 [88.0, 93.0] [1.0] 25179
19 44.6 0.0 45.2 51.7 33.7 0 [93.0] [1.0] 24583
20 34.3 0.0 43.5 50.4 30.6 206 [79.0, 83.0] [1.0] 25939
21 26.6 0.0 42.7 49.6 26.6 241 [92.0, 90.0] [1.0] 30259
22 44.4 0.0 44.7 51.8 0.0 93 [75.0] [1.0] 25997
23 43.8 0.0 44.3 52.2 20.3 206 [75.0, 71.0] [1.0] 25797
24 25.6 0.0 41.4 48.4 27.2 195 [84.0, 86.0, 83.0] [1.0] 30007
25 28.6 0.0 42.9 49.8 31.3 5 [89.0, 81.0] [1.0] 28510
26 28.0 0.0 42.5 49.6 31.6 275 [80.0, 86.0] [1.0] 28501
27 26.2 0.0 42.6 49.0 24.6 341 [89.0, 91.0, 85.0] [1.0] 30121
28 39.7 0.0 44.0 49.7 27.7 207 [85.0, 86.0] [1.0] 23151
29 45.4 0.0 45.9 51.9 33.5 407 [72.0, 73.0] [1.0] 22916
30 45.9 0.0 46.3 53.4 31.9 0 [82.0] [1.0] 23639
31 45.3 0.0 46.2 53.2 26.6 1 [88.0] [1.0] 22279
32 44.9 0.0 47.4 55.5 32.4 247 [86.0, 79.0] [1.0] 24883
DUT GPS L1(CA)

SV AvgEl AvgOffset AvgCNo MaxCNo MinCNo Slip_Count SVChan Ant N_Samples
2 26.1 0.0 43.4 48.8 29.7 1317 [75.0, 76.0] [1.0] 29422
3 32.7 0.0 44.1 51.7 30.7 1035 [94.0, 88.0] [1.0] 26307
4 45.6 0.0 44.8 50.9 32.8 702 [78.0] [1.0] 23117
5 40.0 0.0 45.0 51.2 29.5 1159 [76.0] [1.0] 22028
6 38.4 0.0 44.4 52.0 28.8 906 [82.0, 92.0] [1.0] 23845
7 45.1 0.0 45.4 52.3 30.8 698 [83.0] [1.0] 24807
8 27.4 0.0 42.1 49.3 28.6 1217 [84.0, 82.0] [1.0] 28083
9 44.0 0.0 46.1 53.2 34.5 601 [95.0] [1.0] 20855
10 43.3 0.0 46.2 53.4 20.4 1279 [83.0, 81.0] [1.0] 24865
11 45.9 0.0 45.7 52.1 31.1 904 [87.0] [1.0] 22501
12 37.5 0.0 45.3 51.6 29.4 1043 [84.0] [1.0] 23357
13 26.4 0.0 43.2 49.2 27.0 1440 [75.0, 79.0, 86.0] [1.0] 29067
14 44.3 0.0 44.7 50.7 19.7 799 [77.0] [1.0] 24981
15 29.2 0.0 43.9 49.5 30.7 1403 [73.0, 71.0, 74.0] [1.0] 27008
16 31.4 0.0 42.5 48.7 30.6 1053 [89.0, 93.0, 82.0] [1.0] 26326
17 45.8 0.0 46.0 52.1 31.2 655 [85.0] [1.0] 23463
18 44.7 0.0 44.5 50.9 28.6 1390 [91.0, 93.0] [1.0] 24000
19 44.7 0.0 44.9 51.7 33.1 654 [72.0] [1.0] 23967
20 34.2 0.0 43.2 49.3 27.8 1181 [84.0, 83.0] [1.0] 24968
21 26.6 0.0 42.9 49.7 30.6 1164 [77.0, 84.0] [1.0] 29156
22 44.5 0.0 44.9 51.6 31.5 687 [74.0] [1.0] 25351
23 43.9 0.0 44.5 51.2 31.1 1461 [76.0, 71.0] [1.0] 24582
24 25.7 0.0 41.5 48.1 28.2 1395 [95.0, 82.0, 83.0] [1.0] 28836
25 28.6 0.0 43.0 50.1 30.3 1398 [95.0, 80.0] [1.0] 27298
26 28.1 0.0 42.5 49.4 29.6 1106 [85.0, 77.0] [1.0] 27493
27 26.2 0.0 42.8 49.1 0.0 1625 [85.0, 86.0, 84.0] [1.0] 28877
28 39.8 0.0 44.0 50.2 31.2 1247 [86.0, 79.0] [1.0] 22244
29 45.1 0.0 45.6 51.9 31.9 1231 [72.0, 75.0] [1.0] 21961
30 45.9 0.0 46.2 52.5 33.2 658 [80.0] [1.0] 23032
31 45.5 0.0 45.9 53.0 27.5 727 [91.0] [1.0] 21493
32 45.1 0.0 47.2 53.9 33.8 1305 [81.0, 85.0] [1.0] 23609
DIFF GPS L1(CA)

SV AvgEl AvgCNoDiff MaxCNoDiff MinCNoDiff SVChan N_Samples
2 26.1 -0.1 7.8 -9.5 [79.0, 75.0, 87.0, 76.0] 29407
3 32.8 0.3 8.6 -6.8 [94.0, 92.0, 88.0] 26292
4 45.6 0.2 7.7 -5.6 [95.0, 78.0] 23117
5 40.0 0.1 8.7 -9.3 [87.0, 76.0, 74.0] 22017
6 38.5 -0.0 7.2 -5.4 [86.0, 82.0, 88.0, 92.0] 23813
7 45.1 0.2 7.5 -6.7 [84.0, 83.0] 24804
8 27.4 0.2 7.5 -6.5 [95.0, 84.0, 85.0, 82.0] 28076
9 44.0 0.1 6.4 -5.1 [92.0, 95.0] 20855
10 43.4 0.1 13.7 -12.3 [93.0, 83.0, 94.0, 81.0] 24848
11 46.0 0.4 6.5 -4.9 [91.0, 87.0] 22461
12 37.5 0.0 6.4 -5.4 [95.0, 84.0, 85.0] 23356
13 26.4 0.2 10.5 -6.9 [90.0, 75.0, 79.0, 88.0, 86.0] 29049
14 44.3 -0.1 11.1 -7.2 [77.0] 24981
15 29.2 -0.2 5.4 -7.9 [87.0, 73.0, 91.0, 71.0, 74.0] 26994
16 31.4 0.1 6.1 -6.2 [95.0, 89.0, 90.0, 93.0, 82.0] 26321
17 45.8 0.4 7.6 -5.0 [95.0, 85.0] 23463
18 44.7 0.1 9.6 -6.0 [88.0, 91.0, 93.0] 23970
19 44.7 0.3 7.0 -4.2 [93.0, 72.0] 23967
20 34.3 0.2 8.5 -5.2 [79.0, 84.0, 83.0] 24946
21 26.6 -0.2 6.1 -13.5 [92.0, 77.0, 90.0, 84.0] 29152
22 44.5 -0.2 5.2 -36.4 [75.0, 74.0] 25342
23 43.9 -0.2 5.4 -14.3 [75.0, 76.0, 71.0] 24581
24 25.7 -0.1 8.9 -7.3 [84.0, 95.0, 86.0, 82.0, 83.0] 28836
25 28.6 -0.0 6.8 -5.6 [89.0, 95.0, 81.0, 80.0] 27294
26 28.1 0.1 7.9 -5.9 [80.0, 85.0, 86.0, 77.0] 27460
27 26.3 -0.1 24.6 -7.8 [89.0, 85.0, 91.0, 86.0, 84.0] 28834
28 39.8 0.1 5.9 -8.9 [85.0, 86.0, 79.0] 22219
29 45.1 0.3 6.7 -6.1 [72.0, 73.0, 75.0] 21954
30 45.9 0.1 4.8 -7.2 [82.0, 80.0] 23017
31 45.5 0.3 7.3 -7.4 [88.0, 91.0] 21473
32 45.1 0.3 9.0 -5.1 [86.0, 81.0, 79.0, 85.0] 23609
REF GPS L2(E)

SV AvgEl AvgOffset AvgCNo MaxCNo MinCNo Slip_Count SVChan Ant N_Samples
2 26.1 0.0 29.9 36.5 14.8 148 [79.0, 87.0] [1.0] 30492
3 9.0 0.0 20.0 21.1 18.3 14 [94.0] [1.0] 23
13 26.5 0.0 27.5 35.6 13.9 547 [90.0, 79.0, 88.0] [1.0] 29850
16 31.3 0.0 28.0 40.8 14.8 273 [95.0, 90.0] [1.0] 27123
19 44.8 0.0 34.9 44.1 15.6 1 [93.0] [1.0] 24463
20 34.8 0.0 29.9 41.0 13.9 13 [79.0, 83.0] [1.0] 25458
21 26.6 0.0 27.7 36.6 13.9 111 [92.0, 90.0] [1.0] 30096
22 45.1 0.0 32.6 42.0 13.9 6 [75.0] [1.0] 25487
DUT GPS L2(E)

SV AvgEl AvgOffset AvgCNo MaxCNo MinCNo Slip_Count SVChan Ant N_Samples
2 26.6 0.0 29.8 37.1 15.6 756 [75.0, 76.0] [1.0] 25475
13 27.3 0.0 27.4 36.3 12.6 853 [75.0, 79.0, 86.0] [1.0] 23302
16 33.7 0.0 28.5 40.8 13.9 551 [89.0, 93.0, 82.0] [1.0] 21572
19 44.8 0.0 34.7 45.1 16.9 338 [72.0] [1.0] 21889
20 35.0 0.0 29.4 41.7 13.9 730 [84.0, 83.0] [1.0] 19650
21 27.0 0.0 28.1 37.9 12.6 799 [77.0, 84.0] [1.0] 24226
22 45.6 0.0 32.5 41.4 13.9 351 [74.0] [1.0] 22494
DIFF GPS L2(E)

SV AvgEl AvgCNoDiff MaxCNoDiff MinCNoDiff SVChan N_Samples
2 26.6 0.2 8.5 -6.9 [79.0, 75.0, 87.0, 76.0] 25460
13 27.5 0.4 6.4 -6.1 [90.0, 75.0, 79.0, 88.0, 86.0] 23066
16 33.8 0.5 7.0 -5.2 [95.0, 89.0, 90.0, 93.0, 82.0] 21478
19 45.0 0.2 7.4 -6.9 [93.0, 72.0] 21796
20 35.0 0.6 6.6 -6.2 [79.0, 84.0, 83.0] 19631
21 27.0 -0.3 7.4 -7.0 [92.0, 77.0, 90.0, 84.0] 24107
22 46.1 0.3 7.0 -6.8 [75.0, 74.0] 22126
REF GPS L2(CM+CL)

SV AvgEl AvgOffset AvgCNo MaxCNo MinCNo Slip_Count SVChan Ant N_Samples
3 32.8 0.0 43.1 49.8 18.4 271 [94.0, 92.0] [1.0] 27029
4 45.4 0.0 45.0 51.4 32.3 0 [95.0] [1.0] 23844
5 40.1 0.0 43.7 49.3 25.9 95 [87.0, 74.0] [1.0] 23003
6 38.4 0.0 44.7 50.3 19.6 456 [86.0, 88.0] [1.0] 24478
7 45.1 0.0 43.6 49.0 29.7 0 [84.0] [1.0] 25484
8 27.4 0.0 42.4 49.1 26.6 3 [95.0, 85.0] [1.0] 29151
9 44.0 0.0 45.3 50.5 29.2 0 [92.0] [1.0] 21426
10 43.4 0.0 44.5 48.8 31.3 273 [93.0, 94.0] [1.0] 26016
11 45.8 0.0 46.5 51.5 34.6 0 [91.0] [1.0] 23288
12 37.2 0.0 42.2 48.5 26.1 4 [95.0, 85.0] [1.0] 24310
14 44.1 0.0 46.2 51.1 35.0 0 [77.0] [1.0] 25733
15 29.2 0.0 41.5 47.6 27.7 354 [87.0, 91.0] [1.0] 28045
17 45.7 0.0 44.2 50.1 20.8 19 [95.0] [1.0] 24077
18 44.5 0.0 46.0 52.6 33.6 289 [88.0, 93.0] [1.0] 25179
23 43.8 0.0 45.9 51.0 31.5 175 [75.0, 71.0] [1.0] 25797
24 25.6 0.0 42.4 47.3 20.0 275 [84.0, 86.0, 83.0] [1.0] 30005
25 28.6 0.0 41.9 48.4 21.6 174 [89.0, 81.0] [1.0] 28508
26 28.0 0.0 42.1 48.8 26.8 175 [80.0, 86.0] [1.0] 28501
27 26.2 0.0 42.8 48.6 32.4 305 [89.0, 91.0, 85.0] [1.0] 30121
28 39.7 0.0 45.7 51.1 32.1 123 [85.0, 86.0] [1.0] 23151
29 45.4 0.0 43.2 49.9 23.0 224 [72.0, 73.0] [1.0] 22916
30 45.9 0.0 44.6 49.9 31.7 0 [82.0] [1.0] 23639
31 45.3 0.0 44.6 49.6 34.2 0 [88.0] [1.0] 22279
32 45.0 0.0 44.8 49.5 20.7 82 [86.0, 79.0] [1.0] 24872
DUT GPS L2(CM+CL)

