REF File: 240809_ch11/BX_all.T04
DUT File: 240809_ch11/EB79_all.T04

Comments


CH11

Ref Statistics

DUT Statistics

Difference Statistics
SVType Freq Track N_Samples CNo_Mean CNo_Median CNo_Std CNo_Min CNo_Max CNo_Range El_Mean El_Max
GPS L1 CA 840519 43.9 44.2 4.3 12.5 54.5 42.0 37.0 90.0
GPS L2 CM+CL 645651 44.4 44.9 3.4 25.3 52.0 26.7 38.4 90.0
GPS L2 E 194350 30.2 30.5 6.6 13.9 44.4 30.5 32.6 77.0
GPS L5/E5A I+Q 460409 47.6 47.8 3.0 29.8 54.6 24.8 37.0 88.0
SBAS L1 CA 355102 42.8 44.2 4.0 22.9 48.5 25.6 20.2 42.0
SBAS L5/E5A I 273135 46.3 46.3 0.5 44.4 48.4 4.0 39.8 42.0
GLONASS L1 CA 654611 44.3 45.2 5.1 0.0 53.8 53.8 35.7 89.0
GLONASS L1 P 654471 42.8 43.6 5.0 20.9 52.0 31.1 35.7 89.0
GLONASS L2 CA 557722 44.4 44.9 3.6 10.5 52.1 41.6 35.7 89.0
GLONASS L2 P 557690 42.7 43.2 3.5 11.6 49.9 38.3 35.7 89.0
GLONASS G3 PD 46298 45.4 46.0 3.2 29.3 50.8 21.5 39.9 80.0
Galileo L1 MBOC-PD 642969 45.3 45.6 3.9 10.9 53.8 42.9 36.8 89.0
Galileo L5/E5A BPSK(10)-PD 642969 45.1 45.5 2.7 31.1 50.7 19.6 36.8 89.0
Galileo E5B/B2 BPSK(10)-PD 642969 45.6 46.0 2.9 31.6 51.2 19.6 36.8 89.0
Galileo E5A+B AltBOC-Comp-PD 642969 47.9 48.0 2.4 32.8 52.9 20.1 36.8 89.0
Galileo E6 BPSK(5)-PD 642892 47.1 47.5 3.7 27.1 53.8 26.7 36.8 89.0
BeiDou L1 BOC-PD 635931 45.6 45.8 4.1 20.5 53.0 32.5 37.1 90.0
BeiDou L5/E5A I+Q 635932 46.1 46.2 2.9 31.4 52.1 20.7 37.1 90.0
BeiDou E5B/B2 BPSK(2)-B2 77467 45.9 46.5 2.1 36.2 49.9 13.7 41.9 82.0
BeiDou B1 BPSK(2)-B1 713418 45.5 45.9 4.1 21.7 53.2 31.5 37.6 90.0
BeiDou B3 BPSK(10)-B3 713394 44.7 45.3 3.1 24.0 50.8 26.8 37.6 90.0
start/stop time: 400,754 491,798
Total time: 91,044.0 seconds
Total time: 1,517.400 minutes
Total time: 25.290 hours
Total Samples: 11,230,868
Avg Samples/sec: 123.4

Serial Number : 6221C43829
Firmware Date : Mar 6, 2024
Release Ver : 5.70
Nav Proc Ver : 0.47
Radio Lib Ver : None
Primary Antenna Type : MI
Primary Antenna Height : 0.0000 m
Secondary Antenna Type : MI
Secondary Antenna Height : 0.0000 m
week_list : ['2326']
Start Time : 400754.127
Stop Time : 489600.333
Total Hours : 24.679501666666667
SVType Freq Track N_Samples CNo_Mean CNo_Median CNo_Std CNo_Min CNo_Max CNo_Range El_Mean El_Max
GPS L1 CA 840295 43.5 43.9 4.1 19.2 54.1 34.9 37.0 90.0
GPS L2 CM+CL 645456 44.2 44.6 3.4 8.9 52.3 43.4 38.4 90.0
GPS L2 E 840200 36.3 36.5 7.8 12.6 52.6 40.0 37.0 90.0
GPS L5/E5A I+Q 460294 47.5 47.6 2.9 17.4 53.9 36.5 37.0 88.0
SBAS L1 CA 273147 44.8 44.9 0.9 40.2 47.5 7.3 39.8 42.0
GLONASS L1 CA 649752 43.1 44.1 5.0 9.8 52.8 43.0 35.8 89.0
GLONASS L2 CA 552908 44.5 45.2 3.4 10.1 51.4 41.3 35.9 89.0
Galileo L1 MBOC-PD 643027 44.8 45.2 3.7 0.0 53.3 53.3 36.8 89.0
Galileo E5A+B AltBOC-Comp-PD 643034 47.6 47.7 2.4 32.1 52.3 20.2 36.8 89.0
BeiDou L5/E5A I+Q 636115 46.0 46.1 2.8 21.8 52.1 30.3 37.1 90.0
BeiDou E5B/B2 BPSK(2)-B2 77506 45.4 46.3 2.3 30.4 49.5 19.1 41.9 82.0
BeiDou B1 BPSK(2)-B1 713625 45.1 45.7 3.8 20.9 52.9 32.0 37.6 90.0
BeiDou B3 BPSK(10)-B3 713575 44.5 45.1 3.0 16.9 50.0 33.1 37.6 90.0
start/stop time: 400,758 491,806
Total time: 91,048.0 seconds
Total time: 1,517.467 minutes
Total time: 25.291 hours
Total Samples: 7,688,934
Avg Samples/sec: 84.4

Serial Number : 6348C01835
Firmware Date : Jun 21, 2024
Release Ver : 5.70
Nav Proc Ver : 0.51
Radio Lib Ver : None
Primary Antenna Type : E
Primary Antenna Height : 0.1080 m
Secondary Antenna Type : E
Secondary Antenna Height : 0.1080 m
week_list : ['2326']
Start Time : 400758.108
Stop Time : 490552.096
Total Hours : 24.94277444444445
SVType Freq Track N_Samples CNo_Mean CNo_Median CNo_Std CNo_Min CNo_Max CNo_Range El_Mean El_Max
GPS L1 CA 839729 +0.4 +0.5 +1.8 -22.2 +13.0 +35.2 +37.1 +90.0
GPS L2 CM+CL 645020 +0.2 +0.2 +1.3 -8.3 +28.4 +36.7 +38.4 +90.0
GPS L2 E 194191 +1.1 +1.1 +1.8 -8.6 +9.2 +17.8 +32.6 +77.0
GPS L5/E5A I+Q 459921 +0.1 +0.1 +1.1 -10.5 +26.4 +36.9 +37.0 +88.0
SBAS L1 CA 273123 +0.1 +0.2 +1.2 -4.5 +4.0 +8.5 +39.8 +42.0
GLONASS L1 CA 649318 +1.3 +1.2 +2.0 -22.4 +27.3 +49.7 +35.8 +89.0
GLONASS L2 CA 552469 -0.1 -0.1 +1.5 -11.0 +27.2 +38.2 +35.9 +89.0
Galileo L1 MBOC-PD 642553 +0.4 +0.5 +1.6 -19.8 +27.8 +47.6 +36.8 +89.0
Galileo E5A+B AltBOC-Comp-PD 642560 +0.3 +0.3 +0.8 -6.0 +8.4 +14.4 +36.8 +89.0
BeiDou L5/E5A I+Q 635612 +0.1 +0.0 +1.1 -11.1 +19.9 +31.0 +37.1 +90.0
BeiDou E5B/B2 BPSK(2)-B2 77419 +0.5 +0.4 +1.1 -5.0 +10.6 +15.6 +41.9 +82.0
BeiDou B1 BPSK(2)-B1 713054 +0.4 +0.4 +1.7 -10.9 +16.4 +27.3 +37.6 +90.0
BeiDou B3 BPSK(10)-B3 712980 +0.2 +0.2 +1.2 -15.1 +22.3 +37.4 +37.6 +90.0
start/stop time: 400,758 491,798
Total time: 91,040.0 seconds
Total time: 1,517.333 minutes
Total time: 25.289 hours
Total Samples: 7,037,949
Avg Samples/sec: 77.3

Statistics for full C/No Observations dataset
(df_ref - df_dut => positive numbers mean DUT is worse)
Mean = 0.352
Median = 0.300
Std Dev= 1.520

Plots


REF GPS L1(CA)

SV AvgEl AvgOffset AvgCNo MaxCNo MinCNo Slip_Count SVChan Ant N_Samples
2 26.0 0.0 43.2 49.9 27.4 197 [16.0, 35.0] [0.0] 30523
3 32.7 0.0 42.8 52.2 29.8 213 [25.0, 37.0] [0.0] 27101
4 45.4 0.0 44.7 50.6 33.0 0 [20.0] [0.0] 23831
5 41.6 0.0 44.7 51.7 12.5 303 [17.0, 35.0, 19.0] [0.0] 27969
6 38.4 0.0 43.4 52.1 23.6 147 [32.0, 27.0] [0.0] 24505
7 45.1 0.0 45.8 51.9 31.7 1 [29.0] [0.0] 25519
8 27.3 0.0 42.4 50.6 28.5 235 [33.0, 26.0] [0.0] 29161
9 44.0 0.0 44.8 52.4 31.5 0 [37.0] [0.0] 21445
10 43.4 0.0 46.9 53.6 30.6 211 [36.0, 37.0] [0.0] 25864
11 42.7 0.0 44.5 53.4 26.5 207 [33.0, 36.0] [0.0] 25785
12 36.5 0.0 43.7 51.5 26.3 233 [28.0, 33.0] [0.0] 25028
13 26.9 0.0 42.8 49.9 27.1 257 [33.0, 27.0] [0.0] 23311
14 44.1 0.0 45.3 50.7 30.6 0 [18.0] [0.0] 25739
15 31.0 0.0 43.5 50.8 32.2 365 [34.0, 13.0, 24.0] [0.0] 32671
16 29.6 0.0 41.6 50.5 26.9 206 [33.0, 31.0, 36.0] [0.0] 29384
17 45.7 0.0 45.3 52.5 30.3 9 [30.0] [0.0] 24125
18 44.8 0.0 45.3 51.5 33.6 160 [35.0, 30.0] [0.0] 29847
19 44.6 0.0 44.7 51.4 30.5 3 [25.0] [0.0] 24591
20 32.1 0.0 42.1 51.2 28.7 238 [24.0, 19.0, 28.0] [0.0] 30843
21 26.6 0.0 42.3 48.8 23.0 307 [37.0, 21.0] [0.0] 30229
22 44.5 0.0 45.2 51.2 32.4 1 [31.0] [0.0] 25987
23 40.6 0.0 44.5 51.0 28.9 102 [23.0, 14.0] [0.0] 30433
24 25.6 0.0 41.2 48.9 24.5 226 [24.0, 26.0] [0.0] 29804
25 27.3 0.0 41.0 49.7 24.3 287 [29.0, 23.0] [0.0] 32160
26 26.6 0.0 42.2 50.0 26.0 217 [27.0, 24.0, 29.0] [0.0] 33407
27 26.1 0.0 42.5 49.0 26.4 204 [29.0, 32.0] [0.0] 29883
28 39.7 0.0 43.2 50.2 22.5 88 [19.0, 30.0] [0.0] 23145
29 51.2 0.0 46.4 52.5 30.9 105 [16.0, 18.0] [0.0] 27598
30 45.9 0.0 45.7 52.3 29.9 0 [22.0] [0.0] 23662
31 45.3 0.0 45.4 53.9 19.9 54 [35.0] [0.0] 22332
32 45.3 0.0 47.3 54.5 30.6 6 [32.0] [0.0] 24637
DUT GPS L1(CA)

SV AvgEl AvgOffset AvgCNo MaxCNo MinCNo Slip_Count SVChan Ant N_Samples
2 26.0 0.0 43.1 49.5 34.6 225 [15.0, 29.0] [0.0] 30518
3 32.9 0.0 42.7 51.6 23.8 55 [31.0, 36.0] [0.0] 26898
4 45.4 0.0 44.1 50.9 29.9 0 [23.0] [0.0] 23827
5 41.7 0.0 44.3 51.5 20.4 429 [17.0, 29.0, 19.0] [0.0] 27947
6 38.4 0.0 42.5 51.9 19.2 52 [35.0, 27.0] [0.0] 24498
7 45.1 0.0 45.1 50.2 29.0 3 [32.0] [0.0] 25487
8 27.3 0.0 42.0 49.8 27.0 76 [34.0, 24.0] [0.0] 29161
9 44.1 0.0 44.7 51.6 28.6 0 [36.0] [0.0] 21427
10 43.4 0.0 46.8 53.3 31.1 23 [37.0, 36.0] [0.0] 25851
11 42.6 0.0 43.5 51.8 29.5 58 [34.0, 37.0] [0.0] 25811
12 36.6 0.0 43.6 50.2 28.6 320 [30.0, 34.0, 32.0] [0.0] 24982
13 26.9 0.0 42.1 48.0 27.7 159 [25.0, 27.0] [0.0] 23320
14 44.1 0.0 44.4 49.6 33.7 0 [19.0] [0.0] 25733
15 31.0 0.0 43.3 50.3 32.0 278 [28.0, 31.0, 24.0] [0.0] 32678
16 29.7 0.0 41.5 49.5 29.8 58 [34.0, 26.0, 37.0] [0.0] 29358
17 45.7 0.0 44.1 50.9 25.5 6 [23.0] [0.0] 24129
18 44.8 0.0 44.8 50.7 27.4 214 [29.0, 34.0] [0.0] 29870
19 44.6 0.0 43.7 49.9 33.1 0 [34.0] [0.0] 24609
20 32.2 0.0 41.7 49.5 26.7 333 [37.0, 20.0, 29.0] [0.0] 30787
21 26.6 0.0 42.5 49.6 32.1 213 [35.0, 20.0] [0.0] 30269
22 44.5 0.0 44.5 50.0 31.1 1 [26.0] [0.0] 25973
23 40.6 0.0 44.5 50.5 29.4 22 [19.0, 14.0] [0.0] 30477
24 25.6 0.0 41.0 47.2 31.8 2 [30.0, 24.0] [0.0] 29835
25 27.3 0.0 41.2 49.3 27.8 398 [27.0, 36.0, 25.0] [0.0] 32154
26 26.6 0.0 41.5 50.0 27.9 187 [24.0, 30.0, 31.0] [0.0] 33416
27 26.2 0.0 42.6 48.4 29.7 3 [36.0, 35.0] [0.0] 29853
28 39.7 0.0 43.1 50.8 23.8 140 [20.0, 24.0] [0.0] 23197
29 51.1 0.0 45.7 52.6 34.9 37 [16.0, 18.0] [0.0] 27608
30 45.9 0.0 45.0 51.1 26.8 6 [22.0] [0.0] 23638
31 45.3 0.0 45.2 52.8 21.5 20 [29.0] [0.0] 22335
32 45.3 0.0 47.0 54.1 27.9 5 [32.0] [0.0] 24649
DIFF GPS L1(CA)

