0614 6348C01910*.T04

Meta Data


Serial Number : 6348C01910
Firmware Date : May 23, 2024
Release Ver : 5.70
Nav Proc Ver : 0.50
Radio Lib Ver : None
Primary Antenna Type : -1
Primary Antenna Height : 0.0000 m
Secondary Antenna Type : -1
Secondary Antenna Height : 0.0000 m
week_list : ['2318']
Start Time : 495000.0
Stop Time : 496799.0
Total Hours : 0.4007530555555584
Total Time: 1799.0 seconds = 0.500 hours

6348c01910.t04_d35-2.tsv

Heading, Antenna distance

Weighted Mean heading_mean: 358.7320
Weighted Mean dist_mean: 0.1572
Weighted Mean ant_list: [0, 1]
Weighted Mean hprec: 0.0194
Weighted Mean vprec: 0.0299
Weighted Mean vdiff_mean: -0.0069
Weighted Mean heading_uptime: 0.0000

Stats


antenna w_mean_lat w_mean_lon w_mean_hgt std_err std_err_hprec std_err_vprec count
0 39.895984 -105.113444 1644.975485 0.467805 0.013327 0.028974 1800
1 39.895982 -105.113444 1644.982342 0.111369 0.003125 0.007313 1800

Uptime


antenna limit h_uptime v_uptime hv_uptime
0 0.03 0.000000 0.000000 0.000000
0 0.05 0.991111 0.000000 0.000000
0 0.10 1.000000 0.977222 0.977222
1 0.03 1.000000 0.966667 0.966667
1 0.05 1.000000 1.000000 1.000000
1 0.10 1.000000 1.000000 1.000000

Truth


antenna lat lon hgt
0 39.895983 -105.113444 1644.897
1 39.895983 -105.113444 1644.897

Fix Summary

VSysFlgs MFixType MFixMode MFixInfo MSysFlgs count Fix_Description Ant VFixType VFixMode VFixInfo
NaN 4.0 5.0 3.0 0x17:02x 1800 RTK fixed; 3D solution; Ione free 0 NaN NaN NaN
0x0:02x NaN NaN NaN NaN 1800 RTK fixed; 3D solution; Min error 1 4.0 5.0 0.0
Flags Bit Table
Bit Description
0 1 if this is the master position (i.e. record 29 position)
1 1 if the solution is a propagated solution (e.g. PM_FIX_20_HZ)
3 1 if reference station is sending moving base CMRs. Only b0 and b1 of "rtkMode" are defined in Record 29, in the rtk block "mode" field.
4 rtkMode bit 0: 0=synchronized rtk solution; 1=low-latency rtk solution;
5 rtkMode bit 1: 0=no canopy detected; 1= canopy detected;
6 1 if a baseline length constraint was used to form RTK vector.
7 1 if a clock constraint was used to form RTK vector.
8 1 if the RTK position is bridged
9 1 if the OmniSTAR position is authenticated

Individual Antennas
