REF File: 1114_469.6mhz/BX_gt35.T04
DUT File: 1114_469.6mhz/P4-03_gt35.T04

Ref Statistics

DUT Statistics

Difference Statistics
SVType Freq Track N_Samples CNo_Mean CNo_Median CNo_Std CNo_Min CNo_Max CNo_Range El_Mean El_Max
GPS L1 CA 389441 47.5 47.5 2.3 37.6 56.1 18.5 55.5 89.0
GPS L2 CM+CL 309608 47.7 47.8 1.7 40.9 52.5 11.6 56.6 89.0
GPS L2 E 79833 36.6 36.5 3.3 28.3 45.3 17.0 51.2 78.0
GPS L5/E5A I+Q 216614 50.0 50.0 1.8 44.1 54.3 10.2 55.8 89.0
SBAS L1 CA 254250 42.8 42.9 0.8 39.7 45.6 5.9 39.9 42.0
GLONASS L1 CA 303906 46.8 48.3 4.5 30.9 54.8 23.9 53.6 88.0
GLONASS L2 CA 258757 46.7 47.4 2.6 1.0 51.4 50.4 53.2 88.0
Galileo L1 MBOC-PD 280858 48.4 48.3 2.3 39.4 54.8 15.4 54.7 87.0
Galileo E5A+B AltBOC-Comp-PD 280858 49.5 49.7 1.5 44.2 53.4 9.2 54.7 87.0
BeiDou L1 BOC-PD 301499 49.1 49.3 2.0 40.9 53.5 12.6 55.8 90.0
BeiDou L5/E5A I+Q 301499 48.3 48.5 1.5 42.6 52.1 9.5 55.8 90.0
BeiDou E5B/B2 BPSK(2)-B2 36680 47.5 47.5 0.7 44.3 50.0 5.7 53.4 83.0
BeiDou B1 BPSK(2)-B1 338179 48.7 48.9 2.3 39.4 54.1 14.7 55.5 90.0
BeiDou B3 BPSK(10)-B3 338179 47.5 47.6 1.1 41.8 50.2 8.4 55.5 90.0
MSS MSS None 58811 49.2 49.3 0.8 45.1 51.6 6.5 NaN NaN
start/stop time: 153,380 238,129
Total time: 84,749.0 seconds
Total time: 1,412.483 minutes
Total time: 23.541 hours
Total Samples: 3,748,972
Avg Samples/sec: 44.2

Serial Number : 6221C43829
Firmware Date : Jun 27, 2023
Release target version :
Navigation Processor Version: 6.21
Radio library version : 5.61
SVType Freq Track N_Samples CNo_Mean CNo_Median CNo_Std CNo_Min CNo_Max CNo_Range El_Mean El_Max
GPS L1 CA 389425 47.4 47.5 2.2 38.1 54.9 16.8 55.5 89.0
GPS L2 CM+CL 309592 47.4 47.6 1.8 39.9 52.4 12.5 56.6 89.0
GPS L2 E 79833 36.1 36.2 3.3 26.0 44.8 18.8 51.2 78.0
GPS L5/E5A I+Q 216604 49.4 49.5 1.8 43.7 53.8 10.1 55.8 89.0
SBAS L1 CA 254226 43.2 42.6 1.7 39.4 47.5 8.1 39.9 42.0
GLONASS L1 CA 303870 46.3 47.9 4.4 31.4 53.4 22.0 53.6 88.0
GLONASS L2 CA 258722 46.4 47.2 2.6 4.5 51.2 46.7 53.2 88.0
Galileo L1 MBOC-PD 280831 48.3 48.3 2.2 38.7 54.2 15.5 54.7 87.0
Galileo E5A+B AltBOC-Comp-PD 280831 49.3 49.6 1.5 43.1 52.6 9.5 54.7 87.0
BeiDou L1 BOC-PD 301464 48.9 49.2 1.8 40.5 53.4 12.9 55.8 90.0
BeiDou L5/E5A I+Q 301464 47.8 47.9 1.4 41.3 51.5 10.2 55.8 90.0
BeiDou E5B/B2 BPSK(2)-B2 36679 47.5 47.6 0.9 43.3 50.2 6.9 53.4 83.0
BeiDou B1 BPSK(2)-B1 338143 48.6 48.8 2.1 40.2 54.0 13.8 55.5 90.0
BeiDou B3 BPSK(10)-B3 338143 47.4 47.6 1.3 39.9 50.3 10.4 55.5 90.0
MSS MSS NaN 58567 50.2 50.2 0.7 48.1 52.2 4.1 NaN NaN
start/stop time: 153,382 238,123
Total time: 84,741.0 seconds
Total time: 1,412.350 minutes
Total time: 23.539 hours
Total Samples: 3,748,394
Avg Samples/sec: 44.2

Serial Number : 6303C55289
Firmware Date : Jun 27, 2023
Release target version :
Navigation Processor Version: 6.21
Radio library version : 5.61
SVType Freq Track N_Samples CNo_Mean CNo_Median CNo_Std CNo_Min CNo_Max CNo_Range El_Mean El_Max
GPS L1 CA 389401 +0.1 +0.1 +1.2 -5.3 +5.8 +11.1 +55.5 +89.0
GPS L2 CM+CL 309573 +0.2 +0.2 +0.8 -4.1 +4.3 +8.4 +56.6 +89.0
GPS L2 E 79828 +0.5 +0.4 +1.2 -3.9 +5.3 +9.2 +51.2 +78.0
GPS L5/E5A I+Q 216589 +0.6 +0.6 +0.7 -2.4 +4.2 +6.6 +55.8 +89.0
SBAS L1 CA 254226 -0.3 -0.2 +1.5 -4.5 +3.3 +7.8 +39.9 +42.0
GLONASS L1 CA 303852 +0.5 +0.5 +1.4 -5.3 +9.5 +14.8 +53.6 +88.0
GLONASS L2 CA 258677 +0.3 +0.3 +0.9 -5.3 +6.3 +11.6 +53.2 +88.0
Galileo L1 MBOC-PD 280819 +0.1 +0.1 +1.0 -4.5 +5.0 +9.5 +54.7 +87.0
Galileo E5A+B AltBOC-Comp-PD 280819 +0.2 +0.2 +0.5 -2.3 +2.4 +4.7 +54.7 +87.0
BeiDou L1 BOC-PD 301453 +0.2 +0.2 +1.1 -4.5 +5.0 +9.5 +55.8 +90.0
BeiDou L5/E5A I+Q 301453 +0.5 +0.5 +0.7 -2.6 +3.5 +6.1 +55.8 +90.0
BeiDou E5B/B2 BPSK(2)-B2 36677 +0.0 +0.0 +0.6 -2.2 +3.4 +5.6 +53.4 +83.0
BeiDou B1 BPSK(2)-B1 338130 +0.1 +0.1 +1.1 -5.4 +8.1 +13.5 +55.6 +90.0
BeiDou B3 BPSK(10)-B3 338130 +0.1 +0.1 +0.7 -3.5 +3.8 +7.3 +55.6 +90.0
MSS MSS nan 51652 -1.0 -1.0 +0.8 -4.3 +1.5 +5.8 +nan +nan
start/stop time: 153,382 238,123
Total time: 84,741.0 seconds
Total time: 1,412.350 minutes
Total time: 23.539 hours
Total Samples: 3,741,279
Avg Samples/sec: 44.1

Statistics for full C/No Observations dataset
(df_ref - df_dut => positive numbers mean DUT is worse)
Mean = 0.209
Median = 0.200
Std Dev= 1.044

Plots


REF GPS L1(CA)

SV AvgEl AvgOffset AvgCNo MaxCNo MinCNo Slip_Count SVChan Ant N_Samples
2 41.1 -0.0 45.4 48.7 41.2 0 [14.0] [0.0] 7156
3 55.5 0.0 47.9 51.9 41.8 119 [31.0, 32.0] [0.0] 10423
4 60.4 -0.0 47.0 52.0 40.9 0 [34.0] [0.0] 14888
5 58.8 -0.0 47.8 51.8 41.6 0 [34.0] [0.0] 12785
6 59.3 0.0 48.3 52.8 38.4 0 [36.0] [0.0] 12982
7 58.8 -0.0 47.9 52.1 40.7 0 [29.0] [0.0] 16233
8 47.4 0.0 46.5 50.7 40.9 0 [36.0] [0.0] 9456
9 59.5 0.0 48.6 53.2 40.4 0 [33.0] [0.0] 13211
10 55.7 -0.0 49.4 54.5 39.0 0 [22.0] [0.0] 16769
11 61.2 -0.0 47.7 52.1 40.8 0 [32.0] [0.0] 14427
12 57.5 -0.0 48.3 51.9 41.4 0 [29.0] [0.0] 12438
13 37.3 0.1 45.9 49.3 40.9 22 [4.0, 37.0] [0.0] 8867
14 56.5 0.0 47.1 51.1 40.5 0 [11.0] [0.0] 16753
15 51.1 -0.0 47.1 50.3 42.3 0 [24.0] [0.0] 10605
16 52.4 -0.0 46.4 49.6 40.1 0 [21.0] [0.0] 10827
17 60.9 -0.0 48.2 52.5 41.3 0 [3.0] [0.0] 14972
18 58.3 0.0 47.5 52.2 41.4 0 [25.0] [0.0] 15593
19 58.8 0.0 47.6 52.1 39.4 0 [24.0] [0.0] 15394
20 54.3 -0.0 46.1 49.7 40.7 0 [30.0] [0.0] 11843
21 43.7 -0.0 46.0 49.0 40.2 0 [17.0] [0.0] 8546
22 56.5 0.0 47.5 51.3 40.7 0 [15.0] [0.0] 17200
23 56.1 -0.0 47.0 51.1 40.9 0 [35.0] [0.0] 16466
24 39.6 0.0 45.1 49.0 41.2 0 [23.0] [0.0] 6228
25 47.9 0.0 46.4 50.5 38.5 0 [18.0] [0.0] 9700
26 50.3 0.0 46.3 50.0 41.1 0 [25.0] [0.0] 9019
27 37.1 0.0 45.5 48.1 41.4 248 [28.0, 32.0] [0.0] 8716
28 59.4 0.0 46.2 50.6 37.6 185 [16.0, 13.0] [0.0] 11590
29 61.1 -0.0 48.3 52.7 41.1 0 [21.0] [0.0] 13776
30 61.3 -0.0 48.8 53.1 40.3 0 [22.0] [0.0] 14670
31 58.5 0.0 48.2 52.6 43.2 26 [11.0, 24.0] [0.0] 12185
32 59.3 -0.0 50.2 56.1 42.4 0 [20.0] [0.0] 15723
DUT GPS L1(CA)