SV AvgEl AvgCNoDiff MaxCNoDiff MinCNoDiff SVChan N_Samples
2 26.1 0.2 5.7 -11.0 [16.0, 15.0, 35.0, 29.0] 30501
3 32.9 0.1 11.9 -7.9 [25.0, 31.0, 37.0, 36.0] 26890
4 45.4 0.6 7.0 -7.3 [20.0, 23.0] 23813
5 41.7 0.4 9.7 -22.2 [17.0, 35.0, 29.0, 19.0] 27935
6 38.4 0.9 10.6 -11.1 [32.0, 35.0, 27.0] 24462
7 45.1 0.8 8.0 -4.5 [29.0, 32.0] 25487
8 27.4 0.4 8.3 -7.8 [33.0, 34.0, 26.0, 24.0] 29141
9 44.1 0.1 4.9 -8.5 [37.0, 36.0] 21427
10 43.4 0.2 6.4 -7.9 [36.0, 37.0] 25838
11 42.7 0.9 7.8 -7.1 [33.0, 34.0, 36.0, 37.0] 25781
12 36.6 0.1 6.8 -11.1 [28.0, 30.0, 33.0, 34.0, 32.0] 24981
13 26.9 0.7 9.5 -10.8 [33.0, 25.0, 27.0] 23305
14 44.1 0.9 6.5 -7.7 [18.0, 19.0] 25732
15 31.0 0.2 6.8 -7.0 [34.0, 28.0, 13.0, 31.0, 24.0] 32650
16 29.7 0.2 7.1 -7.8 [33.0, 34.0, 31.0, 26.0, 36.0, 37.0] 29330
17 45.7 1.2 12.3 -7.1 [30.0, 23.0] 24125
18 44.8 0.5 7.7 -4.3 [35.0, 29.0, 30.0, 34.0] 29837
19 44.6 1.0 6.2 -6.9 [25.0, 34.0] 24591
20 32.2 0.4 7.9 -7.2 [24.0, 37.0, 19.0, 20.0, 28.0, 29.0] 30787
21 26.6 -0.2 5.9 -13.1 [37.0, 35.0, 21.0, 20.0] 30217
22 44.5 0.7 8.0 -8.4 [31.0, 26.0] 25973
23 40.6 -0.0 5.5 -10.5 [23.0, 19.0, 14.0] 30429
24 25.6 0.2 6.5 -11.0 [24.0, 30.0, 26.0] 29801
25 27.3 -0.1 7.2 -14.7 [29.0, 27.0, 36.0, 23.0, 25.0] 32129
26 26.6 0.7 8.6 -9.4 [27.0, 24.0, 30.0, 29.0, 31.0] 33385
27 26.2 -0.1 5.5 -8.1 [29.0, 36.0, 32.0, 35.0] 29853
28 39.8 0.1 9.0 -14.1 [19.0, 20.0, 30.0, 24.0] 23136
29 51.1 0.7 6.4 -7.4 [16.0, 18.0] 27594
30 45.9 0.7 9.8 -6.2 [22.0] 23638
31 45.3 0.2 13.0 -16.3 [35.0, 29.0] 22331
32 45.3 0.3 7.2 -10.2 [32.0] 24630
REF GPS L2(E)

SV AvgEl AvgOffset AvgCNo MaxCNo MinCNo Slip_Count SVChan Ant N_Samples
2 26.0 0.0 30.6 38.4 14.8 31 [16.0, 35.0] [0.0] 30523
13 27.0 0.0 28.1 36.8 14.8 89 [33.0, 27.0] [0.0] 23234
16 29.6 0.0 28.0 41.1 15.6 362 [33.0, 31.0, 36.0] [0.0] 29378
19 44.7 0.0 34.9 44.4 15.6 4 [25.0] [0.0] 24579
20 32.1 0.0 29.2 41.1 14.8 92 [24.0, 19.0, 28.0] [0.0] 30843
21 26.9 0.0 28.3 38.3 13.9 54 [37.0, 21.0] [0.0] 29806
22 44.5 0.0 33.4 41.6 16.3 1 [31.0] [0.0] 25987
DUT GPS L2(E)

SV AvgEl AvgOffset AvgCNo MaxCNo MinCNo Slip_Count SVChan Ant N_Samples
2 26.0 0.0 29.9 36.9 17.4 49 [15.0, 29.0] [0.0] 30518
3 32.9 0.0 39.3 50.2 22.5 33 [31.0, 36.0] [0.0] 26880
4 45.4 0.0 32.8 42.1 15.6 0 [23.0] [0.0] 23827
5 41.7 0.0 41.5 49.8 21.8 187 [17.0, 29.0, 19.0] [0.0] 27903
6 38.4 0.0 40.2 51.0 20.6 60 [35.0, 27.0] [0.0] 24478
7 45.1 0.0 41.0 48.3 21.3 3 [32.0] [0.0] 25487
8 27.3 0.0 38.2 46.6 21.8 258 [34.0, 24.0] [0.0] 29161
9 44.1 0.0 43.3 51.7 26.7 0 [36.0] [0.0] 21427
10 43.4 0.0 44.4 51.6 26.9 170 [37.0, 36.0] [0.0] 25851
11 42.6 0.0 31.9 42.7 15.6 212 [34.0, 37.0] [0.0] 25811
12 36.6 0.0 39.8 48.6 24.4 356 [30.0, 34.0, 32.0] [0.0] 24982
13 26.9 0.0 26.5 34.3 14.8 167 [25.0, 27.0] [0.0] 23320
14 44.1 0.0 33.3 40.2 17.8 0 [19.0] [0.0] 25733
15 31.0 0.0 38.7 47.2 21.3 221 [28.0, 31.0, 24.0] [0.0] 32678
16 29.7 0.0 27.2 39.7 14.8 212 [34.0, 26.0, 37.0] [0.0] 29358
17 45.7 0.0 40.8 48.9 15.6 6 [23.0] [0.0] 24129
18 44.8 0.0 33.9 42.8 15.6 14 [29.0, 34.0] [0.0] 29870
19 44.6 0.0 33.1 42.5 13.9 0 [34.0] [0.0] 24609
20 32.2 0.0 28.2 39.8 12.6 85 [37.0, 20.0, 29.0] [0.0] 30787
21 26.6 0.0 27.8 37.6 14.8 166 [35.0, 20.0] [0.0] 30269
22 44.5 0.0 31.7 38.7 14.8 1 [26.0] [0.0] 25973
23 40.6 0.0 33.4 41.3 17.4 117 [19.0, 14.0] [0.0] 30477
24 25.6 0.0 37.8 45.2 25.1 126 [30.0, 24.0] [0.0] 29835
25 27.3 0.0 36.7 46.5 20.1 376 [27.0, 36.0, 25.0] [0.0] 32154
26 26.6 0.0 37.0 46.8 21.7 394 [24.0, 30.0, 31.0] [0.0] 33416
27 26.2 0.0 39.5 46.5 25.7 254 [36.0, 35.0] [0.0] 29853
28 39.7 0.0 31.8 41.7 13.9 36 [20.0, 24.0] [0.0] 23188
29 51.1 0.0 43.4 52.1 26.5 85 [16.0, 18.0] [0.0] 27608
30 45.9 0.0 42.2 49.9 22.2 6 [22.0] [0.0] 23638
31 45.3 0.0 41.9 51.0 24.6 18 [29.0] [0.0] 22331
32 45.3 0.0 44.3 52.6 19.9 5 [32.0] [0.0] 24649
DIFF GPS L2(E)

SV AvgEl AvgCNoDiff MaxCNoDiff MinCNoDiff SVChan N_Samples
2 26.1 0.7 6.3 -8.6 [16.0, 15.0, 35.0, 29.0] 30501
13 27.0 1.6 9.2 -6.2 [33.0, 25.0, 27.0] 23233
16 29.7 0.8 7.7 -4.4 [33.0, 34.0, 31.0, 26.0, 36.0, 37.0] 29324
19 44.7 1.7 6.4 -5.4 [25.0, 34.0] 24579
20 32.2 1.0 8.4 -6.8 [24.0, 37.0, 19.0, 20.0, 28.0, 29.0] 30787
21 26.9 0.4 6.7 -6.6 [37.0, 35.0, 21.0, 20.0] 29794
22 44.5 1.6 6.8 -5.2 [31.0, 26.0] 25973
REF GPS L2(CM+CL)

SV AvgEl AvgOffset AvgCNo MaxCNo MinCNo Slip_Count SVChan Ant N_Samples
3 32.7 0.0 43.0 49.2 34.6 89 [25.0, 37.0] [0.0] 27101
4 45.4 0.0 46.7 51.8 36.0 0 [20.0] [0.0] 23831
5 41.6 0.0 44.6 49.7 31.1 429 [17.0, 35.0, 19.0] [0.0] 27969
6 38.4 0.0 44.9 50.1 32.1 170 [32.0, 27.0] [0.0] 24505
7 45.1 0.0 44.7 49.2 33.0 0 [29.0] [0.0] 25519
8 27.3 0.0 42.9 47.5 33.3 252 [33.0, 26.0] [0.0] 29161
9 44.0 0.0 45.2 49.8 34.0 0 [37.0] [0.0] 21445
10 43.4 0.0 44.9 49.3 36.0 209 [36.0, 37.0] [0.0] 25864
11 42.7 0.0 46.1 52.0 32.4 107 [33.0, 36.0] [0.0] 25785
12 36.5 0.0 43.9 49.3 32.7 67 [28.0, 33.0] [0.0] 25028
14 44.1 0.0 46.7 51.9 29.8 0 [18.0] [0.0] 25739
15 31.0 0.0 42.9 47.6 34.0 319 [34.0, 13.0, 24.0] [0.0] 32671
17 45.7 0.0 44.3 50.0 30.9 0 [30.0] [0.0] 24125
18 44.8 0.0 47.0 51.4 36.5 23 [35.0, 30.0] [0.0] 29847
23 40.6 0.0 46.1 51.2 34.7 12 [23.0, 14.0] [0.0] 30433
24 25.6 0.0 42.4 47.4 33.5 126 [24.0, 26.0] [0.0] 29804
25 27.3 0.0 41.7 48.0 28.1 236 [29.0, 23.0] [0.0] 32160
26 26.6 0.0 42.4 47.8 32.7 54 [27.0, 24.0, 29.0] [0.0] 33407
27 26.1 0.0 42.6 46.9 32.6 50 [29.0, 32.0] [0.0] 29883
28 39.7 0.0 46.4 51.6 36.0 43 [19.0, 30.0] [0.0] 23145
29 51.2 0.0 45.2 49.6 35.7 227 [16.0, 18.0] [0.0] 27598
30 45.9 0.0 44.5 49.3 35.6 0 [22.0] [0.0] 23662
31 45.3 0.0 44.8 50.0 34.2 0 [35.0] [0.0] 22332
32 45.3 0.0 45.0 49.7 25.3 3 [32.0] [0.0] 24637
DUT GPS L2(CM+CL)

