CH48, Mode A

Files


240813_ch48_mode_a/BX_all.T04 240813_ch48_mode_a/EB79_all.T04 240813_ch48_mode_a/EB81_all.T04
Modified: 2024-08-29 13:06:10

Serial Number : 6221C43829
Firmware Date : Mar 6, 2024
Release Ver : 5.70
Nav Proc Ver : 0.47
Radio Lib Ver : None
Primary Antenna Type : MI
Primary Antenna Height : 0.0000 m
Secondary Antenna Type : MI
Secondary Antenna Height : 0.0000 m
week_list : ['2327']
Start Time : 143136.126
Stop Time : 219600.396
Total Hours : 21.240075000000004

Mean Primary Pos: [39.896474936405866, -105.11507296813825]
Mean Secondary Pos: [39.89648864117487, -105.11507652199374]
Mean Heading: 168.75 (deg)
Mean Slope Distance: 1.5538 (m)
 Modified: 2024-08-29 13:06:10

Serial Number : 6348C01835
Firmware Date : Jun 21, 2024
Release Ver : 5.70
Nav Proc Ver : 0.51
Radio Lib Ver : None
Primary Antenna Type : E
Primary Antenna Height : 0.1080 m
Secondary Antenna Type : E
Secondary Antenna Height : 0.1080 m
week_list : ['2327']
Start Time : 143139.1
Stop Time : 222352.363
Total Hours : 22.00368416666667

Mean Primary Pos: [39.896474583612225, -105.1150585677274]
Mean Secondary Pos: [39.89648848707686, -105.11506126849174]
Mean Heading: 171.52 (deg)
Mean Slope Distance: 1.5631 (m)
 Modified: 2024-08-29 13:06:11

Serial Number : 6348C01910
Firmware Date : Jun 21, 2024
Release Ver : 5.70
Nav Proc Ver : 0.51
Radio Lib Ver : None
Primary Antenna Type : -1
Primary Antenna Height : 0.1080 m
Secondary Antenna Type : -1
Secondary Antenna Height : 0.1080 m
week_list : ['2327']
Start Time : 143152.095
Stop Time : 222341.704
Total Hours : 21.99711361111111

Mean Primary Pos: [39.896473185920996, -105.1150481850063]
Mean Secondary Pos: [39.896488483345784, -105.11504727228738]
Mean Heading: 182.62 (deg)
Mean Slope Distance: 1.7028 (m)

Difference Report Links

240813_ch48_mode_a/results/BX_all_0-EB79_all_0.html
240813_ch48_mode_a/results/BX_all_0-EB81_all_0.html
240813_ch48_mode_a/results/BX_all_1-EB79_all_1.html
240813_ch48_mode_a/results/BX_all_1-EB81_all_1.html

Summary Table

SVType Freq Track N_Samples_EB79_0 CNo_Mean_EB79_0 N_Samples_EB81_0 CNo_Mean_EB81_0 N_Samples_EB79_1 CNo_Mean_EB79_1 N_Samples_EB81_1 CNo_Mean_EB81_1
GPS L1 BOC-PD 0 0 0 0
GPS L1 CA 741,744 0.1 741,422 0.2 741,740 -0.1 741,409 0.1
GPS L2 CM+CL 559,360 0.2 559,069 0.5 559,351 0.2 559,051 0.5
GPS L2 E 182,254 0.4 182,097 0.8 181,767 0.2 179,963 0.6
GPS L5/E5A I+Q 412,579 -0.1 412,368 0.4 412,568 -0.3 412,344 -0.2
SBAS L1 CA 239,307 -0.5 0 0 0
SBAS L5/E5A I 0 0 0 0
GLONASS L1 CA 562,271 0.5 561,320 0.9 562,296 0.3 561,342 0.4
GLONASS L1 P 0 0 0 0
GLONASS L2 CA 488,046 -0.1 486,491 0.6 488,116 0.0 487,803 0.2
GLONASS L2 P 0 0 0 0
GLONASS G3 PD 0 0 0 0
Galileo L1 MBOC-PD 533,008 -0.0 533,033 0.2 532,991 -0.0 533,027 0.1
Galileo L5/E5A BPSK(10)-PD 0 0 0 0
Galileo E5B/B2 BPSK(10)-PD 0 0 0 0
Galileo E5A+B AltBOC-Comp-PD 533,008 0.1 533,032 0.1 532,991 -0.4 533,027 -0.1
Galileo E6 BPSK(5)-PD 0 0 0 0
BeiDou L1 BOC-PD 0 0 0 0
BeiDou L5/E5A I+Q 563,380 -0.1 563,260 0.3 563,364 -0.3 563,242 -0.1
BeiDou E5B/B2 BPSK(2)-B2 53,715 0.4 53,691 -0.2 53,728 -0.7 53,733 -0.2
BeiDou B1 BPSK(2)-B1 617,109 -0.1 616,996 0.2 617,095 -0.3 616,980 -0.2
BeiDou B3 BPSK(10)-B3 617,080 0.1 616,937 0.1 617,031 -0.0 616,895 0.2
QZSS L1 CA 0 0 0 0
QZSS L1 SLAS 0 0 0 0
QZSS L2 CM+CL 0 0 0 0
QZSS L5/E5A I+Q 0 0 0 0
MSS 0 0 0 0
Total 6,102,861 0.0 5,859,716 0.3 5,863,038 -0.1 5,858,816 0.1