SV AvgEl AvgOffset AvgCNo MaxCNo MinCNo Slip_Count SVChan Ant N_Samples
3 32.7 0.0 43.2 50.1 30.4 447 [94.0, 88.0] [1.0] 24368
4 45.7 0.0 44.9 51.8 30.5 357 [78.0] [1.0] 21441
5 38.3 0.0 43.1 50.0 24.6 719 [76.0] [1.0] 18486
6 38.7 0.0 44.5 50.7 29.8 370 [82.0, 92.0] [1.0] 21879
7 45.0 0.0 43.0 49.4 29.3 354 [83.0] [1.0] 23177
8 27.7 0.0 42.5 49.3 29.1 559 [84.0, 82.0] [1.0] 24923
9 43.9 0.0 45.2 50.8 24.7 325 [95.0] [1.0] 19425
10 42.4 0.0 43.9 50.2 31.7 770 [83.0, 81.0] [1.0] 21195
11 47.3 0.0 46.3 51.9 33.6 453 [87.0] [1.0] 19421
12 38.4 0.0 42.4 49.0 23.8 573 [84.0] [1.0] 20263
14 44.4 0.0 46.1 51.1 32.2 355 [77.0] [1.0] 23268
15 28.8 0.0 41.2 48.3 22.5 865 [73.0, 71.0, 74.0] [1.0] 23247
17 45.9 0.0 44.1 50.2 19.9 425 [85.0] [1.0] 21812
18 45.9 0.0 45.7 52.1 30.1 764 [91.0, 93.0] [1.0] 19457
23 44.6 0.0 46.0 51.2 34.2 682 [76.0, 71.0] [1.0] 20283
24 26.0 0.0 42.5 47.4 28.6 834 [95.0, 82.0, 83.0] [1.0] 25254
25 28.3 0.0 42.0 48.5 24.7 799 [95.0, 80.0] [1.0] 23473
26 28.8 0.0 42.4 49.1 29.0 619 [85.0, 77.0] [1.0] 24057
27 26.6 0.0 42.5 48.4 32.5 951 [85.0, 86.0, 84.0] [1.0] 25197
28 40.4 0.0 45.5 51.9 28.6 730 [86.0, 79.0] [1.0] 19262
29 43.3 0.0 42.5 49.8 22.7 799 [72.0, 75.0] [1.0] 18289
30 46.0 0.0 44.4 50.5 32.2 335 [80.0] [1.0] 21449
31 45.4 0.0 44.3 50.6 32.1 362 [91.0] [1.0] 19670
32 43.7 0.0 44.6 49.4 24.1 746 [81.0, 85.0] [1.0] 20353
DIFF GPS L2(CM+CL)

SV AvgEl AvgCNoDiff MaxCNoDiff MinCNoDiff SVChan N_Samples
3 32.7 -0.1 7.3 -15.6 [94.0, 92.0, 88.0] 24313
4 45.7 0.1 6.6 -9.5 [95.0, 78.0] 21441
5 38.3 0.3 10.8 -7.8 [87.0, 76.0, 74.0] 18476
6 38.8 0.3 7.9 -15.4 [86.0, 82.0, 88.0, 92.0] 21842
7 45.0 0.5 7.2 -5.5 [84.0, 83.0] 23174
8 27.7 0.1 7.4 -6.4 [95.0, 84.0, 85.0, 82.0] 24916
9 43.9 0.1 8.1 -9.7 [92.0, 95.0] 19425
10 42.4 0.4 6.8 -4.5 [93.0, 83.0, 94.0, 81.0] 21178
11 47.4 0.3 6.2 -3.3 [91.0, 87.0] 19381
12 38.4 0.0 10.4 -8.6 [95.0, 84.0, 85.0] 20262
14 44.4 0.2 9.3 -5.9 [77.0] 23268
15 28.8 0.1 13.7 -11.0 [87.0, 73.0, 91.0, 71.0, 74.0] 23233
17 45.9 0.2 14.6 -7.3 [95.0, 85.0] 21812
18 46.0 0.4 8.1 -4.4 [88.0, 91.0, 93.0] 19427
23 44.6 0.1 5.2 -8.0 [75.0, 76.0, 71.0] 20282
24 26.0 0.0 5.7 -14.3 [84.0, 95.0, 86.0, 82.0, 83.0] 25252
25 28.4 -0.1 8.7 -7.9 [89.0, 95.0, 81.0, 80.0] 23468
26 28.8 -0.3 5.1 -7.8 [80.0, 85.0, 86.0, 77.0] 24024
27 26.6 0.3 7.3 -6.2 [89.0, 85.0, 91.0, 86.0, 84.0] 25154
28 40.4 0.4 10.2 -5.6 [85.0, 86.0, 79.0] 19238
29 43.3 0.4 7.3 -5.5 [72.0, 73.0, 75.0] 18282
30 46.0 0.3 7.9 -7.3 [82.0, 80.0] 21434
31 45.4 0.4 6.1 -3.9 [88.0, 91.0] 19650
32 43.7 0.1 5.6 -7.9 [86.0, 81.0, 79.0, 85.0] 20342
REF GPS L5/E5A(I+Q)

SV AvgEl AvgOffset AvgCNo MaxCNo MinCNo Slip_Count SVChan Ant N_Samples
3 32.7 0.0 46.5 52.2 35.1 57 [94.0, 92.0] [1.0] 27069
4 45.4 0.0 47.4 53.2 37.8 0 [95.0] [1.0] 23844
6 38.4 0.0 47.4 52.7 36.5 18 [86.0, 88.0] [1.0] 24483
8 27.4 0.0 45.8 51.5 36.0 248 [95.0, 85.0] [1.0] 29151
9 44.0 0.0 47.4 52.2 37.9 0 [92.0] [1.0] 21426
10 43.4 0.0 47.6 51.7 37.3 207 [93.0, 94.0] [1.0] 26016
11 45.8 0.0 48.9 54.1 36.5 0 [91.0] [1.0] 23288
14 44.1 0.0 48.1 53.1 40.1 0 [77.0] [1.0] 25733
18 44.5 0.0 48.2 53.4 37.0 215 [88.0, 93.0] [1.0] 25179
23 43.8 0.0 48.4 53.4 39.7 358 [75.0, 71.0] [1.0] 25797
24 25.6 0.0 46.0 49.1 39.4 205 [84.0, 86.0, 83.0] [1.0] 30007
25 28.6 0.0 46.0 51.2 25.4 60 [89.0, 81.0] [1.0] 28510
26 28.0 0.0 45.4 50.8 35.4 194 [80.0, 86.0] [1.0] 28501
27 26.2 0.0 46.1 50.1 40.2 368 [89.0, 91.0, 85.0] [1.0] 30121
28 39.7 0.0 48.0 53.5 38.1 116 [85.0, 86.0] [1.0] 23151
30 45.9 0.0 47.8 52.7 37.3 0 [82.0] [1.0] 23639
32 45.0 0.0 46.7 51.0 20.6 168 [86.0, 79.0] [1.0] 24881
DUT GPS L5/E5A(I+Q)

SV AvgEl AvgOffset AvgCNo MaxCNo MinCNo Slip_Count SVChan Ant N_Samples
3 32.7 0.0 46.7 53.4 35.7 465 [94.0, 88.0] [1.0] 24399
4 45.7 0.0 47.4 54.6 34.8 365 [78.0] [1.0] 21468
6 38.7 0.0 47.3 53.9 36.2 525 [82.0, 92.0] [1.0] 21902
8 27.7 0.0 46.0 52.4 32.7 777 [84.0, 82.0] [1.0] 24979
9 43.9 0.0 47.4 53.6 33.4 317 [95.0] [1.0] 19446
10 42.3 0.0 47.1 53.0 37.4 698 [83.0, 81.0] [1.0] 21229
11 47.3 0.0 48.9 54.4 34.6 463 [87.0] [1.0] 19447
14 44.4 0.0 47.8 54.4 37.6 365 [77.0] [1.0] 23289
18 45.9 0.0 48.3 54.7 34.6 743 [91.0, 93.0] [1.0] 19502
23 44.6 0.0 48.5 54.3 38.3 859 [76.0, 71.0] [1.0] 20341
24 26.0 0.0 45.6 50.5 23.0 889 [95.0, 82.0, 83.0] [1.0] 25304
25 28.3 0.0 46.1 52.6 31.9 746 [95.0, 80.0] [1.0] 23543
26 28.8 0.0 45.7 52.1 34.8 556 [85.0, 77.0] [1.0] 24116
27 26.5 0.0 45.9 50.8 39.1 987 [85.0, 86.0, 84.0] [1.0] 25257
28 40.4 0.0 48.0 54.3 35.4 576 [86.0, 79.0] [1.0] 19304
30 45.9 0.0 47.8 54.5 35.2 346 [80.0] [1.0] 21479
32 43.7 0.0 46.9 52.9 28.7 645 [81.0, 85.0] [1.0] 20370
DIFF GPS L5/E5A(I+Q)

SV AvgEl AvgCNoDiff MaxCNoDiff MinCNoDiff SVChan N_Samples
3 32.7 -0.3 3.7 -4.5 [94.0, 92.0, 88.0] 24384
4 45.7 0.1 5.7 -6.1 [95.0, 78.0] 21468
6 38.8 0.2 4.4 -5.0 [86.0, 82.0, 88.0, 92.0] 21870
8 27.7 -0.0 4.4 -6.3 [95.0, 84.0, 85.0, 82.0] 24972
9 43.9 -0.0 5.9 -4.0 [92.0, 95.0] 19446
10 42.4 0.3 5.6 -3.5 [93.0, 83.0, 94.0, 81.0] 21212
11 47.4 0.2 4.6 -3.1 [91.0, 87.0] 19407
14 44.4 0.3 4.7 -3.1 [77.0] 23289
18 46.0 0.1 5.4 -3.5 [88.0, 91.0, 93.0] 19472
23 44.6 0.1 4.3 -3.5 [75.0, 76.0, 71.0] 20340
24 26.0 0.4 18.9 -3.5 [84.0, 95.0, 86.0, 82.0, 83.0] 25304
25 28.3 -0.1 4.9 -14.8 [89.0, 95.0, 81.0, 80.0] 23539
26 28.8 -0.2 6.5 -9.0 [80.0, 85.0, 86.0, 77.0] 24083
27 26.6 0.2 5.5 -3.7 [89.0, 85.0, 91.0, 86.0, 84.0] 25214
28 40.4 0.1 4.7 -4.3 [85.0, 86.0, 79.0] 19280
30 46.0 -0.0 5.2 -6.9 [82.0, 80.0] 21464
32 43.7 -0.3 5.3 -22.0 [86.0, 81.0, 79.0, 85.0] 20369
REF GLONASS L1(CA)

SV AvgEl AvgOffset AvgCNo MaxCNo MinCNo Slip_Count FDMA Ant N_Samples
1 30.5 0.0 42.7 49.0 30.7 146 [1.0] [1.0] 32768
2 42.4 0.0 48.0 54.4 29.8 366 [-4.0] [1.0] 31971
3 39.5 0.0 45.8 51.4 31.2 324 [5.0] [1.0] 29177
4 37.0 0.0 44.4 51.3 18.8 174 [6.0] [1.0] 24695
5 41.6 0.0 47.5 52.7 36.4 0 [1.0] [1.0] 21593
6 36.8 0.0 36.3 41.8 23.7 264 [-4.0] [1.0] 23518
7 30.8 0.0 45.5 51.9 35.9 231 [5.0] [1.0] 25848
8 28.3 0.0 43.0 49.5 28.4 76 [6.0] [1.0] 26812
9 39.8 0.0 47.5 53.4 33.1 0 [-2.0] [1.0] 23105
10 38.8 0.0 42.4 48.9 19.7 136 [-7.0] [1.0] 23421
11 37.4 0.0 47.0 53.5 37.0 203 [0.0] [1.0] 24919
12 35.9 0.0 47.6 53.8 30.3 149 [-1.0] [1.0] 27973
13 33.7 0.0 35.9 43.0 25.4 194 [-2.0] [1.0] 29167
14 32.9 0.0 47.2 52.6 34.2 131 [-7.0] [1.0] 29604
15 34.9 0.0 46.8 52.4 29.5 149 [0.0] [1.0] 28513
16 36.4 0.0 47.3 53.8 34.2 118 [-1.0] [1.0] 26584
17 43.5 0.0 46.1 51.5 30.3 670 [4.0] [1.0] 31406
18 32.0 0.0 46.3 54.0 34.5 503 [-3.0] [1.0] 32794
19 28.7 0.0 35.4 41.8 21.5 875 [3.0] [1.0] 27610
20 29.8 0.0 34.6 40.0 22.0 733 [2.0] [1.0] 26352
21 35.4 0.0 45.7 51.6 32.1 42 [4.0] [1.0] 24377
22 44.3 0.0 48.4 54.6 35.5 0 [-3.0] [1.0] 20239
23 38.9 0.0 44.8 50.5 33.2 157 [3.0] [1.0] 22905
24 38.3 0.0 46.0 53.1 26.0 243 [2.0] [1.0] 29753
DUT GLONASS L1(CA)