SV AvgEl AvgOffset AvgCNo MaxCNo MinCNo Slip_Count SVChan Ant N_Samples
3 32.9 0.0 43.1 48.8 30.9 30 [31.0, 36.0] [0.0] 26898
4 45.4 0.0 46.3 51.9 33.6 0 [23.0] [0.0] 23827
5 41.7 0.0 44.5 49.7 33.3 160 [17.0, 29.0, 19.0] [0.0] 27947
6 38.4 0.0 44.5 50.2 30.9 41 [35.0, 27.0] [0.0] 24498
7 45.1 0.0 44.1 49.3 32.5 0 [32.0] [0.0] 25487
8 27.3 0.0 43.0 48.4 33.7 136 [34.0, 24.0] [0.0] 29161
9 44.1 0.0 44.6 49.3 35.0 0 [36.0] [0.0] 21427
10 43.4 0.0 44.7 49.5 36.1 11 [37.0, 36.0] [0.0] 25851
11 42.6 0.0 46.0 52.3 30.1 25 [34.0, 37.0] [0.0] 25811
12 36.6 0.0 43.5 48.6 33.4 381 [30.0, 34.0, 32.0] [0.0] 24982
14 44.1 0.0 46.5 51.5 32.8 0 [19.0] [0.0] 25733
15 31.0 0.0 42.6 47.4 28.0 173 [28.0, 31.0, 24.0] [0.0] 32678
17 45.7 0.0 44.4 49.9 28.3 0 [23.0] [0.0] 24129
18 44.8 0.0 46.6 51.8 35.7 216 [29.0, 34.0] [0.0] 29870
23 40.6 0.0 46.1 51.0 36.6 251 [19.0, 14.0] [0.0] 30477
24 25.6 0.0 42.2 47.1 33.8 65 [30.0, 24.0] [0.0] 29835
25 27.3 0.0 41.7 47.2 8.9 310 [27.0, 36.0, 25.0] [0.0] 32149
26 26.6 0.0 42.2 47.5 32.8 380 [24.0, 30.0, 31.0] [0.0] 33416
27 26.2 0.0 42.8 46.8 32.1 217 [36.0, 35.0] [0.0] 29853
28 39.7 0.0 46.2 51.4 36.2 76 [20.0, 24.0] [0.0] 23197
29 51.1 0.0 44.8 49.3 32.9 197 [16.0, 18.0] [0.0] 27608
30 45.9 0.0 43.9 48.6 33.1 0 [22.0] [0.0] 23638
31 45.3 0.0 44.9 49.3 35.5 0 [29.0] [0.0] 22335
32 45.3 0.0 45.0 49.6 19.6 8 [32.0] [0.0] 24649
DIFF GPS L2(CM+CL)

SV AvgEl AvgCNoDiff MaxCNoDiff MinCNoDiff SVChan N_Samples
3 32.9 -0.1 6.7 -6.4 [25.0, 31.0, 37.0, 36.0] 26890
4 45.4 0.4 7.1 -6.1 [20.0, 23.0] 23813
5 41.7 0.1 4.8 -6.7 [17.0, 35.0, 29.0, 19.0] 27935
6 38.4 0.4 9.6 -6.3 [32.0, 35.0, 27.0] 24462
7 45.1 0.6 5.7 -4.0 [29.0, 32.0] 25487
8 27.4 -0.1 5.7 -4.8 [33.0, 34.0, 26.0, 24.0] 29141
9 44.1 0.6 5.1 -4.1 [37.0, 36.0] 21427
10 43.4 0.3 4.3 -5.2 [36.0, 37.0] 25838
11 42.7 0.1 8.3 -5.6 [33.0, 34.0, 36.0, 37.0] 25781
12 36.6 0.5 5.6 -4.7 [28.0, 30.0, 33.0, 34.0, 32.0] 24981
14 44.1 0.2 4.6 -7.5 [18.0, 19.0] 25732
15 31.0 0.4 7.0 -6.0 [34.0, 28.0, 13.0, 31.0, 24.0] 32650
17 45.7 -0.1 6.8 -6.6 [30.0, 23.0] 24125
18 44.8 0.5 5.8 -3.6 [35.0, 29.0, 30.0, 34.0] 29837
23 40.6 -0.0 6.8 -5.0 [23.0, 19.0, 14.0] 30429
24 25.6 0.2 6.3 -5.0 [24.0, 30.0, 26.0] 29801
25 27.3 0.0 28.4 -8.3 [29.0, 27.0, 36.0, 23.0, 25.0] 32124
26 26.6 0.2 6.7 -4.8 [27.0, 24.0, 30.0, 29.0, 31.0] 33385
27 26.2 -0.2 6.6 -6.4 [29.0, 36.0, 32.0, 35.0] 29853
28 39.8 0.2 5.3 -4.7 [19.0, 20.0, 30.0, 24.0] 23136
29 51.1 0.4 6.3 -3.7 [16.0, 18.0] 27594
30 45.9 0.6 6.1 -4.4 [22.0] 23638
31 45.3 -0.1 7.1 -5.3 [35.0, 29.0] 22331
32 45.3 -0.1 18.5 -7.7 [32.0] 24630
REF GPS L5/E5A(I+Q)

SV AvgEl AvgOffset AvgCNo MaxCNo MinCNo Slip_Count SVChan Ant N_Samples
3 32.7 0.0 47.2 51.8 40.2 161 [25.0, 37.0] [0.0] 27101
4 45.4 0.0 48.5 52.7 39.9 0 [20.0] [0.0] 23831
6 38.4 0.0 47.9 52.5 37.5 3 [32.0, 27.0] [0.0] 24505
8 27.3 0.0 46.6 50.7 38.0 208 [33.0, 26.0] [0.0] 29161
9 44.0 0.0 49.1 53.0 42.0 0 [37.0] [0.0] 21445
10 43.4 0.0 48.2 51.6 40.4 53 [36.0, 37.0] [0.0] 25864
11 42.7 0.0 48.2 54.6 37.7 46 [33.0, 36.0] [0.0] 25785
14 44.1 0.0 48.6 53.4 41.1 0 [18.0] [0.0] 25739
18 44.8 0.0 49.3 53.5 41.5 33 [35.0, 30.0] [0.0] 29847
23 40.6 0.0 48.4 53.4 38.4 167 [23.0, 14.0] [0.0] 30433
24 25.6 0.0 46.3 50.9 33.3 68 [24.0, 26.0] [0.0] 29804
25 27.3 0.0 46.3 51.9 32.7 233 [29.0, 23.0] [0.0] 32160
26 26.6 0.0 46.3 50.6 39.9 380 [27.0, 24.0, 29.0] [0.0] 33407
27 26.1 0.0 46.4 50.2 39.5 207 [29.0, 32.0] [0.0] 29883
28 39.7 0.0 48.3 52.9 41.5 189 [19.0, 30.0] [0.0] 23145
30 45.9 0.0 49.1 52.9 40.9 0 [22.0] [0.0] 23662
32 45.3 0.0 46.6 50.7 29.8 0 [32.0] [0.0] 24637
DUT GPS L5/E5A(I+Q)

SV AvgEl AvgOffset AvgCNo MaxCNo MinCNo Slip_Count SVChan Ant N_Samples
3 32.9 0.0 47.3 52.1 38.9 158 [31.0, 36.0] [0.0] 26898
4 45.4 0.0 48.1 53.2 39.8 0 [23.0] [0.0] 23827
6 38.4 0.0 47.8 52.5 36.9 224 [35.0, 27.0] [0.0] 24498
8 27.3 0.0 46.7 51.2 38.9 134 [34.0, 24.0] [0.0] 29161
9 44.1 0.0 48.6 52.3 40.5 0 [36.0] [0.0] 21427
10 43.4 0.0 48.1 51.1 40.6 169 [37.0, 36.0] [0.0] 25851
11 42.6 0.0 48.4 53.9 17.4 266 [34.0, 37.0] [0.0] 25810
14 44.1 0.0 48.5 53.4 40.8 0 [19.0] [0.0] 25733
18 44.8 0.0 48.9 53.2 40.1 245 [29.0, 34.0] [0.0] 29870
23 40.6 0.0 48.3 53.3 39.7 7 [19.0, 14.0] [0.0] 30477
24 25.6 0.0 46.1 50.2 37.0 219 [30.0, 24.0] [0.0] 29835
25 27.3 0.0 46.0 51.6 31.0 234 [27.0, 36.0, 25.0] [0.0] 32154
26 26.6 0.0 46.2 50.8 39.6 115 [24.0, 30.0, 31.0] [0.0] 33416
27 26.2 0.0 46.5 49.5 40.6 252 [36.0, 35.0] [0.0] 29853
28 39.7 0.0 48.2 52.8 39.9 221 [20.0, 24.0] [0.0] 23197
30 45.9 0.0 48.7 52.6 40.0 0 [22.0] [0.0] 23638
32 45.3 0.0 46.8 50.5 32.7 0 [32.0] [0.0] 24649
DIFF GPS L5/E5A(I+Q)

SV AvgEl AvgCNoDiff MaxCNoDiff MinCNoDiff SVChan N_Samples
3 32.9 -0.1 5.5 -4.3 [25.0, 31.0, 37.0, 36.0] 26890
4 45.4 0.4 4.9 -2.4 [20.0, 23.0] 23813
6 38.4 0.1 7.6 -6.0 [32.0, 35.0, 27.0] 24462
8 27.4 -0.1 3.6 -3.8 [33.0, 34.0, 26.0, 24.0] 29141
9 44.1 0.5 3.8 -3.3 [37.0, 36.0] 21427
10 43.4 0.1 2.6 -2.7 [36.0, 37.0] 25838
11 42.7 -0.3 26.4 -5.3 [33.0, 34.0, 36.0, 37.0] 25780
14 44.1 0.2 4.1 -2.9 [18.0, 19.0] 25732
18 44.8 0.4 3.0 -2.3 [35.0, 29.0, 30.0, 34.0] 29837
23 40.6 0.1 3.0 -4.0 [23.0, 19.0, 14.0] 30429
24 25.6 0.2 4.6 -10.5 [24.0, 30.0, 26.0] 29801
25 27.3 0.3 9.6 -10.2 [29.0, 27.0, 36.0, 23.0, 25.0] 32129
26 26.6 0.1 3.5 -4.3 [27.0, 24.0, 30.0, 29.0, 31.0] 33385
27 26.2 -0.1 3.1 -4.1 [29.0, 36.0, 32.0, 35.0] 29853
28 39.8 0.1 5.9 -4.0 [19.0, 20.0, 30.0, 24.0] 23136
30 45.9 0.4 3.8 -2.6 [22.0] 23638
32 45.3 -0.2 4.9 -5.7 [32.0] 24630
REF SBAS L1(CA)

SV AvgEl AvgOffset AvgCNo MaxCNo MinCNo Slip_Count SVChan Ant N_Samples
131 42.0 0.0 46.4 48.5 43.9 0 [57.0] [0.0] 91045
133 38.0 0.0 43.6 46.0 41.3 0 [55.0] [0.0] 91045
135 39.3 0.0 44.6 46.8 42.2 0 [56.0] [0.0] 91045
158 -45.0 0.0 36.0 40.3 22.9 548 [54.0] [0.0] 81967
DUT SBAS L1(CA)

SV AvgEl AvgOffset AvgCNo MaxCNo MinCNo Slip_Count SVChan Ant N_Samples
131 42.0 0.0 45.2 47.5 41.7 0 [55.0] [0.0] 91049
133 38.0 0.0 44.7 47.5 40.2 0 [57.0] [0.0] 91049
135 39.3 0.0 44.6 47.3 40.6 0 [56.0] [0.0] 91049
DIFF SBAS L1(CA)

SV AvgEl AvgCNoDiff MaxCNoDiff MinCNoDiff SVChan N_Samples
131 42.0 1.1 4.0 -1.3 [57.0, 55.0] 91041
133 38.0 -1.1 3.3 -4.5 [55.0, 57.0] 91041
135 39.3 0.1 2.7 -2.1 [56.0] 91041
REF SBAS L5/E5A(I)

SV AvgEl AvgOffset AvgCNo MaxCNo MinCNo Slip_Count SVChan Ant N_Samples
131 42.0 0.0 46.7 48.4 45.0 0 [57.0] [0.0] 91045
133 38.0 0.0 46.1 47.8 44.5 0 [55.0] [0.0] 91045
135 39.3 0.0 46.1 48.0 44.4 0 [56.0] [0.0] 91045
DUT SBAS L5/E5A(I)
DIFF SBAS L5/E5A(I)
REF GLONASS L1(CA)

SV AvgEl AvgOffset AvgCNo MaxCNo MinCNo Slip_Count FDMA Ant N_Samples
1 36.9 0.0 42.3 49.3 26.9 340 [1.0] [0.0] 32795
2 37.4 0.0 47.4 53.1 23.3 53 [-4.0] [0.0] 24867
3 38.7 0.0 46.6 51.8 31.2 0 [5.0] [0.0] 23361
4 41.9 0.0 46.1 51.2 34.8 0 [6.0] [0.0] 21482
5 39.3 0.0 45.8 53.3 14.6 204 [1.0] [0.0] 22650
6 29.1 0.0 35.6 43.1 0.0 1089 [-4.0] [0.0] 29296
7 31.3 0.0 45.3 50.7 27.6 112 [5.0] [0.0] 36240
8 38.1 0.0 44.1 50.3 30.5 260 [6.0] [0.0] 37807
9 39.4 0.0 47.5 52.7 36.6 0 [-2.0] [0.0] 23268
11 36.1 0.0 45.8 52.9 14.3 104 [0.0] [0.0] 27784
12 32.5 0.0 46.5 53.2 29.8 142 [-1.0] [0.0] 30614
13 31.2 0.0 40.8 47.2 26.3 231 [-2.0] [0.0] 33142
14 31.1 0.0 46.8 53.8 36.2 422 [-7.0] [0.0] 33979
15 37.4 0.0 46.2 52.9 30.6 52 [0.0] [0.0] 25784
16 39.5 0.0 47.9 53.4 29.7 16 [-1.0] [0.0] 22914
17 30.1 0.0 44.8 51.2 31.6 349 [4.0] [0.0] 27482
18 28.7 0.0 45.4 51.8 29.3 225 [-3.0] [0.0] 26785
19 29.3 0.0 35.6 41.8 24.3 270 [3.0] [0.0] 26537
20 34.7 0.0 35.5 41.3 23.3 481 [2.0] [0.0] 24567
21 40.3 0.0 45.7 52.5 30.1 208 [4.0] [0.0] 23030
22 39.0 0.0 47.4 53.4 23.5 209 [-3.0] [0.0] 32914
23 44.8 0.0 45.6 50.3 21.2 58 [3.0] [0.0] 34595
24 37.3 0.0 45.7 52.8 30.1 372 [2.0] [0.0] 32718
DUT GLONASS L1(CA)

