T04: /home/russ/Documents/_GNSS_data/2024/CSNMR-3030_WiFi_montera/240809_ch11 BX992

Meta Data


Start : 2326 400754.0
Stop : 2326 491798.0
Number Samples : 91045
Input Source : T04
Total Time: 91044.0 seconds = 25.290 hours

pos_ant.csv

Heading, Antenna distance

Weighted Mean heading_mean: 176.7128
Weighted Mean dist_mean: 0.8210
Weighted Mean ant_list: [0, 1]
Weighted Mean hprec: 0.8287
Weighted Mean vprec: 1.3867
Weighted Mean vdiff_mean: -0.8286
Weighted Mean heading_uptime: 0.0000

Stats


antenna w_mean_lat w_mean_lon w_mean_hgt std_err std_err_hprec std_err_vprec count datum datum_epoch
0 39.896476 -105.115073 1668.108172 2.967175 0.585956 1.386646 91045 ('WGS-84',) ('0',)
1 39.896483 -105.115073 1668.936726 0.007102 0.002485 0.003231 91045 ('WGS-84',) ('0',)

Uptime


antenna limit h_uptime v_uptime hv_uptime
0 0.03 0.000000 0.000000 0.000000
0 0.05 0.000000 0.000000 0.000000
0 0.10 0.000000 0.000000 0.000000
1 0.03 0.999901 0.999901 0.999901
1 0.05 0.999901 0.999901 0.999901
1 0.10 0.999901 0.999901 0.999901
center 0.03 0.000000 0.000000 0.000000
center 0.05 0.000000 0.000000 0.000000
center 0.10 0.000000 0.000000 0.000000

Fix Summary

VSysFlgs MFixType MFixMode MFixInfo MSysFlgs count Fix_Description Ant VFixType VFixMode VFixInfo
NaN 11.0 5.0 0.0 0x1:02x 91045 SBAS corrected DGPS (Kalman Filter); 3D solution; Unknown fix_type 11 to get fix_info. 0 NaN NaN NaN
0x0.0:02x NaN NaN NaN NaN 2 RTK float; 3D solution; Unknown fix_info RTK value 10.0. 1 3.0 5.0 10.0
0x0.0:02x NaN NaN NaN NaN 91037 RTK fixed; 3D solution; Unknown fix_info RTK value 10.0. 1 4.0 5.0 10.0
Flags Bit Table
Bit Description
0 1 if this is the master position (i.e. record 29 position)
1 1 if the solution is a propagated solution (e.g. PM_FIX_20_HZ)
3 1 if reference station is sending moving base CMRs. Only b0 and b1 of "rtkMode" are defined in Record 29, in the rtk block "mode" field.
4 rtkMode bit 0: 0=synchronized rtk solution; 1=low-latency rtk solution;
5 rtkMode bit 1: 0=no canopy detected; 1= canopy detected;
6 1 if a baseline length constraint was used to form RTK vector.
7 1 if a clock constraint was used to form RTK vector.
8 1 if the RTK position is bridged
9 1 if the OmniSTAR position is authenticated

Individual Antennas