SV AvgEl AvgOffset AvgCNo MaxCNo MinCNo Slip_Count FDMA Ant N_Samples
1 30.6 0.0 42.1 47.4 31.9 1776 [1.0] [1.0] 29329
2 41.7 0.0 47.3 52.7 33.8 1166 [-4.0] [1.0] 29140
3 39.6 0.0 44.9 50.9 31.5 693 [5.0] [1.0] 26695
4 36.9 0.0 43.8 49.8 26.6 724 [6.0] [1.0] 23044
5 41.6 0.0 46.8 51.4 33.9 746 [1.0] [1.0] 20026
6 36.8 0.0 35.9 41.6 24.0 675 [-4.0] [1.0] 21820
7 30.9 0.0 44.7 51.4 33.1 1723 [5.0] [1.0] 23536
8 28.2 0.0 42.0 48.2 22.4 1587 [6.0] [1.0] 24446
9 39.7 0.0 47.0 53.9 33.4 665 [-2.0] [1.0] 21470
10 38.9 0.0 42.0 47.9 20.5 1489 [-7.0] [1.0] 21731
11 37.2 0.0 46.5 52.7 34.1 1376 [0.0] [1.0] 22726
12 35.3 0.0 46.9 53.3 34.5 993 [-1.0] [1.0] 25705
13 34.3 0.0 35.7 42.2 19.6 2120 [-2.0] [1.0] 25992
14 32.8 0.0 46.6 52.2 23.8 1726 [-7.0] [1.0] 27040
15 35.2 0.0 46.2 51.8 28.8 1886 [0.0] [1.0] 26019
16 36.8 0.0 46.6 52.8 35.7 1783 [-1.0] [1.0] 24307
17 43.0 0.0 45.4 50.7 35.0 2247 [4.0] [1.0] 28473
18 32.2 0.0 45.9 51.8 36.9 2869 [-3.0] [1.0] 29939
19 29.5 0.0 34.8 40.5 19.9 2846 [3.0] [1.0] 24770
20 29.9 0.0 34.0 39.2 21.6 3146 [2.0] [1.0] 24406
21 35.0 0.0 44.9 50.8 30.9 1885 [4.0] [1.0] 22276
22 43.8 0.0 48.1 52.7 37.2 1085 [-3.0] [1.0] 18297
23 39.3 0.0 44.0 50.2 28.7 1822 [3.0] [1.0] 20451
24 38.1 0.0 45.0 50.7 23.1 2935 [2.0] [1.0] 26645
DIFF GLONASS L1(CA)

SV AvgEl AvgCNoDiff MaxCNoDiff MinCNoDiff FDMA N_Samples
1 30.6 0.7 6.6 -5.7 [1.0] 29297
2 41.7 0.6 4.6 -7.9 [-4.0] 29135
3 39.6 0.9 8.1 -6.7 [5.0] 26680
4 36.9 0.5 7.6 -8.2 [6.0] 23044
5 41.6 0.7 6.7 -5.6 [1.0] 20019
6 36.9 0.4 7.2 -4.6 [-4.0] 21790
7 30.9 0.8 7.7 -4.6 [5.0] 23536
8 28.2 1.0 15.0 -3.9 [6.0] 24446
9 39.7 0.5 6.4 -7.1 [-2.0] 21470
10 38.9 0.4 10.5 -13.4 [-7.0] 21731
11 37.2 0.5 6.4 -5.5 [0.0] 22726
12 35.4 0.6 6.0 -8.9 [-1.0] 25675
13 34.3 0.4 8.5 -6.2 [-2.0] 25992
14 32.8 0.6 12.2 -5.6 [-7.0] 27040
15 35.2 0.5 8.3 -8.5 [0.0] 25985
16 36.8 0.8 6.2 -5.0 [-1.0] 24307
17 43.1 0.7 5.8 -7.4 [4.0] 28396
18 32.2 0.4 8.1 -6.8 [-3.0] 29884
19 29.5 0.8 7.4 -9.2 [3.0] 24758
20 30.0 0.6 9.3 -6.3 [2.0] 24351
21 35.0 0.7 6.4 -6.4 [4.0] 22275
22 43.8 0.3 4.7 -5.6 [-3.0] 18297
23 39.3 0.9 9.7 -4.1 [3.0] 20442
24 38.1 0.9 12.9 -8.7 [2.0] 26638
REF GLONASS L1(P)

SV AvgEl AvgOffset AvgCNo MaxCNo MinCNo Slip_Count FDMA Ant N_Samples
1 30.5 0.0 41.2 47.2 29.4 379 [1.0] [1.0] 32766
2 42.4 0.0 46.6 52.2 33.8 315 [-4.0] [1.0] 31969
3 39.5 0.0 44.4 49.4 33.5 99 [5.0] [1.0] 29176
4 37.0 0.0 42.6 49.3 24.8 153 [6.0] [1.0] 24692
5 41.6 0.0 46.1 51.1 36.8 1 [1.0] [1.0] 21592
6 36.8 0.0 34.9 40.4 24.7 217 [-4.0] [1.0] 23507
7 30.8 0.0 43.8 50.2 35.7 2 [5.0] [1.0] 25846
8 28.3 0.0 41.2 47.2 31.0 48 [6.0] [1.0] 26810
9 39.8 0.0 45.9 51.3 33.8 1 [-2.0] [1.0] 23104
10 38.8 0.0 41.0 47.1 20.7 259 [-7.0] [1.0] 23419
11 37.4 0.0 45.3 51.0 36.2 248 [0.0] [1.0] 24917
12 35.9 0.0 46.6 52.3 34.5 11 [-1.0] [1.0] 27971
13 33.7 0.0 34.5 41.4 24.3 494 [-2.0] [1.0] 29163
14 32.9 0.0 45.8 51.0 34.1 110 [-7.0] [1.0] 29602
15 34.9 0.0 45.0 50.3 31.6 11 [0.0] [1.0] 28511
16 36.4 0.0 45.9 52.1 34.2 195 [-1.0] [1.0] 26582
17 43.5 0.0 44.3 49.5 33.3 270 [4.0] [1.0] 31404
18 32.0 0.0 44.8 51.5 36.3 522 [-3.0] [1.0] 32792
19 28.7 0.0 33.5 40.0 20.4 2240 [3.0] [1.0] 27523
20 29.8 0.0 33.5 38.4 21.5 916 [2.0] [1.0] 26348
21 35.4 0.0 44.0 49.5 33.1 13 [4.0] [1.0] 24375
22 44.3 0.0 47.1 52.6 36.6 1 [-3.0] [1.0] 20238
23 38.9 0.0 42.9 48.2 32.5 107 [3.0] [1.0] 22904
24 38.3 0.0 44.3 50.9 26.8 188 [2.0] [1.0] 29752
DUT GLONASS L1(P)
DIFF GLONASS L1(P)
REF GLONASS L2(CA)

SV AvgEl AvgOffset AvgCNo MaxCNo MinCNo Slip_Count FDMA Ant N_Samples
1 30.5 0.0 38.5 45.0 16.9 345 [1.0] [1.0] 32763
2 42.4 0.0 44.6 49.8 28.9 353 [-4.0] [1.0] 31969
3 39.5 0.0 45.2 50.0 28.6 233 [5.0] [1.0] 29176
4 37.0 0.0 44.9 49.9 29.3 161 [6.0] [1.0] 24693
5 41.6 0.0 44.7 49.8 34.1 1 [1.0] [1.0] 21592
7 30.8 0.0 44.3 50.0 17.0 76 [5.0] [1.0] 25838
8 28.3 0.0 44.1 48.3 33.1 149 [6.0] [1.0] 26810
9 39.8 0.0 46.3 50.7 30.0 1 [-2.0] [1.0] 23104
10 53.5 0.0 35.9 41.6 20.5 31 [-7.0] [1.0] 32
11 37.4 0.0 44.6 51.0 29.8 32 [0.0] [1.0] 24917
12 35.9 0.0 44.2 49.9 23.1 50 [-1.0] [1.0] 27971
13 33.7 0.0 36.9 42.2 19.4 535 [-2.0] [1.0] 29162
14 32.9 0.0 44.6 49.3 33.2 165 [-7.0] [1.0] 29602
15 34.9 0.0 44.0 49.9 31.0 49 [0.0] [1.0] 28511
16 36.4 0.0 44.8 49.9 30.7 44 [-1.0] [1.0] 26582
17 43.5 0.0 44.2 49.8 30.9 335 [4.0] [1.0] 31404
18 32.0 0.0 44.0 49.2 22.0 578 [-3.0] [1.0] 32791
19 28.7 0.0 41.5 46.6 20.5 266 [3.0] [1.0] 27604
20 29.8 0.0 37.6 43.8 23.6 60 [2.0] [1.0] 26349
21 35.4 0.0 43.6 49.2 23.6 242 [4.0] [1.0] 24375
22 44.3 0.0 45.9 50.9 32.3 1 [-3.0] [1.0] 20238
23 50.7 0.0 35.5 41.3 18.7 22 [3.0] [1.0] 23
24 38.3 0.0 44.4 49.4 31.5 279 [2.0] [1.0] 29752
DUT GLONASS L2(CA)

SV AvgEl AvgOffset AvgCNo MaxCNo MinCNo Slip_Count FDMA Ant N_Samples
1 30.6 0.0 38.8 45.1 19.8 2218 [1.0] [1.0] 29241
2 41.7 0.0 44.3 49.5 24.7 1251 [-4.0] [1.0] 29074
3 39.6 0.0 45.0 50.0 24.0 719 [5.0] [1.0] 26635
4 36.9 0.0 44.6 49.9 22.5 720 [6.0] [1.0] 23004
5 41.6 0.0 44.6 50.0 30.4 662 [1.0] [1.0] 19989
7 30.9 0.0 44.2 49.5 26.3 1708 [5.0] [1.0] 23481
8 28.2 0.0 43.9 48.8 29.7 1760 [6.0] [1.0] 24395
9 39.7 0.0 46.4 50.8 28.2 903 [-2.0] [1.0] 21429
10 55.4 0.0 32.7 39.9 19.1 310 [-7.0] [1.0] 9
11 37.2 0.0 44.6 51.1 32.2 1283 [0.0] [1.0] 22675
12 35.3 0.0 43.8 49.6 13.8 1202 [-1.0] [1.0] 25648
13 34.7 0.0 36.7 41.9 20.6 2316 [-2.0] [1.0] 25559
14 32.8 0.0 44.5 49.1 33.1 2156 [-7.0] [1.0] 26982
15 35.2 0.0 44.1 49.3 25.4 2247 [0.0] [1.0] 25963
16 36.8 0.0 44.7 49.9 29.5 1831 [-1.0] [1.0] 24253
17 43.0 0.0 44.1 49.8 24.2 2537 [4.0] [1.0] 28402
18 32.2 0.0 43.9 49.1 21.0 2764 [-3.0] [1.0] 29870
19 29.6 0.0 41.5 46.5 29.3 2613 [3.0] [1.0] 24159
20 30.4 0.0 37.7 43.4 24.4 2653 [2.0] [1.0] 23843
21 35.0 0.0 43.4 49.3 22.3 1429 [4.0] [1.0] 22224
22 43.8 0.0 45.8 50.7 20.1 889 [-3.0] [1.0] 18242
23 54.6 0.0 34.5 40.8 20.4 751 [3.0] [1.0] 24
24 38.1 0.0 43.9 48.8 31.8 2342 [2.0] [1.0] 26575
DIFF GLONASS L2(CA)