SV AvgEl AvgOffset AvgCNo MaxCNo MinCNo Slip_Count SVChan Ant N_Samples
2 41.1 0.0 45.6 49.6 40.4 0 [15.0] [0.0] 7156
3 55.5 0.0 47.6 52.2 42.1 106 [21.0, 34.0] [0.0] 10414
4 60.4 0.0 46.8 51.6 41.8 0 [14.0] [0.0] 14888
5 58.8 0.0 47.8 51.6 41.8 0 [27.0] [0.0] 12787
6 59.3 -0.0 48.2 52.3 40.6 0 [37.0] [0.0] 12984
7 58.8 -0.0 47.5 51.5 42.0 0 [34.0] [0.0] 16233
8 47.4 0.0 46.6 50.7 40.8 0 [37.0] [0.0] 9458
9 59.5 -0.0 48.5 53.2 41.3 0 [28.0] [0.0] 13211
10 55.7 -0.0 49.2 54.1 41.2 0 [12.0] [0.0] 16769
11 61.2 0.0 47.7 51.9 42.2 0 [34.0] [0.0] 14428
12 57.5 0.0 48.0 52.1 41.0 0 [17.0] [0.0] 12439
13 37.3 0.0 45.6 48.7 42.1 254 [8.0, 36.0] [0.0] 8868
14 56.5 -0.0 47.1 50.8 39.5 0 [16.0] [0.0] 16754
15 51.1 0.0 47.2 50.3 42.3 0 [19.0] [0.0] 10605
16 52.4 -0.0 46.4 49.7 41.3 0 [31.0] [0.0] 10828
17 60.9 0.0 48.1 52.2 42.1 0 [7.0] [0.0] 14973
18 58.3 -0.0 47.2 51.6 40.2 0 [23.0] [0.0] 15593
19 58.8 -0.0 47.5 51.9 39.4 0 [18.0] [0.0] 15393
20 54.3 -0.0 46.1 50.2 40.5 0 [33.0] [0.0] 11846
21 43.7 -0.0 45.9 49.7 38.1 0 [22.0] [0.0] 8544
22 56.5 -0.0 47.2 51.6 40.8 0 [22.0] [0.0] 17198
23 56.1 -0.0 46.9 50.7 40.4 0 [35.0] [0.0] 16465
24 39.6 -0.0 44.8 49.1 40.5 0 [19.0] [0.0] 6229
25 47.9 0.0 46.2 51.1 39.0 0 [26.0] [0.0] 9699
26 50.3 -0.0 46.6 50.5 40.8 0 [30.0] [0.0] 9018
27 37.1 -0.0 45.5 49.3 39.9 38 [25.0, 34.0] [0.0] 8715
28 59.4 0.0 46.1 49.6 39.9 44 [13.0, 14.0] [0.0] 11585
29 61.1 0.0 48.1 52.7 41.4 0 [31.0] [0.0] 13774
30 61.3 0.0 48.6 52.8 40.1 0 [26.0] [0.0] 14671
31 58.5 0.0 48.1 52.0 44.1 37 [29.0, 19.0] [0.0] 12177
32 59.3 -0.0 50.1 54.9 42.4 0 [21.0] [0.0] 15723
DIFF GPS L1(CA)

SV AvgEl AvgCNoDiff MaxCNoDiff MinCNoDiff SVChan N_Samples
2 41.1 -0.2 4.3 -3.8 [14.0, 15.0] 7156
3 55.5 0.2 4.2 -3.9 [31.0, 21.0, 32.0, 34.0] 10414
4 60.4 0.3 4.2 -3.4 [34.0, 14.0] 14888
5 58.8 -0.0 5.0 -4.3 [34.0, 27.0] 12785
6 59.3 0.1 4.9 -4.9 [36.0, 37.0] 12982
7 58.8 0.4 4.7 -4.1 [29.0, 34.0] 16233
8 47.4 -0.1 4.8 -3.5 [36.0, 37.0] 9456
9 59.5 0.1 3.9 -4.4 [33.0, 28.0] 13211
10 55.7 0.2 4.3 -4.4 [22.0, 12.0] 16769
11 61.2 -0.0 4.7 -5.1 [32.0, 34.0] 14427
12 57.5 0.3 5.8 -3.2 [29.0, 17.0] 12438
13 37.3 0.3 4.5 -4.3 [4.0, 8.0, 37.0, 36.0] 8867
14 56.5 0.0 3.6 -4.1 [11.0, 16.0] 16753
15 51.1 -0.1 4.6 -3.5 [24.0, 19.0] 10605
16 52.4 0.0 4.9 -4.0 [21.0, 31.0] 10827
17 60.9 0.0 5.0 -5.2 [3.0, 7.0] 14972
18 58.3 0.3 5.6 -4.1 [25.0, 23.0] 15592
19 58.8 0.1 4.7 -3.7 [24.0, 18.0] 15393
20 54.3 0.0 3.8 -4.3 [30.0, 33.0] 11843
21 43.7 0.1 5.6 -4.3 [17.0, 22.0] 8544
22 56.5 0.3 3.7 -3.5 [15.0, 22.0] 17198
23 56.1 0.1 5.8 -4.8 [35.0] 16465
24 39.6 0.3 4.9 -2.9 [23.0, 19.0] 6228
25 47.9 0.2 5.1 -4.6 [18.0, 26.0] 9699
26 50.3 -0.2 3.7 -4.3 [25.0, 30.0] 9017
27 37.1 0.0 5.5 -4.4 [28.0, 25.0, 32.0, 34.0] 8714
28 59.4 0.1 4.9 -4.4 [16.0, 13.0, 14.0] 11582
29 61.1 0.2 5.7 -4.5 [21.0, 31.0] 13774
30 61.3 0.2 4.7 -4.2 [22.0, 26.0] 14670
31 58.5 0.0 4.0 -5.3 [11.0, 29.0, 24.0, 19.0] 12177
32 59.3 0.1 3.5 -3.6 [20.0, 21.0] 15722
REF GPS L2(E)

SV AvgEl AvgOffset AvgCNo MaxCNo MinCNo Slip_Count SVChan Ant N_Samples
2 41.1 -0.0 35.1 37.9 29.3 0 [14.0] [0.0] 7156
13 37.3 0.1 32.2 35.9 28.4 28 [4.0, 37.0] [0.0] 8867
16 52.4 -0.0 35.8 40.3 28.3 0 [21.0] [0.0] 10827
19 58.8 0.0 39.8 45.3 30.4 0 [24.0] [0.0] 15394
20 54.3 -0.0 36.6 40.3 28.9 0 [30.0] [0.0] 11843
21 43.7 -0.0 34.8 39.4 28.7 0 [17.0] [0.0] 8546
22 56.5 0.0 37.8 42.3 29.4 0 [15.0] [0.0] 17200
DUT GPS L2(E)

SV AvgEl AvgOffset AvgCNo MaxCNo MinCNo Slip_Count SVChan Ant N_Samples
2 41.1 0.0 34.5 38.8 28.5 0 [15.0] [0.0] 7156
13 37.3 0.0 32.0 35.3 28.3 137 [8.0, 36.0] [0.0] 8868
16 52.4 -0.0 35.6 39.9 26.9 0 [31.0] [0.0] 10828
19 58.8 -0.0 39.4 44.8 30.7 0 [18.0] [0.0] 15393
20 54.3 -0.0 36.5 40.4 28.2 0 [33.0] [0.0] 11846
21 43.7 -0.0 33.9 38.4 26.8 0 [22.0] [0.0] 8544
22 56.5 -0.0 37.0 41.4 26.0 0 [22.0] [0.0] 17198
DIFF GPS L2(E)

SV AvgEl AvgCNoDiff MaxCNoDiff MinCNoDiff SVChan N_Samples
2 41.1 0.6 4.7 -3.1 [14.0, 15.0] 7156
13 37.3 0.3 5.3 -3.9 [4.0, 8.0, 37.0, 36.0] 8867
16 52.4 0.2 5.0 -3.0 [21.0, 31.0] 10827
19 58.8 0.4 4.8 -3.0 [24.0, 18.0] 15393
20 54.3 0.1 4.4 -2.9 [30.0, 33.0] 11843
21 43.7 1.0 4.8 -3.3 [17.0, 22.0] 8544
22 56.5 0.8 5.3 -3.6 [15.0, 22.0] 17198
REF GPS L2(CM+CL)

SV AvgEl AvgOffset AvgCNo MaxCNo MinCNo Slip_Count SVChan Ant N_Samples
3 55.5 0.0 48.0 50.3 44.1 75 [31.0, 32.0] [0.0] 10423
4 60.4 -0.0 48.6 52.5 42.5 0 [34.0] [0.0] 14888
5 58.8 -0.0 47.2 50.1 42.6 0 [34.0] [0.0] 12785
6 59.3 0.0 48.6 50.9 44.2 0 [36.0] [0.0] 12982
7 58.8 -0.0 46.4 49.9 40.9 0 [29.0] [0.0] 16233
8 47.4 0.0 47.2 49.3 43.5 0 [36.0] [0.0] 9456
9 59.5 0.0 48.5 51.2 42.2 0 [33.0] [0.0] 13211
10 55.7 -0.0 48.2 51.1 43.7 0 [22.0] [0.0] 16769
11 61.2 -0.0 49.1 52.1 45.6 0 [32.0] [0.0] 14427
12 57.5 -0.0 46.8 49.7 42.2 0 [29.0] [0.0] 12438
14 56.5 0.0 48.7 51.8 43.1 0 [11.0] [0.0] 16753
15 51.1 -0.0 45.7 48.6 41.4 0 [24.0] [0.0] 10605
17 60.9 -0.0 46.9 50.0 41.8 0 [3.0] [0.0] 14972
18 58.3 0.0 48.8 51.7 42.8 0 [25.0] [0.0] 15593
23 56.1 -0.0 48.2 51.2 43.6 0 [35.0] [0.0] 16466
24 39.6 0.0 46.5 48.8 44.1 0 [23.0] [0.0] 6228
25 47.9 0.0 46.8 48.8 43.8 0 [18.0] [0.0] 9700
26 50.3 0.0 47.1 49.2 43.4 0 [25.0] [0.0] 9019
27 37.1 0.0 45.5 47.9 42.3 241 [28.0, 32.0] [0.0] 8716
28 59.4 0.0 48.7 51.5 44.7 118 [16.0, 13.0] [0.0] 11590
29 61.1 -0.0 47.2 50.0 41.3 0 [21.0] [0.0] 13776
30 61.3 -0.0 48.0 50.9 42.7 0 [22.0] [0.0] 14670
31 58.5 0.0 46.4 49.5 41.4 5 [11.0, 24.0] [0.0] 12185
32 59.3 -0.0 47.8 50.9 43.0 0 [20.0] [0.0] 15723
DUT GPS L2(CM+CL)