Az-El Plots

BX_all_0-EB79_all_0 BX_all_0-EB81_all_0 BX_all_1-EB79_all_1 BX_all_1-EB81_all_1

Mean Elevation Plots

Antenna 0

GPS
SBAS
GLONASS
Galileo
BeiDou

Antenna 1

GPS
GLONASS
Galileo
BeiDou

Oscillation Check

BX_all_0: 1296.7
Antenna SVType Freq Track SV osc_factor
0 GPS L1 0 29 1,297
0 GPS L5/E5A 8 11 1,292
0 GPS L1 0 2 1,257
0 BeiDou B1 26 21 1,226
0 Galileo E5A+B 14 21 1,222
0 GPS L1 0 3 1,173
0 GPS L1 0 11 1,156
0 BeiDou L1 20 21 1,155
0 GLONASS L1 0 24 1,154
0 GPS L1 0 12 1,139
EB79_all_0: 1474.6
Antenna SVType Freq Track SV osc_factor
0 GLONASS L1 0 6 1,475
0 GPS L1 0 12 1,436
0 GPS L1 0 11 1,391
0 GLONASS L1 0 9 1,298
0 GPS L1 0 8 1,260
0 Galileo E5A+B 14 21 1,222
0 GPS L1 0 29 1,192
0 GPS L2 2 5 1,180
0 GPS L1 0 6 1,173
0 GLONASS L1 0 14 1,168
EB81_all_0: 2048.3
Antenna SVType Freq Track SV osc_factor
0 GLONASS L1 0 9 2,048
0 GPS L1 0 25 1,556
0 GLONASS L1 0 6 1,511
0 BeiDou B3 29 45 1,452
0 GPS L1 0 16 1,388
0 GLONASS L1 0 15 1,272
0 BeiDou B1 26 23 1,270
0 GLONASS L1 0 11 1,265
0 GPS L1 0 6 1,256
0 GPS L1 0 29 1,243
BX_all_1: 1808.0
Antenna SVType Freq Track SV osc_factor
1 GLONASS L1 0 8 1,808
1 GPS L1 0 10 1,698
1 GPS L1 0 3 1,674
1 BeiDou L1 20 26 1,577
1 GPS L1 0 9 1,565
1 GLONASS L1 1 8 1,551
1 BeiDou B1 26 26 1,549
1 BeiDou B1 26 21 1,499
1 Galileo E6 36 2 1,366
1 BeiDou B1 26 22 1,343
EB79_all_1: 1652.7
Antenna SVType Freq Track SV osc_factor
1 GLONASS L1 0 9 1,653
1 GPS L1 0 6 1,399
1 GPS L1 0 11 1,349
1 GLONASS L1 0 12 1,337
1 GPS L1 0 3 1,331
1 GLONASS L1 0 1 1,316
1 GPS L2 2 6 1,316
1 Galileo L1 23 26 1,288
1 GPS L2 2 3 1,267
1 GPS L1 0 12 1,202
EB81_all_1: 1554.7
Antenna SVType Freq Track SV osc_factor
1 GPS L1 0 25 1,555
1 GPS L2 5 25 1,539
1 GLONASS L1 0 9 1,526
1 GLONASS L1 0 5 1,445
1 GLONASS L1 0 12 1,392
1 GLONASS L1 0 8 1,363
1 GPS L1 0 6 1,351
1 GLONASS L2 0 17 1,276
1 GPS L1 0 30 1,267
1 GPS L1 0 12 1,264

FFT Plots

L1 L2 L5 E6 G1 B1
BX
EB79
EB81
