HUD: /home/russ/Documents/_GNSS_data/2024/CSNMR-2919-WCO_Roof_montera/231027 titan P4-03-all

Meta Data


Start : 2285 416975.0
Stop : 2285 511305.0
Number Samples : 94311
Input Source : HUD
Total Time: 94330.0 seconds = 26.203 hours

P4-03-all

Heading, Antenna distance

Weighted Mean heading_mean: 319.2220
Weighted Mean dist_mean: 0.0775
Weighted Mean ant_list: [0, 1]
Weighted Mean hprec: 0.0072
Weighted Mean vprec: 0.0109
Weighted Mean vdiff_mean: -0.0031
Weighted Mean heading_uptime: 0.0000

Stats


antenna w_mean_lat w_mean_lon w_mean_hgt std_err std_err_hprec std_err_vprec count datum datum_epoch
0 39.896468 -105.115028 1668.565919 0.022469 0.004626 0.010588 94311.0 NaN NaN
1 39.896467 -105.115027 1668.568973 0.007465 0.002170 0.002561 94311.0 NaN NaN
ref 39.897093 -105.115120 1672.416900 NaN NaN NaN NaN NaN NaN

Uptime


antenna limit h_uptime v_uptime hv_uptime
0 0.03 1.0 1.0 1.0
0 0.05 1.0 1.0 1.0
0 0.10 1.0 1.0 1.0
1 0.03 1.0 1.0 1.0
1 0.05 1.0 1.0 1.0
1 0.10 1.0 1.0 1.0

Fix Summary

VFixedFlag MGnssSolution MFixedFlag count Fix_Description Ant VGnssSolution
NaN 3.0 1.0 94311 RTK solution 0 NaN
1.0 NaN NaN 94311 RTK solution 1 3.0
Flags Bit Table
Bit Description
0 1 if this is the master position (i.e. record 29 position)
1 1 if the solution is a propagated solution (e.g. PM_FIX_20_HZ)
3 1 if reference station is sending moving base CMRs. Only b0 and b1 of "rtkMode" are defined in Record 29, in the rtk block "mode" field.
4 rtkMode bit 0: 0=synchronized rtk solution; 1=low-latency rtk solution;
5 rtkMode bit 1: 0=no canopy detected; 1= canopy detected;
6 1 if a baseline length constraint was used to form RTK vector.
7 1 if a clock constraint was used to form RTK vector.
8 1 if the RTK position is bridged
9 1 if the OmniSTAR position is authenticated

Individual Antennas