SV AvgEl AvgOffset AvgCNo MaxCNo MinCNo Slip_Count SVChan Ant N_Samples
3 55.5 0.0 47.7 50.0 43.0 97 [21.0, 34.0] [0.0] 10414
4 60.4 0.0 48.5 52.0 42.6 0 [14.0] [0.0] 14888
5 58.8 0.0 47.0 49.6 41.9 0 [27.0] [0.0] 12787
6 59.3 -0.0 48.4 50.9 42.2 0 [37.0] [0.0] 12984
7 58.8 -0.0 46.1 49.6 39.9 0 [34.0] [0.0] 16233
8 47.4 0.0 47.1 49.6 41.6 0 [37.0] [0.0] 9458
9 59.5 -0.0 48.3 51.0 42.6 0 [28.0] [0.0] 13211
10 55.7 -0.0 48.0 50.8 43.4 0 [12.0] [0.0] 16769
11 61.2 0.0 49.0 52.4 43.5 0 [34.0] [0.0] 14428
12 57.5 0.0 46.3 49.2 40.7 0 [17.0] [0.0] 12439
14 56.5 -0.0 48.5 51.9 42.8 0 [16.0] [0.0] 16754
15 51.1 0.0 45.6 48.3 40.8 0 [19.0] [0.0] 10605
17 60.9 0.0 46.7 50.2 40.8 0 [7.0] [0.0] 14973
18 58.3 -0.0 48.6 51.4 43.0 0 [23.0] [0.0] 15593
23 56.1 -0.0 47.8 50.9 43.2 0 [35.0] [0.0] 16465
24 39.6 -0.0 46.0 48.1 43.2 0 [19.0] [0.0] 6229
25 47.9 0.0 46.2 48.7 41.9 0 [26.0] [0.0] 9699
26 50.3 -0.0 47.1 49.5 42.5 0 [30.0] [0.0] 9018
27 37.1 -0.0 45.5 48.1 42.5 8 [25.0, 34.0] [0.0] 8715
28 59.4 0.0 48.6 51.2 43.8 243 [13.0, 14.0] [0.0] 11585
29 61.1 0.0 47.0 50.1 41.2 0 [31.0] [0.0] 13774
30 61.3 0.0 47.9 50.6 42.5 0 [26.0] [0.0] 14671
31 58.5 0.0 46.3 50.0 41.2 185 [29.0, 19.0] [0.0] 12177
32 59.3 -0.0 47.6 50.4 42.6 0 [21.0] [0.0] 15723
DIFF GPS L2(CM+CL)

SV AvgEl AvgCNoDiff MaxCNoDiff MinCNoDiff SVChan N_Samples
3 55.5 0.2 3.5 -2.7 [31.0, 21.0, 32.0, 34.0] 10414
4 60.4 0.1 2.5 -4.1 [34.0, 14.0] 14888
5 58.8 0.2 2.8 -2.1 [34.0, 27.0] 12785
6 59.3 0.2 3.1 -2.3 [36.0, 37.0] 12982
7 58.8 0.3 3.2 -2.9 [29.0, 34.0] 16233
8 47.4 0.1 4.2 -2.4 [36.0, 37.0] 9456
9 59.5 0.2 3.7 -2.4 [33.0, 28.0] 13211
10 55.7 0.2 3.4 -2.4 [22.0, 12.0] 16769
11 61.2 0.1 3.3 -2.8 [32.0, 34.0] 14427
12 57.5 0.4 4.3 -4.1 [29.0, 17.0] 12438
14 56.5 0.2 3.7 -2.6 [11.0, 16.0] 16753
15 51.1 0.1 2.8 -3.6 [24.0, 19.0] 10605
17 60.9 0.2 2.8 -2.7 [3.0, 7.0] 14972
18 58.3 0.2 4.1 -2.3 [25.0, 23.0] 15592
23 56.1 0.4 3.3 -2.4 [35.0] 16465
24 39.6 0.6 3.6 -2.3 [23.0, 19.0] 6228
25 47.9 0.6 3.9 -3.0 [18.0, 26.0] 9699
26 50.3 -0.0 3.3 -2.2 [25.0, 30.0] 9017
27 37.1 -0.1 3.5 -2.9 [28.0, 25.0, 32.0, 34.0] 8714
28 59.4 0.1 3.0 -2.7 [16.0, 13.0, 14.0] 11582
29 61.1 0.2 3.6 -2.7 [21.0, 31.0] 13774
30 61.3 0.1 2.8 -2.3 [22.0, 26.0] 14670
31 58.5 0.1 3.4 -4.0 [11.0, 29.0, 24.0, 19.0] 12177
32 59.3 0.3 2.8 -2.5 [20.0, 21.0] 15722
REF GPS L5/E5A(I+Q)

SV AvgEl AvgOffset AvgCNo MaxCNo MinCNo Slip_Count SVChan Ant N_Samples
3 55.5 0.0 50.7 52.8 46.5 39 [31.0, 32.0] [0.0] 10423
4 60.4 -0.0 50.3 53.2 45.7 0 [34.0] [0.0] 14888
6 59.3 0.0 50.2 53.3 45.8 0 [36.0] [0.0] 12982
8 47.4 0.0 49.3 50.8 45.8 0 [36.0] [0.0] 9456
9 59.5 0.0 50.6 52.6 45.9 0 [33.0] [0.0] 13211
10 55.7 -0.0 49.7 52.0 45.8 0 [22.0] [0.0] 16769
11 61.2 -0.0 50.9 53.9 45.2 0 [32.0] [0.0] 14427
14 56.5 0.0 50.6 54.3 45.9 0 [11.0] [0.0] 16753
18 58.3 0.0 50.8 53.3 45.4 0 [25.0] [0.0] 15593
23 56.1 -0.0 49.9 53.2 45.5 0 [35.0] [0.0] 16466
24 39.6 0.0 48.5 50.0 45.8 0 [23.0] [0.0] 6228
25 47.9 0.0 49.3 52.0 46.8 0 [18.0] [0.0] 9700
26 50.3 0.0 49.4 51.2 46.0 0 [25.0] [0.0] 9019
27 37.1 0.0 47.0 48.8 44.8 118 [28.0, 32.0] [0.0] 8716
28 59.4 0.0 50.5 52.9 45.8 45 [16.0, 13.0] [0.0] 11590
30 61.3 -0.0 51.1 53.0 45.8 0 [22.0] [0.0] 14670
32 59.3 -0.0 48.5 51.0 44.1 0 [20.0] [0.0] 15723
DUT GPS L5/E5A(I+Q)

SV AvgEl AvgOffset AvgCNo MaxCNo MinCNo Slip_Count SVChan Ant N_Samples
3 55.5 0.0 49.9 51.7 46.7 79 [21.0, 34.0] [0.0] 10414
4 60.4 0.0 49.7 52.6 44.9 0 [14.0] [0.0] 14888
6 59.3 -0.0 49.4 51.6 44.5 0 [37.0] [0.0] 12984
8 47.4 0.0 48.9 51.0 45.0 0 [37.0] [0.0] 9458
9 59.5 -0.0 50.1 52.3 46.2 0 [28.0] [0.0] 13211
10 55.7 -0.0 49.3 51.2 45.6 0 [12.0] [0.0] 16769
11 61.2 0.0 50.2 53.8 45.5 0 [34.0] [0.0] 14428
14 56.5 -0.0 49.9 53.2 43.7 0 [16.0] [0.0] 16754
18 58.3 -0.0 50.3 53.0 44.6 0 [23.0] [0.0] 15593
23 56.1 -0.0 49.3 53.0 44.6 0 [35.0] [0.0] 16465
24 39.6 -0.0 47.5 49.7 43.7 0 [19.0] [0.0] 6229
25 47.9 0.0 48.4 50.7 45.1 0 [26.0] [0.0] 9699
26 50.3 -0.0 48.8 50.9 44.9 0 [30.0] [0.0] 9018
27 37.1 -0.0 47.1 50.4 44.5 54 [25.0, 34.0] [0.0] 8715
28 59.4 0.0 49.9 52.4 45.1 118 [13.0, 14.0] [0.0] 11585
30 61.3 0.0 50.6 53.0 46.7 0 [26.0] [0.0] 14671
32 59.3 -0.0 48.0 50.9 44.3 0 [21.0] [0.0] 15723
DIFF GPS L5/E5A(I+Q)

SV AvgEl AvgCNoDiff MaxCNoDiff MinCNoDiff SVChan N_Samples
3 55.5 0.8 2.7 -1.5 [31.0, 21.0, 32.0, 34.0] 10414
4 60.4 0.6 2.7 -2.1 [34.0, 14.0] 14888
6 59.3 0.7 2.6 -1.2 [36.0, 37.0] 12982
8 47.4 0.3 2.8 -2.1 [36.0, 37.0] 9456
9 59.5 0.5 2.5 -1.5 [33.0, 28.0] 13211
10 55.7 0.4 2.0 -1.8 [22.0, 12.0] 16769
11 61.2 0.7 3.0 -1.3 [32.0, 34.0] 14427
14 56.5 0.7 3.0 -2.2 [11.0, 16.0] 16753
18 58.3 0.5 2.3 -2.1 [25.0, 23.0] 15592
23 56.1 0.6 3.6 -2.0 [35.0] 16465
24 39.6 1.0 4.2 -0.9 [23.0, 19.0] 6228
25 47.9 0.9 2.7 -1.3 [18.0, 26.0] 9699
26 50.3 0.6 2.5 -0.9 [25.0, 30.0] 9017
27 37.1 -0.1 2.6 -2.4 [28.0, 25.0, 32.0, 34.0] 8714
28 59.4 0.5 2.8 -1.5 [16.0, 13.0, 14.0] 11582
30 61.3 0.5 2.6 -1.9 [22.0, 26.0] 14670
32 59.3 0.5 2.4 -1.8 [20.0, 21.0] 15722
REF SBAS L1(CA)

SV AvgEl AvgOffset AvgCNo MaxCNo MinCNo Slip_Count SVChan Ant N_Samples
131 42.0 0.0 43.2 45.6 40.9 0 [57.0] [0.0] 84750
133 38.0 0.0 42.3 44.5 39.7 0 [55.0] [0.0] 84750
135 39.6 0.0 43.0 45.1 40.6 0 [54.0] [0.0] 84750
DUT SBAS L1(CA)

SV AvgEl AvgOffset AvgCNo MaxCNo MinCNo Slip_Count SVChan Ant N_Samples
131 42.0 0.0 45.3 47.5 43.0 0 [56.0] [0.0] 84742
133 38.0 0.0 42.5 44.7 39.8 0 [57.0] [0.0] 84742
135 39.6 0.0 41.7 43.8 39.4 0 [55.0] [0.0] 84742
DIFF SBAS L1(CA)

SV AvgEl AvgCNoDiff MaxCNoDiff MinCNoDiff SVChan N_Samples
131 42.0 -2.1 -0.1 -4.5 [57.0, 56.0] 84742
133 38.0 -0.2 2.4 -2.3 [55.0, 57.0] 84742
135 39.6 1.3 3.3 -0.8 [54.0, 55.0] 84742
REF GLONASS L1(CA)