SV AvgEl AvgOffset AvgCNo MaxCNo MinCNo Slip_Count FDMA Ant N_Samples
1 36.9 0.0 41.4 47.9 17.4 250 [1.0] [0.0] 32836
2 37.4 0.0 47.0 52.8 29.7 198 [-4.0] [0.0] 24902
3 38.7 0.0 45.4 51.0 32.0 0 [5.0] [0.0] 23363
4 41.9 0.0 44.5 49.5 27.3 0 [6.0] [0.0] 21461
5 39.3 0.0 44.5 51.8 18.7 272 [1.0] [0.0] 22649
6 29.2 0.0 34.1 41.4 20.6 2579 [-4.0] [0.0] 29151
7 31.3 0.0 43.2 50.2 22.0 376 [5.0] [0.0] 36234
8 38.2 0.0 42.2 49.7 27.4 166 [6.0] [0.0] 37757
9 39.4 0.0 46.1 50.3 34.4 0 [-2.0] [0.0] 23270
11 36.1 0.0 44.5 51.0 27.8 59 [0.0] [0.0] 27777
12 32.6 0.0 45.7 51.0 34.5 212 [-1.0] [0.0] 30575
13 31.2 0.0 39.7 46.7 22.7 588 [-2.0] [0.0] 33132
14 31.1 0.0 45.5 52.7 30.1 265 [-7.0] [0.0] 33973
15 37.5 0.0 45.3 52.0 30.1 192 [0.0] [0.0] 25748
16 39.4 0.0 46.7 51.9 25.3 3 [-1.0] [0.0] 22925
17 30.1 0.0 43.9 50.5 29.2 239 [4.0] [0.0] 27467
18 28.7 0.0 45.0 51.7 36.9 93 [-3.0] [0.0] 26760
19 31.0 0.0 34.7 40.6 23.0 904 [3.0] [0.0] 23981
20 36.2 0.0 34.0 39.4 23.7 1478 [2.0] [0.0] 22593
21 40.3 0.0 43.9 50.0 9.8 188 [4.0] [0.0] 23030
22 39.0 0.0 46.1 52.7 31.6 188 [-3.0] [0.0] 32918
23 44.9 0.0 44.1 49.2 26.7 82 [3.0] [0.0] 34554
24 37.3 0.0 44.5 51.4 26.3 149 [2.0] [0.0] 32696
DIFF GLONASS L1(CA)

SV AvgEl AvgCNoDiff MaxCNoDiff MinCNoDiff FDMA N_Samples
1 36.9 0.9 15.7 -7.6 [1.0] 32792
2 37.4 0.3 9.7 -13.3 [-4.0] 24864
3 38.7 1.2 7.9 -5.6 [5.0] 23361
4 41.9 1.6 10.8 -3.7 [6.0] 21452
5 39.4 1.2 15.8 -14.8 [1.0] 22618
6 29.2 1.6 10.0 -9.3 [-4.0] 29082
7 31.4 2.1 16.8 -7.7 [5.0] 36218
8 38.2 1.9 10.3 -6.5 [6.0] 37742
9 39.4 1.4 6.2 -5.7 [-2.0] 23268
11 36.1 1.3 9.9 -22.4 [0.0] 27754
12 32.6 0.9 9.0 -12.9 [-1.0] 30564
13 31.2 1.1 11.9 -8.2 [-2.0] 33108
14 31.1 1.3 13.7 -6.4 [-7.0] 33955
15 37.5 0.9 9.4 -8.8 [0.0] 25740
16 39.5 1.2 13.1 -10.1 [-1.0] 22914
17 30.1 0.9 7.5 -9.4 [4.0] 27441
18 28.7 0.4 5.7 -11.3 [-3.0] 26760
19 31.0 1.2 6.3 -4.8 [3.0] 23981
20 36.3 1.9 7.8 -4.9 [2.0] 22572
21 40.4 1.8 27.3 -7.5 [4.0] 22999
22 39.0 1.3 9.0 -12.2 [-3.0] 32904
23 44.9 1.5 10.6 -13.3 [3.0] 34546
24 37.3 1.2 10.9 -10.5 [2.0] 32683
REF GLONASS L1(P)

SV AvgEl AvgOffset AvgCNo MaxCNo MinCNo Slip_Count FDMA Ant N_Samples
1 36.9 0.0 40.8 47.0 28.4 335 [1.0] [0.0] 32795
2 37.4 0.0 46.1 51.5 27.7 183 [-4.0] [0.0] 24867
3 38.7 0.0 44.8 50.2 30.5 0 [5.0] [0.0] 23361
4 41.9 0.0 44.0 49.0 32.2 0 [6.0] [0.0] 21482
5 39.3 0.0 44.5 51.1 27.1 203 [1.0] [0.0] 22650
6 29.2 0.0 34.4 41.1 22.6 1886 [-4.0] [0.0] 29175
7 31.3 0.0 43.5 48.4 28.1 42 [5.0] [0.0] 36240
8 38.1 0.0 42.1 47.8 29.9 308 [6.0] [0.0] 37807
9 39.4 0.0 46.0 51.1 35.6 0 [-2.0] [0.0] 23268
11 36.1 0.0 44.2 50.7 27.3 224 [0.0] [0.0] 27784
12 32.5 0.0 45.6 51.9 32.2 245 [-1.0] [0.0] 30614
13 31.2 0.0 39.5 45.6 23.1 315 [-2.0] [0.0] 33142
14 31.1 0.0 45.4 52.0 36.0 300 [-7.0] [0.0] 33979
15 37.4 0.0 44.5 50.9 33.0 142 [0.0] [0.0] 25784
16 39.5 0.0 46.5 52.0 31.0 3 [-1.0] [0.0] 22896
17 30.1 0.0 42.7 49.1 31.5 314 [4.0] [0.0] 27482
18 28.7 0.0 44.0 49.6 31.0 214 [-3.0] [0.0] 26785
19 29.3 0.0 33.6 39.6 20.9 2733 [3.0] [0.0] 26537
20 34.7 0.0 34.4 39.9 21.1 608 [2.0] [0.0] 24567
21 40.3 0.0 43.8 50.0 31.9 82 [4.0] [0.0] 23030
22 39.0 0.0 46.2 51.6 31.6 70 [-3.0] [0.0] 32913
23 44.8 0.0 43.6 48.1 29.5 70 [3.0] [0.0] 34595
24 37.3 0.0 44.1 50.8 30.1 377 [2.0] [0.0] 32718
DUT GLONASS L1(P)
DIFF GLONASS L1(P)
REF GLONASS L2(CA)

SV AvgEl AvgOffset AvgCNo MaxCNo MinCNo Slip_Count FDMA Ant N_Samples
1 36.9 0.0 39.9 45.0 24.3 199 [1.0] [0.0] 32795
2 37.4 0.0 45.0 49.5 31.2 130 [-4.0] [0.0] 24867
3 38.7 0.0 45.5 50.3 35.3 0 [5.0] [0.0] 23361
4 41.9 0.0 46.4 50.3 37.0 0 [6.0] [0.0] 21482
5 39.3 0.0 44.9 50.2 34.8 245 [1.0] [0.0] 22650
7 31.3 0.0 44.4 49.5 31.9 429 [5.0] [0.0] 36240
8 38.1 0.0 45.2 49.6 33.9 185 [6.0] [0.0] 37807
9 39.4 0.0 47.2 51.4 38.6 0 [-2.0] [0.0] 23268
11 36.1 0.0 45.3 51.4 36.0 27 [0.0] [0.0] 27784
12 32.5 0.0 44.8 49.9 30.5 149 [-1.0] [0.0] 30614
13 39.4 0.0 25.4 38.2 10.5 202 [-2.0] [0.0] 10
14 31.1 0.0 45.0 50.3 34.1 100 [-7.0] [0.0] 33979
15 37.4 0.0 45.1 50.2 34.3 141 [0.0] [0.0] 25784
16 39.5 0.0 46.2 50.7 27.8 2 [-1.0] [0.0] 22897
17 30.1 0.0 43.4 49.8 26.9 399 [4.0] [0.0] 27482
18 28.7 0.0 44.6 50.6 32.1 100 [-3.0] [0.0] 26785
19 29.3 0.0 41.9 46.9 33.5 135 [3.0] [0.0] 26537
20 34.7 0.0 38.4 43.6 26.9 133 [2.0] [0.0] 24567
21 40.3 0.0 44.2 48.9 30.6 253 [4.0] [0.0] 23030
22 39.0 0.0 46.1 52.1 28.9 101 [-3.0] [0.0] 32913
23 55.7 0.0 35.1 42.9 11.0 373 [3.0] [0.0] 152
24 37.3 0.0 44.8 49.8 35.0 305 [2.0] [0.0] 32718
DUT GLONASS L2(CA)

SV AvgEl AvgOffset AvgCNo MaxCNo MinCNo Slip_Count FDMA Ant N_Samples
1 36.9 0.0 39.9 45.5 26.5 173 [1.0] [0.0] 32836
2 37.4 0.0 45.0 49.9 13.9 89 [-4.0] [0.0] 24899
3 38.7 0.0 46.3 50.3 35.6 0 [5.0] [0.0] 23363
4 41.9 0.0 46.2 50.0 35.1 0 [6.0] [0.0] 21461
5 39.3 0.0 45.0 50.3 32.2 164 [1.0] [0.0] 22649
7 31.3 0.0 45.2 50.0 33.5 417 [5.0] [0.0] 36234
8 38.2 0.0 45.3 50.0 34.5 160 [6.0] [0.0] 37757
9 39.4 0.0 46.8 51.0 32.6 0 [-2.0] [0.0] 23270
11 36.1 0.0 45.2 51.2 33.9 91 [0.0] [0.0] 27777
12 32.6 0.0 44.8 50.0 21.5 317 [-1.0] [0.0] 30575
13 45.0 0.0 22.2 38.9 10.1 142 [-2.0] [0.0] 6
14 31.1 0.0 44.7 50.5 36.8 318 [-7.0] [0.0] 33973
15 37.5 0.0 45.3 49.8 33.3 48 [0.0] [0.0] 25748
16 39.4 0.0 46.3 50.4 32.7 0 [-1.0] [0.0] 22925
17 30.1 0.0 44.3 49.9 10.8 439 [4.0] [0.0] 27458
18 28.7 0.0 44.7 49.8 34.6 234 [-3.0] [0.0] 26760
19 31.0 0.0 42.0 46.8 31.2 251 [3.0] [0.0] 23951
20 36.3 0.0 38.4 43.2 28.3 247 [2.0] [0.0] 22531
21 40.3 0.0 44.8 49.2 30.7 244 [4.0] [0.0] 23040
22 39.0 0.0 46.2 51.4 32.1 177 [-3.0] [0.0] 32918
23 54.9 0.0 33.9 41.4 11.1 159 [3.0] [0.0] 82
24 37.3 0.0 44.5 49.3 34.6 261 [2.0] [0.0] 32695
DIFF GLONASS L2(CA)

SV AvgEl AvgCNoDiff MaxCNoDiff MinCNoDiff FDMA N_Samples
1 36.9 -0.1 8.0 -8.3 [1.0] 32792
2 37.4 -0.1 20.1 -10.5 [-4.0] 24861
3 38.7 -0.8 5.2 -6.7 [5.0] 23361
4 41.9 0.2 7.6 -4.8 [6.0] 21452
5 39.4 -0.0 7.3 -6.6 [1.0] 22618
7 31.4 -0.8 6.3 -7.3 [5.0] 36218
8 38.2 -0.1 6.9 -5.7 [6.0] 37742
9 39.4 0.4 9.7 -4.9 [-2.0] 23268
11 36.1 0.1 8.3 -5.3 [0.0] 27754
12 32.6 0.0 16.0 -7.3 [-1.0] 30564
14 31.1 0.2 6.9 -7.2 [-7.0] 33955
15 37.5 -0.2 5.7 -8.0 [0.0] 25740
16 39.5 -0.1 5.4 -11.0 [-1.0] 22897
17 30.1 -0.9 27.2 -9.7 [4.0] 27432
18 28.7 -0.1 5.5 -6.5 [-3.0] 26760
19 31.0 0.3 6.9 -6.1 [3.0] 23951
20 36.3 0.1 6.1 -6.7 [2.0] 22510
21 40.4 -0.5 5.6 -7.3 [4.0] 23009
22 39.0 -0.0 5.8 -10.0 [-3.0] 32903
24 37.3 0.3 6.6 -6.3 [2.0] 32682
REF GLONASS L2(P)