SV AvgEl AvgCNoDiff MaxCNoDiff MinCNoDiff FDMA N_Samples
1 30.6 -0.2 11.8 -10.1 [1.0] 29207
2 41.7 0.2 10.1 -7.8 [-4.0] 29069
3 39.6 0.1 11.9 -8.2 [5.0] 26620
4 36.9 0.3 14.1 -6.3 [6.0] 23004
5 41.6 0.1 8.0 -5.7 [1.0] 19982
7 31.0 0.1 9.2 -12.5 [5.0] 23474
8 28.2 0.1 7.0 -6.1 [6.0] 24395
9 39.7 -0.1 9.9 -7.6 [-2.0] 21429
11 37.2 -0.1 7.4 -6.7 [0.0] 22675
12 35.3 0.3 18.1 -10.8 [-1.0] 25618
13 34.7 0.4 10.1 -9.3 [-2.0] 25556
14 32.8 0.2 6.5 -5.6 [-7.0] 26982
15 35.2 -0.1 9.8 -5.2 [0.0] 25930
16 36.8 0.1 8.4 -7.3 [-1.0] 24253
17 43.1 0.1 12.0 -7.9 [4.0] 28325
18 32.2 0.2 14.7 -7.2 [-3.0] 29815
19 29.6 0.0 7.1 -11.6 [3.0] 24144
20 30.4 0.1 8.6 -5.6 [2.0] 23825
21 35.0 0.1 6.3 -7.4 [4.0] 22223
22 43.8 0.1 17.2 -4.2 [-3.0] 18242
24 38.1 0.4 8.1 -6.4 [2.0] 26568
REF GLONASS L2(P)

SV AvgEl AvgOffset AvgCNo MaxCNo MinCNo Slip_Count FDMA Ant N_Samples
1 30.5 0.0 36.7 43.1 17.8 1697 [1.0] [1.0] 32759
2 42.4 0.0 42.9 48.2 26.3 344 [-4.0] [1.0] 31969
3 39.5 0.0 43.7 48.4 30.1 355 [5.0] [1.0] 29176
4 37.0 0.0 43.1 48.1 31.8 118 [6.0] [1.0] 24693
5 41.6 0.0 43.2 48.0 32.9 1 [1.0] [1.0] 21592
6 23.5 0.0 16.7 17.1 16.3 1 [-4.0] [1.0] 2
7 30.8 0.0 42.6 47.7 18.7 58 [5.0] [1.0] 25833
8 28.3 0.0 42.5 46.4 33.0 144 [6.0] [1.0] 26810
9 39.8 0.0 44.4 48.8 29.4 1 [-2.0] [1.0] 23104
10 43.9 0.0 21.7 37.2 11.3 10 [-7.0] [1.0] 11
11 37.4 0.0 42.9 49.0 31.0 17 [0.0] [1.0] 24917
12 35.9 0.0 42.2 48.1 18.4 144 [-1.0] [1.0] 27967
13 33.7 0.0 38.3 43.5 18.6 605 [-2.0] [1.0] 29165
14 32.9 0.0 43.0 47.5 32.9 252 [-7.0] [1.0] 29602
15 34.9 0.0 42.5 48.0 27.7 127 [0.0] [1.0] 28511
16 36.4 0.0 43.0 48.4 27.8 53 [-1.0] [1.0] 26582
17 43.5 0.0 42.6 48.4 30.7 392 [4.0] [1.0] 31404
18 32.0 0.0 42.3 47.8 19.4 472 [-3.0] [1.0] 32785
19 28.7 0.0 40.0 45.0 18.4 438 [3.0] [1.0] 27592
20 29.8 0.0 36.2 41.8 20.3 1379 [2.0] [1.0] 26342
21 35.4 0.0 42.4 47.5 21.8 220 [4.0] [1.0] 24375
22 44.3 0.0 44.3 49.1 33.2 1 [-3.0] [1.0] 20238
23 37.6 0.0 26.2 39.7 9.3 10 [3.0] [1.0] 11
24 38.3 0.0 42.6 47.3 31.1 130 [2.0] [1.0] 29752
DUT GLONASS L2(P)
DIFF GLONASS L2(P)
REF GLONASS G3(PD)

SV AvgEl AvgOffset AvgCNo MaxCNo MinCNo Slip_Count FDMA Ant N_Samples
9 39.8 0.0 45.1 49.5 31.8 1 [-2.0] [1.0] 23104
21 35.4 0.0 43.5 50.1 27.9 180 [4.0] [1.0] 24375
DUT GLONASS G3(PD)
DIFF GLONASS G3(PD)
REF Galileo L1(BOC-PD)
DUT Galileo L1(BOC-PD)

SV AvgEl AvgOffset AvgCNo MaxCNo MinCNo Slip_Count SVChan Ant N_Samples
2 45.3 0.0 47.0 52.8 32.2 148 [100.0, 111.0] [1.0] 32654
3 34.6 0.0 46.1 52.6 34.0 546 [111.0, 109.0, 105.0] [1.0] 40457
4 50.0 0.0 46.9 50.5 34.9 39 [100.0, 111.0, 110.0] [1.0] 25085
5 41.0 0.0 46.3 52.6 32.9 1067 [105.0, 110.0, 109.0, 106.0, 108.0, 98.0, 104.0] [1.0] 35820
7 25.6 0.0 43.5 48.9 30.2 335 [106.0, 110.0, 99.0, 105.0] [1.0] 23143
8 33.9 0.0 45.6 52.4 34.6 604 [104.0, 105.0, 108.0, 111.0, 103.0] [1.0] 34366
9 45.3 0.0 46.7 52.4 32.9 217 [99.0, 110.0, 109.0, 108.0] [1.0] 32543
10 39.9 0.0 46.0 52.5 32.1 438 [101.0, 110.0, 109.0, 108.0, 104.0] [1.0] 26796
11 38.2 0.0 43.1 48.2 30.7 606 [96.0, 109.0, 108.0, 107.0, 97.0, 100.0, 106.0] [1.0] 34295
12 38.2 0.0 41.6 46.9 30.8 565 [102.0, 108.0, 107.0, 106.0, 98.0] [1.0] 18004
13 49.9 0.0 46.8 51.3 33.8 281 [99.0, 103.0, 102.0] [1.0] 23652
15 38.2 0.0 45.7 51.7 32.2 590 [107.0, 96.0, 104.0, 102.0, 101.0] [1.0] 38459
19 37.2 0.0 41.7 46.3 35.3 497 [98.0, 107.0, 106.0, 105.0] [1.0] 12209
21 30.9 0.0 44.6 51.1 30.9 270 [100.0, 101.0] [1.0] 19847
24 39.8 0.0 46.7 51.7 35.7 336 [108.0, 106.0, 104.0, 110.0] [1.0] 24482
25 44.4 0.0 46.7 52.0 33.6 1060 [97.0, 106.0, 96.0, 105.0, 100.0] [1.0] 31139
26 34.4 0.0 45.5 51.5 31.5 193 [97.0, 99.0] [1.0] 13561
27 41.4 0.0 47.2 52.6 34.6 341 [97.0, 103.0, 100.0, 98.0] [1.0] 25659
30 45.8 0.0 47.1 54.1 32.2 567 [96.0, 97.0, 104.0, 102.0, 99.0] [1.0] 30882
31 26.2 0.0 44.5 49.5 34.2 394 [106.0, 105.0, 99.0, 98.0] [1.0] 21797
33 16.8 0.0 42.3 46.6 35.8 334 [103.0, 105.0, 97.0] [1.0] 7572
34 34.5 0.0 45.9 51.5 33.5 826 [105.0, 99.0, 98.0, 110.0, 103.0, 101.0] [1.0] 40750
36 33.2 0.0 45.4 51.5 32.1 572 [106.0, 99.0, 97.0, 108.0, 100.0] [1.0] 41166
DIFF Galileo L1(BOC-PD)
REF Galileo L1(MBOC-PD)

SV AvgEl AvgOffset AvgCNo MaxCNo MinCNo Slip_Count SVChan Ant N_Samples
2 45.3 0.0 46.6 51.7 33.2 0 [108.0] [1.0] 32772
3 34.5 0.0 46.4 52.9 33.8 261 [99.0, 104.0] [1.0] 40911
4 49.9 0.0 47.0 50.9 34.2 0 [109.0] [1.0] 25305
5 40.9 0.0 46.5 53.7 26.9 78 [106.0, 100.0] [1.0] 36122
7 25.5 0.0 43.9 48.8 34.8 179 [96.0, 111.0] [1.0] 23470
8 34.0 0.0 45.9 51.8 33.1 218 [107.0, 97.0] [1.0] 34573
9 45.3 0.0 46.5 51.9 36.3 0 [105.0] [1.0] 32659
10 40.1 0.0 46.5 52.9 32.7 98 [99.0, 105.0] [1.0] 26960
11 38.3 0.0 43.2 49.3 28.3 22 [96.0, 101.0] [1.0] 34437
12 38.4 0.0 42.0 46.9 33.2 6 [102.0] [1.0] 18168
13 50.0 0.0 46.3 50.6 31.4 35 [101.0] [1.0] 23912
15 38.2 0.0 45.8 51.3 33.8 268 [102.0, 99.0] [1.0] 38811
19 37.3 0.0 42.1 46.0 34.7 0 [110.0] [1.0] 12376
21 30.9 0.0 44.8 50.9 31.6 153 [106.0] [1.0] 20107
24 39.7 0.0 47.0 52.2 37.9 0 [100.0] [1.0] 24698
25 44.4 0.0 47.3 52.6 35.7 2 [97.0] [1.0] 31297
26 34.4 0.0 46.1 52.2 33.9 254 [109.0] [1.0] 13704
27 41.5 0.0 47.7 53.6 34.1 0 [102.0] [1.0] 25815
30 45.7 0.0 47.7 54.8 33.6 0 [103.0] [1.0] 31103
31 26.2 0.0 44.7 49.7 35.3 96 [107.0, 108.0] [1.0] 21858
33 16.9 0.0 41.8 45.1 33.8 0 [111.0, 105.0] [1.0] 7719
34 34.4 0.0 46.0 52.1 30.1 25 [110.0, 111.0] [1.0] 40966
36 33.2 0.0 45.7 52.2 35.2 132 [104.0, 106.0] [1.0] 41316
DUT Galileo L1(MBOC-PD)
DIFF Galileo L1(MBOC-PD)
REF Galileo L5/E5A(BPSK(10)-PD)

SV AvgEl AvgOffset AvgCNo MaxCNo MinCNo Slip_Count SVChan Ant N_Samples
2 45.3 0.0 46.8 51.0 38.1 0 [108.0] [1.0] 32772
3 34.5 0.0 44.8 49.9 30.4 192 [99.0, 104.0] [1.0] 40911
4 49.9 0.0 46.8 50.3 30.3 0 [109.0] [1.0] 25305
5 40.9 0.0 45.0 50.1 34.8 254 [106.0, 100.0] [1.0] 36122
7 25.5 0.0 43.7 49.8 33.9 246 [96.0, 111.0] [1.0] 23470
8 34.0 0.0 45.7 49.4 38.1 323 [107.0, 97.0] [1.0] 34573
9 45.3 0.0 46.3 50.1 35.9 0 [105.0] [1.0] 32659
10 40.1 0.0 44.9 50.3 34.2 214 [99.0, 105.0] [1.0] 26960
11 38.3 0.0 41.9 46.3 24.6 53 [96.0, 101.0] [1.0] 34437
12 38.4 0.0 42.2 47.9 33.9 9 [102.0] [1.0] 18168
13 50.0 0.0 47.2 50.5 39.3 15 [101.0] [1.0] 23912
15 38.2 0.0 45.6 50.9 30.5 221 [102.0, 99.0] [1.0] 38811
19 37.3 0.0 42.1 46.2 34.6 0 [110.0] [1.0] 12376
21 30.9 0.0 44.9 48.3 36.2 1 [106.0] [1.0] 20107
24 39.7 0.0 45.8 50.2 35.4 0 [100.0] [1.0] 24698
25 44.4 0.0 46.0 50.2 28.8 50 [97.0] [1.0] 31297
26 34.4 0.0 43.7 50.3 34.2 180 [109.0] [1.0] 13704
27 41.5 0.0 45.6 50.3 33.9 0 [102.0] [1.0] 25815
30 45.7 0.0 45.7 50.2 35.5 0 [103.0] [1.0] 31103
31 26.2 0.0 44.3 48.9 36.6 375 [107.0, 108.0] [1.0] 21858
33 16.9 0.0 42.0 46.3 32.4 98 [111.0, 105.0] [1.0] 7719
34 34.4 0.0 45.3 50.9 32.0 251 [110.0, 111.0] [1.0] 40966
36 33.2 0.0 45.4 49.6 37.0 136 [104.0, 106.0] [1.0] 41316
DUT Galileo L5/E5A(BPSK(10)-PD)
DIFF Galileo L5/E5A(BPSK(10)-PD)
REF Galileo E5B/B2(BPSK(10)-PD)