SV AvgEl AvgOffset AvgCNo MaxCNo MinCNo Slip_Count FDMA Ant N_Samples
1 39.2 0.0 44.5 48.3 39.3 167 [1.0] [0.0] 10004
2 49.3 0.0 49.3 52.8 43.1 0 [-4.0] [0.0] 8707
3 59.2 -0.0 47.8 51.5 42.2 0 [5.0] [0.0] 11050
4 59.3 -0.0 48.1 51.2 43.0 0 [6.0] [0.0] 12372
5 50.5 0.0 49.9 53.5 42.9 71 [1.0] [0.0] 15491
6 57.3 -0.0 38.8 42.0 33.7 204 [-4.0] [0.0] 19239
7 58.1 -0.0 48.7 52.2 42.7 54 [5.0] [0.0] 12940
8 52.8 0.0 45.9 48.8 40.6 0 [6.0] [0.0] 9566
9 57.1 0.0 49.0 52.8 43.7 150 [-2.0] [0.0] 14174
10 52.4 0.0 44.9 48.9 38.0 0 [-7.0] [0.0] 13683
11 49.7 -0.0 49.9 54.8 44.9 0 [0.0] [0.0] 14339
12 56.9 -0.0 50.3 54.2 44.0 0 [-1.0] [0.0] 12907
13 61.1 0.0 39.2 43.9 31.6 0 [-2.0] [0.0] 11637
14 52.3 -0.0 51.2 54.5 44.1 0 [-7.0] [0.0] 9487
15 39.7 -0.0 48.7 52.1 44.6 265 [0.0] [0.0] 11192
16 58.0 -0.0 49.7 53.1 44.3 252 [-1.0] [0.0] 13606
17 49.4 -0.0 48.8 53.2 42.6 0 [4.0] [0.0] 14192
18 55.4 -0.0 49.6 52.6 43.4 0 [-3.0] [0.0] 12911
19 60.8 -0.0 39.0 41.8 33.3 0 [3.0] [0.0] 11897
20 50.6 -0.0 37.4 40.7 30.9 111 [2.0] [0.0] 12914
21 46.3 -0.0 48.6 52.3 43.7 3 [4.0] [0.0] 14777
22 58.0 -0.0 50.1 53.7 44.0 0 [-3.0] [0.0] 10744
23 59.1 0.0 47.2 50.6 41.8 0 [3.0] [0.0] 12264
24 51.6 0.0 49.8 53.2 44.5 0 [2.0] [0.0] 13813
DUT GLONASS L1(CA)

SV AvgEl AvgOffset AvgCNo MaxCNo MinCNo Slip_Count FDMA Ant N_Samples
1 39.2 -0.0 44.7 47.7 39.6 158 [1.0] [0.0] 10004
2 49.3 -0.0 49.0 52.4 42.5 0 [-4.0] [0.0] 8707
3 59.2 -0.0 47.2 50.5 41.8 0 [5.0] [0.0] 11051
4 59.3 0.0 47.5 50.9 42.7 0 [6.0] [0.0] 12370
5 50.5 -0.0 49.6 52.6 41.9 182 [1.0] [0.0] 15488
6 57.3 -0.0 38.1 41.7 33.7 73 [-4.0] [0.0] 19231
7 58.1 0.0 48.1 51.3 42.4 118 [5.0] [0.0] 12933
8 52.8 -0.0 45.5 48.4 41.9 0 [6.0] [0.0] 9566
9 57.1 -0.0 48.6 52.5 42.6 137 [-2.0] [0.0] 14169
10 52.4 -0.0 43.8 47.6 36.3 0 [-7.0] [0.0] 13685
11 49.7 -0.0 49.6 52.8 42.6 0 [0.0] [0.0] 14340
12 56.9 0.0 49.9 52.5 44.2 0 [-1.0] [0.0] 12908
13 61.1 -0.0 38.7 42.6 32.2 0 [-2.0] [0.0] 11636
14 52.3 0.0 48.5 53.4 39.4 0 [-7.0] [0.0] 9485
15 39.7 -0.0 48.9 51.5 44.4 240 [0.0] [0.0] 11188
16 58.0 0.0 49.5 52.4 40.4 169 [-1.0] [0.0] 13597
17 49.4 0.0 48.2 51.9 41.0 0 [4.0] [0.0] 14191
18 55.4 -0.0 48.7 51.4 42.5 0 [-3.0] [0.0] 12911
19 60.8 0.0 38.5 41.1 33.9 0 [3.0] [0.0] 11896
20 50.6 0.0 37.3 40.3 31.4 20 [2.0] [0.0] 12912
21 46.3 -0.0 48.5 52.1 42.8 206 [4.0] [0.0] 14780
22 58.0 -0.0 48.8 52.5 42.9 0 [-3.0] [0.0] 10744
23 59.1 0.0 46.7 49.9 42.1 0 [3.0] [0.0] 12265
24 51.6 0.0 49.4 52.7 44.5 0 [2.0] [0.0] 13813
DIFF GLONASS L1(CA)

SV AvgEl AvgCNoDiff MaxCNoDiff MinCNoDiff FDMA N_Samples
1 39.2 -0.2 5.8 -4.4 [1.0] 10003
2 49.3 0.2 4.4 -4.7 [-4.0] 8706
3 59.2 0.7 4.5 -2.7 [5.0] 11050
4 59.3 0.6 4.3 -3.5 [6.0] 12370
5 50.5 0.3 5.5 -4.4 [1.0] 15487
6 57.3 0.7 5.2 -2.9 [-4.0] 19230
7 58.1 0.6 4.5 -2.4 [5.0] 12932
8 52.8 0.4 3.6 -4.3 [6.0] 9566
9 57.1 0.4 4.8 -4.2 [-2.0] 14167
10 52.4 1.1 7.6 -4.8 [-7.0] 13683
11 49.7 0.4 5.0 -3.9 [0.0] 14339
12 56.9 0.4 4.6 -3.7 [-1.0] 12907
13 61.1 0.5 5.2 -4.0 [-2.0] 11636
14 52.3 2.7 9.5 -3.0 [-7.0] 9485
15 39.7 -0.2 5.1 -4.9 [0.0] 11188
16 58.0 0.2 8.0 -3.2 [-1.0] 13597
17 49.4 0.5 5.2 -3.5 [4.0] 14191
18 55.4 0.9 4.6 -3.1 [-3.0] 12911
19 60.8 0.4 3.8 -3.3 [3.0] 11896
20 50.6 0.0 4.7 -5.1 [2.0] 12911
21 46.3 0.1 4.5 -5.3 [4.0] 14777
22 58.0 1.3 5.2 -2.0 [-3.0] 10743
23 59.1 0.5 5.3 -3.0 [3.0] 12264
24 51.6 0.4 4.7 -5.1 [2.0] 13813
REF GLONASS L2(CA)

SV AvgEl AvgOffset AvgCNo MaxCNo MinCNo Slip_Count FDMA Ant N_Samples
1 39.2 0.0 41.4 44.8 37.4 225 [1.0] [0.0] 10004
2 49.3 0.0 46.8 48.8 43.0 0 [-4.0] [0.0] 8707
3 59.2 -0.0 47.8 50.0 42.7 0 [5.0] [0.0] 11050
4 59.3 -0.0 47.9 50.0 44.7 0 [6.0] [0.0] 12372
5 50.5 0.0 47.5 50.2 42.8 149 [1.0] [0.0] 15491
7 58.1 -0.0 48.0 51.1 44.2 246 [5.0] [0.0] 12940
8 52.8 0.0 47.3 49.8 43.6 0 [6.0] [0.0] 9566
9 57.1 0.0 48.8 51.4 44.3 96 [-2.0] [0.0] 14174
10 58.1 0.1 30.4 41.4 1.0 15 [-7.0] [0.0] 16
11 49.7 -0.0 48.3 51.0 44.0 0 [0.0] [0.0] 14339
12 56.9 -0.0 48.1 50.3 43.4 0 [-1.0] [0.0] 12907
13 61.1 0.0 40.7 43.1 37.1 0 [-2.0] [0.0] 11637
14 52.3 -0.0 47.6 49.9 44.7 0 [-7.0] [0.0] 9487
15 39.7 -0.0 46.1 48.5 43.0 218 [0.0] [0.0] 11192
16 58.0 -0.0 47.7 50.0 43.8 148 [-1.0] [0.0] 13606
17 49.4 -0.0 47.4 50.3 43.4 0 [4.0] [0.0] 14192
18 55.4 -0.0 47.6 50.4 43.3 0 [-3.0] [0.0] 12911
19 60.8 -0.0 45.6 48.0 42.5 0 [3.0] [0.0] 11897
20 50.6 -0.0 41.0 43.9 37.3 192 [2.0] [0.0] 12914
21 46.3 -0.0 46.8 49.4 43.2 157 [4.0] [0.0] 14777
22 58.0 -0.0 48.5 50.8 44.3 0 [-3.0] [0.0] 10744
23 59.0 0.0 35.4 42.4 24.8 20 [3.0] [0.0] 21
24 51.6 0.0 47.5 50.0 42.5 0 [2.0] [0.0] 13813
DUT GLONASS L2(CA)

SV AvgEl AvgOffset AvgCNo MaxCNo MinCNo Slip_Count FDMA Ant N_Samples
1 39.2 -0.0 40.7 44.6 36.7 93 [1.0] [0.0] 10004
2 49.3 -0.0 46.7 48.9 43.6 0 [-4.0] [0.0] 8707
3 59.2 -0.0 47.8 49.8 44.3 0 [5.0] [0.0] 11051
4 59.3 0.0 47.8 49.8 44.1 0 [6.0] [0.0] 12370
5 50.5 -0.0 47.0 49.9 43.2 223 [1.0] [0.0] 15488
7 58.1 0.0 47.8 50.1 43.9 143 [5.0] [0.0] 12933
8 52.8 -0.0 47.2 49.3 42.0 0 [6.0] [0.0] 9566
9 57.1 -0.0 48.6 51.2 43.7 173 [-2.0] [0.0] 14169
10 62.0 -0.0 29.8 40.3 4.5 19 [-7.0] [0.0] 20
11 49.7 -0.0 47.8 51.1 42.6 0 [0.0] [0.0] 14340
12 56.9 0.0 47.8 50.4 43.8 0 [-1.0] [0.0] 12908
13 61.1 -0.0 40.4 42.8 35.1 0 [-2.0] [0.0] 11636
14 52.3 0.0 47.3 50.4 43.6 0 [-7.0] [0.0] 9485
15 39.7 -0.0 45.5 48.6 42.5 311 [0.0] [0.0] 11188
16 58.0 0.0 47.5 50.3 43.6 214 [-1.0] [0.0] 13597
17 49.4 0.0 47.1 49.9 41.4 0 [4.0] [0.0] 14191
18 55.4 -0.0 47.5 49.8 43.7 0 [-3.0] [0.0] 12911
19 60.8 0.0 45.3 47.8 40.9 0 [3.0] [0.0] 11896
20 50.6 0.0 40.6 43.7 35.9 224 [2.0] [0.0] 12912
21 46.3 -0.0 46.6 49.1 43.0 13 [4.0] [0.0] 14780
22 58.0 -0.0 48.3 51.0 43.8 0 [-3.0] [0.0] 10744
23 59.3 0.1 34.3 42.9 26.0 12 [3.0] [0.0] 13
24 51.6 0.0 47.0 49.9 41.4 0 [2.0] [0.0] 13813
DIFF GLONASS L2(CA)