SV AvgEl AvgOffset AvgCNo MaxCNo MinCNo Slip_Count FDMA Ant N_Samples
1 36.9 0.0 37.7 42.6 24.1 729 [1.0] [0.0] 32795
2 37.4 0.0 43.5 48.7 30.8 73 [-4.0] [0.0] 24867
3 38.7 0.0 44.6 48.8 35.4 0 [5.0] [0.0] 23361
4 41.9 0.0 44.3 47.6 36.2 0 [6.0] [0.0] 21482
5 39.3 0.0 43.1 48.0 34.4 47 [1.0] [0.0] 22650
6 15.0 0.0 18.7 18.7 18.7 0 [-4.0] [0.0] 1
7 31.3 0.0 43.3 47.8 33.5 426 [5.0] [0.0] 36240
8 38.1 0.0 43.6 48.0 32.4 213 [6.0] [0.0] 37807
9 39.4 0.0 45.1 49.3 37.2 0 [-2.0] [0.0] 23268
11 36.1 0.0 43.4 48.8 34.5 15 [0.0] [0.0] 27784
12 32.5 0.0 42.9 47.9 30.4 197 [-1.0] [0.0] 30614
13 38.7 0.0 20.0 34.6 13.9 142 [-2.0] [0.0] 15
14 31.1 0.0 43.3 48.3 34.4 323 [-7.0] [0.0] 33979
15 37.4 0.0 43.5 48.5 33.7 214 [0.0] [0.0] 25784
16 39.5 0.0 44.4 48.9 25.3 63 [-1.0] [0.0] 22897
17 30.1 0.0 42.2 48.0 28.8 229 [4.0] [0.0] 27482
18 28.7 0.0 43.0 49.1 32.2 197 [-3.0] [0.0] 26785
19 29.3 0.0 40.2 44.9 32.4 43 [3.0] [0.0] 26537
20 34.7 0.0 36.7 41.8 23.3 313 [2.0] [0.0] 24567
21 40.3 0.0 43.3 47.5 32.8 189 [4.0] [0.0] 23030
22 39.0 0.0 44.4 49.9 28.8 111 [-3.0] [0.0] 32913
23 49.8 0.0 26.6 42.1 11.6 298 [3.0] [0.0] 114
24 37.3 0.0 43.0 47.7 33.4 217 [2.0] [0.0] 32718
DUT GLONASS L2(P)
DIFF GLONASS L2(P)
REF GLONASS G3(PD)

SV AvgEl AvgOffset AvgCNo MaxCNo MinCNo Slip_Count FDMA Ant N_Samples
9 39.4 0.0 45.8 49.9 37.6 0 [-2.0] [0.0] 23268
21 40.3 0.0 44.9 50.8 29.3 28 [4.0] [0.0] 23030
DUT GLONASS G3(PD)
DIFF GLONASS G3(PD)
REF Galileo L1(MBOC-PD)

SV AvgEl AvgOffset AvgCNo MaxCNo MinCNo Slip_Count SVChan Ant N_Samples
2 17.7 0.0 42.4 47.4 29.4 236 [39.0, 44.0, 48.0] [0.0] 21265
3 40.0 0.0 46.2 51.8 35.2 0 [41.0] [0.0] 23064
4 31.2 0.0 45.1 50.8 34.2 184 [51.0, 38.0] [0.0] 29250
5 24.6 0.0 44.5 49.9 37.3 172 [43.0, 46.0] [0.0] 18325
7 45.5 0.0 46.6 50.9 31.6 0 [50.0] [0.0] 32675
8 45.4 0.0 46.8 53.0 19.1 18 [45.0] [0.0] 29602
9 18.9 0.0 43.6 49.2 35.1 380 [45.0, 41.0, 46.0] [0.0] 22875
10 51.7 0.0 48.3 52.9 33.9 0 [51.0] [0.0] 23160
11 47.1 0.0 44.1 48.5 31.6 0 [43.0] [0.0] 18666
12 41.2 0.0 42.8 48.8 29.1 36 [41.0, 40.0] [0.0] 34387
13 35.5 0.0 44.8 50.0 31.8 25 [40.0, 43.0] [0.0] 40683
15 45.7 0.0 46.0 51.1 33.6 108 [48.0, 50.0] [0.0] 27290
19 36.5 0.0 41.4 49.0 10.9 310 [40.0, 41.0] [0.0] 38348
21 38.3 0.0 46.0 53.1 33.4 150 [50.0, 45.0] [0.0] 38715
24 41.6 0.0 47.0 52.7 30.9 1 [53.0] [0.0] 25945
25 34.0 0.0 46.1 50.8 36.9 0 [52.0] [0.0] 17403
26 33.0 0.0 45.8 51.8 33.0 250 [49.0, 52.0] [0.0] 41425
27 35.6 0.0 46.1 53.7 30.8 210 [46.0, 52.0] [0.0] 34339
30 27.5 0.0 44.8 49.9 33.3 206 [49.0, 48.0] [0.0] 25308
31 45.7 0.0 47.7 53.8 36.4 0 [42.0] [0.0] 31088
33 34.4 0.0 44.8 50.2 34.2 182 [43.0, 50.0] [0.0] 41004
34 39.0 0.0 46.9 52.5 37.8 0 [47.0] [0.0] 14983
36 21.4 0.0 44.0 50.4 34.1 61 [38.0, 39.0] [0.0] 13169
DUT Galileo L1(MBOC-PD)

SV AvgEl AvgOffset AvgCNo MaxCNo MinCNo Slip_Count SVChan Ant N_Samples
2 17.7 0.0 42.2 46.1 32.8 315 [44.0, 52.0, 39.0] [0.0] 21193
3 39.9 0.0 46.1 51.7 36.4 0 [43.0] [0.0] 23082
4 31.2 0.0 44.4 50.0 34.4 16 [53.0, 46.0] [0.0] 29255
5 24.6 0.0 44.0 49.3 35.6 69 [45.0, 43.0] [0.0] 18341
7 45.4 0.0 46.6 50.4 36.1 0 [50.0] [0.0] 32686
8 45.4 0.0 46.7 52.6 30.2 0 [41.0] [0.0] 29613
9 18.9 0.0 42.6 47.4 33.1 433 [49.0, 40.0, 52.0] [0.0] 22860
10 51.7 0.0 47.8 51.5 33.1 0 [53.0] [0.0] 23165
11 47.1 0.0 43.8 48.0 32.2 0 [43.0] [0.0] 18709
12 41.2 0.0 42.1 48.0 16.2 225 [44.0, 41.0] [0.0] 34385
13 35.5 0.0 44.6 49.9 33.4 224 [38.0, 44.0] [0.0] 40718
15 45.8 0.0 46.2 50.9 34.3 37 [47.0, 50.0] [0.0] 27240
19 36.4 0.0 40.8 47.1 0.0 331 [43.0, 48.0] [0.0] 38430
21 38.3 0.0 45.3 52.1 32.0 191 [40.0, 52.0] [0.0] 38730
24 41.6 0.0 46.6 51.5 17.9 20 [49.0] [0.0] 25942
25 34.0 0.0 45.0 49.7 33.1 0 [51.0] [0.0] 17381
26 33.0 0.0 45.7 51.5 34.1 239 [46.0, 51.0] [0.0] 41407
27 35.6 0.0 45.8 53.3 32.0 239 [46.0, 51.0] [0.0] 34329
30 27.5 0.0 45.0 49.7 33.8 29 [51.0, 47.0] [0.0] 25286
31 45.6 0.0 46.7 52.5 32.0 0 [42.0] [0.0] 31107
33 34.3 0.0 44.2 49.7 28.2 122 [48.0, 50.0] [0.0] 41012
34 39.0 0.0 46.6 51.9 36.9 0 [48.0] [0.0] 14967
36 21.4 0.0 43.2 48.7 32.5 207 [39.0, 40.0] [0.0] 13189
DIFF Galileo L1(MBOC-PD)

SV AvgEl AvgCNoDiff MaxCNoDiff MinCNoDiff SVChan N_Samples
2 17.7 0.2 7.2 -9.7 [39.0, 44.0, 52.0, 48.0] 21183
3 40.0 0.1 3.9 -5.5 [41.0, 43.0] 23060
4 31.2 0.7 6.4 -4.9 [51.0, 53.0, 38.0, 46.0] 29229
5 24.6 0.5 6.0 -3.7 [43.0, 45.0, 46.0] 18321
7 45.5 -0.0 4.4 -7.2 [50.0] 32675
8 45.4 0.1 6.7 -19.8 [45.0, 41.0] 29600
9 18.9 1.0 8.5 -5.5 [45.0, 49.0, 41.0, 40.0, 46.0, 52.0] 22844
10 51.7 0.5 5.4 -8.7 [51.0, 53.0] 23157
11 47.1 0.3 3.5 -6.1 [43.0] 18666
12 41.2 0.7 14.2 -8.2 [41.0, 44.0, 40.0] 34359
13 35.5 0.2 5.6 -7.0 [40.0, 38.0, 43.0, 44.0] 40683
15 45.8 -0.2 4.0 -6.6 [48.0, 47.0, 50.0] 27240
19 36.5 0.5 27.8 -17.5 [40.0, 43.0, 41.0, 48.0] 38341
21 38.3 0.7 7.2 -5.7 [50.0, 40.0, 45.0, 52.0] 38702
24 41.6 0.4 16.2 -9.8 [53.0, 49.0] 25934
25 34.0 1.2 7.0 -3.7 [52.0, 51.0] 17373
26 33.0 0.1 5.0 -8.1 [49.0, 46.0, 52.0, 51.0] 41373
27 35.7 0.3 5.5 -5.5 [46.0, 52.0, 51.0] 34324
30 27.5 -0.2 4.0 -7.3 [49.0, 51.0, 48.0, 47.0] 25286
31 45.7 1.0 7.8 -5.0 [42.0] 31088
33 34.4 0.7 13.4 -3.8 [43.0, 48.0, 50.0] 40983
34 39.0 0.3 4.5 -5.1 [47.0, 48.0] 14967
36 21.4 0.9 9.3 -3.4 [38.0, 39.0, 40.0] 13165
REF Galileo L5/E5A(BPSK(10)-PD)

SV AvgEl AvgOffset AvgCNo MaxCNo MinCNo Slip_Count SVChan Ant N_Samples
2 17.7 0.0 43.3 47.6 31.4 291 [39.0, 44.0, 48.0] [0.0] 21265
3 40.0 0.0 45.9 49.5 39.1 0 [41.0] [0.0] 23064
4 31.2 0.0 45.7 50.7 35.7 64 [51.0, 38.0] [0.0] 29250
5 24.6 0.0 43.9 47.3 33.3 29 [43.0, 46.0] [0.0] 18325
7 45.5 0.0 46.3 50.2 37.8 0 [50.0] [0.0] 32675
8 45.4 0.0 45.6 50.1 33.7 0 [45.0] [0.0] 29602
9 18.9 0.0 44.1 47.6 35.7 120 [45.0, 41.0, 46.0] [0.0] 22875
10 51.7 0.0 47.2 50.5 38.1 0 [51.0] [0.0] 23160
11 47.1 0.0 43.3 46.2 34.8 0 [43.0] [0.0] 18666
12 41.2 0.0 43.5 48.5 34.7 187 [41.0, 40.0] [0.0] 34387
13 35.5 0.0 45.3 49.9 33.6 124 [40.0, 43.0] [0.0] 40683
15 45.7 0.0 46.6 50.5 38.9 75 [48.0, 50.0] [0.0] 27290
19 36.5 0.0 41.9 47.4 31.1 75 [40.0, 41.0] [0.0] 38348
21 38.3 0.0 45.2 50.6 35.1 84 [50.0, 45.0] [0.0] 38715
24 41.6 0.0 46.1 50.0 36.1 0 [53.0] [0.0] 25945
25 34.0 0.0 46.0 50.6 36.9 0 [52.0] [0.0] 17403
26 33.0 0.0 45.3 50.2 35.9 66 [49.0, 52.0] [0.0] 41425
27 35.6 0.0 45.9 50.4 39.0 203 [46.0, 52.0] [0.0] 34339
30 27.5 0.0 44.6 48.7 36.7 114 [49.0, 48.0] [0.0] 25308
31 45.7 0.0 46.3 50.4 37.6 0 [42.0] [0.0] 31088
33 34.4 0.0 45.6 49.9 36.8 92 [43.0, 50.0] [0.0] 41004
34 39.0 0.0 45.6 49.6 38.6 0 [47.0] [0.0] 14983
36 21.4 0.0 43.4 49.6 34.8 94 [38.0, 39.0] [0.0] 13169
DUT Galileo L5/E5A(BPSK(10)-PD)
DIFF Galileo L5/E5A(BPSK(10)-PD)
REF Galileo E5B/B2(BPSK(10)-PD)

