T04: /home/russ/Documents/_GNSS_data/2024/CSNMR-2919-WCO_Roof_montera/231019 P4-05-all

Meta Data


Start : 2284 336926.0
Stop : 2284 431999.0
Number Samples : 95074
Input Source : T04
Total Time: 95073.0 seconds = 26.409 hours

pos_ant.csv

Heading, Antenna distance

Weighted Mean heading_mean: 319.1693
Weighted Mean dist_mean: 0.1552
Weighted Mean ant_list: [0, 1]
Weighted Mean hprec: 0.0200
Weighted Mean vprec: 0.0346
Weighted Mean vdiff_mean: -0.0065
Weighted Mean heading_uptime: 0.0000

Stats


antenna w_mean_lat w_mean_lon w_mean_hgt std_err std_err_hprec std_err_vprec count datum datum_epoch
0 39.896473 -105.115072 1667.597706 0.059266 0.014003 0.034484 95074 ITRF2020 202380
1 39.896472 -105.115071 1667.604157 0.006729 0.002056 0.002134 95074 ITRF2020 202380
ref 39.896473 -105.115072 1667.596966 3.243166 NaN NaN 95074 ITRF2020 202380

Uptime


antenna limit h_uptime v_uptime hv_uptime
0 0.03 0.997360 0.733292 0.733292
0 0.05 0.997602 0.995456 0.995456
0 0.10 0.998075 0.997118 0.997118
1 0.03 1.000000 1.000000 1.000000
1 0.05 1.000000 1.000000 1.000000
1 0.10 1.000000 1.000000 1.000000

Fix Summary

VSysFlgs MFixType MFixMode MFixInfo MSysFlgs count Fix_Description Ant VFixType VFixMode VFixInfo
NaN 15.0 5.0 1.0 0x17:02x 95074 RTx; 3D solution; AM 0 NaN NaN NaN
0x0:02x NaN NaN NaN NaN 95074 RTK fixed; 3D solution; Unknown fix_info RTK value 10. 1 4.0 5.0 10.0
Flags Bit Table
Bit Description
0 1 if this is the master position (i.e. record 29 position)
1 1 if the solution is a propagated solution (e.g. PM_FIX_20_HZ)
3 1 if reference station is sending moving base CMRs. Only b0 and b1 of "rtkMode" are defined in Record 29, in the rtk block "mode" field.
4 rtkMode bit 0: 0=synchronized rtk solution; 1=low-latency rtk solution;
5 rtkMode bit 1: 0=no canopy detected; 1= canopy detected;
6 1 if a baseline length constraint was used to form RTK vector.
7 1 if a clock constraint was used to form RTK vector.
8 1 if the RTK position is bridged
9 1 if the OmniSTAR position is authenticated

Individual Antennas