SV AvgEl AvgCNoDiff MaxCNoDiff MinCNoDiff FDMA N_Samples
1 39.2 0.7 4.6 -2.7 [1.0] 10003
2 49.3 0.1 3.1 -2.7 [-4.0] 8706
3 59.2 0.1 2.7 -3.4 [5.0] 11050
4 59.3 0.1 2.4 -3.0 [6.0] 12370
5 50.5 0.4 3.4 -3.1 [1.0] 15487
7 58.1 0.2 3.0 -2.8 [5.0] 12932
8 52.8 0.1 3.2 -3.0 [6.0] 9566
9 57.1 0.2 3.9 -3.9 [-2.0] 14167
10 64.0 -3.6 -1.9 -5.3 [-7.0] 2
11 49.7 0.4 3.7 -2.9 [0.0] 14339
12 56.9 0.2 3.7 -4.1 [-1.0] 12907
13 61.1 0.3 4.5 -3.8 [-2.0] 11636
14 52.3 0.3 3.3 -2.9 [-7.0] 9485
15 39.7 0.6 3.6 -2.3 [0.0] 11188
16 58.0 0.2 3.2 -2.8 [-1.0] 13597
17 49.4 0.3 3.2 -2.7 [4.0] 14191
18 55.4 0.2 3.5 -4.0 [-3.0] 12911
19 60.8 0.3 3.4 -2.5 [3.0] 11896
20 50.6 0.4 4.0 -3.0 [2.0] 12911
21 46.3 0.2 3.9 -3.6 [4.0] 14777
22 58.0 0.2 6.3 -4.6 [-3.0] 10743
24 51.6 0.5 5.0 -2.7 [2.0] 13813
REF Galileo L1(MBOC-PD)

SV AvgEl AvgOffset AvgCNo MaxCNo MinCNo Slip_Count SVChan Ant N_Samples
3 54.0 0.0 49.5 52.9 43.2 0 [44.0] [0.0] 9767
4 44.4 -0.0 47.5 50.6 42.6 137 [50.0, 40.0] [0.0] 20284
7 48.5 0.0 47.5 49.8 43.8 0 [42.0] [0.0] 6664
9 57.2 -0.0 48.6 51.5 44.1 0 [53.0] [0.0] 15613
10 56.8 0.0 49.7 53.5 43.6 0 [50.0] [0.0] 21418
11 55.9 0.0 45.9 49.4 39.4 0 [52.0] [0.0] 22216
12 59.7 -0.0 45.9 49.2 41.0 0 [45.0] [0.0] 19326
15 42.1 -0.0 47.2 49.8 42.4 0 [50.0] [0.0] 8695
19 58.6 0.0 45.4 48.7 40.2 0 [45.0] [0.0] 16273
21 60.7 0.0 50.0 54.5 44.5 0 [53.0] [0.0] 18935
24 56.5 0.0 50.1 53.5 45.1 0 [49.0] [0.0] 15311
25 42.5 -0.0 47.9 50.9 41.0 46 [48.0, 39.0] [0.0] 9967
26 43.3 0.0 47.8 50.5 43.7 0 [39.0] [0.0] 9409
27 54.3 0.0 49.4 52.5 44.3 0 [51.0] [0.0] 14388
30 40.7 0.0 47.4 49.7 45.3 0 [38.0] [0.0] 4775
31 60.1 0.0 50.3 54.8 44.4 0 [41.0] [0.0] 19619
33 56.0 -0.0 47.8 50.7 42.6 0 [51.0] [0.0] 14742
34 55.5 0.0 49.8 53.0 42.5 0 [51.0] [0.0] 14533
36 60.2 -0.0 49.8 53.7 42.7 0 [42.0] [0.0] 18923
DUT Galileo L1(MBOC-PD)

SV AvgEl AvgOffset AvgCNo MaxCNo MinCNo Slip_Count SVChan Ant N_Samples
3 54.0 0.0 49.8 53.0 43.6 0 [52.0] [0.0] 9762
4 44.4 0.0 47.5 50.3 41.3 31 [42.0, 39.0] [0.0] 20286
7 48.5 -0.0 47.7 50.0 41.8 0 [50.0] [0.0] 6662
9 57.2 -0.0 48.4 50.8 43.9 0 [53.0] [0.0] 15611
10 56.8 -0.0 49.7 52.9 43.3 0 [49.0] [0.0] 21417
11 55.9 -0.0 45.9 48.9 38.7 0 [46.0] [0.0] 22217
12 59.7 -0.0 45.9 48.6 42.0 0 [48.0] [0.0] 19325
15 42.1 0.0 47.1 49.8 43.1 0 [49.0] [0.0] 8690
19 58.6 0.0 45.3 48.3 40.7 0 [48.0] [0.0] 16274
21 60.7 -0.0 50.1 53.5 44.8 0 [47.0] [0.0] 18935
24 56.5 0.0 49.7 52.7 44.2 0 [50.0] [0.0] 15311
25 42.5 0.0 47.7 50.4 39.4 133 [43.0, 39.0] [0.0] 9960
26 43.3 0.0 48.1 50.8 43.0 0 [40.0] [0.0] 9407
27 54.3 -0.0 49.5 52.8 44.3 0 [53.0] [0.0] 14387
30 40.7 0.0 48.5 50.6 45.6 0 [49.0] [0.0] 4771
31 60.1 0.0 49.8 54.2 43.2 0 [41.0] [0.0] 19618
33 56.0 0.0 47.6 49.9 42.9 0 [53.0] [0.0] 14741
34 55.5 -0.0 49.4 52.9 44.3 0 [45.0] [0.0] 14536
36 60.2 -0.0 49.7 53.3 44.3 0 [40.0] [0.0] 18921
DIFF Galileo L1(MBOC-PD)

SV AvgEl AvgCNoDiff MaxCNoDiff MinCNoDiff SVChan N_Samples
3 54.0 -0.2 2.4 -4.3 [44.0, 52.0] 9761
4 44.4 0.0 3.6 -4.0 [50.0, 42.0, 40.0, 39.0] 20283
7 48.5 -0.2 3.7 -2.9 [42.0, 50.0] 6662
9 57.2 0.2 3.7 -2.6 [53.0] 15611
10 56.8 0.0 3.7 -3.4 [50.0, 49.0] 21417
11 55.9 0.0 3.2 -3.4 [52.0, 46.0] 22216
12 59.7 0.1 2.9 -4.2 [45.0, 48.0] 19325
15 42.1 0.1 3.6 -4.0 [50.0, 49.0] 8689
19 58.6 0.1 3.9 -4.2 [45.0, 48.0] 16273
21 60.7 -0.1 3.7 -4.0 [53.0, 47.0] 18935
24 56.5 0.4 4.7 -2.8 [49.0, 50.0] 15310
25 42.5 0.3 3.9 -3.8 [48.0, 43.0, 39.0] 9959
26 43.3 -0.3 2.6 -3.3 [39.0, 40.0] 9407
27 54.3 -0.0 3.2 -4.2 [51.0, 53.0] 14387
30 40.7 -1.1 2.2 -4.1 [38.0, 49.0] 4771
31 60.1 0.5 5.0 -4.1 [41.0] 19618
33 56.0 0.1 3.1 -3.2 [51.0, 53.0] 14741
34 55.5 0.4 4.1 -4.0 [51.0, 45.0] 14533
36 60.2 0.1 4.0 -4.5 [42.0, 40.0] 18921
REF Galileo E5A+B(AltBOC-Comp-PD)

SV AvgEl AvgOffset AvgCNo MaxCNo MinCNo Slip_Count SVChan Ant N_Samples
3 54.0 0.0 50.3 53.1 46.9 0 [44.0] [0.0] 9767
4 44.4 -0.0 49.4 51.7 47.1 74 [50.0, 40.0] [0.0] 20284
7 48.5 0.0 49.7 52.2 47.4 0 [42.0] [0.0] 6664
9 57.2 -0.0 50.1 52.4 46.6 0 [53.0] [0.0] 15613
10 56.8 0.0 50.4 52.6 47.4 0 [50.0] [0.0] 21418
11 55.9 0.0 46.7 49.0 44.2 0 [52.0] [0.0] 22216
12 59.7 -0.0 48.4 51.0 45.2 0 [45.0] [0.0] 19326
15 42.1 -0.0 49.1 51.3 47.2 0 [50.0] [0.0] 8695
19 58.6 0.0 47.4 49.6 44.4 0 [45.0] [0.0] 16273
21 60.7 0.0 50.3 52.4 47.0 0 [53.0] [0.0] 18935
24 56.5 0.0 50.4 52.6 47.2 0 [49.0] [0.0] 15311
25 42.5 -0.0 49.0 51.6 47.0 137 [48.0, 39.0] [0.0] 9967
26 43.3 0.0 49.2 51.3 47.0 0 [39.0] [0.0] 9409
27 54.3 0.0 50.0 52.8 47.1 0 [51.0] [0.0] 14388
30 40.7 0.0 48.9 50.5 47.0 0 [38.0] [0.0] 4775
31 60.1 0.0 50.4 52.9 45.8 0 [41.0] [0.0] 19619
33 56.0 -0.0 50.3 53.4 47.3 0 [51.0] [0.0] 14742
34 55.5 0.0 50.3 52.5 47.0 0 [51.0] [0.0] 14533
36 60.2 -0.0 50.3 52.4 45.8 0 [42.0] [0.0] 18923
DUT Galileo E5A+B(AltBOC-Comp-PD)

SV AvgEl AvgOffset AvgCNo MaxCNo MinCNo Slip_Count SVChan Ant N_Samples
3 54.0 0.0 49.9 52.4 47.0 0 [52.0] [0.0] 9762
4 44.4 0.0 49.1 51.5 46.6 73 [42.0, 39.0] [0.0] 20286
7 48.5 -0.0 49.6 52.1 47.5 0 [50.0] [0.0] 6662
9 57.2 -0.0 50.1 52.3 46.6 0 [53.0] [0.0] 15611
10 56.8 -0.0 50.2 52.6 47.3 0 [49.0] [0.0] 21417
11 55.9 -0.0 46.4 48.2 43.1 0 [46.0] [0.0] 22217
12 59.7 -0.0 48.3 50.7 45.5 0 [48.0] [0.0] 19325
15 42.1 0.0 49.1 51.3 46.9 0 [49.0] [0.0] 8690
19 58.6 0.0 47.5 50.0 44.0 0 [48.0] [0.0] 16274
21 60.7 -0.0 50.1 52.6 46.9 0 [47.0] [0.0] 18935
24 56.5 0.0 50.2 52.1 47.2 0 [50.0] [0.0] 15311
25 42.5 0.0 48.8 51.2 46.3 170 [43.0, 39.0] [0.0] 9960
26 43.3 0.0 49.0 51.2 46.7 0 [40.0] [0.0] 9407
27 54.3 -0.0 50.1 52.5 47.2 0 [53.0] [0.0] 14387
30 40.7 0.0 48.7 50.7 47.1 0 [49.0] [0.0] 4771
31 60.1 0.0 50.1 52.2 45.9 0 [41.0] [0.0] 19618
33 56.0 0.0 50.2 52.3 46.7 0 [53.0] [0.0] 14741
34 55.5 -0.0 50.2 52.4 47.3 0 [45.0] [0.0] 14536
36 60.2 -0.0 50.3 52.4 46.4 0 [40.0] [0.0] 18921
DIFF Galileo E5A+B(AltBOC-Comp-PD)