SV AvgEl AvgOffset AvgCNo MaxCNo MinCNo Slip_Count SVChan Ant N_Samples
2 17.7 0.0 43.4 47.0 32.1 89 [39.0, 44.0, 48.0] [0.0] 21265
3 40.0 0.0 46.8 51.0 40.7 0 [41.0] [0.0] 23064
4 31.2 0.0 46.0 50.9 35.3 229 [51.0, 38.0] [0.0] 29250
5 24.6 0.0 43.9 47.6 31.6 105 [43.0, 46.0] [0.0] 18325
7 45.5 0.0 46.9 51.2 37.0 0 [50.0] [0.0] 32675
8 45.4 0.0 46.4 50.4 33.3 0 [45.0] [0.0] 29602
9 18.9 0.0 44.7 48.4 37.9 155 [45.0, 41.0, 46.0] [0.0] 22875
10 51.7 0.0 47.8 50.9 36.5 0 [51.0] [0.0] 23160
11 47.1 0.0 43.6 46.7 35.2 0 [43.0] [0.0] 18666
12 41.2 0.0 44.1 48.8 33.9 100 [41.0, 40.0] [0.0] 34387
13 35.5 0.0 45.9 50.8 36.8 164 [40.0, 43.0] [0.0] 40683
15 45.7 0.0 47.1 50.6 40.0 110 [48.0, 50.0] [0.0] 27290
19 36.5 0.0 42.4 47.7 31.7 163 [40.0, 41.0] [0.0] 38348
21 38.3 0.0 45.9 51.0 36.0 7 [50.0, 45.0] [0.0] 38715
24 41.6 0.0 46.9 50.8 37.3 0 [53.0] [0.0] 25945
25 34.0 0.0 46.2 49.9 33.6 0 [52.0] [0.0] 17403
26 33.0 0.0 45.9 50.6 35.7 138 [49.0, 52.0] [0.0] 41425
27 35.6 0.0 46.4 51.1 39.0 77 [46.0, 52.0] [0.0] 34339
30 27.5 0.0 45.0 49.3 36.7 65 [49.0, 48.0] [0.0] 25308
31 45.7 0.0 47.1 51.1 38.4 0 [42.0] [0.0] 31088
33 34.4 0.0 46.0 50.6 36.9 210 [43.0, 50.0] [0.0] 41004
34 39.0 0.0 46.2 50.7 38.6 0 [47.0] [0.0] 14983
36 21.4 0.0 43.8 49.4 35.0 164 [38.0, 39.0] [0.0] 13169
DUT Galileo E5B/B2(BPSK(10)-PD)
DIFF Galileo E5B/B2(BPSK(10)-PD)
REF Galileo E5A+B(AltBOC-Comp-PD)

SV AvgEl AvgOffset AvgCNo MaxCNo MinCNo Slip_Count SVChan Ant N_Samples
2 17.7 0.0 46.1 49.8 35.9 354 [39.0, 44.0, 48.0] [0.0] 21265
3 40.0 0.0 48.7 52.5 43.4 0 [41.0] [0.0] 23064
4 31.2 0.0 48.2 52.6 39.4 181 [51.0, 38.0] [0.0] 29250
5 24.6 0.0 46.6 49.8 38.7 208 [43.0, 46.0] [0.0] 18325
7 45.5 0.0 49.1 52.7 41.3 0 [50.0] [0.0] 32675
8 45.4 0.0 48.5 52.3 38.2 0 [45.0] [0.0] 29602
9 18.9 0.0 47.0 49.9 40.7 206 [45.0, 41.0, 46.0] [0.0] 22875
10 51.7 0.0 49.9 52.6 41.0 0 [51.0] [0.0] 23160
11 47.1 0.0 45.8 48.3 39.4 0 [43.0] [0.0] 18666
12 41.2 0.0 46.4 50.8 38.3 40 [41.0, 40.0] [0.0] 34387
13 35.5 0.0 48.1 52.7 38.9 138 [40.0, 43.0] [0.0] 40683
15 45.7 0.0 49.3 52.6 42.7 43 [48.0, 50.0] [0.0] 27290
19 36.5 0.0 45.1 50.1 32.8 226 [40.0, 41.0] [0.0] 38348
21 38.3 0.0 48.1 52.9 39.2 201 [50.0, 45.0] [0.0] 38715
24 41.6 0.0 48.9 52.3 40.6 0 [53.0] [0.0] 25945
25 34.0 0.0 48.4 52.1 39.1 0 [52.0] [0.0] 17403
26 33.0 0.0 48.1 52.2 40.9 193 [49.0, 52.0] [0.0] 41425
27 35.6 0.0 48.5 52.8 42.7 134 [46.0, 52.0] [0.0] 34339
30 27.5 0.0 47.3 51.2 40.5 134 [49.0, 48.0] [0.0] 25308
31 45.7 0.0 49.0 52.7 42.5 0 [42.0] [0.0] 31088
33 34.4 0.0 48.2 52.4 40.8 66 [43.0, 50.0] [0.0] 41004
34 39.0 0.0 48.4 52.2 42.6 0 [47.0] [0.0] 14983
36 21.4 0.0 46.3 51.3 38.5 134 [38.0, 39.0] [0.0] 13169
DUT Galileo E5A+B(AltBOC-Comp-PD)

SV AvgEl AvgOffset AvgCNo MaxCNo MinCNo Slip_Count SVChan Ant N_Samples
2 17.7 0.0 46.0 48.9 32.1 359 [44.0, 52.0, 39.0] [0.0] 21193
3 39.9 0.0 48.4 51.8 43.4 0 [43.0] [0.0] 23082
4 31.2 0.0 47.8 51.7 39.8 62 [53.0, 46.0] [0.0] 29255
5 24.6 0.0 46.3 50.3 39.7 23 [45.0, 43.0] [0.0] 18341
7 45.4 0.0 48.8 52.2 36.0 3 [50.0] [0.0] 32686
8 45.4 0.0 48.3 51.9 36.7 3 [41.0] [0.0] 29613
9 18.9 0.0 46.6 50.2 36.0 167 [49.0, 40.0, 52.0] [0.0] 22860
10 51.7 0.0 49.6 52.2 35.8 26 [53.0] [0.0] 23165
11 47.1 0.0 45.5 48.1 38.2 0 [43.0] [0.0] 18709
12 41.2 0.0 46.2 50.5 37.8 67 [44.0, 41.0] [0.0] 34385
13 35.5 0.0 47.8 51.9 36.7 197 [38.0, 44.0] [0.0] 40718
15 45.8 0.0 48.7 52.0 43.1 192 [47.0, 50.0] [0.0] 27240
19 36.4 0.0 44.7 49.5 32.1 42 [43.0, 48.0] [0.0] 38437
21 38.3 0.0 47.9 52.3 39.3 162 [40.0, 52.0] [0.0] 38730
24 41.6 0.0 48.6 52.0 41.2 0 [49.0] [0.0] 25942
25 34.0 0.0 48.1 51.3 40.9 0 [51.0] [0.0] 17381
26 33.0 0.0 47.8 51.8 38.9 49 [46.0, 51.0] [0.0] 41407
27 35.6 0.0 48.1 52.1 41.6 49 [46.0, 51.0] [0.0] 34329
30 27.5 0.0 47.1 51.3 36.9 258 [51.0, 47.0] [0.0] 25286
31 45.6 0.0 48.6 52.3 41.0 0 [42.0] [0.0] 31107
33 34.3 0.0 47.9 52.3 41.1 144 [48.0, 50.0] [0.0] 41012
34 39.0 0.0 48.2 52.0 41.2 0 [48.0] [0.0] 14967
36 21.4 0.0 45.8 50.0 38.7 149 [39.0, 40.0] [0.0] 13189
DIFF Galileo E5A+B(AltBOC-Comp-PD)

SV AvgEl AvgCNoDiff MaxCNoDiff MinCNoDiff SVChan N_Samples
2 17.7 0.1 5.5 -2.9 [39.0, 44.0, 52.0, 48.0] 21183
3 40.0 0.3 3.2 -2.4 [41.0, 43.0] 23060
4 31.2 0.4 3.3 -3.8 [51.0, 53.0, 38.0, 46.0] 29229
5 24.6 0.3 5.9 -5.0 [43.0, 45.0, 46.0] 18321
7 45.5 0.3 6.1 -2.4 [50.0] 32675
8 45.4 0.1 3.1 -3.9 [45.0, 41.0] 29600
9 18.9 0.4 5.4 -2.8 [45.0, 49.0, 41.0, 40.0, 46.0, 52.0] 22844
10 51.7 0.3 8.4 -2.3 [51.0, 53.0] 23157
11 47.1 0.3 2.6 -2.0 [43.0] 18666
12 41.2 0.2 5.0 -3.5 [41.0, 44.0, 40.0] 34359
13 35.5 0.3 3.6 -3.5 [40.0, 38.0, 43.0, 44.0] 40683
15 45.8 0.6 3.0 -1.9 [48.0, 47.0, 50.0] 27240
19 36.5 0.3 5.1 -3.3 [40.0, 43.0, 41.0, 48.0] 38348
21 38.3 0.2 3.4 -2.8 [50.0, 40.0, 45.0, 52.0] 38702
24 41.6 0.3 4.1 -4.7 [53.0, 49.0] 25934
25 34.0 0.4 4.0 -6.0 [52.0, 51.0] 17373
26 33.0 0.2 5.7 -3.0 [49.0, 46.0, 52.0, 51.0] 41373
27 35.7 0.4 3.1 -2.9 [46.0, 52.0, 51.0] 34324
30 27.5 0.2 7.8 -2.0 [49.0, 51.0, 48.0, 47.0] 25286
31 45.7 0.4 3.1 -2.1 [42.0] 31088
33 34.4 0.3 3.6 -3.0 [43.0, 48.0, 50.0] 40983
34 39.0 0.2 2.4 -1.6 [47.0, 48.0] 14967
36 21.4 0.4 2.8 -2.3 [38.0, 39.0, 40.0] 13165
REF Galileo E6(BPSK(5)-PD)

SV AvgEl AvgOffset AvgCNo MaxCNo MinCNo Slip_Count SVChan Ant N_Samples
2 17.7 0.0 43.8 48.0 34.7 165 [39.0, 44.0, 48.0] [0.0] 21265
3 40.0 0.0 47.8 51.8 39.4 0 [41.0] [0.0] 23064
4 31.2 0.0 47.1 52.3 36.4 158 [51.0, 38.0] [0.0] 29250
5 24.6 0.0 45.4 49.8 35.7 58 [43.0, 46.0] [0.0] 18325
7 45.5 0.0 48.9 53.8 36.5 0 [50.0] [0.0] 32675
8 45.4 0.0 48.3 53.0 29.3 5 [45.0] [0.0] 29587
9 18.9 0.0 45.3 49.4 36.6 316 [45.0, 41.0, 46.0] [0.0] 22875
10 51.7 0.0 50.1 53.5 27.3 0 [51.0] [0.0] 23160
11 47.2 0.0 45.7 49.7 29.4 0 [43.0] [0.0] 18665
12 41.2 0.0 45.2 50.5 29.0 131 [41.0, 40.0] [0.0] 34384
13 35.5 0.0 47.2 52.7 34.6 227 [40.0, 43.0] [0.0] 40680
15 45.7 0.0 49.0 53.1 39.5 169 [48.0, 50.0] [0.0] 27290
19 36.5 0.0 42.6 49.1 28.1 182 [40.0, 41.0] [0.0] 38293
21 38.3 0.0 47.3 52.8 29.4 188 [50.0, 45.0] [0.0] 38715
24 41.6 0.0 49.0 53.8 38.7 1 [53.0] [0.0] 25945
25 34.0 0.0 48.1 52.0 27.1 0 [52.0] [0.0] 17403
26 33.0 0.0 47.2 51.8 33.5 250 [49.0, 52.0] [0.0] 41425
27 35.6 0.0 47.9 52.3 38.2 168 [46.0, 52.0] [0.0] 34339
30 27.5 0.0 46.7 51.5 34.7 199 [49.0, 48.0] [0.0] 25308
31 45.7 0.0 48.8 53.0 34.8 0 [42.0] [0.0] 31088
33 34.4 0.0 47.5 52.4 34.9 81 [43.0, 50.0] [0.0] 41004
34 39.0 0.0 47.5 52.3 37.6 0 [47.0] [0.0] 14983
36 21.4 0.0 45.0 51.5 33.2 87 [38.0, 39.0] [0.0] 13169
DUT Galileo E6(BPSK(5)-PD)
DIFF Galileo E6(BPSK(5)-PD)
REF BeiDou L1(BOC-PD)

SV AvgEl AvgOffset AvgCNo MaxCNo MinCNo Slip_Count SVChan Ant N_Samples
19 30.8 0.0 45.2 51.2 34.5 345 [21.0, 48.0, 31.0] [0.0] 30025
20 29.6 0.0 45.5 51.8 34.2 240 [49.0, 21.0] [0.0] 34693
21 44.3 0.0 46.5 52.1 35.0 196 [44.0, 42.0] [0.0] 21144
22 29.5 0.0 44.6 51.9 20.5 454 [32.0, 20.0, 44.0] [0.0] 25824
23 45.8 0.0 46.5 52.5 29.9 0 [46.0] [0.0] 26134
24 24.2 0.0 44.1 49.8 36.0 173 [22.0, 26.0] [0.0] 27809
25 38.6 0.0 45.3 51.6 32.7 202 [50.0, 51.0] [0.0] 23908
26 22.2 0.0 43.1 50.2 32.1 6 [46.0] [0.0] 28750
27 30.9 0.0 44.5 51.6 34.4 2 [26.0, 15.0] [0.0] 33851
28 28.8 0.0 44.4 49.5 27.6 65 [52.0, 28.0] [0.0] 34950
29 44.8 0.0 46.6 51.4 33.1 0 [49.0] [0.0] 28378
30 41.5 0.0 45.4 52.3 27.4 209 [21.0, 47.0] [0.0] 28077
32 34.3 0.0 45.1 52.5 23.3 55 [33.0, 44.0] [0.0] 32434
33 44.1 0.0 47.2 53.0 29.3 1 [42.0] [0.0] 28700
34 50.3 0.0 46.8 52.5 35.7 238 [26.0, 35.0] [0.0] 19638
35 45.4 0.0 47.1 51.7 35.7 58 [42.0, 45.0] [0.0] 23755
36 44.6 0.0 46.7 52.1 33.3 0 [17.0] [0.0] 24725
37 44.9 0.0 47.4 53.0 33.5 0 [53.0] [0.0] 28570
38 7.0 0.0 39.7 42.6 36.3 0 [17.0] [0.0] 2454
41 45.3 0.0 47.0 52.5 34.6 0 [18.0] [0.0] 27105
42 45.2 0.0 46.7 52.7 29.5 0 [30.0] [0.0] 27228
43 32.1 0.0 44.5 51.5 29.0 211 [13.0, 47.0] [0.0] 33171
44 38.1 0.0 46.1 51.9 34.5 110 [52.0, 34.0] [0.0] 22296
45 35.2 0.0 45.6 51.9 33.3 192 [22.0, 48.0] [0.0] 22312
DUT BeiDou L1(BOC-PD)
DIFF BeiDou L1(BOC-PD)
REF BeiDou L5/E5A(I+Q)

