HUD: /home/russ/Documents/_GNSS_data/2024/CSNMR-2877_VSBL_Urban_Canyon/240120 titan P4-03

Meta Data


Start Time : 498777.0
Stop Time : 588504.0
Input Source : HUD
Total Time: 89727.0 seconds = 24.924 hours

P4-03

Heading, Antenna distance

Weighted Mean heading_mean: 94.5980
Weighted Mean dist_mean: 0.1514
Weighted Mean ant_list: [0, 1]
Weighted Mean hprec: 0.0448
Weighted Mean vprec: 0.0748
Weighted Mean vdiff_mean: -0.0018
Weighted Mean heading_uptime: 0.0000

Stats


antenna w_mean_lat w_mean_lon w_mean_hgt std_err std_err_hprec std_err_vprec count
0 39.896908 -105.115072 1650.043009 0.075735 0.041727 0.098023 89728
1 39.896908 -105.115074 1650.044791 0.008269 0.003075 0.004601 89728

Uptime


antenna limit h_uptime v_uptime hv_uptime
0 0.03 0.061564 0.000000 0.000000
0 0.05 0.844697 0.000000 0.000000
0 0.10 0.991508 0.366329 0.366329
1 0.03 0.999922 0.999922 0.999922
1 0.05 0.999922 0.999922 0.999922
1 0.10 0.999922 0.999922 0.999922
center 0.03 0.048859 0.000000 0.000000
center 0.05 0.834188 0.035329 0.035329
center 0.10 0.991485 0.906205 0.906205

Fix Summary

VFixedFlag MGnssSolution MFixedFlag count Fix_Description Ant VGnssSolution
NaN 2.0 0.0 37 Autonomous solution 0 NaN
NaN 5.0 0.0 866 RTX Regional Augmentation Model solution 0 NaN
NaN 5.0 1.0 88825 RTX Regional Augmentation Model solution 0 NaN
0.0 NaN NaN 3 RTK solution 1 3.0
1.0 NaN NaN 89722 RTK solution 1 3.0
Flags Bit Table
Bit Description
0 1 if this is the master position (i.e. record 29 position)
1 1 if the solution is a propagated solution (e.g. PM_FIX_20_HZ)
3 1 if reference station is sending moving base CMRs. Only b0 and b1 of "rtkMode" are defined in Record 29, in the rtk block "mode" field.
4 rtkMode bit 0: 0=synchronized rtk solution; 1=low-latency rtk solution;
5 rtkMode bit 1: 0=no canopy detected; 1= canopy detected;
6 1 if a baseline length constraint was used to form RTK vector.
7 1 if a clock constraint was used to form RTK vector.
8 1 if the RTK position is bridged
9 1 if the OmniSTAR position is authenticated

Individual Antennas