SV AvgEl AvgCNoDiff MaxCNoDiff MinCNoDiff SVChan N_Samples
3 54.0 0.4 1.8 -1.2 [44.0, 52.0] 9761
4 44.4 0.3 1.9 -1.9 [50.0, 42.0, 40.0, 39.0] 20283
7 48.5 0.1 1.5 -1.5 [42.0, 50.0] 6662
9 57.2 0.0 1.5 -1.6 [53.0] 15611
10 56.8 0.2 1.8 -1.9 [50.0, 49.0] 21417
11 55.9 0.3 2.4 -1.6 [52.0, 46.0] 22216
12 59.7 0.1 1.8 -1.5 [45.0, 48.0] 19325
15 42.1 -0.0 1.5 -2.1 [50.0, 49.0] 8689
19 58.6 -0.0 1.7 -1.9 [45.0, 48.0] 16273
21 60.7 0.1 1.8 -1.3 [53.0, 47.0] 18935
24 56.5 0.3 1.9 -1.6 [49.0, 50.0] 15310
25 42.5 0.2 2.3 -1.7 [48.0, 43.0, 39.0] 9959
26 43.3 0.3 2.0 -1.4 [39.0, 40.0] 9407
27 54.3 -0.1 1.4 -1.7 [51.0, 53.0] 14387
30 40.7 0.1 1.9 -1.6 [38.0, 49.0] 4771
31 60.1 0.2 1.7 -2.0 [41.0] 19618
33 56.0 0.2 1.7 -1.6 [51.0, 53.0] 14741
34 55.5 0.1 1.5 -1.7 [51.0, 45.0] 14533
36 60.2 0.0 1.7 -2.3 [42.0, 40.0] 18921
REF BeiDou L1(BOC-PD)

SV AvgEl AvgOffset AvgCNo MaxCNo MinCNo Slip_Count SVChan Ant N_Samples
19 59.6 0.0 50.0 52.8 45.9 0 [46.0] [0.0] 12826
20 56.7 0.0 49.8 53.0 43.2 0 [41.0] [0.0] 18632
21 67.1 -0.0 49.7 53.1 43.1 0 [15.0] [0.0] 10315
22 43.1 0.0 47.6 52.3 42.7 209 [46.0, 11.0] [0.0] 5837
23 57.5 0.0 49.9 53.5 45.0 0 [40.0] [0.0] 14111
24 56.9 0.0 49.9 53.4 42.9 0 [48.0] [0.0] 19038
25 60.7 -0.0 49.5 52.6 44.1 0 [12.0] [0.0] 16867
26 59.7 -0.0 48.9 52.1 43.3 0 [23.0] [0.0] 17470
27 58.9 -0.0 49.2 53.0 40.9 0 [16.0] [0.0] 17680
28 56.5 0.0 49.0 52.3 43.9 0 [38.0] [0.0] 19031
29 47.6 -0.0 47.7 50.6 42.0 0 [49.0] [0.0] 10544
30 59.2 -0.0 48.8 51.4 42.8 0 [47.0] [0.0] 14614
32 61.2 -0.0 49.7 52.9 43.6 0 [26.0] [0.0] 15740
33 40.6 -0.0 47.7 50.2 45.2 199 [44.0, 9.0] [0.0] 14427
34 56.9 -0.0 49.1 52.0 42.8 0 [42.0] [0.0] 13773
36 44.6 0.0 46.4 50.4 42.4 111 [52.0, 47.0] [0.0] 3425
37 45.5 0.0 48.4 51.8 42.4 0 [44.0] [0.0] 9755
41 52.9 -0.0 48.9 51.6 43.9 0 [15.0] [0.0] 12349
42 54.2 -0.0 49.3 52.1 44.7 0 [20.0] [0.0] 12773
43 60.8 -0.0 49.5 53.3 44.2 0 [17.0] [0.0] 16636
44 44.4 0.0 47.4 49.7 41.8 0 [35.0] [0.0] 9208
45 60.6 0.0 49.7 52.5 45.0 0 [40.0] [0.0] 9117
46 50.5 0.0 48.3 50.8 43.4 0 [48.0] [0.0] 7331
DUT BeiDou L1(BOC-PD)

SV AvgEl AvgOffset AvgCNo MaxCNo MinCNo Slip_Count SVChan Ant N_Samples
19 59.6 -0.0 49.3 52.4 43.2 0 [51.0] [0.0] 12820
20 56.7 0.0 49.6 52.8 42.3 0 [47.0] [0.0] 18632
21 67.1 0.0 49.5 52.5 45.0 0 [22.0] [0.0] 10312
22 43.1 0.0 47.3 51.6 40.5 216 [20.0, 11.0] [0.0] 5827
23 57.5 0.0 49.7 52.8 45.1 0 [23.0] [0.0] 14111
24 56.9 0.0 49.7 53.4 42.3 0 [51.0] [0.0] 19039
25 60.7 -0.0 49.1 52.3 42.6 0 [29.0] [0.0] 16866
26 59.7 -0.0 48.7 51.4 43.3 0 [19.0] [0.0] 17469
27 58.9 -0.0 48.8 52.1 43.6 0 [20.0] [0.0] 17680
28 56.5 -0.0 48.7 51.7 42.8 0 [44.0] [0.0] 19032
29 47.6 -0.0 47.6 51.1 42.0 0 [50.0] [0.0] 10543
30 59.2 -0.0 48.6 51.2 44.3 0 [30.0] [0.0] 14615
32 61.2 0.0 49.3 52.4 44.5 0 [24.0] [0.0] 15741
33 40.6 0.0 48.0 50.8 44.2 238 [52.0, 8.0] [0.0] 14428
34 56.9 0.0 48.9 51.8 44.1 0 [11.0] [0.0] 13773
36 44.5 0.0 46.9 48.7 42.7 148 [16.0, 30.0] [0.0] 3418
37 45.5 -0.0 48.2 50.4 42.8 0 [45.0] [0.0] 9754
41 52.9 -0.0 48.7 51.3 44.1 0 [22.0] [0.0] 12347
42 54.2 -0.0 49.0 52.3 44.5 0 [15.0] [0.0] 12771
43 60.8 -0.0 49.4 52.8 44.5 0 [25.0] [0.0] 16637
44 44.4 -0.0 47.5 50.1 41.1 0 [35.0] [0.0] 9209
45 60.6 -0.0 49.4 51.2 45.0 0 [11.0] [0.0] 9116
46 50.5 0.0 48.5 51.0 43.7 0 [48.0] [0.0] 7324
DIFF BeiDou L1(BOC-PD)

SV AvgEl AvgCNoDiff MaxCNoDiff MinCNoDiff SVChan N_Samples
19 59.6 0.7 4.1 -2.0 [46.0, 51.0] 12820
20 56.7 0.1 3.8 -3.6 [41.0, 47.0] 18632
21 67.1 0.1 2.5 -3.8 [15.0, 22.0] 10312
22 43.1 0.3 5.0 -3.4 [46.0, 20.0, 11.0] 5827
23 57.5 0.2 3.2 -2.7 [40.0, 23.0] 14111
24 56.9 0.2 2.8 -3.4 [48.0, 51.0] 19038
25 60.7 0.4 3.8 -4.1 [12.0, 29.0] 16866
26 59.7 0.2 4.6 -3.6 [23.0, 19.0] 17469
27 58.9 0.4 4.0 -4.5 [16.0, 20.0] 17680
28 56.5 0.2 3.0 -3.1 [38.0, 44.0] 19031
29 47.6 0.1 3.7 -3.8 [49.0, 50.0] 10543
30 59.2 0.2 2.9 -3.6 [47.0, 30.0] 14614
32 61.2 0.4 4.4 -3.3 [26.0, 24.0] 15740
33 40.6 -0.3 4.0 -3.5 [44.0, 52.0, 9.0, 8.0] 14426
34 56.9 0.2 3.3 -3.7 [42.0, 11.0] 13772
36 44.5 -0.5 3.0 -3.2 [52.0, 16.0, 47.0, 30.0] 3417
37 45.5 0.1 3.9 -4.2 [44.0, 45.0] 9754
41 52.9 0.2 2.7 -2.4 [15.0, 22.0] 12347
42 54.2 0.3 4.2 -2.9 [20.0, 15.0] 12771
43 60.8 0.1 2.7 -3.5 [17.0, 25.0] 16636
44 44.4 -0.2 5.0 -4.1 [35.0] 9208
45 60.6 0.3 3.4 -2.4 [40.0, 11.0] 9115
46 50.5 -0.1 2.8 -2.4 [48.0] 7324
REF BeiDou L5/E5A(I+Q)

SV AvgEl AvgOffset AvgCNo MaxCNo MinCNo Slip_Count SVChan Ant N_Samples
19 59.6 0.0 49.1 51.0 43.5 0 [46.0] [0.0] 12826
20 56.7 0.0 48.6 51.3 44.5 0 [41.0] [0.0] 18632
21 67.1 -0.0 49.5 51.4 44.9 0 [15.0] [0.0] 10315
22 43.1 0.0 47.9 51.1 45.1 110 [46.0, 11.0] [0.0] 5837
23 57.5 0.0 49.9 51.9 46.3 0 [40.0] [0.0] 14111
24 56.9 0.0 49.4 52.1 45.7 0 [48.0] [0.0] 19038
25 60.7 -0.0 48.3 50.5 43.2 0 [12.0] [0.0] 16867
26 59.7 -0.0 47.6 50.1 43.6 0 [23.0] [0.0] 17470
27 58.9 -0.0 48.0 50.2 43.7 0 [16.0] [0.0] 17680
28 56.5 0.0 46.9 49.7 42.6 0 [38.0] [0.0] 19031
29 47.6 -0.0 47.1 49.3 44.2 0 [49.0] [0.0] 10544
30 59.2 -0.0 47.8 49.9 44.3 0 [47.0] [0.0] 14614
32 61.2 -0.0 48.9 50.8 44.4 0 [26.0] [0.0] 15740
33 40.6 -0.0 47.2 49.6 45.4 211 [44.0, 9.0] [0.0] 14427
34 56.9 -0.0 48.0 50.1 44.3 0 [42.0] [0.0] 13773
36 44.6 0.0 48.1 51.3 44.9 80 [52.0, 47.0] [0.0] 3425
37 45.5 0.0 48.6 50.3 45.8 0 [44.0] [0.0] 9755
41 52.9 -0.0 48.8 50.8 45.3 0 [15.0] [0.0] 12349
42 54.2 -0.0 49.1 51.6 44.7 0 [20.0] [0.0] 12773
43 60.8 -0.0 47.9 49.9 43.4 0 [17.0] [0.0] 16636
44 44.4 0.0 46.9 48.8 44.6 0 [35.0] [0.0] 9208
45 60.6 0.0 49.3 51.4 45.5 0 [40.0] [0.0] 9117
46 50.5 0.0 48.6 50.3 45.1 0 [48.0] [0.0] 7331
DUT BeiDou L5/E5A(I+Q)