SV AvgEl AvgOffset AvgCNo MaxCNo MinCNo Slip_Count SVChan Ant N_Samples
19 30.8 0.0 46.1 49.8 38.6 238 [21.0, 48.0, 31.0] [0.0] 30025
20 29.6 0.0 45.7 51.4 36.9 52 [49.0, 21.0] [0.0] 34693
21 44.3 0.0 46.6 50.8 34.0 232 [44.0, 42.0] [0.0] 21144
22 29.5 0.0 45.7 50.5 38.7 339 [32.0, 20.0, 44.0] [0.0] 25824
23 45.8 0.0 47.4 52.1 35.4 0 [46.0] [0.0] 26134
24 24.2 0.0 45.2 49.2 38.9 17 [22.0, 26.0] [0.0] 27809
25 38.6 0.0 45.9 49.9 39.4 2 [50.0, 51.0] [0.0] 23908
26 22.2 0.0 43.5 47.6 34.6 6 [46.0] [0.0] 28750
27 30.9 0.0 45.0 49.7 38.3 50 [26.0, 15.0] [0.0] 33851
28 28.8 0.0 44.3 48.6 31.4 128 [52.0, 28.0] [0.0] 34950
29 44.8 0.0 46.0 49.9 36.4 0 [49.0] [0.0] 28378
30 41.5 0.0 45.7 50.4 36.8 117 [21.0, 47.0] [0.0] 28077
32 34.3 0.0 46.3 51.2 38.1 71 [33.0, 44.0] [0.0] 32435
33 44.1 0.0 47.4 50.9 38.7 0 [42.0] [0.0] 28700
34 50.3 0.0 46.8 50.2 39.1 78 [26.0, 35.0] [0.0] 19638
35 45.4 0.0 45.7 50.0 34.0 16 [42.0, 45.0] [0.0] 23755
36 44.6 0.0 48.3 51.9 40.8 0 [17.0] [0.0] 24725
37 44.9 0.0 47.7 51.9 37.9 0 [53.0] [0.0] 28570
38 7.0 0.0 39.4 41.4 37.3 0 [17.0] [0.0] 2454
41 45.3 0.0 47.8 51.6 39.5 0 [18.0] [0.0] 27105
42 45.2 0.0 47.0 51.1 36.1 0 [30.0] [0.0] 27228
43 32.1 0.0 44.7 49.6 33.0 217 [13.0, 47.0] [0.0] 33171
44 38.1 0.0 45.9 50.1 37.9 84 [52.0, 34.0] [0.0] 22296
45 35.2 0.0 47.2 51.9 37.5 222 [22.0, 48.0] [0.0] 22312
DUT BeiDou L5/E5A(I+Q)

SV AvgEl AvgOffset AvgCNo MaxCNo MinCNo Slip_Count SVChan Ant N_Samples
19 30.8 0.0 45.9 49.8 37.4 422 [23.0, 47.0, 26.0] [0.0] 30026
20 29.5 0.0 45.8 50.3 35.7 244 [46.0, 21.0] [0.0] 34714
21 44.3 0.0 46.8 50.5 37.6 99 [53.0, 38.0] [0.0] 21144
22 29.6 0.0 45.3 50.6 38.6 234 [32.0, 41.0, 45.0] [0.0] 25809
23 45.8 0.0 47.7 52.1 34.9 0 [34.0] [0.0] 26166
24 24.2 0.0 45.2 49.9 38.8 100 [22.0, 23.0] [0.0] 27804
25 38.6 0.0 45.9 49.5 38.2 117 [33.0, 53.0] [0.0] 23913
26 22.2 0.0 43.6 47.4 35.4 247 [25.0, 52.0] [0.0] 28760
27 30.9 0.0 45.0 49.4 36.3 27 [17.0, 15.0] [0.0] 33857
28 28.8 0.0 44.3 48.0 37.3 37 [51.0, 33.0] [0.0] 34903
29 44.8 0.0 46.2 49.9 33.7 0 [47.0] [0.0] 28376
30 41.6 0.0 45.6 49.8 21.8 128 [44.0, 48.0] [0.0] 28069
32 34.3 0.0 46.4 52.0 38.3 189 [25.0, 45.0] [0.0] 32467
33 44.0 0.0 47.4 51.3 39.2 0 [27.0] [0.0] 28725
34 50.2 0.0 46.2 49.9 35.9 140 [15.0, 35.0] [0.0] 19682
35 45.4 0.0 45.4 49.2 36.6 203 [41.0, 44.0] [0.0] 23762
36 44.5 0.0 47.7 51.4 38.8 0 [17.0] [0.0] 24743
37 44.9 0.0 47.8 51.6 36.7 0 [49.0] [0.0] 28617
38 7.0 0.0 41.9 44.1 40.3 0 [18.0] [0.0] 2449
41 45.3 0.0 47.4 51.4 38.6 0 [18.0] [0.0] 27089
42 45.1 0.0 47.2 51.2 36.2 0 [42.0] [0.0] 27267
43 32.1 0.0 44.6 49.6 29.5 119 [44.0, 48.0] [0.0] 33180
44 38.0 0.0 45.6 50.0 36.4 16 [50.0, 30.0] [0.0] 22320
45 35.2 0.0 46.9 51.6 38.3 235 [22.0, 46.0] [0.0] 22273
DIFF BeiDou L5/E5A(I+Q)

SV AvgEl AvgCNoDiff MaxCNoDiff MinCNoDiff SVChan N_Samples
19 30.9 0.2 3.8 -2.6 [21.0, 23.0, 48.0, 47.0, 31.0, 26.0] 29981
20 29.6 -0.0 5.6 -4.6 [49.0, 46.0, 21.0] 34682
21 44.3 -0.2 3.7 -11.1 [44.0, 53.0, 42.0, 38.0] 21136
22 29.5 0.4 3.9 -3.3 [32.0, 20.0, 41.0, 44.0, 45.0] 25801
23 45.8 -0.3 3.5 -7.8 [46.0, 34.0] 26134
24 24.2 0.0 3.5 -3.1 [22.0, 26.0, 23.0] 27794
25 38.6 -0.0 3.5 -5.3 [50.0, 33.0, 51.0, 53.0] 23883
26 22.2 -0.1 4.0 -3.9 [46.0, 25.0, 52.0] 28749
27 30.9 0.0 4.9 -3.5 [26.0, 17.0, 15.0] 33824
28 28.8 -0.1 3.3 -9.2 [52.0, 51.0, 28.0, 33.0] 34903
29 44.8 -0.1 5.5 -4.3 [49.0, 47.0] 28376
30 41.6 0.1 19.9 -3.7 [21.0, 44.0, 47.0, 48.0] 28069
32 34.3 -0.0 4.2 -4.5 [33.0, 25.0, 44.0, 45.0] 32428
33 44.1 -0.0 3.6 -4.3 [42.0, 27.0] 28696
34 50.3 0.6 6.0 -2.5 [26.0, 15.0, 35.0] 19634
35 45.4 0.2 3.5 -4.2 [42.0, 41.0, 45.0, 44.0] 23751
36 44.6 0.5 4.5 -3.3 [17.0] 24725
37 45.0 -0.1 3.4 -3.1 [53.0, 49.0] 28558
38 7.0 -2.5 0.1 -5.0 [17.0, 18.0] 2449
41 45.3 0.3 4.9 -3.0 [18.0] 27076
42 45.2 -0.2 2.8 -7.5 [30.0, 42.0] 27228
43 32.1 0.1 5.3 -5.9 [13.0, 44.0, 47.0, 48.0] 33170
44 38.1 0.3 4.9 -2.6 [52.0, 50.0, 34.0, 30.0] 22292
45 35.2 0.4 4.6 -5.7 [22.0, 48.0, 46.0] 22273
REF BeiDou E5B/B2(BPSK(2)-B2)

SV AvgEl AvgOffset AvgCNo MaxCNo MinCNo Slip_Count SVChan Ant N_Samples
11 39.5 0.0 45.7 49.7 38.9 241 [51.0, 21.0] [0.0] 27845
12 41.7 0.0 45.9 49.8 38.9 17 [22.0, 50.0] [0.0] 21282
14 44.4 0.0 46.0 49.9 36.2 0 [53.0] [0.0] 28340
DUT BeiDou E5B/B2(BPSK(2)-B2)

SV AvgEl AvgOffset AvgCNo MaxCNo MinCNo Slip_Count SVChan Ant N_Samples
11 39.5 0.0 45.2 49.1 37.9 124 [52.0, 44.0] [0.0] 27846
12 41.7 0.0 45.2 49.5 30.4 160 [25.0, 42.0] [0.0] 21269
14 44.3 0.0 45.7 49.4 36.1 0 [49.0] [0.0] 28391
DIFF BeiDou E5B/B2(BPSK(2)-B2)

SV AvgEl AvgCNoDiff MaxCNoDiff MinCNoDiff SVChan N_Samples
11 39.6 0.4 4.2 -3.6 [51.0, 52.0, 21.0, 44.0] 27827
12 41.7 0.8 10.6 -3.0 [22.0, 25.0, 50.0, 42.0] 21261
14 44.4 0.3 6.7 -5.0 [53.0, 49.0] 28331
REF BeiDou B1(BPSK(2)-B1)

SV AvgEl AvgOffset AvgCNo MaxCNo MinCNo Slip_Count SVChan Ant N_Samples
11 39.5 0.0 43.3 51.0 21.7 207 [51.0, 21.0] [0.0] 27864
12 41.7 0.0 43.0 50.1 31.0 145 [22.0, 50.0] [0.0] 21282
14 44.4 0.0 44.9 51.1 28.7 0 [53.0] [0.0] 28340
19 30.8 0.0 44.9 51.4 33.4 111 [21.0, 48.0, 31.0] [0.0] 30025
20 29.6 0.0 45.8 52.7 31.5 176 [49.0, 21.0] [0.0] 34693
21 44.3 0.0 46.3 52.4 34.0 11 [44.0, 42.0] [0.0] 21144
22 29.5 0.0 44.7 52.0 30.8 62 [32.0, 20.0, 44.0] [0.0] 25824
23 45.8 0.0 46.6 53.2 30.4 0 [46.0] [0.0] 26134
24 24.2 0.0 43.8 49.8 35.6 14 [22.0, 26.0] [0.0] 27809
25 38.6 0.0 45.8 52.8 32.1 192 [50.0, 51.0] [0.0] 23908
26 22.2 0.0 43.2 50.3 32.6 6 [46.0] [0.0] 28750
27 30.9 0.0 45.4 53.0 35.6 211 [26.0, 15.0] [0.0] 33851
28 28.8 0.0 45.0 50.0 30.4 191 [52.0, 28.0] [0.0] 34950
29 44.8 0.0 47.3 53.2 31.3 0 [49.0] [0.0] 28378
30 41.5 0.0 46.1 52.9 30.4 36 [21.0, 47.0] [0.0] 28077
32 34.3 0.0 44.9 52.8 31.1 160 [33.0, 44.0] [0.0] 32435
33 44.1 0.0 47.1 52.9 31.6 0 [42.0] [0.0] 28700
34 50.3 0.0 46.4 52.5 34.6 99 [26.0, 35.0] [0.0] 19638
35 45.4 0.0 47.4 52.9 32.0 167 [42.0, 45.0] [0.0] 23755
36 44.6 0.0 47.0 52.6 33.4 0 [17.0] [0.0] 24725
37 44.9 0.0 47.2 52.5 32.5 0 [53.0] [0.0] 28570
38 7.0 0.0 40.2 43.1 35.9 0 [17.0] [0.0] 2454
41 45.3 0.0 46.9 52.7 36.5 0 [18.0] [0.0] 27105
42 45.2 0.0 45.9 52.1 31.9 0 [30.0] [0.0] 27228
43 32.1 0.0 44.5 51.9 31.2 176 [13.0, 47.0] [0.0] 33171
44 38.1 0.0 45.8 51.8 34.6 94 [52.0, 34.0] [0.0] 22296
45 35.2 0.0 45.4 52.0 32.6 37 [22.0, 48.0] [0.0] 22312
DUT BeiDou B1(BPSK(2)-B1)