SV AvgEl AvgOffset AvgCNo MaxCNo MinCNo Slip_Count SVChan Ant N_Samples
2 45.3 0.0 47.1 51.9 37.2 0 [108.0] [1.0] 32772
3 34.5 0.0 45.6 50.7 27.8 190 [99.0, 104.0] [1.0] 40911
4 49.9 0.0 47.5 51.7 28.7 0 [109.0] [1.0] 25305
5 40.9 0.0 45.8 51.0 34.5 132 [106.0, 100.0] [1.0] 36122
7 25.5 0.0 44.5 50.3 35.4 285 [96.0, 111.0] [1.0] 23470
8 34.0 0.0 46.0 50.3 22.9 181 [107.0, 97.0] [1.0] 34572
9 45.3 0.0 47.1 51.8 36.4 0 [105.0] [1.0] 32659
10 40.1 0.0 45.8 51.0 22.3 137 [99.0, 105.0] [1.0] 26959
11 38.3 0.0 42.3 46.9 20.1 233 [96.0, 101.0] [1.0] 34436
12 38.4 0.0 42.8 48.7 33.4 6 [102.0] [1.0] 18168
13 50.0 0.0 47.6 51.5 36.0 105 [101.0] [1.0] 23912
15 38.2 0.0 46.1 51.5 28.1 43 [102.0, 99.0] [1.0] 38811
19 37.3 0.0 42.7 46.7 35.7 0 [110.0] [1.0] 12376
21 30.9 0.0 45.5 48.9 38.1 160 [106.0] [1.0] 20107
24 39.7 0.0 46.8 51.2 37.4 0 [100.0] [1.0] 24698
25 44.4 0.0 46.8 51.4 22.0 56 [97.0] [1.0] 31297
26 34.4 0.0 44.7 50.9 35.1 240 [109.0] [1.0] 13704
27 41.5 0.0 46.2 50.8 35.2 0 [102.0] [1.0] 25815
30 45.7 0.0 46.5 51.0 27.4 2 [103.0] [1.0] 31103
31 26.2 0.0 44.7 49.7 37.2 200 [107.0, 108.0] [1.0] 21858
33 16.9 0.0 42.2 46.2 34.9 69 [111.0, 105.0] [1.0] 7719
34 34.4 0.0 46.1 51.5 34.1 12 [110.0, 111.0] [1.0] 40966
36 33.2 0.0 46.0 50.5 36.5 253 [104.0, 106.0] [1.0] 41316
DUT Galileo E5B/B2(BPSK(10)-PD)
DIFF Galileo E5B/B2(BPSK(10)-PD)
REF Galileo E5A+B(AltBOC-Comp-PD)

SV AvgEl AvgOffset AvgCNo MaxCNo MinCNo Slip_Count SVChan Ant N_Samples
2 45.3 0.0 49.5 53.3 42.3 0 [108.0] [1.0] 32772
3 34.5 0.0 47.9 52.6 36.5 235 [99.0, 104.0] [1.0] 40911
4 49.9 0.0 49.6 53.1 35.6 2 [109.0] [1.0] 25305
5 40.9 0.0 48.1 52.8 39.8 140 [106.0, 100.0] [1.0] 36122
7 25.5 0.0 47.0 52.5 38.9 397 [96.0, 111.0] [1.0] 23470
8 34.0 0.0 48.5 52.3 41.0 151 [107.0, 97.0] [1.0] 34573
9 45.3 0.0 49.3 52.9 41.3 0 [105.0] [1.0] 32659
10 40.1 0.0 48.1 52.7 35.8 206 [99.0, 105.0] [1.0] 26960
11 38.3 0.0 44.8 48.3 30.2 30 [96.0, 101.0] [1.0] 34437
12 38.4 0.0 45.5 51.1 37.9 4 [102.0] [1.0] 18168
13 50.0 0.0 49.8 52.9 42.1 205 [101.0] [1.0] 23912
15 38.2 0.0 48.5 53.4 37.0 185 [102.0, 99.0] [1.0] 38811
19 37.3 0.0 45.6 49.3 39.1 0 [110.0] [1.0] 12376
21 30.9 0.0 48.0 51.1 41.8 142 [106.0] [1.0] 20107
24 39.7 0.0 48.9 52.9 40.2 0 [100.0] [1.0] 24698
25 44.4 0.0 49.0 53.0 32.8 8 [97.0] [1.0] 31297
26 34.4 0.0 47.1 52.6 38.9 242 [109.0] [1.0] 13704
27 41.5 0.0 48.5 52.8 38.1 0 [102.0] [1.0] 25815
30 45.7 0.0 48.7 52.7 39.8 0 [103.0] [1.0] 31103
31 26.2 0.0 47.4 51.4 41.0 193 [107.0, 108.0] [1.0] 21858
33 16.9 0.0 45.4 48.7 37.9 1 [111.0, 105.0] [1.0] 7719
34 34.4 0.0 48.4 53.3 38.7 170 [110.0, 111.0] [1.0] 40966
36 33.2 0.0 48.3 52.4 41.4 198 [104.0, 106.0] [1.0] 41316
DUT Galileo E5A+B(AltBOC-Comp-PD)

SV AvgEl AvgOffset AvgCNo MaxCNo MinCNo Slip_Count SVChan Ant N_Samples
2 45.3 0.0 48.9 52.9 37.1 152 [100.0, 111.0] [1.0] 32654
3 34.6 0.0 48.0 52.4 36.7 551 [111.0, 109.0, 105.0] [1.0] 40457
4 50.0 0.0 49.7 52.8 32.7 329 [100.0, 111.0, 110.0] [1.0] 25085
5 41.0 0.0 48.0 52.7 38.1 514 [105.0, 110.0, 109.0, 106.0, 108.0, 98.0, 104.0] [1.0] 35820
7 25.6 0.0 46.9 52.3 38.4 620 [106.0, 110.0, 99.0, 105.0] [1.0] 23143
8 33.9 0.0 48.1 52.1 38.6 300 [104.0, 105.0, 108.0, 111.0, 103.0] [1.0] 34366
9 45.3 0.0 48.9 53.1 39.3 303 [99.0, 110.0, 109.0, 108.0] [1.0] 32543
10 39.9 0.0 48.0 52.9 36.9 543 [101.0, 110.0, 109.0, 108.0, 104.0] [1.0] 26796
11 38.2 0.0 44.7 48.3 30.2 772 [96.0, 109.0, 108.0, 107.0, 97.0, 100.0, 106.0] [1.0] 34295
12 38.2 0.0 45.3 50.8 32.4 320 [102.0, 108.0, 107.0, 106.0, 98.0] [1.0] 18004
13 49.9 0.0 49.4 52.9 39.9 94 [99.0, 103.0, 102.0] [1.0] 23652
15 38.2 0.0 48.3 52.8 37.3 415 [107.0, 96.0, 104.0, 102.0, 101.0] [1.0] 38459
19 37.2 0.0 45.4 49.6 38.0 350 [98.0, 107.0, 106.0, 105.0] [1.0] 12209
21 30.9 0.0 47.7 50.9 39.5 265 [100.0, 101.0] [1.0] 19847
24 39.8 0.0 48.6 52.9 36.4 257 [108.0, 106.0, 104.0, 110.0] [1.0] 24482
25 44.4 0.0 48.7 52.6 36.1 838 [97.0, 106.0, 96.0, 105.0, 100.0] [1.0] 31139
26 34.4 0.0 47.4 52.9 38.5 69 [97.0, 99.0] [1.0] 13561
27 41.4 0.0 48.4 52.3 39.4 469 [97.0, 103.0, 100.0, 98.0] [1.0] 25659
30 45.8 0.0 48.4 52.6 37.7 365 [96.0, 97.0, 104.0, 102.0, 99.0] [1.0] 30882
31 26.2 0.0 47.2 51.5 40.2 270 [106.0, 105.0, 99.0, 98.0] [1.0] 21797
33 16.8 0.0 45.1 48.3 40.0 199 [103.0, 105.0, 97.0] [1.0] 7572
34 34.5 0.0 48.1 52.5 38.4 935 [105.0, 99.0, 98.0, 110.0, 103.0, 101.0] [1.0] 40750
36 33.2 0.0 48.1 52.3 39.6 602 [106.0, 99.0, 97.0, 108.0, 100.0] [1.0] 41166
DIFF Galileo E5A+B(AltBOC-Comp-PD)

SV AvgEl AvgCNoDiff MaxCNoDiff MinCNoDiff SVChan N_Samples
2 45.3 0.5 6.5 -2.0 [108.0, 100.0, 111.0] 32632
3 34.6 -0.0 4.5 -4.4 [99.0, 111.0, 109.0, 104.0, 105.0] 40451
4 50.0 -0.1 4.6 -2.4 [109.0, 100.0, 111.0, 110.0] 25085
5 41.1 0.1 4.1 -3.1 [106.0, 105.0, 110.0, 109.0, 108.0, 100.0, 98.0, 104.0] 35787
7 25.6 0.1 3.7 -3.6 [96.0, 106.0, 110.0, 111.0, 99.0, 105.0] 23134
8 33.9 0.4 4.8 -1.5 [107.0, 104.0, 105.0, 108.0, 97.0, 111.0, 103.0] 34344
9 45.3 0.4 4.2 -1.6 [105.0, 99.0, 110.0, 109.0, 108.0] 32521
10 39.9 0.1 5.3 -3.2 [99.0, 101.0, 110.0, 109.0, 108.0, 105.0, 104.0] 26776
11 38.2 0.0 4.7 -3.0 [96.0, 109.0, 108.0, 107.0, 101.0, 97.0, 100.0, 106.0] 34205
12 38.2 0.2 6.9 -3.3 [102.0, 108.0, 107.0, 106.0, 98.0] 17969
13 49.9 0.4 3.9 -1.5 [101.0, 99.0, 103.0, 102.0] 23652
15 38.2 0.2 3.8 -3.3 [102.0, 107.0, 99.0, 96.0, 104.0, 101.0] 38452
19 37.2 0.2 2.9 -1.8 [110.0, 98.0, 107.0, 106.0, 105.0] 12209
21 30.9 0.3 4.1 -1.8 [106.0, 100.0, 101.0] 19847
24 39.8 0.3 5.3 -1.7 [100.0, 108.0, 106.0, 104.0, 110.0] 24474
25 44.5 0.2 5.4 -4.4 [97.0, 106.0, 96.0, 105.0, 100.0] 31131
26 34.4 -0.3 2.7 -3.7 [109.0, 97.0, 99.0] 13561
27 41.4 0.1 2.9 -3.4 [102.0, 97.0, 103.0, 100.0, 98.0] 25622
30 45.8 0.3 4.0 -2.1 [103.0, 96.0, 97.0, 104.0, 102.0, 99.0] 30865
31 26.2 0.2 3.8 -3.0 [107.0, 106.0, 105.0, 99.0, 108.0, 98.0] 21775
33 16.8 0.3 4.0 -4.4 [111.0, 103.0, 105.0, 97.0] 7572
34 34.5 0.2 3.1 -1.9 [110.0, 105.0, 99.0, 98.0, 111.0, 103.0, 101.0] 40715
36 33.2 0.2 4.2 -3.0 [104.0, 106.0, 99.0, 97.0, 108.0, 100.0] 41155
REF Galileo E6(BPSK(5)-PD)

SV AvgEl AvgOffset AvgCNo MaxCNo MinCNo Slip_Count SVChan Ant N_Samples
2 45.3 0.0 47.9 52.7 30.9 0 [108.0] [1.0] 32772
3 34.5 0.0 45.5 51.9 24.7 389 [99.0, 104.0] [1.0] 40911
4 49.9 0.0 48.8 53.5 27.0 0 [109.0] [1.0] 25305
5 40.9 0.0 47.0 52.8 34.3 89 [106.0, 100.0] [1.0] 36120
7 25.5 0.0 45.3 51.5 23.8 278 [96.0, 111.0] [1.0] 23470
8 34.0 0.0 46.7 51.5 29.7 347 [107.0, 97.0] [1.0] 34573
9 45.3 0.0 47.9 52.5 32.1 0 [105.0] [1.0] 32659
10 40.1 0.0 46.9 54.1 27.0 87 [99.0, 105.0] [1.0] 26960
11 38.3 0.0 43.3 49.8 24.9 44 [96.0, 101.0] [1.0] 34437
12 38.4 0.0 43.5 51.3 30.0 6 [102.0] [1.0] 18168
13 50.0 0.0 48.4 52.1 27.9 217 [101.0] [1.0] 23912
15 38.2 0.0 47.0 52.7 28.3 354 [102.0, 99.0] [1.0] 38811
19 37.3 0.0 42.8 49.7 33.2 0 [110.0] [1.0] 12376
21 30.9 0.0 45.5 50.9 29.9 181 [106.0] [1.0] 20107
24 39.7 0.0 48.1 52.8 35.3 0 [100.0] [1.0] 24698
25 44.4 0.0 48.0 53.2 19.3 2 [97.0] [1.0] 31297
26 34.4 0.0 45.6 51.3 34.1 45 [109.0] [1.0] 13704
27 41.5 0.0 46.9 52.2 30.2 0 [102.0] [1.0] 25815
30 45.7 0.0 48.1 53.2 34.2 0 [103.0] [1.0] 31103
31 26.2 0.0 44.9 50.7 31.2 293 [107.0, 108.0] [1.0] 21858
33 16.9 0.0 42.5 48.1 29.7 243 [111.0, 105.0] [1.0] 7719
34 34.4 0.0 46.9 52.4 36.3 57 [110.0, 111.0] [1.0] 40966
36 33.2 0.0 46.3 52.0 28.9 140 [104.0, 106.0] [1.0] 41316
DUT Galileo E6(BPSK(5)-PD)