SV AvgEl AvgOffset AvgCNo MaxCNo MinCNo Slip_Count SVChan Ant N_Samples
19 59.6 -0.0 48.5 50.5 43.7 0 [51.0] [0.0] 12820
20 56.7 0.0 48.2 51.2 43.4 0 [47.0] [0.0] 18632
21 67.1 0.0 49.1 50.8 45.7 0 [22.0] [0.0] 10312
22 43.1 0.0 47.5 49.9 45.2 118 [20.0, 11.0] [0.0] 5827
23 57.5 0.0 49.3 51.3 46.0 0 [23.0] [0.0] 14111
24 56.9 0.0 48.9 51.5 44.2 0 [51.0] [0.0] 19039
25 60.7 -0.0 47.9 50.2 42.8 0 [29.0] [0.0] 16866
26 59.7 -0.0 47.2 49.6 44.1 0 [19.0] [0.0] 17469
27 58.9 -0.0 47.4 49.9 43.0 0 [20.0] [0.0] 17680
28 56.5 -0.0 46.4 48.9 41.3 0 [44.0] [0.0] 19032
29 47.6 -0.0 46.4 48.7 44.0 0 [50.0] [0.0] 10543
30 59.2 -0.0 47.4 49.7 44.1 0 [30.0] [0.0] 14615
32 61.2 0.0 48.3 50.3 44.7 0 [24.0] [0.0] 15741
33 40.6 0.0 46.8 49.0 42.9 110 [52.0, 8.0] [0.0] 14428
34 56.9 0.0 47.4 49.7 43.4 0 [11.0] [0.0] 13773
36 44.5 0.0 48.0 50.6 44.0 167 [16.0, 30.0] [0.0] 3418
37 45.5 -0.0 47.6 49.7 43.7 0 [45.0] [0.0] 9754
41 52.9 -0.0 48.4 50.5 44.7 0 [22.0] [0.0] 12347
42 54.2 -0.0 48.5 50.4 44.7 0 [15.0] [0.0] 12771
43 60.8 -0.0 47.4 49.8 43.8 0 [25.0] [0.0] 16637
44 44.4 -0.0 46.5 48.7 43.4 0 [35.0] [0.0] 9209
45 60.6 -0.0 48.5 50.9 44.1 0 [11.0] [0.0] 9116
46 50.5 0.0 48.6 50.5 45.3 0 [48.0] [0.0] 7324
DIFF BeiDou L5/E5A(I+Q)

SV AvgEl AvgCNoDiff MaxCNoDiff MinCNoDiff SVChan N_Samples
19 59.6 0.6 2.1 -2.0 [46.0, 51.0] 12820
20 56.7 0.4 2.8 -1.9 [41.0, 47.0] 18632
21 67.1 0.5 2.0 -2.6 [15.0, 22.0] 10312
22 43.1 0.4 2.0 -1.9 [46.0, 20.0, 11.0] 5827
23 57.5 0.6 2.7 -1.5 [40.0, 23.0] 14111
24 56.9 0.5 3.0 -1.6 [48.0, 51.0] 19038
25 60.7 0.5 2.5 -2.1 [12.0, 29.0] 16866
26 59.7 0.4 2.2 -2.5 [23.0, 19.0] 17469
27 58.9 0.5 2.4 -1.9 [16.0, 20.0] 17680
28 56.5 0.6 3.5 -2.1 [38.0, 44.0] 19031
29 47.6 0.6 2.3 -1.8 [49.0, 50.0] 10543
30 59.2 0.4 2.3 -1.5 [47.0, 30.0] 14614
32 61.2 0.6 2.5 -1.3 [26.0, 24.0] 15740
33 40.6 0.4 3.5 -2.3 [44.0, 52.0, 9.0, 8.0] 14426
34 56.9 0.5 2.6 -2.2 [42.0, 11.0] 13772
36 44.5 0.2 2.5 -1.7 [52.0, 16.0, 47.0, 30.0] 3417
37 45.5 1.0 3.3 -1.6 [44.0, 45.0] 9754
41 52.9 0.5 2.6 -1.9 [15.0, 22.0] 12347
42 54.2 0.7 2.5 -1.6 [20.0, 15.0] 12771
43 60.8 0.5 2.5 -1.7 [17.0, 25.0] 16636
44 44.4 0.4 2.2 -1.6 [35.0] 9208
45 60.6 0.9 2.6 -0.7 [40.0, 11.0] 9115
46 50.5 -0.0 2.1 -2.5 [48.0] 7324
REF BeiDou E5B/B2(BPSK(2)-B2)

SV AvgEl AvgOffset AvgCNo MaxCNo MinCNo Slip_Count SVChan Ant N_Samples
11 60.1 -0.0 47.5 50.0 44.3 0 [19.0] [0.0] 14833
12 49.8 0.0 47.2 49.6 44.7 0 [25.0] [0.0] 11229
14 48.0 -0.0 47.6 49.8 44.8 0 [47.0] [0.0] 10618
DUT BeiDou E5B/B2(BPSK(2)-B2)

SV AvgEl AvgOffset AvgCNo MaxCNo MinCNo Slip_Count SVChan Ant N_Samples
11 60.1 -0.0 47.5 50.2 43.3 0 [39.0] [0.0] 14834
12 49.8 -0.0 47.3 49.3 44.3 0 [30.0] [0.0] 11226
14 48.0 -0.0 47.5 50.0 44.1 0 [45.0] [0.0] 10619
DIFF BeiDou E5B/B2(BPSK(2)-B2)

SV AvgEl AvgCNoDiff MaxCNoDiff MinCNoDiff SVChan N_Samples
11 60.1 0.0 3.4 -1.7 [19.0, 39.0] 14833
12 49.8 -0.1 2.0 -2.2 [25.0, 30.0] 11226
14 48.0 0.1 3.1 -2.2 [47.0, 45.0] 10618
REF BeiDou B1(BPSK(2)-B1)

SV AvgEl AvgOffset AvgCNo MaxCNo MinCNo Slip_Count SVChan Ant N_Samples
11 60.1 -0.0 47.3 51.0 39.4 0 [19.0] [0.0] 14833
12 49.8 0.0 45.8 48.5 40.2 0 [25.0] [0.0] 11229
14 48.0 -0.0 46.3 50.5 41.6 0 [47.0] [0.0] 10618
19 59.6 0.0 50.0 53.5 44.6 0 [46.0] [0.0] 12826
20 56.7 0.0 50.4 53.9 43.9 0 [41.0] [0.0] 18632
21 67.1 -0.0 49.7 53.6 41.8 0 [15.0] [0.0] 10315
22 43.1 0.0 47.7 52.8 41.2 148 [46.0, 11.0] [0.0] 5837
23 57.5 0.0 49.3 52.8 43.8 0 [40.0] [0.0] 14111
24 56.9 0.0 49.6 54.1 42.6 0 [48.0] [0.0] 19038
25 60.7 -0.0 49.4 53.0 43.4 0 [12.0] [0.0] 16867
26 59.7 -0.0 48.9 53.0 43.1 0 [23.0] [0.0] 17470
27 58.9 -0.0 49.6 53.4 41.8 0 [16.0] [0.0] 17680
28 56.5 0.0 49.1 53.2 42.3 0 [38.0] [0.0] 19031
29 47.6 -0.0 48.2 52.1 43.2 0 [49.0] [0.0] 10544
30 59.2 -0.0 49.3 52.6 43.4 0 [47.0] [0.0] 14614
32 61.2 -0.0 49.4 53.2 43.7 0 [26.0] [0.0] 15740
33 40.6 -0.0 46.7 50.5 42.8 135 [44.0, 9.0] [0.0] 14427
34 56.9 -0.0 48.9 52.4 43.2 0 [42.0] [0.0] 13773
36 44.6 0.0 46.2 49.6 43.7 168 [52.0, 47.0] [0.0] 3425
37 45.5 0.0 47.5 51.4 42.2 0 [44.0] [0.0] 9755
41 52.9 -0.0 48.0 51.2 42.2 0 [15.0] [0.0] 12349
42 54.2 -0.0 48.3 51.8 42.8 0 [20.0] [0.0] 12773
43 60.8 -0.0 49.3 53.8 43.1 0 [17.0] [0.0] 16636
44 44.4 0.0 47.2 50.3 41.4 0 [35.0] [0.0] 9208
45 60.6 0.0 49.3 51.9 44.1 0 [40.0] [0.0] 9117
46 50.5 0.0 47.8 50.5 43.0 0 [48.0] [0.0] 7331
DUT BeiDou B1(BPSK(2)-B1)

SV AvgEl AvgOffset AvgCNo MaxCNo MinCNo Slip_Count SVChan Ant N_Samples
11 60.1 -0.0 47.1 51.0 42.0 0 [39.0] [0.0] 14834
12 49.8 -0.0 45.7 49.0 40.2 0 [30.0] [0.0] 11226
14 48.0 -0.0 46.2 49.7 41.3 0 [45.0] [0.0] 10619
19 59.6 -0.0 49.5 53.0 43.0 0 [51.0] [0.0] 12820
20 56.7 0.0 50.2 53.5 42.8 0 [47.0] [0.0] 18632
21 67.1 0.0 49.5 53.9 43.9 0 [22.0] [0.0] 10312
22 43.1 0.0 47.7 51.7 40.3 137 [20.0, 11.0] [0.0] 5827
23 57.5 0.0 49.2 52.4 44.3 0 [23.0] [0.0] 14111
24 56.9 0.0 49.4 53.0 41.6 0 [51.0] [0.0] 19039
25 60.7 -0.0 49.0 52.8 42.9 0 [29.0] [0.0] 16866
26 59.7 -0.0 48.9 52.0 43.0 0 [19.0] [0.0] 17469
27 58.9 -0.0 49.5 54.0 43.2 0 [20.0] [0.0] 17680
28 56.5 -0.0 49.0 52.8 42.4 0 [44.0] [0.0] 19032
29 47.6 -0.0 48.2 51.7 43.0 0 [50.0] [0.0] 10543
30 59.2 -0.0 49.2 52.3 44.1 0 [30.0] [0.0] 14615
32 61.2 0.0 49.2 52.3 44.3 0 [24.0] [0.0] 15741
33 40.6 0.0 47.0 51.2 42.1 59 [52.0, 8.0] [0.0] 14428
34 56.9 0.0 48.6 51.9 43.1 0 [11.0] [0.0] 13773
36 44.5 0.0 46.9 49.1 42.9 77 [16.0, 30.0] [0.0] 3418
37 45.5 -0.0 47.2 50.3 40.8 0 [45.0] [0.0] 9754
41 52.9 -0.0 48.0 51.6 41.2 0 [22.0] [0.0] 12347
42 54.2 -0.0 48.4 51.5 42.7 0 [15.0] [0.0] 12771
43 60.8 -0.0 49.1 53.4 43.4 0 [25.0] [0.0] 16637
44 44.4 -0.0 47.7 50.7 41.6 0 [35.0] [0.0] 9209
45 60.6 -0.0 49.1 51.4 44.1 0 [11.0] [0.0] 9116
46 50.5 0.0 48.0 50.8 42.9 0 [48.0] [0.0] 7324
DIFF BeiDou B1(BPSK(2)-B1)