SV AvgEl AvgOffset AvgCNo MaxCNo MinCNo Slip_Count SVChan Ant N_Samples
11 39.5 0.0 43.6 50.5 27.7 70 [52.0, 44.0] [0.0] 27846
12 41.7 0.0 42.7 49.1 30.9 84 [25.0, 42.0] [0.0] 21269
14 44.3 0.0 44.9 50.5 32.7 0 [49.0] [0.0] 28391
19 30.8 0.0 44.5 51.0 29.5 385 [23.0, 47.0, 26.0] [0.0] 30030
20 29.5 0.0 45.4 51.8 34.7 189 [46.0, 21.0] [0.0] 34714
21 44.3 0.0 46.5 52.9 35.7 6 [53.0, 38.0] [0.0] 21144
22 29.6 0.0 44.8 51.9 28.9 386 [32.0, 41.0, 45.0] [0.0] 25809
23 45.8 0.0 46.0 52.1 29.4 0 [34.0] [0.0] 26166
24 24.2 0.0 43.4 49.9 30.5 94 [22.0, 23.0] [0.0] 27804
25 38.6 0.0 45.6 51.9 34.1 98 [33.0, 53.0] [0.0] 23913
26 22.2 0.0 42.8 49.1 34.4 110 [25.0, 52.0] [0.0] 28760
27 30.9 0.0 44.5 51.3 32.7 192 [17.0, 15.0] [0.0] 33857
28 28.8 0.0 44.9 50.3 34.5 172 [51.0, 33.0] [0.0] 34903
29 44.8 0.0 46.4 52.1 35.7 0 [47.0] [0.0] 28376
30 41.6 0.0 44.6 52.1 25.1 231 [44.0, 48.0] [0.0] 28069
32 34.3 0.0 44.3 52.2 20.9 110 [25.0, 45.0] [0.0] 32467
33 44.0 0.0 47.3 52.9 34.4 0 [27.0] [0.0] 28725
34 50.2 0.0 46.5 52.2 32.9 175 [15.0, 35.0] [0.0] 19682
35 45.4 0.0 46.4 52.3 32.2 68 [41.0, 44.0] [0.0] 23762
36 44.5 0.0 46.1 51.4 32.7 0 [17.0] [0.0] 24743
37 44.9 0.0 46.3 51.4 31.8 0 [49.0] [0.0] 28617
38 7.0 0.0 38.5 41.4 33.0 0 [18.0] [0.0] 2449
41 45.3 0.0 46.5 52.2 31.7 0 [18.0] [0.0] 27089
42 45.1 0.0 46.1 52.2 26.1 2 [42.0] [0.0] 27267
43 32.1 0.0 44.4 52.0 31.1 227 [44.0, 48.0] [0.0] 33180
44 38.0 0.0 45.0 51.6 30.5 209 [50.0, 30.0] [0.0] 22320
45 35.2 0.0 45.0 51.0 29.2 36 [22.0, 46.0] [0.0] 22273
DIFF BeiDou B1(BPSK(2)-B1)

SV AvgEl AvgCNoDiff MaxCNoDiff MinCNoDiff SVChan N_Samples
11 39.5 -0.3 5.2 -10.9 [51.0, 52.0, 21.0, 44.0] 27846
12 41.7 0.2 7.2 -4.8 [22.0, 25.0, 50.0, 42.0] 21261
14 44.4 -0.1 4.6 -8.9 [53.0, 49.0] 28331
19 30.9 0.5 8.9 -5.7 [21.0, 23.0, 48.0, 47.0, 31.0, 26.0] 29985
20 29.6 0.4 5.2 -7.8 [49.0, 46.0, 21.0] 34682
21 44.3 -0.2 4.9 -6.6 [44.0, 53.0, 42.0, 38.0] 21136
22 29.5 -0.1 5.9 -8.6 [32.0, 20.0, 41.0, 44.0, 45.0] 25801
23 45.8 0.6 6.1 -9.2 [46.0, 34.0] 26134
24 24.2 0.4 9.6 -4.5 [22.0, 26.0, 23.0] 27794
25 38.6 0.2 5.4 -5.5 [50.0, 33.0, 51.0, 53.0] 23883
26 22.2 0.4 6.2 -8.5 [46.0, 25.0, 52.0] 28749
27 30.9 0.9 10.7 -4.6 [26.0, 17.0, 15.0] 33824
28 28.8 0.2 5.8 -9.1 [52.0, 51.0, 28.0, 33.0] 34903
29 44.8 0.9 5.2 -7.3 [49.0, 47.0] 28376
30 41.6 1.5 7.8 -7.9 [21.0, 44.0, 47.0, 48.0] 28069
32 34.3 0.6 16.4 -6.8 [33.0, 25.0, 44.0, 45.0] 32428
33 44.1 -0.2 4.6 -8.8 [42.0, 27.0] 28696
34 50.3 -0.1 5.5 -5.4 [26.0, 15.0, 35.0] 19634
35 45.4 1.0 6.5 -5.9 [42.0, 41.0, 45.0, 44.0] 23751
36 44.6 0.9 7.6 -5.5 [17.0] 24725
37 45.0 0.9 6.9 -5.5 [53.0, 49.0] 28558
38 7.0 1.7 5.8 -2.2 [17.0, 18.0] 2449
41 45.3 0.4 8.2 -5.4 [18.0] 27076
42 45.2 -0.3 9.3 -8.8 [30.0, 42.0] 27228
43 32.1 0.1 6.5 -8.5 [13.0, 44.0, 47.0, 48.0] 33170
44 38.1 0.8 7.5 -5.7 [52.0, 50.0, 34.0, 30.0] 22292
45 35.2 0.4 7.3 -7.9 [22.0, 48.0, 46.0] 22273
REF BeiDou B3(BPSK(10)-B3)

SV AvgEl AvgOffset AvgCNo MaxCNo MinCNo Slip_Count SVChan Ant N_Samples
11 39.5 0.0 44.2 49.4 33.4 256 [51.0, 21.0] [0.0] 27845
12 41.7 0.0 45.0 49.6 33.7 242 [22.0, 50.0] [0.0] 21282
14 44.4 0.0 45.5 50.0 34.6 0 [53.0] [0.0] 28340
19 30.8 0.0 44.8 49.5 34.2 294 [21.0, 48.0, 31.0] [0.0] 30025
20 29.6 0.0 44.0 49.4 25.6 207 [49.0, 21.0] [0.0] 34693
21 44.3 0.0 45.2 50.0 34.2 233 [44.0, 42.0] [0.0] 21144
22 29.5 0.0 44.2 50.0 33.9 351 [32.0, 20.0, 44.0] [0.0] 25824
23 45.8 0.0 45.7 50.0 32.1 0 [46.0] [0.0] 26134
24 24.2 0.0 43.7 49.0 35.3 62 [22.0, 26.0] [0.0] 27809
25 38.6 0.0 45.1 50.0 28.8 189 [50.0, 51.0] [0.0] 23908
26 22.2 0.0 42.7 47.5 34.2 7 [46.0] [0.0] 28750
27 30.9 0.0 43.9 48.9 33.0 77 [26.0, 15.0] [0.0] 33851
28 28.8 0.0 43.4 48.5 32.7 95 [52.0, 28.0] [0.0] 34950
29 44.8 0.0 45.2 49.8 32.5 0 [49.0] [0.0] 28378
30 41.5 0.0 44.1 49.5 33.3 70 [21.0, 47.0] [0.0] 28077
32 34.3 0.0 44.6 50.8 32.4 6 [33.0, 44.0] [0.0] 32430
33 44.1 0.0 45.8 49.6 37.1 0 [42.0] [0.0] 28700
34 50.3 0.0 45.3 49.4 35.8 190 [26.0, 35.0] [0.0] 19638
35 45.4 0.0 45.5 49.6 32.9 175 [42.0, 45.0] [0.0] 23755
36 44.6 0.0 46.4 50.5 37.7 0 [17.0] [0.0] 24725
37 44.9 0.0 45.8 50.6 30.5 0 [53.0] [0.0] 28570
38 7.0 0.0 37.2 39.7 34.2 0 [17.0] [0.0] 2454
41 45.3 0.0 46.1 50.0 29.3 0 [18.0] [0.0] 27105
42 45.2 0.0 45.7 49.7 31.1 0 [30.0] [0.0] 27228
43 32.1 0.0 43.5 49.5 31.6 124 [13.0, 47.0] [0.0] 33171
44 38.1 0.0 44.5 49.8 35.5 230 [52.0, 34.0] [0.0] 22296
45 35.2 0.0 45.3 49.6 24.0 107 [22.0, 48.0] [0.0] 22312
DUT BeiDou B3(BPSK(10)-B3)

SV AvgEl AvgOffset AvgCNo MaxCNo MinCNo Slip_Count SVChan Ant N_Samples
11 39.5 0.0 44.2 48.8 36.8 174 [52.0, 44.0] [0.0] 27846
12 41.7 0.0 44.6 48.8 33.8 59 [25.0, 42.0] [0.0] 21269
14 44.3 0.0 45.4 49.3 32.1 0 [49.0] [0.0] 28391
19 30.8 0.0 44.4 49.4 35.8 250 [23.0, 47.0, 26.0] [0.0] 30022
20 29.5 0.0 44.0 48.7 25.3 189 [46.0, 21.0] [0.0] 34714
21 44.3 0.0 45.4 49.6 23.9 155 [53.0, 38.0] [0.0] 21144
22 29.6 0.0 44.0 50.0 34.8 181 [32.0, 41.0, 45.0] [0.0] 25809
23 45.8 0.0 45.9 49.9 30.2 0 [34.0] [0.0] 26166
24 24.2 0.0 43.2 49.1 33.8 209 [22.0, 23.0] [0.0] 27804
25 38.6 0.0 44.7 49.2 26.1 173 [33.0, 53.0] [0.0] 23913
26 22.2 0.0 42.3 46.4 35.3 191 [25.0, 52.0] [0.0] 28760
27 30.9 0.0 43.5 48.8 33.2 48 [17.0, 15.0] [0.0] 33857
28 28.8 0.0 43.4 47.8 34.8 117 [51.0, 33.0] [0.0] 34903
29 44.8 0.0 45.2 49.1 32.3 0 [47.0] [0.0] 28376
30 41.6 0.0 44.2 49.2 30.5 223 [44.0, 48.0] [0.0] 28063
32 34.3 0.0 44.5 49.7 30.4 167 [25.0, 45.0] [0.0] 32445
33 44.0 0.0 45.7 49.8 35.6 0 [27.0] [0.0] 28725
34 50.2 0.0 45.0 49.2 32.3 123 [15.0, 35.0] [0.0] 19682
35 45.4 0.0 45.0 48.9 34.8 77 [41.0, 44.0] [0.0] 23762
36 44.5 0.0 45.8 50.0 34.6 0 [17.0] [0.0] 24743
37 44.9 0.0 45.8 49.7 22.3 0 [49.0] [0.0] 28617
38 7.0 0.0 40.0 41.7 38.1 0 [18.0] [0.0] 2449
41 45.3 0.0 45.7 49.7 28.7 0 [18.0] [0.0] 27089
42 45.1 0.0 45.7 49.8 32.6 2 [42.0] [0.0] 27267
43 32.1 0.0 43.3 49.1 29.6 222 [44.0, 48.0] [0.0] 33180
44 38.0 0.0 43.8 49.3 34.1 79 [50.0, 30.0] [0.0] 22320
45 35.2 0.0 45.2 49.9 16.9 237 [22.0, 46.0] [0.0] 22259
DIFF BeiDou B3(BPSK(10)-B3)

SV AvgEl AvgCNoDiff MaxCNoDiff MinCNoDiff SVChan N_Samples
11 39.6 0.0 4.2 -6.0 [51.0, 52.0, 21.0, 44.0] 27827
12 41.7 0.4 6.0 -3.4 [22.0, 25.0, 50.0, 42.0] 21261
14 44.4 0.0 6.5 -4.5 [53.0, 49.0] 28331
19 30.9 0.4 6.4 -3.4 [21.0, 23.0, 48.0, 47.0, 31.0, 26.0] 29977
20 29.6 -0.1 3.7 -5.6 [49.0, 46.0, 21.0] 34682
21 44.3 -0.2 15.3 -5.3 [44.0, 53.0, 42.0, 38.0] 21136
22 29.5 0.2 6.0 -4.4 [32.0, 20.0, 41.0, 44.0, 45.0] 25801
23 45.8 -0.2 4.0 -3.8 [46.0, 34.0] 26134
24 24.2 0.5 7.5 -3.6 [22.0, 26.0, 23.0] 27794
25 38.6 0.4 5.6 -8.2 [50.0, 33.0, 51.0, 53.0] 23883
26 22.2 0.3 4.9 -4.1 [46.0, 25.0, 52.0] 28749
27 30.9 0.5 5.0 -3.2 [26.0, 17.0, 15.0] 33824
28 28.8 0.0 4.0 -5.4 [52.0, 51.0, 28.0, 33.0] 34903
29 44.8 -0.0 4.7 -7.1 [49.0, 47.0] 28376
30 41.6 -0.1 6.4 -5.2 [21.0, 44.0, 47.0, 48.0] 28063
32 34.3 0.2 4.8 -5.4 [33.0, 25.0, 44.0, 45.0] 32401
33 44.1 0.1 3.7 -4.0 [42.0, 27.0] 28696
34 50.3 0.3 4.4 -2.7 [26.0, 15.0, 35.0] 19634
35 45.4 0.6 5.5 -4.7 [42.0, 41.0, 45.0, 44.0] 23751
36 44.6 0.6 5.1 -4.1 [17.0] 24725
37 45.0 0.1 17.2 -9.1 [53.0, 49.0] 28558
38 7.0 -2.8 0.3 -6.1 [17.0, 18.0] 2449
41 45.3 0.5 4.7 -5.3 [18.0] 27076
42 45.2 -0.0 4.0 -4.6 [30.0, 42.0] 27228
43 32.1 0.2 8.2 -5.3 [13.0, 44.0, 47.0, 48.0] 33170
44 38.1 0.7 4.9 -2.6 [52.0, 50.0, 34.0, 30.0] 22292
45 35.2 0.1 22.3 -15.1 [22.0, 48.0, 46.0] 22259