SV AvgEl AvgOffset AvgCNo MaxCNo MinCNo Slip_Count SVChan Ant N_Samples
2 45.3 0.0 47.7 52.3 29.8 36 [100.0, 111.0] [1.0] 32654
3 34.6 0.0 45.7 52.5 28.6 625 [111.0, 109.0, 105.0] [1.0] 40457
4 50.0 0.0 48.9 52.7 31.0 249 [100.0, 111.0, 110.0] [1.0] 25085
5 41.1 0.0 46.8 52.8 34.1 767 [105.0, 110.0, 109.0, 106.0, 108.0, 98.0, 104.0] [1.0] 35816
7 25.6 0.0 44.9 52.1 25.7 354 [106.0, 110.0, 99.0, 105.0] [1.0] 23143
8 33.9 0.0 46.5 51.5 27.6 272 [104.0, 105.0, 108.0, 111.0, 103.0] [1.0] 34366
9 45.3 0.0 47.5 52.1 29.3 228 [99.0, 110.0, 109.0, 108.0] [1.0] 32543
10 39.9 0.0 46.5 53.6 28.8 232 [101.0, 110.0, 109.0, 108.0, 104.0] [1.0] 26796
11 38.2 0.0 43.2 49.4 21.7 689 [96.0, 109.0, 108.0, 107.0, 97.0, 100.0, 106.0] [1.0] 34295
12 38.2 0.0 43.1 51.2 28.5 722 [102.0, 108.0, 107.0, 106.0, 98.0] [1.0] 18004
13 49.9 0.0 48.2 51.7 30.0 144 [99.0, 103.0, 102.0] [1.0] 23652
15 38.2 0.0 46.8 52.8 30.4 485 [107.0, 96.0, 104.0, 102.0, 101.0] [1.0] 38459
19 37.2 0.0 43.2 48.8 34.6 465 [98.0, 107.0, 106.0, 105.0] [1.0] 12209
21 30.9 0.0 45.6 50.2 31.9 270 [100.0, 101.0] [1.0] 19847
24 39.8 0.0 47.8 53.0 36.2 272 [108.0, 106.0, 104.0, 110.0] [1.0] 24482
25 44.4 0.0 47.9 53.2 28.3 1123 [97.0, 106.0, 96.0, 105.0, 100.0] [1.0] 31139
26 34.4 0.0 45.6 51.6 34.0 13 [97.0, 99.0] [1.0] 13561
27 41.4 0.0 46.9 52.5 27.6 435 [97.0, 103.0, 100.0, 98.0] [1.0] 25659
30 45.8 0.0 47.9 53.0 34.1 391 [96.0, 97.0, 104.0, 102.0, 99.0] [1.0] 30882
31 26.2 0.0 44.7 50.9 32.8 409 [106.0, 105.0, 99.0, 98.0] [1.0] 21797
33 16.8 0.0 41.7 47.7 33.1 308 [103.0, 105.0, 97.0] [1.0] 7572
34 34.5 0.0 46.5 53.1 33.5 858 [105.0, 99.0, 98.0, 110.0, 103.0, 101.0] [1.0] 40750
36 33.2 0.0 46.3 51.4 26.5 559 [106.0, 99.0, 97.0, 108.0, 100.0] [1.0] 41166
DIFF Galileo E6(BPSK(5)-PD)

SV AvgEl AvgCNoDiff MaxCNoDiff MinCNoDiff SVChan N_Samples
2 45.3 0.2 6.7 -5.8 [108.0, 100.0, 111.0] 32632
3 34.6 -0.1 7.1 -10.8 [99.0, 111.0, 109.0, 104.0, 105.0] 40451
4 50.0 -0.1 3.5 -6.2 [109.0, 100.0, 111.0, 110.0] 25085
5 41.1 0.2 5.6 -5.3 [106.0, 105.0, 110.0, 109.0, 108.0, 100.0, 98.0, 104.0] 35783
7 25.6 0.5 6.8 -6.0 [96.0, 106.0, 110.0, 111.0, 99.0, 105.0] 23134
8 33.9 0.2 9.1 -4.5 [107.0, 104.0, 105.0, 108.0, 97.0, 111.0, 103.0] 34344
9 45.3 0.4 8.5 -2.9 [105.0, 99.0, 110.0, 109.0, 108.0] 32521
10 39.9 0.4 7.5 -4.3 [99.0, 101.0, 110.0, 109.0, 108.0, 105.0, 104.0] 26776
11 38.2 0.1 8.0 -9.5 [96.0, 109.0, 108.0, 107.0, 101.0, 97.0, 100.0, 106.0] 34205
12 38.2 0.4 6.3 -5.3 [102.0, 108.0, 107.0, 106.0, 98.0] 17969
13 49.9 0.2 5.8 -7.3 [101.0, 99.0, 103.0, 102.0] 23652
15 38.2 0.2 6.0 -6.9 [102.0, 107.0, 99.0, 96.0, 104.0, 101.0] 38452
19 37.2 -0.5 3.1 -4.5 [110.0, 98.0, 107.0, 106.0, 105.0] 12209
21 30.9 -0.1 4.2 -5.6 [106.0, 100.0, 101.0] 19847
24 39.8 0.2 5.2 -3.6 [100.0, 108.0, 106.0, 104.0, 110.0] 24474
25 44.5 0.1 10.5 -12.4 [97.0, 106.0, 96.0, 105.0, 100.0] 31131
26 34.4 -0.0 5.1 -4.8 [109.0, 97.0, 99.0] 13561
27 41.4 -0.0 9.9 -10.8 [102.0, 97.0, 103.0, 100.0, 98.0] 25622
30 45.8 0.3 5.5 -4.0 [103.0, 96.0, 97.0, 104.0, 102.0, 99.0] 30865
31 26.2 0.2 7.4 -6.4 [107.0, 106.0, 105.0, 99.0, 108.0, 98.0] 21775
33 16.8 0.8 7.9 -8.8 [111.0, 103.0, 105.0, 97.0] 7572
34 34.5 0.4 6.8 -4.4 [110.0, 105.0, 99.0, 98.0, 111.0, 103.0, 101.0] 40715
36 33.2 0.1 8.5 -4.9 [104.0, 106.0, 99.0, 97.0, 108.0, 100.0] 41155
REF BeiDou L1(BOC-PD)

SV AvgEl AvgOffset AvgCNo MaxCNo MinCNo Slip_Count SVChan Ant N_Samples
19 30.0 0.0 45.4 51.4 35.5 198 [109.0, 79.0] [1.0] 34459
20 35.1 0.0 46.4 53.2 32.2 126 [101.0, 82.0] [1.0] 32070
21 37.4 0.0 45.7 51.4 37.2 281 [89.0, 98.0] [1.0] 23681
22 29.9 0.0 44.7 50.1 22.7 148 [88.0, 75.0] [1.0] 34537
23 38.7 0.0 46.0 51.4 32.3 0 [111.0] [1.0] 21672
24 22.9 0.0 44.2 49.8 31.6 59 [103.0, 84.0] [1.0] 28379
25 23.5 0.0 43.4 48.0 33.1 34 [76.0, 108.0] [1.0] 28152
26 37.6 0.0 46.4 51.5 36.2 0 [109.0] [1.0] 21192
27 29.5 0.0 44.3 49.0 31.4 59 [83.0, 80.0] [1.0] 33819
28 32.8 0.0 45.2 51.1 31.7 154 [107.0, 111.0] [1.0] 24471
29 39.3 0.0 45.6 50.8 26.1 173 [102.0, 100.0] [1.0] 29440
30 30.3 0.0 44.3 49.5 29.3 2 [74.0] [1.0] 34135
32 45.0 0.0 46.7 53.7 33.0 0 [87.0] [1.0] 27396
33 44.9 0.0 46.7 52.2 28.5 85 [98.0, 106.0] [1.0] 18674
34 50.5 0.0 47.3 51.5 35.3 222 [105.0, 80.0] [1.0] 18013
35 44.8 0.0 46.6 52.5 35.2 0 [105.0] [1.0] 28327
36 45.1 0.0 46.2 52.5 16.6 306 [110.0] [1.0] 28321
37 45.4 0.0 47.0 52.0 33.1 0 [103.0] [1.0] 25624
38 7.0 0.0 42.8 44.3 41.6 0 [75.0] [1.0] 1066
41 47.1 0.0 47.0 53.0 32.7 0 [108.0] [1.0] 26072
42 32.9 0.0 45.7 50.9 36.6 115 [100.0, 84.0] [1.0] 16064
43 31.3 0.0 44.8 51.3 34.8 347 [92.0, 70.0] [1.0] 15620
44 45.8 0.0 46.0 53.0 25.9 201 [107.0] [1.0] 27716
45 45.4 0.0 47.5 52.7 34.0 0 [104.0] [1.0] 25463
DUT BeiDou L1(BOC-PD)
DIFF BeiDou L1(BOC-PD)
REF BeiDou L5/E5A(I+Q)

SV AvgEl AvgOffset AvgCNo MaxCNo MinCNo Slip_Count SVChan Ant N_Samples
19 30.0 0.0 45.3 49.5 35.8 57 [109.0, 79.0] [1.0] 34459
20 35.1 0.0 45.1 50.8 32.9 74 [101.0, 82.0] [1.0] 32070
21 37.4 0.0 45.7 51.1 35.4 169 [89.0, 98.0] [1.0] 23681
22 29.9 0.0 45.2 50.2 35.5 293 [88.0, 75.0] [1.0] 34537
23 38.7 0.0 46.9 50.9 32.5 0 [111.0] [1.0] 21672
24 22.9 0.0 44.8 48.2 32.1 155 [103.0, 84.0] [1.0] 28379
25 23.5 0.0 43.3 48.4 36.0 67 [76.0, 108.0] [1.0] 28152
26 37.6 0.0 45.1 49.5 32.6 0 [109.0] [1.0] 21192
27 29.5 0.0 44.4 47.8 36.4 17 [83.0, 80.0] [1.0] 33819
28 32.8 0.0 43.5 50.1 28.7 196 [107.0, 111.0] [1.0] 24471
29 39.3 0.0 45.1 50.3 30.5 141 [102.0, 100.0] [1.0] 29440
30 30.3 0.0 44.2 49.2 34.8 2 [74.0] [1.0] 34135
32 45.0 0.0 46.2 51.0 34.7 0 [87.0] [1.0] 27396
33 44.9 0.0 47.0 51.4 31.6 86 [98.0, 106.0] [1.0] 18674
34 50.5 0.0 45.5 49.7 35.1 192 [105.0, 80.0] [1.0] 18013
35 44.8 0.0 45.7 49.7 34.9 0 [105.0] [1.0] 28327
36 45.1 0.0 47.1 51.7 36.8 0 [110.0] [1.0] 28325
37 45.4 0.0 47.3 51.4 35.1 0 [103.0] [1.0] 25624
38 7.0 0.0 43.5 45.1 41.7 0 [75.0] [1.0] 1066
41 47.1 0.0 47.7 51.5 39.7 0 [108.0] [1.0] 26072
42 32.9 0.0 45.9 51.1 38.1 465 [100.0, 84.0] [1.0] 16064
43 31.3 0.0 43.8 49.9 19.9 318 [92.0, 70.0] [1.0] 15618
44 45.8 0.0 46.0 50.0 37.5 68 [107.0] [1.0] 27716
45 45.4 0.0 46.8 51.7 34.9 0 [104.0] [1.0] 25463
DUT BeiDou L5/E5A(I+Q)
DIFF BeiDou L5/E5A(I+Q)
REF BeiDou E5B/B2(BPSK(2)-B2)

SV AvgEl AvgOffset AvgCNo MaxCNo MinCNo Slip_Count SVChan Ant N_Samples
11 38.1 0.0 45.0 50.0 30.7 323 [78.0, 96.0] [1.0] 16998
12 49.0 0.0 46.4 50.5 34.2 113 [92.0] [1.0] 23637
14 33.6 0.0 46.0 50.9 37.4 290 [106.0, 110.0] [1.0] 17392
DUT BeiDou E5B/B2(BPSK(2)-B2)

SV AvgEl AvgOffset AvgCNo MaxCNo MinCNo Slip_Count SVChan Ant N_Samples
11 41.3 0.0 42.2 47.4 30.6 9184 [111.0, 104.0, 106.0, 110.0] [1.0] 8520
12 52.4 0.0 44.2 48.5 32.2 13073 [110.0, 111.0, 109.0] [1.0] 12491
14 39.3 0.0 43.5 47.5 32.2 8943 [110.0, 103.0, 104.0, 105.0, 108.0, 109.0] [1.0] 8313
DIFF BeiDou E5B/B2(BPSK(2)-B2)