SV AvgEl AvgCNoDiff MaxCNoDiff MinCNoDiff SVChan N_Samples
11 60.1 0.2 4.7 -4.2 [19.0, 39.0] 14833
12 49.8 0.2 3.8 -3.8 [25.0, 30.0] 11226
14 48.0 0.2 3.6 -3.7 [47.0, 45.0] 10618
19 59.6 0.5 4.4 -2.6 [46.0, 51.0] 12820
20 56.7 0.3 4.0 -3.3 [41.0, 47.0] 18632
21 67.1 0.2 4.4 -3.7 [15.0, 22.0] 10312
22 43.1 -0.0 6.3 -5.4 [46.0, 20.0, 11.0] 5827
23 57.5 0.2 3.7 -3.6 [40.0, 23.0] 14111
24 56.9 0.1 3.7 -4.2 [48.0, 51.0] 19038
25 60.7 0.3 4.0 -3.1 [12.0, 29.0] 16866
26 59.7 0.1 4.4 -4.2 [23.0, 19.0] 17469
27 58.9 0.1 5.2 -3.8 [16.0, 20.0] 17680
28 56.5 0.1 3.7 -4.5 [38.0, 44.0] 19031
29 47.6 0.0 3.9 -4.0 [49.0, 50.0] 10543
30 59.2 0.1 3.8 -4.7 [47.0, 30.0] 14614
32 61.2 0.2 3.9 -3.8 [26.0, 24.0] 15740
33 40.6 -0.3 4.0 -3.9 [44.0, 52.0, 9.0, 8.0] 14426
34 56.9 0.2 4.6 -3.8 [42.0, 11.0] 13772
36 44.5 -0.7 2.5 -4.0 [52.0, 16.0, 47.0, 30.0] 3417
37 45.5 0.4 4.1 -3.8 [44.0, 45.0] 9754
41 52.9 0.0 8.1 -3.7 [15.0, 22.0] 12347
42 54.2 -0.1 4.6 -3.6 [20.0, 15.0] 12771
43 60.8 0.2 4.8 -4.4 [17.0, 25.0] 16636
44 44.4 -0.5 3.4 -5.3 [35.0] 9208
45 60.6 0.2 2.9 -2.9 [40.0, 11.0] 9115
46 50.5 -0.2 2.6 -3.1 [48.0] 7324
REF BeiDou B3(BPSK(10)-B3)

SV AvgEl AvgOffset AvgCNo MaxCNo MinCNo Slip_Count SVChan Ant N_Samples
11 60.1 -0.0 47.5 49.4 44.6 0 [19.0] [0.0] 14833
12 49.8 0.0 47.5 49.7 44.3 0 [25.0] [0.0] 11229
14 48.0 -0.0 47.2 49.4 43.9 0 [47.0] [0.0] 10618
19 59.6 0.0 48.0 50.0 43.9 0 [46.0] [0.0] 12826
20 56.7 0.0 47.6 49.8 43.2 0 [41.0] [0.0] 18632
21 67.1 -0.0 48.2 49.9 43.5 0 [15.0] [0.0] 10315
22 43.1 0.0 46.7 48.9 42.8 49 [46.0, 11.0] [0.0] 5837
23 57.5 0.0 48.1 50.2 44.2 0 [40.0] [0.0] 14111
24 56.9 0.0 47.9 50.0 43.2 0 [48.0] [0.0] 19038
25 60.7 -0.0 47.6 50.0 42.2 0 [12.0] [0.0] 16867
26 59.7 -0.0 47.4 49.4 42.9 0 [23.0] [0.0] 17470
27 58.9 -0.0 47.1 49.4 41.8 0 [16.0] [0.0] 17680
28 56.5 0.0 46.9 49.4 42.9 0 [38.0] [0.0] 19031
29 47.6 -0.0 46.7 48.9 43.0 0 [49.0] [0.0] 10544
30 59.2 -0.0 47.2 49.4 43.0 0 [47.0] [0.0] 14614
32 61.2 -0.0 48.1 50.0 44.7 0 [26.0] [0.0] 15740
33 40.6 -0.0 46.4 48.3 43.1 49 [44.0, 9.0] [0.0] 14427
34 56.9 -0.0 47.5 49.9 43.4 0 [42.0] [0.0] 13773
36 44.6 0.0 47.9 49.8 44.5 131 [52.0, 47.0] [0.0] 3425
37 45.5 0.0 47.2 48.9 43.8 0 [44.0] [0.0] 9755
41 52.9 -0.0 47.9 49.9 43.1 0 [15.0] [0.0] 12349
42 54.2 -0.0 47.9 50.2 43.9 0 [20.0] [0.0] 12773
43 60.8 -0.0 47.4 49.9 42.5 0 [17.0] [0.0] 16636
44 44.4 0.0 46.2 48.3 43.0 0 [35.0] [0.0] 9208
45 60.6 0.0 48.1 50.0 44.7 0 [40.0] [0.0] 9117
46 50.5 0.0 47.5 49.3 44.0 0 [48.0] [0.0] 7331
DUT BeiDou B3(BPSK(10)-B3)

SV AvgEl AvgOffset AvgCNo MaxCNo MinCNo Slip_Count SVChan Ant N_Samples
11 60.1 -0.0 47.7 49.9 44.0 0 [39.0] [0.0] 14834
12 49.8 -0.0 47.3 49.4 43.0 0 [30.0] [0.0] 11226
14 48.0 -0.0 46.8 49.2 42.4 0 [45.0] [0.0] 10619
19 59.6 -0.0 47.7 50.0 43.0 0 [51.0] [0.0] 12820
20 56.7 0.0 47.3 50.2 42.7 0 [47.0] [0.0] 18632
21 67.1 0.0 48.2 49.9 43.9 0 [22.0] [0.0] 10312
22 43.1 0.0 46.7 49.1 42.8 171 [20.0, 11.0] [0.0] 5827
23 57.5 0.0 48.1 50.3 43.2 0 [23.0] [0.0] 14111
24 56.9 0.0 47.8 50.3 42.6 0 [51.0] [0.0] 19039
25 60.7 -0.0 47.7 50.0 39.9 0 [29.0] [0.0] 16866
26 59.7 -0.0 47.4 49.7 42.5 0 [19.0] [0.0] 17469
27 58.9 -0.0 47.0 49.4 40.6 0 [20.0] [0.0] 17680
28 56.5 -0.0 46.6 49.4 41.3 0 [44.0] [0.0] 19032
29 47.6 -0.0 46.5 48.5 42.7 0 [50.0] [0.0] 10543
30 59.2 -0.0 47.1 49.6 42.3 0 [30.0] [0.0] 14615
32 61.2 0.0 48.2 50.1 44.3 0 [24.0] [0.0] 15741
33 40.6 0.0 45.8 48.2 42.0 118 [52.0, 8.0] [0.0] 14428
34 56.9 0.0 47.6 49.7 43.8 0 [11.0] [0.0] 13773
36 44.5 0.0 47.6 49.7 43.4 25 [16.0, 30.0] [0.0] 3418
37 45.5 -0.0 46.7 49.0 43.4 0 [45.0] [0.0] 9754
41 52.9 -0.0 48.0 50.2 44.4 0 [22.0] [0.0] 12347
42 54.2 -0.0 47.7 49.7 42.5 0 [15.0] [0.0] 12771
43 60.8 -0.0 47.5 49.9 43.1 0 [25.0] [0.0] 16637
44 44.4 -0.0 46.2 48.2 43.5 0 [35.0] [0.0] 9209
45 60.6 -0.0 48.0 50.1 44.2 0 [11.0] [0.0] 9116
46 50.5 0.0 47.6 49.4 44.6 0 [48.0] [0.0] 7324
DIFF BeiDou B3(BPSK(10)-B3)

SV AvgEl AvgCNoDiff MaxCNoDiff MinCNoDiff SVChan N_Samples
11 60.1 -0.2 1.7 -2.4 [19.0, 39.0] 14833
12 49.8 0.2 3.1 -2.0 [25.0, 30.0] 11226
14 48.0 0.3 2.9 -1.7 [47.0, 45.0] 10618
19 59.6 0.3 2.6 -1.6 [46.0, 51.0] 12820
20 56.7 0.2 3.0 -2.2 [41.0, 47.0] 18632
21 67.1 -0.0 2.0 -2.0 [15.0, 22.0] 10312
22 43.1 0.0 2.1 -2.8 [46.0, 20.0, 11.0] 5827
23 57.5 0.1 2.6 -2.1 [40.0, 23.0] 14111
24 56.9 0.1 3.2 -2.4 [48.0, 51.0] 19038
25 60.7 -0.1 3.2 -3.3 [12.0, 29.0] 16866
26 59.7 0.1 2.8 -1.9 [23.0, 19.0] 17469
27 58.9 0.0 2.9 -3.1 [16.0, 20.0] 17680
28 56.5 0.2 3.8 -2.6 [38.0, 44.0] 19031
29 47.6 0.3 2.7 -2.3 [49.0, 50.0] 10543
30 59.2 0.2 2.3 -1.9 [47.0, 30.0] 14614
32 61.2 -0.1 2.4 -2.0 [26.0, 24.0] 15740
33 40.6 0.6 3.5 -2.5 [44.0, 52.0, 9.0, 8.0] 14426
34 56.9 -0.1 2.4 -2.8 [42.0, 11.0] 13772
36 44.5 0.3 2.6 -1.4 [52.0, 16.0, 47.0, 30.0] 3417
37 45.5 0.5 3.4 -1.7 [44.0, 45.0] 9754
41 52.9 -0.2 2.4 -3.4 [15.0, 22.0] 12347
42 54.2 0.1 3.3 -2.4 [20.0, 15.0] 12771
43 60.8 -0.2 1.9 -2.7 [17.0, 25.0] 16636
44 44.4 0.1 2.2 -2.9 [35.0] 9208
45 60.6 0.0 2.0 -2.1 [40.0, 11.0] 9115
46 50.5 -0.1 2.1 -3.5 [48.0] 7324
MSS Ref

Mean CNo: 49.18
MSS DUT

Mean CNo: 50.18
MSS Diff

Mean Diff CNo: -1.00