SV AvgEl AvgCNoDiff MaxCNoDiff MinCNoDiff SVChan N_Samples
11 41.3 3.4 9.5 -2.9 [78.0, 111.0, 104.0, 106.0, 96.0, 110.0] 8518
12 52.4 2.9 7.7 -0.9 [92.0, 110.0, 111.0, 109.0] 12491
14 39.3 3.3 8.7 -1.2 [106.0, 110.0, 103.0, 104.0, 105.0, 108.0, 109.0] 8313
REF BeiDou B1(BPSK(2)-B1)

SV AvgEl AvgOffset AvgCNo MaxCNo MinCNo Slip_Count SVChan Ant N_Samples
11 38.1 0.0 43.1 51.1 20.5 378 [78.0, 96.0] [1.0] 17016
12 49.0 0.0 44.2 51.2 27.3 77 [92.0] [1.0] 23637
14 33.6 0.0 41.9 48.5 25.2 458 [106.0, 110.0] [1.0] 17392
19 30.0 0.0 45.4 51.2 36.0 221 [109.0, 79.0] [1.0] 34459
20 35.1 0.0 46.8 53.9 35.5 104 [101.0, 82.0] [1.0] 32070
21 37.4 0.0 45.5 52.8 35.7 254 [89.0, 98.0] [1.0] 23681
22 29.9 0.0 45.3 51.5 27.5 217 [88.0, 75.0] [1.0] 34537
23 38.7 0.0 45.7 52.0 30.5 0 [111.0] [1.0] 21672
24 22.9 0.0 44.0 50.4 29.6 111 [103.0, 84.0] [1.0] 28379
25 23.5 0.0 44.0 49.4 34.3 174 [76.0, 108.0] [1.0] 28152
26 37.6 0.0 46.5 53.0 36.1 0 [109.0] [1.0] 21192
27 29.5 0.0 45.2 50.5 33.5 132 [83.0, 80.0] [1.0] 33819
28 32.8 0.0 45.7 51.7 32.4 204 [107.0, 111.0] [1.0] 24471
29 39.3 0.0 46.2 52.5 35.5 158 [102.0, 100.0] [1.0] 29440
30 30.3 0.0 45.1 51.4 31.3 2 [74.0] [1.0] 34135
32 45.0 0.0 46.6 52.8 35.3 0 [87.0] [1.0] 27397
33 44.9 0.0 45.7 52.3 28.0 23 [98.0, 106.0] [1.0] 18674
34 50.5 0.0 47.1 51.9 34.9 202 [105.0, 80.0] [1.0] 18013
35 44.8 0.0 47.2 52.9 35.1 0 [105.0] [1.0] 28327
36 45.1 0.0 46.6 53.0 14.6 53 [110.0] [1.0] 28325
37 45.4 0.0 46.4 52.9 31.4 0 [103.0] [1.0] 25624
38 7.0 0.0 43.5 45.1 41.9 0 [75.0] [1.0] 1066
41 47.1 0.0 46.7 52.3 33.5 0 [108.0] [1.0] 26072
42 32.9 0.0 44.4 50.7 35.4 341 [100.0, 84.0] [1.0] 16064
43 31.3 0.0 44.4 51.2 30.6 178 [92.0, 70.0] [1.0] 15620
44 45.8 0.0 46.1 51.9 0.0 105 [107.0] [1.0] 27716
45 45.4 0.0 46.7 52.8 33.9 0 [104.0] [1.0] 25463
DUT BeiDou B1(BPSK(2)-B1)

SV AvgEl AvgOffset AvgCNo MaxCNo MinCNo Slip_Count SVChan Ant N_Samples
11 37.2 0.0 43.1 51.0 28.1 584 [111.0, 104.0, 106.0, 77.0, 110.0] [1.0] 13790
12 47.5 0.0 43.8 51.4 28.2 933 [81.0, 110.0, 111.0, 109.0] [1.0] 20075
14 34.9 0.0 42.2 49.1 27.3 858 [110.0, 103.0, 104.0, 105.0, 108.0, 109.0] [1.0] 14109
19 30.7 0.0 45.7 52.1 34.6 1468 [83.0, 110.0, 107.0, 78.0, 109.0, 108.0] [1.0] 32029
20 35.1 0.0 47.0 53.5 33.4 1108 [73.0, 107.0, 104.0, 108.0, 81.0, 110.0, 109.0] [1.0] 31269
21 35.7 0.0 45.6 51.9 34.0 1083 [94.0, 107.0, 103.0, 109.0, 108.0] [1.0] 20327
22 28.8 0.0 45.2 50.3 18.9 1930 [91.0, 107.0, 103.0, 102.0, 74.0, 108.0, 106.0] [1.0] 31132
23 38.9 0.0 46.1 51.1 29.4 300 [104.0, 103.0] [1.0] 20862
24 23.4 0.0 44.2 50.0 29.1 1843 [98.0, 104.0, 103.0, 108.0, 110.0, 109.0, 107.0, 106.0, 96.0, 99.0] [1.0] 24945
25 24.4 0.0 44.5 49.3 35.1 1928 [75.0, 103.0, 102.0, 74.0, 106.0, 105.0, 96.0, 94.0, 82.0, 104.0] [1.0] 24197
26 38.1 0.0 46.6 52.6 35.7 997 [109.0, 110.0, 108.0, 106.0, 107.0, 88.0, 93.0, 105.0, 95.0] [1.0] 20292
27 28.6 0.0 45.3 50.5 34.6 1584 [108.0, 102.0, 103.0, 101.0, 99.0] [1.0] 31231
28 32.2 0.0 45.9 52.4 32.1 1596 [107.0, 101.0, 102.0, 100.0, 81.0, 99.0] [1.0] 22085
29 39.0 0.0 46.4 52.4 34.0 1456 [93.0, 86.0, 99.0, 102.0, 107.0, 108.0, 109.0, 105.0, 106.0, 88.0] [1.0] 28843
30 30.8 0.0 45.2 50.8 32.6 1524 [74.0, 100.0, 91.0, 80.0, 101.0, 99.0, 94.0, 86.0, 102.0, 107.0, 108.0] [1.0] 31801
32 46.4 0.0 46.8 53.6 29.0 1685 [101.0, 80.0, 90.0, 91.0, 79.0, 98.0, 102.0, 103.0, 104.0] [1.0] 25078
33 46.2 0.0 46.6 51.8 29.0 1528 [106.0, 100.0, 101.0, 79.0, 80.0, 78.0, 94.0, 107.0] [1.0] 15571
34 50.1 0.0 47.1 52.1 35.5 2248 [105.0, 77.0, 86.0, 88.0, 93.0, 94.0, 91.0, 81.0, 82.0, 84.0, 104.0, 106.0, 85.0] [1.0] 14545
35 46.2 0.0 47.3 52.9 34.8 2160 [107.0, 101.0, 106.0, 88.0, 86.0, 81.0, 91.0, 90.0, 79.0, 104.0] [1.0] 25645
36 45.1 0.0 46.9 53.0 24.2 1590 [81.0, 102.0, 103.0, 101.0, 91.0, 94.0, 78.0, 99.0, 105.0, 106.0] [1.0] 27579
37 45.2 0.0 46.6 51.9 34.5 1152 [103.0, 101.0, 100.0, 102.0, 91.0, 81.0] [1.0] 25058
38 7.0 0.0 41.4 42.6 40.4 168 [75.0, 76.0] [1.0] 987
41 46.0 0.0 46.8 51.7 33.8 2011 [94.0, 99.0, 100.0, 89.0, 86.0, 78.0, 79.0, 74.0, 80.0, 98.0] [1.0] 23542
42 31.7 0.0 44.7 50.2 33.6 1849 [92.0, 86.0, 89.0, 78.0, 79.0, 84.0, 91.0, 104.0, 87.0, 80.0, 85.0, 95.0] [1.0] 13858
43 30.6 0.0 44.3 51.3 31.7 1795 [84.0, 86.0, 78.0, 77.0, 70.0, 81.0, 91.0, 85.0, 87.0, 79.0, 80.0] [1.0] 13409
44 45.0 0.0 46.0 52.5 9.7 3295 [86.0, 105.0, 106.0, 81.0, 78.0, 90.0, 89.0, 79.0, 73.0, 84.0, 85.0] [1.0] 24116
45 45.2 0.0 46.9 52.6 31.3 1324 [99.0, 91.0, 81.0, 75.0, 98.0, 102.0, 86.0, 105.0, 88.0] [1.0] 24744
DIFF BeiDou B1(BPSK(2)-B1)

SV AvgEl AvgCNoDiff MaxCNoDiff MinCNoDiff SVChan N_Samples
11 37.2 -0.1 6.7 -12.1 [78.0, 111.0, 104.0, 106.0, 96.0, 77.0, 110.0] 13773
12 47.5 0.1 7.4 -3.6 [92.0, 81.0, 110.0, 111.0, 109.0] 20075
14 34.9 -0.1 6.3 -5.0 [106.0, 110.0, 103.0, 104.0, 105.0, 108.0, 109.0] 14109
19 30.7 -0.2 5.8 -4.7 [109.0, 83.0, 110.0, 107.0, 79.0, 78.0, 108.0] 31982
20 35.1 -0.2 5.9 -5.4 [101.0, 73.0, 107.0, 104.0, 108.0, 82.0, 81.0, 110.0, 109.0] 31258
21 35.7 -0.4 4.7 -6.5 [89.0, 94.0, 107.0, 103.0, 98.0, 109.0, 108.0] 20327
22 28.8 -0.0 8.7 -4.9 [88.0, 91.0, 107.0, 103.0, 102.0, 75.0, 74.0, 108.0, 106.0] 31113
23 38.9 -0.4 5.7 -6.3 [111.0, 104.0, 103.0] 20862
24 23.4 -0.0 9.5 -7.2 [103.0, 98.0, 104.0, 84.0, 108.0, 110.0, 109.0, 107.0, 106.0, 96.0, 99.0] 24915
25 24.4 -0.3 5.0 -5.0 [76.0, 75.0, 103.0, 102.0, 108.0, 74.0, 106.0, 105.0, 96.0, 94.0, 82.0, 104.0] 24166
26 38.1 -0.0 5.2 -5.2 [109.0, 110.0, 108.0, 106.0, 107.0, 88.0, 93.0, 105.0, 95.0] 20292
27 28.6 -0.2 4.6 -4.8 [83.0, 108.0, 102.0, 103.0, 101.0, 80.0, 99.0] 31231
28 32.2 -0.2 5.4 -5.5 [107.0, 101.0, 102.0, 100.0, 111.0, 81.0, 99.0] 22085
29 39.0 -0.2 5.5 -7.1 [102.0, 93.0, 100.0, 86.0, 99.0, 107.0, 108.0, 109.0, 105.0, 106.0, 88.0] 28843
30 30.8 -0.1 7.7 -4.1 [74.0, 100.0, 91.0, 80.0, 101.0, 99.0, 94.0, 86.0, 102.0, 107.0, 108.0] 31797
32 46.5 0.1 9.4 -5.0 [87.0, 101.0, 80.0, 90.0, 91.0, 79.0, 98.0, 102.0, 103.0, 104.0] 25061
33 46.2 -0.5 6.2 -7.4 [98.0, 106.0, 100.0, 101.0, 79.0, 80.0, 78.0, 94.0, 107.0] 15571
34 50.1 -0.2 4.0 -4.5 [105.0, 80.0, 77.0, 86.0, 88.0, 93.0, 94.0, 91.0, 81.0, 82.0, 84.0, 104.0, 106.0, 85.0] 14545
35 46.2 0.2 5.5 -3.6 [105.0, 107.0, 101.0, 106.0, 88.0, 86.0, 81.0, 91.0, 90.0, 79.0, 104.0] 25645
36 45.1 -0.2 6.2 -14.8 [110.0, 81.0, 102.0, 103.0, 101.0, 91.0, 94.0, 78.0, 99.0, 105.0, 106.0] 27579
37 45.2 -0.2 6.6 -6.7 [103.0, 101.0, 100.0, 102.0, 91.0, 81.0] 25058
38 7.0 2.0 4.1 -0.2 [75.0, 76.0] 987
41 46.0 -0.2 5.7 -5.6 [108.0, 94.0, 99.0, 100.0, 89.0, 86.0, 78.0, 79.0, 74.0, 80.0, 98.0] 23542
42 31.8 -0.4 5.4 -4.9 [100.0, 92.0, 86.0, 89.0, 78.0, 84.0, 79.0, 91.0, 104.0, 87.0, 80.0, 85.0, 95.0] 13852
43 30.6 -0.2 4.3 -5.5 [92.0, 84.0, 86.0, 78.0, 77.0, 70.0, 81.0, 91.0, 85.0, 87.0, 79.0, 80.0] 13404
44 45.1 0.0 22.9 -29.0 [107.0, 86.0, 105.0, 106.0, 81.0, 78.0, 90.0, 89.0, 79.0, 73.0, 84.0, 85.0] 24056
45 45.2 -0.2 7.3 -7.4 [104.0, 99.0, 91.0, 81.0, 75.0, 98.0, 102.0, 86.0, 105.0, 88.0] 24744
REF BeiDou B3(BPSK(10)-B3)

SV AvgEl AvgOffset AvgCNo MaxCNo MinCNo Slip_Count SVChan Ant N_Samples
11 38.1 0.0 42.9 48.8 30.8 131 [78.0, 96.0] [1.0] 16998
12 49.0 0.0 45.2 49.3 32.5 25 [92.0] [1.0] 23637
14 33.6 0.0 43.9 51.1 33.5 125 [106.0, 110.0] [1.0] 17392
19 30.0 0.0 43.5 49.5 32.7 47 [109.0, 79.0] [1.0] 34459
20 35.1 0.0 43.3 49.2 31.3 10 [101.0, 82.0] [1.0] 32070
21 37.4 0.0 43.8 49.3 34.5 79 [89.0, 98.0] [1.0] 23681
22 29.9 0.0 43.6 49.0 30.2 46 [88.0, 75.0] [1.0] 34537
23 38.7 0.0 45.5 50.0 34.9 0 [111.0] [1.0] 21672
24 22.9 0.0 42.5 46.8 27.2 139 [103.0, 84.0] [1.0] 28379
25 23.5 0.0 41.7 48.5 32.1 241 [76.0, 108.0] [1.0] 28152
26 37.6 0.0 43.8 49.1 24.9 0 [109.0] [1.0] 21192
27 29.5 0.0 42.6 48.3 28.1 85 [83.0, 80.0] [1.0] 33819
28 32.8 0.0 42.5 50.5 28.2 194 [107.0, 111.0] [1.0] 24471
29 39.3 0.0 43.8 49.3 27.9 44 [102.0, 100.0] [1.0] 29440
30 30.3 0.0 43.1 48.7 31.4 2 [74.0] [1.0] 34135
32 45.0 0.0 44.9 49.7 33.6 0 [87.0] [1.0] 27392
33 44.9 0.0 45.1 51.9 27.2 252 [98.0, 106.0] [1.0] 18674
34 50.5 0.0 44.2 49.2 33.0 256 [105.0, 80.0] [1.0] 18013
35 44.8 0.0 44.6 49.3 32.1 0 [105.0] [1.0] 28327
36 45.2 0.0 45.5 49.9 33.3 8 [110.0] [1.0] 28258
37 45.4 0.0 45.5 49.4 34.7 0 [103.0] [1.0] 25624
38 7.0 0.0 40.6 41.9 39.0 0 [75.0] [1.0] 1066
41 47.1 0.0 45.9 50.8 36.3 0 [108.0] [1.0] 26072
42 32.9 0.0 43.9 51.1 33.1 139 [100.0, 84.0] [1.0] 16064
43 31.3 0.0 42.7 48.9 27.3 404 [92.0, 70.0] [1.0] 15620
44 45.8 0.0 44.4 49.0 30.8 145 [107.0] [1.0] 27666
45 45.4 0.0 44.9 49.8 29.7 0 [104.0] [1.0] 25463
DUT BeiDou B3(BPSK(10)-B3)

SV AvgEl AvgOffset AvgCNo MaxCNo MinCNo Slip_Count SVChan Ant N_Samples
11 37.2 0.0 42.5 48.8 27.6 844 [111.0, 104.0, 106.0, 110.0] [1.0] 13733
12 47.5 0.0 45.0 49.5 34.0 1707 [81.0, 110.0, 111.0, 109.0] [1.0] 20016
14 34.9 0.0 43.8 50.9 31.1 1281 [110.0, 103.0, 104.0, 105.0, 108.0, 109.0] [1.0] 14062
19 30.7 0.0 43.9 49.5 31.4 1229 [83.0, 110.0, 107.0, 78.0, 109.0, 108.0] [1.0] 31990
20 35.1 0.0 43.4 49.2 28.3 1612 [73.0, 107.0, 104.0, 108.0, 81.0, 110.0, 109.0] [1.0] 31254
21 35.7 0.0 43.1 49.4 30.4 1238 [94.0, 107.0, 103.0, 109.0, 108.0] [1.0] 20295
22 28.9 0.0 43.4 48.8 32.8 1837 [91.0, 107.0, 103.0, 102.0, 74.0, 108.0, 106.0] [1.0] 31060
23 38.9 0.0 45.2 50.0 32.2 302 [104.0, 103.0] [1.0] 20850
24 23.4 0.0 42.7 47.1 27.7 2021 [98.0, 104.0, 103.0, 108.0, 110.0, 109.0, 107.0, 106.0, 96.0, 99.0] [1.0] 24847
25 24.4 0.0 42.3 48.3 30.2 1750 [75.0, 103.0, 102.0, 74.0, 106.0, 105.0, 96.0, 94.0, 82.0, 104.0] [1.0] 24131
26 38.1 0.0 43.8 49.5 26.2 1076 [109.0, 110.0, 108.0, 106.0, 107.0, 88.0, 93.0, 105.0, 95.0] [1.0] 20274
27 28.6 0.0 42.3 47.9 29.5 1183 [108.0, 102.0, 103.0, 101.0, 99.0] [1.0] 31210
28 32.2 0.0 42.4 50.4 28.6 1236 [107.0, 101.0, 102.0, 100.0, 81.0, 99.0] [1.0] 22057
29 39.0 0.0 43.6 49.3 31.5 1123 [93.0, 86.0, 99.0, 102.0, 107.0, 108.0, 109.0, 105.0, 106.0, 88.0] [1.0] 28834
30 30.8 0.0 43.0 49.2 32.4 2243 [74.0, 100.0, 91.0, 80.0, 101.0, 99.0, 94.0, 86.0, 102.0, 107.0, 108.0] [1.0] 31768
32 46.5 0.0 44.7 49.8 29.0 1734 [101.0, 80.0, 90.0, 91.0, 79.0, 98.0, 102.0, 103.0, 104.0] [1.0] 25033
33 46.3 0.0 45.6 51.6 31.2 1391 [106.0, 100.0, 101.0, 79.0, 80.0, 78.0, 94.0, 107.0] [1.0] 15483
34 50.1 0.0 44.2 49.1 32.9 1706 [105.0, 77.0, 86.0, 88.0, 93.0, 94.0, 91.0, 81.0, 82.0, 84.0, 104.0, 106.0, 85.0] [1.0] 14501
35 46.2 0.0 45.0 49.1 30.3 2360 [107.0, 101.0, 106.0, 88.0, 86.0, 81.0, 91.0, 90.0, 79.0, 104.0] [1.0] 25606
36 45.2 0.0 45.4 50.0 32.4 1715 [81.0, 102.0, 103.0, 101.0, 91.0, 94.0, 78.0, 99.0, 105.0, 106.0] [1.0] 27537
37 45.2 0.0 45.3 49.3 29.0 1122 [103.0, 101.0, 100.0, 102.0, 91.0, 81.0] [1.0] 25046
38 7.0 0.0 40.7 42.6 33.9 168 [75.0, 76.0] [1.0] 986
41 46.0 0.0 45.7 49.9 34.4 2033 [94.0, 99.0, 100.0, 89.0, 86.0, 78.0, 79.0, 74.0, 80.0, 98.0] [1.0] 23511
42 31.7 0.0 43.6 50.3 31.3 1851 [92.0, 86.0, 89.0, 78.0, 79.0, 84.0, 91.0, 104.0, 87.0, 80.0, 85.0, 95.0] [1.0] 13817
43 30.6 0.0 42.1 49.6 31.5 2072 [84.0, 86.0, 78.0, 77.0, 70.0, 81.0, 91.0, 85.0, 87.0, 79.0, 80.0] [1.0] 13383
44 45.4 0.0 44.4 49.2 32.0 3101 [86.0, 105.0, 106.0, 81.0, 78.0, 90.0, 89.0, 79.0, 73.0, 84.0, 85.0] [1.0] 23795
45 45.2 0.0 44.9 50.0 29.0 1451 [99.0, 91.0, 81.0, 75.0, 98.0, 102.0, 86.0, 105.0, 88.0] [1.0] 24733
DIFF BeiDou B3(BPSK(10)-B3)

SV AvgEl AvgCNoDiff MaxCNoDiff MinCNoDiff SVChan N_Samples
11 37.3 0.4 8.0 -5.3 [78.0, 111.0, 104.0, 106.0, 96.0, 110.0] 13698
12 47.5 -0.0 8.4 -3.4 [92.0, 81.0, 110.0, 111.0, 109.0] 20016
14 34.9 0.2 7.9 -3.8 [106.0, 110.0, 103.0, 104.0, 105.0, 108.0, 109.0] 14062
19 30.7 -0.2 7.7 -4.6 [109.0, 83.0, 110.0, 107.0, 79.0, 78.0, 108.0] 31943
20 35.1 -0.1 7.0 -6.6 [101.0, 73.0, 107.0, 104.0, 108.0, 82.0, 81.0, 110.0, 109.0] 31243
21 35.7 0.3 7.8 -5.8 [89.0, 94.0, 107.0, 103.0, 98.0, 109.0, 108.0] 20295
22 28.9 0.1 9.5 -4.3 [88.0, 91.0, 107.0, 103.0, 102.0, 75.0, 74.0, 108.0, 106.0] 31051
23 38.9 0.4 10.7 -2.9 [111.0, 104.0, 103.0] 20850
24 23.4 -0.1 6.9 -5.0 [103.0, 98.0, 104.0, 84.0, 108.0, 110.0, 109.0, 107.0, 106.0, 96.0, 99.0] 24817
25 24.4 -0.2 6.9 -6.0 [76.0, 75.0, 103.0, 102.0, 108.0, 74.0, 106.0, 105.0, 96.0, 94.0, 82.0, 104.0] 24100
26 38.1 0.2 8.2 -8.1 [109.0, 110.0, 108.0, 106.0, 107.0, 88.0, 93.0, 105.0, 95.0] 20274
27 28.6 0.2 6.8 -4.8 [83.0, 108.0, 102.0, 103.0, 101.0, 80.0, 99.0] 31210
28 32.2 0.1 6.9 -6.3 [107.0, 101.0, 102.0, 100.0, 111.0, 81.0, 99.0] 22057
29 39.0 0.2 7.1 -6.1 [102.0, 93.0, 100.0, 86.0, 99.0, 107.0, 108.0, 109.0, 105.0, 106.0, 88.0] 28834
30 30.8 0.1 5.2 -3.9 [74.0, 100.0, 91.0, 80.0, 101.0, 99.0, 94.0, 86.0, 102.0, 107.0, 108.0] 31764
32 46.5 0.5 7.9 -2.8 [87.0, 101.0, 80.0, 90.0, 91.0, 79.0, 98.0, 102.0, 103.0, 104.0] 25016
33 46.3 -0.3 5.0 -6.7 [98.0, 106.0, 100.0, 101.0, 79.0, 80.0, 78.0, 94.0, 107.0] 15483
34 50.1 -0.1 5.7 -6.8 [105.0, 80.0, 77.0, 86.0, 88.0, 93.0, 94.0, 91.0, 81.0, 82.0, 84.0, 104.0, 106.0, 85.0] 14501
35 46.2 -0.1 6.9 -5.5 [105.0, 107.0, 101.0, 106.0, 88.0, 86.0, 81.0, 91.0, 90.0, 79.0, 104.0] 25606
36 45.2 0.0 4.9 -4.1 [110.0, 81.0, 102.0, 103.0, 101.0, 91.0, 94.0, 78.0, 99.0, 105.0, 106.0] 27492
37 45.2 0.2 8.0 -3.2 [103.0, 101.0, 100.0, 102.0, 91.0, 81.0] 25046
38 7.0 -0.1 7.0 -2.0 [75.0, 76.0] 986
41 46.0 0.1 5.3 -2.9 [108.0, 94.0, 99.0, 100.0, 89.0, 86.0, 78.0, 79.0, 74.0, 80.0, 98.0] 23511
42 31.8 0.2 6.3 -4.0 [100.0, 92.0, 86.0, 89.0, 78.0, 84.0, 79.0, 91.0, 104.0, 87.0, 80.0, 85.0, 95.0] 13811
43 30.6 0.6 6.4 -6.2 [92.0, 84.0, 86.0, 78.0, 77.0, 70.0, 81.0, 91.0, 85.0, 87.0, 79.0, 80.0] 13378
44 45.5 0.1 7.5 -5.1 [107.0, 86.0, 105.0, 106.0, 81.0, 78.0, 90.0, 89.0, 79.0, 73.0, 84.0, 85.0] 23709
45 45.2 0.0 10.6 -6.8 [104.0, 99.0, 91.0, 81.0, 75.0, 98.0, 102.0, 86.0, 105.0, 88.0] 24733
